USB充电线 x1
耳机
充电盒 x1
耳塞套 x10
说明书 x1
收纳袋
x1
打开充电盒时，耳机会自动开机。
将耳机放回充电盒并合上盒盖，耳机将自动关机。
1.选择适合您耳朵的耳塞尺寸，然后将其滑到耳机顶端。
2.将耳机插入耳道并调整至舒适的位置，确保耳塞紧密贴合。
保用前，Noble Osprey 需要与您的设备配对。配对后，每次激活它们都
会自动连接。
1.打开充电盒盖子。耳机将自动开机并进入配对模式，红白指示 灯交替
闪烁。
2.在智能手机上启用蓝牙并在可用的蓝牙设备中搜索“Noble Osprey ”。
找到后， 选择“ Noble Osprey ” 开始配对。 你会听到“连接成功的
提示音”， 耳机就可以使用了。
配对
配对新设备
1.打开充电盒的盖子, 耳机将自动开机并连接到您当前的设备。
2.通过从智能手机的蓝牙设备列表 中“断开连接”或删除“ Noble Osprey ”
来取消耳机与上次连接的智能手机的配对。
3.断开连接后，耳机将自动进入配对模式，红白指示灯交替闪烁。
4.在新设备上启用蓝牙，并在可用的蓝牙设备中搜索“ Noble Osprey”。
找到后，选择“ Noble Osprey ”开始配对。你会听到“ 连接成功的
提示音”，耳机就可以使用了。
使用场景
LED指示灯状态
开机
关机
配对
配对成功
播放音乐或通话
耳机低电量
将耳机放入充电盒中
耳机放入充电盒满电后
充电盒充电中
充电盒满电后
白色灯常亮
白色灯慢闪
红色灯关闭
红色灯常亮
红色灯每5秒闪烁两次
LED 灯关闭
白灯亮2s,熄灭
红白交替闪烁
红色灯亮一秒
白色灯亮一秒
单声道模式：蓝牙成功连接后，只要把任意一只耳机放回充电盒并合上盖
子，另一只耳机将独立工作。
超距离回连：当耳机超出手机连接范围时，3分钟内回到有效距离会自动
回连手机；若超时3分钟未回连接，耳机将自动关机。
开机并连接后，如果任一只耳机电量耗尽并关机，另一只耳机可继续使用。
声明和警告
在配对新设备之前请断开当前设备。
警告！
长期暴露在高噪音环境中可能会导致永久性听力损伤。
请勿在禁止使用电子设备的场所使用 Noble Osprey耳机。
如果您有心脏起搏器或其他电子医疗设备，请在使用您
Noble Osprey
耳机前咨询您的医生。
此包装包含小零件，可能对小孩造成危险。
请勿擅自拆卸
Noble Osprey
，因为它包含锂电池，拆卸可能会导致触
电、火灾或人身伤害的危险。
避免在过高或过低温环境中使用。
任何未经授权的人员拆卸更换或试图维修 Noble Osprey，都会导致
Noble Osprey 的保修失效。
本产品不适用于在水中或过于潮湿的环境中使用，请勿放入或浸没在水
或其它液体中。
否则将导致任何保修失效，并可能对产品造成永久性损坏。
500mAh
5H (降噪开），7H（降噪关）
产品型号
蓝牙版本
支持协议
音频传输
驱动单元
频率响应
连接距离
耳机电池容量（单个）
充电保护盒电池容量
播放时间（因音量和内容而异）
充电时间
充电接口类型
电源输入
10m
50mAh
耳机：1.5小时;充电盒：2小时
Type C
FCC
Noble Osprey
V 6.0
A2DP、AVRCP、HFP
SBC、AAC、LDAC
10mm Dynamic, 1*BA Drive
20Hz~40KHz
信息
FCC ID: 2AT8X-OSPREY
本设备符合FCC规则第15部分的规定。 操作须符合以下两个条件：
1.本设备不得产生有害干扰。
2.本设备必须接受任何收到的干扰，包括可能导致意外操作的干扰。
警告：未经制造商授权的修改可能会导致用户丧失操作本设备的权力。
注意：本设备经过测试，符合FCC规则第15部分对B类数字设备的限制性
要求。这些限制旨在提供合理的保护，以防止住宅环境中的有害干扰。
设备会产生、使用、并发射无线电波，如果未按照说明进行安装和使用，
可能对无线电通信造成有害干扰。然而，我们不能保证在特定安装条件
下不会发生干扰。
如果本设备确实对无线或电视接收造成有害干扰（可通过关闭和打开设备
来确定），我们建议用户尝试以下方法来解除干扰：
调整接收天线的方向或位置。
增加设备和接收器之间的距离。
将设备连接到与接收器不同的电路插座上。
咨询经销商或有经验的无线电/电视技术人员，寻求帮助。
FCC射频辐射暴露警告声明：
本设备符合FCC针对非受控环境规定的射频辐射暴露限值，可在便携式
使用条件下使用。
制造商: Noble Hifi. LLC
KC ID: R-R-NoH-Osprey
真无线立体声耳机
使用说明书
60mm
95mm
包装清单
外观图示
LED 指示灯
麦克风
麦克风
LED 指示灯
多功能传感器（FMS)
复位键
LED 指示灯
USB Type C 充电端口
01 02
充电中：白灯慢闪
充满电：白灯常亮
说明：首次使用前请确保耳机和充电盒已充满电。
充电前和充电过程中，耳机和充电盒需要保持干净和干燥。
充电步骤：
1.耳机放回充电盒且关闭充电盖时
会自动关机。
打开或关闭充电盒盖子时，LED指示
灯会显示电量状态。
2.插入USB Type C 充电线，将充电
盒与电源连接。
03 04
充电
开机/关机
05 06
佩戴 配对/取消配对程序
07 08
控制 LED指示灯
09 10
模式切换 在待机模式或播放音乐时 重置程序
11 12
产品规格
13
要手动打开耳机，请长按MFS按钮3秒种。
要手动关闭耳机，请长按MFS按钮5秒种。
两侧耳机都会自动断电。
Noble Osprey
三击 MFS(R)
上一曲
双击 MFS(R)
下一曲
长按 MFS 2秒 (R)
语音助手功能 -
Siri / Google
单击 MFS(L/R)
播放/暂停
双击 MFS(L)
音量减小 -
三击 MFS(L)
提高音量 +
单击 MFS(L/R)
接听/挂断电话
长按 MFS 2秒 (L/R)
拒接来电
长按 MFS 2秒 (L)
降噪模式
5V 1A
听到通透模式的提示音
开启降噪模式
长按 2 秒
开启通透模式
长按 2 秒
返回普通模式
长按 2 秒
长按左耳塞触摸传感器2秒钟，听到普通模式提示音
简而言之，这是“降噪开”，“通透开”和
“普通模式”循环，长按左耳塞2秒
长按左耳塞触摸传感器2秒钟，听到降噪开的提示音，
将滤掉外界噪音。
长按左耳塞触摸传感器2秒钟，
*如果耳机无法相互配对或者无法与其他设备配对，请重置耳机。
1.将耳机放回充电仓内
2.按下复位按键 10 秒，直到两个耳机上的红白灯同时闪烁 3 次，重置完成，
所有先前配对的设备都将被清除。
如果不小心只重置了一只耳机，则需要重置两只耳机才能再次作为一对
耳机使用。
2. Enable Bluetooth on your smartphone and search for "Noble Osprey" in available
Bluetooth devices. Once found, select "Noble Osprey " to initiate pairing.
You will hear a "prompt tone", the earphones are now ready for use.
20Hz~40KHz
500mAh
SBC, AAC, LDAC
10m
50mAh
Type C
1x 10mm Dynamic
1x Balanced Armature
KC ID: R-R-NoH-Osprey
60mm
95mm
USB Type C Charging Port
01 02
03 04
05 06
07 08
09 10
11 12
13
Noble Osprey
5V 1A
Packing List
Overview
Earphones Charging Case x1
Ear Tips x10 Charging cable x1
Storage Bag x1
Instruction Manual x1
LED Light Indicators
LED Light Indicators
Microphone
Multifunction Sensor (MFS)
Microphone
Reset Button
LED Light Indicators
Charging
Notes:
Please make sure the earphones and charging case are fully charged prior to first use.
The earphones and charging case need to be clean and dry before and during the
charging process.
Charging Steps:
when placed back into the charging case
and the lid is closed.
The LED light will indicate the power
capacity when the lid is opened or closed.
2. Connect the charging case to a power
source via the included USB Type C charging
cable.
In charging: White LED will flash
Fully charged: White LED is solid
The earphones will power on automatically when charging lid is opened.
the charging lid is closed.
To manually turn the earphones on, hold the MFS button for 3 seconds.
Both sides
Fit
1. Select an eartip size suitable for your ear and insert them over the nozzle of the
earphone.
Pairing / Unpairing Procedure
The Noble Osprey will need to be paired to your device before use.
Once paired,they will connect automatically each time they are removed from the charging case
and powered on.
Pairing
1. Open the lid of the charging case. The earphones will power on automatically and
enter pairing mode, red and white indicator lights will flash alternately
Pairing a new device
1. Open the lid of your charging case. The earphones will power on automatically
and connect to your current device.
2. To unpair the earphones from your last connected smartphone by "disconnecting"
or deleting "Noble Osprey" from your smartphone's Bluetooth device list
.
3. Once disconnected, the earphones will automatically enter pairing mode, with red
and white indicator lights will flash alternately.
4. Enable Bluetooth on your smartphone and search for "Noble Osprey" in available
Bluetooth devices. Once found, select "Noble Osprey " to initiate pairing.
You will hear a "prompt tone" the earphones are now ready for use.
Operation
Play/Pause
Volume Up+
Volume Down-
Previous Track
Next Track
Answer Call/Hang Up
Reject Call
Voice Assistant function-
Siri/Google
ANC mode
Single Click MFS (L/R)
Triple Click MFS (L)
Double Click MFS (L)
Triple Click MFS (R)
Double Click MFS (R)
Single Click MFS (L/R)
Press the MFS for 2 seconds (L/R)
Press the MFS for 2 seconds (R)
Press the MFS for 2 seconds (L)
LED Indicator Lights
Usage Scenario
Power On
Power O
Pairing
Pairing succesful
Playing music or on calling
Low Power
Case is charging
Case full charged
Earphones inserted into charging case
Earphones fully charged in the charging case
LED Indicator Status
White LED light flashes for one second
Red LED light flashes for one second
Red and white light flashes alternately
LED ligh
Red LED light flashes twice every 5 seconds
Red LED light on
LED ligh
White light is flashing slowly
White LED light on
White LED remains on for 2 seconds
Single Pairing mode: Insert one side back into the charging case and the other earphone
will work independently.
One side will continue working even when the other side is powered
Pairing after being taken out of range: The earphones will automatically pair to the
smartphone within 3 minutes if they are close to the smartphone again after being
taken out of range. If they are not brought within range within three minutes, the
earphones will automatically power
Mode Switch
In standby mode or when playing music
ANC On Press and hold for 2 secs
Press and hold the left earbud touch sensor for 2 seconds with voice prompt .
Press and hold for 2 secs
Ambient Mode On
Press and hold the left earbud touch sensor for 2 seconds with voice prompt .
Press and hold for 2 secs
Normal mode on
Press and hold the left earbud touch sensor for 2 seconds with voice prompt .
There are three modes available. “ANC on, ”Ambient mode” and “Normal
mode”. To switch between modes,press and hold the left earbud for two
seconds. The voice prompt will confirm current selected mode.
Press and hold
for 2 secs
Reset Procedure
* If the earphones cannot pair to each other or to your bluetooth devices, please
reset them.
1. Put both earphones into the charging case
2. Hold the reset button for 10 seconds, the red and white LED lights will flash in
sequence 3 times on both earbuds. All previously paired devices will be removed.
The reset process is now completed.
In the case that only one earphone is accidentally reset, both earphones will need to
be reset to function as a pair again.
Earbuds = 1.5 hours
Charging case = 2 hours
Up to 5 hours with ANC on
Product Model
Bluetooth Version
Bluetooth Profile
Audio Codec
Driver Architecture
Frequency Response
Earphone Battery Capacity
Connection Distance
Charging Case Battery Capacity
Play Time
Charging Time
Charging Port
Power Input
Specification
Declarations and Warnings
Disconnect previous devices before pairing a new device.
WARNING!
Long-term exposure to high noise volumes may cause permanent hearing loss.
Do not use the Noble Osprey earphones in locations prohibiting the use of electronic
equipment.
Consult your physician prior to using your Noble Osprey earphones if you have a
pacemaker or other electrical medical devices.
This package contains small parts, which may pose a hazard to small children.
Do not disassemble the Noble Osprey as it contains lithium batteries, and disassembly
could result in electric shock or fi
re or serious injury.
Any disassembly of the Noble Osprey , or attempt to replace or repair the Noble Osprey
by
an unauthorized person, will void the Noble Osprey warranty.
This product is not designed for use in water or wet environments. Keep product
away from water and liquids.
Failure to do so will void any warranty and may cause permanent damage to the product.
Dispose of the product if it becomes swollen or cracked as it may be an indication
that the battery is degraded and may burst and cause a fire.
FCC STATEMENT
FCC ID: 2AT8X-OSPREY
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
Warning:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interferen
ce in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
encouraged to try to correct the inter
ference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CMIIT ID: 26J9987C4970
Manufacturer: Noble HiFi, LLC
TRUE WIRELESS STEREO EARPHONE
INSTRUCTION MANUAL
Noble Osprey
V 6.0
A2DP, AVRCP, HFP
European Union Representative
EARP B.V., Keizersgracht 555, 1017 DR Amsterdam, The Netherlands.
earpcorp.com/report
222-260378
FCC RF Exposure Warning Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment can be used in portable exposure
conditions.
FCC ID: 2AT8X-OSPREY
www.nobleaudio.com
Water Resistance
The Noble Audio Osprey earphones carry an IPX4 water resistance rating in accordance
with IEC 60529.
This indicates protection against water splashes from any direction under defined test
conditions. IPX4 does not constitute waterproofing.
The Osprey earphones must not be submerged in water or any other liquid.
Exposure to saltwater, chlorinated water, soaps, solvents, or high-pressure water jets
may cause damage not covered under warranty.
Water resistance may degrade over time with normal use.
Noble HiFi, LLC accepts no liability for damage resulting from water exposure beyond
the rated conditions.
European Union Representative
EARP B.V., Keizersgracht 555, 1017 DR Amsterdam, The Netherlands.
earpcorp.com/report
www.nobleaudio.com
222-260378
FCC ID: 2AT8X-OSPREY
CMIIT ID: 26J9987C4970
Scan this QR code to register your product
and access manuals in other languages.
Scan this QR code to register your product
and access manuals in other languages.
Scan this QR code to register your product
and access manuals in other languages.
