ROVSUN SF105B-18R 23'' High 1400W 120V Electric Fireplace User Manual

SF105B-18R/SF105B-23R

MADE IN CHINA

ELECTRIC FIREPLACE

TableofContents

Safety Information..................................................................................3

Pre-installation.......................................................................................6

Assembly......................................................................................7

Operation.........................................................................................8

Using the Remote Control....................................................................11

Smart Connection Guide.......................................................................12

Using the APP........................................................................................15

Care and Maintenance..........................................................................16

Troubleshooting....................................................................................17

SafetyInformation

IMPORTANTSAFETYINFORMATION

PLEASEREADALLOFTHEINFORMATIONINTHISOPERATINGMANUAL,INCLUDING

ALLSAFETY,OPERATING,ANDMAINTENANCEINFORMATION.TOAVOIDTHE

POTENTIALRISKOFFIRE,ELECTRICSHOCK,ORINJURYTOPERSONS,

USERSSHOULDFOLLOWTHEDIRECTIONSANDWARNINGSINTHISMANUAL

1.Readallinstructionsbeforeusingthisheater.

2.Donotusethisheateroutdoors.

3.Thisheaterisnotintendedforuseinbathrooms,laundryareasandsimilarindoorlocations.Neverlocatethe

heaterwhereitmayfallintoabathtuborotherwatercontainer.

4.Donotrunthepowercordundercarpeting.Donotcoverthepowercordwiththrowrugs,runners,orthelike.

Arrangethepowercordawayfromtrafcareasandwhereitwillnotbetrippedover.

5.Todisconnecttheheater,turncontrolstooff,thenremovetheplugfromtheoutlet.

6.Connecttoproperlygroundedoutletsonly.Alwaysplugheatersdirectlyintoawalloutlet/receptacle.Never

usewithanextensioncordorrelocatablepowertap(outlet/powerstrip).

7.Topreventapossiblere,donotblockreboxairintakesortheexhaustinanymanner.Donotoperatethe

reboxonsoftsurfaces,likeabed,whereopeningsmaybecomeblocked.

8.Thereisathermostatlimiterinsidetheheater.Whentheinnertemperatureoverheatsorabnormalheating

occurs,thethermostatprotectivedevicecutsoffthepowersupplytoavoidreplacedamagedorriskofre.

9.Usethisheateronlyasdescribedinthismanual.Anyotherusenotrecommendedbythemanufacturermay

causere,electricalshock,orinjurytopersons.

SAVETHESEINSTRUCTIONS

WARNING

Therearenouserserviceablepartsinsidethereplace/heater,

Iftheunitappearstomalfunction,

turmtheunitoffandunplugtheunitfromthewallimmediately,andcontactCustomer.

WARNING

Thisheaterishotwheninuse.Toavoidburns,donotletbareskintouchhotsurfaces.

Ifprovided,usehandleswhenmovingthisheater,Keepcombustiblematerial,

suchasfurniture,pillows,bedding,papers,clothesandcurtains

atleast3f.t(0.9meters)fromthefrontoftheheaterandkeepthemawayfrom

thesidesandrear.

WARNING

Extremecautionisnecessarywhenanyheaterisusedbyornearchildrenorinvalids

andwhenevertheheaterisleftoperatingandunattended.

WARNING

Alwaysunplugtheheaterwhennotinuse.

WARNING

Donotoperateanyheaterwithadamagedcordorplugor

aftertheheatermalfunctions,hasbeendroppedordamagedinanymanner.

Returntheheatertoanauthorizedservicefacilityforexamination,

electricalormechanicaladjustment,orrepair.

WARNING

Donotinsertorallowforeignobjectstoenteranyventilationorexhaustopenings

asthismaycauseanelectricshockorre,ordamagetheheater.

WARNING

Aheaterhashotandarchingorsparkingpartsinside.

Donotuseinareaswheregasoline,paint,orammableliquidsareusedorstored.

CAUTION

Whiletheheaterisinuse,thetopcenterofthereplacecangethottothetouch,

andmaycauseseriousinjuryorburns.

Alwayssupervisesmallchildrenaroundthereplace/heater.

Donotplaceanyclothordecorationsovertheheateroutletofthereplace,

orotherwiseobstructtheheateroutletofthereplace,

asthismaycauseareandseriousinjurymayresult,

SafetyInformation(continued)

GROUNDINGINSTRUCTIONS

Thisproductmustbegrounded.Ifitshouldmalfunctionorbreakdown,groundingprovidesapathofleast

resistanceforelectriccurrenttoreducetheriskofelectricshock,Thisproductisequippedwithacordhaving

anequipment-groundingconductorandagroundingplug.Theplugmustbepluggedintoanappropriateoutlet

thatisproperlyinstalledandgroundedinaccordancewithalllocalcodesandordinances.

Thisheaterisforuseon120-voltcircuitsandhasagroundedplug.Anadapterisavailablefromyourlocal

electronicsstoreoronlinesupplierforconnectingthree-bladegrounding-typeplugstotwo-slotreceptacles.

Thegreengroundinglugextendingfromtheadaptermustbeconnectedtoapermanentground

suchasaproperlygroundedoutletbox.Theadaptershouldnotbeusedifathree-slotgroundedreceptacle

isavailable.

DANGER

Improperconnectionoftheequipment-groundingconductorcanresult

inariskofelectricshock.Checkwithaqualiedelectrician

orservicemanifyouareindoubtastowhethertheproductisproperlygrounded.

Donotmodifytheplugprovidedwiththeproduct.

Ifitwillnotttheoutlet,haveaproperoutletinstalledbyaqualiedelectrician.

Cover of Grounded Outlet Box

Grounding Pin

Adapter

Grounding Lug

Metal Screw

Cover of Grounded Outlet Box

Pre-installation

TECHNICAL SPECIFICATION

24x 5.1x 17.5 Inch

Dimensions(WxDxH)/SF105B-23R

Net Weight

Gross Weight

Power Rating

Voltage

Frequency

12.6 Ib

14.8 Ib

1400W

120V

60Hz

PACKAGE CONTENT

Fireplace Unit Remote Control Screw x5

19x 5.1x 17.5 Inch

Dimensions(WxDxH)/SF105B-18R

Assembly

●STEP 1

Take out the unit from the box and layout all the spare parts for easy assembly. Make sure all small items

are not left in packaging materials.

NOTE:

Do not attempt to install the unit from the front of the mantel. It will not t.

●STEP 2



Carefully set the unit from the back of the mantel and center it in the opening.

Check the alignment and attach the unit of the mantel by inserting screws through the drilled holes

on the trim of the mantel.

Operation

●󵿎Identifyingthecontrolpanel



•Thecontrolpanelislocatedonthetoprightcornerofthereplace/heaterunit.

•Thecontrolpanelcontainsthedisplayunit(1),functionindicator(2),timerfunction(3),heatercontrol(4),

amescontrol(5),andmainpower(6).

•Thedisplayunit(1)displaysinformationabouttheamelevel,timer,andcurrenttemperature.

●󵿎Understandingthefunctionindicator

•Thefunctionindicator(2)hasthreesquareLEDS-red,green,andblue.TheredLEDindicatesthattheFahrenheit

temperatureheatingfunctionisrunning,thegreenLEDindicatesthattheCelsiustemperatureheatingfunction

isrunning,andtheblueLEDindicatesthatthetimerfunctionisengaged.

•TothebottomofthethreeLEDS,istheinfraredreceivermodulewhichcommunicateswiththeremotecontrol

tocontroltheheater.

Operation

●󵿎Usingthetimerfunction

Thetimerbutton(3)allowsyoutosettheamountoftimeyouwantthereplace/heatertorun.Thetimerbutton(3)

operatesboththeamesandtheheaterfunction.iftheheaterisoperatingwhenthetimerisset,thentheheater

isonthetimer.iftheamesareoperating,thenthetimerwillcontroltheames.ifboththeheaterandamesare

operatingwiththetimerset,thenthetimercontrolsboththeamesandtheheater.Pressingthebuttoninsequence

willsetthetimerforasetinterval.Thisintervalperiodisshowninthedisplay(1),inblue.Thesetintervals

aredisplayedinthistable.Thetimerintervalissetfromthetimetheintervalisselected.Thereisnoclockfunction

forturningtheheateroramesonoroffataspecictime.

●󵿎Usingtheheatercontrol

•Theheaterbutton(4)turnstheheateronoroff.Thereisnospeedsettingfortheheaterblower.lfyouputthe

heaterinastandbymode(turnoffbythemainpowerbutton6),theunitwillholdthesettingsinthememory.

Whenthepoweristurnedbackon,theheaterwillturnonatthesamesettings.

•Whentheheatingfunctionturnson,pressandholdtheheaterbutton(4)forvesecondstoentertemperature

adjustmentmode.TheLEDindicatorisred.Inadjustmentmode,thedisplayunit(1)ashes(intervalis0.5second).

Thereare22levelstochangeFahrenheittemperature72°F—73°F...82°F—ON—62°F—63°F...71°F.

Afterthisisset,thedisplay(1)willashvetimesandexitfromsettingstatus.

Ifidle,thedisplayturnsoffafter10seconds.

•Withtheheateron,gentlypressandholdthemainpowerbuttonforvesecondstoentertemperature

convertingmode.TheLEDindicatorashesvetimesinredcolorthenchangestogreen.Inthisconvertingmode,

thedisplay(1)ashes(intervalis0.5second).Pressandholdtheheaterbutton(4)forvesecondstoenter

temperatureadjustmentmode.Thereare12levelstochangeCelsiustemperature

22°c—23°c...27°c—ON—17°c—18..21°c.Afteriisset,thedisplay(1)ashesvetimes.Ifidle,thedisplayturnsoff

after10seconds.RepeatthesameprocesstoconvertCelsiustemperatureintoFahrenheittemperature.

ButtonPress

1stpress

2ndpress

3rdpress

4th press

5th press

6th press

7th press

8th press

TimerInterval Display

30Minutes

30

1Hour

2Hours

3Hours

4Hours

5Hours

6Hours

OFF

1h

2h

3h

4h

5h

6h

None

Operation

●󵿎Usingthef amecontrol

•Press the ame control button manually set ame color. The ame color settings are as follows:

Display

Color Name

Orange

Red

Orange Red

Blue Red

●󵿎Usingthemainpowerbutton

•Pressthepowerbutton(6)toturnthereplace/heaterunitonandoft.

Pressthepowerbutton(6)oncetoturntheuniton.Pressagaintoturntheunitoff.

Blue Orange

Blue Orange Red

Automatically cycle through all ame colors

UsingtheRemoteControl

1.Non-rechargeablebatteriesarenottoberecharged.

2.Batteriesaretobeinsertedwiththecorrectpolarity.

3.Exhaustedbatteriesaretoberemovedfromtheproduct.

4.Alwayspurchasethecorrectsizeandgradeofbatterymostsuitable

fortheintendeduse.

5.Replaceallbatteriesofasetatthesametime..

6.Cleanthebatterycontactsandalsothoseofthedevicepriortobatteryinstallation.

7.Removebatteriesfromequipmentwhennotusedforanextendedperiodoftime.

WARNING

Donotingestbatteries.

NOTE:

Batterydisposal

Pleasealwaysdispose

ofbatteries atasuitable

recyclingpoint.

Flame Control

Heater Control

●󵿎Using the Remote control

The operation of the remote control buttons work the same as button on the control panel.

●󵾯Install the battery

For replacement batteries, use AAA batteries.

Press down and slide back cover off the battery compartment.

Insert two provided AAA batteries into the battery compartment making sure that the ends of the batteries

with the negative(-) symbols are against the springs in the battery compartment.

Replace the battery compartment cover, making sure it snaps into position.

Main Power

Time Control

Heater Down

Heater Up

Smart Connection Guide

●󵿎SYSTEM REQUIREMENTS

•Supported wireless routers must have a 2.4 GHz operating frequency

•Standard: 802.11b/g/n bans

•Supported smartphone systems: Android 6.0 or later iOS 11 or later

Step 1

To download the app, scan the QR code. You can download the iOS or Android version, then install on your mobile

device.

Step 2

Open the app, turn on Bluetooth,then sign up for a free account, Log in with your account name and password.

Smart Connection Guide

Step 3

Select your network and enter the password. The network must be 2.4 Ghz.

Step 4

When the replace is plugged in, you can search for replace’s name.

To activate Wi-Fi pairing mode in replace standby mode, press and hold the Timer Button for 5 seconds. The

display screen will ash “PO” continuously.The mode will automatically turn off after 90 seconds of inactivity.

Step 5

Open the app, then select the ADD DEVICE button. The app will search for the replace automatically. Press the

green ADD DEVICE button to add your device.

Smart Connection Guide

Step 6

Choose your Wi-Fi name (the one your phone is connected to) and enter the password, Press the “Next” button

to continue.

Tip: If the WI-FI password is displayed, please press Next.

Step 7

The app starts connect to your replace. It may take some time, but please wait patiently to set up the connection.

USING THE APP

RF Exposure Warning Statements:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment. This equipment shall be installed and operated with minimum distance 20cm

between the radiator & body.

Care and Maintenance

WARNING

Alwaysdisconnectfromthepowersupplybeforecleaningtheheater.

Firstturnoffthemain power.

Thenremovetheelectricalplugfromthewall outlet.

WARNING

Donotusethisreplaceinsertifanypartof ithasbeenunderwater.

Immediatelycallaqualied servicetechniciantoinspectthereboxand

replace anypartoftheelectricalsystemwhichhasbeenunderwater.

Theblowermotorandamemotorarepre-lubricatedforadurableusingtimeandneednofurtherlubrication

ormaintenance.Toremoveanyaccumulationofdustordebris,thesoftbrushattachmentofavacuumcleaner

shouldoccasionallybeusedtocleantheoutletgrilleofthefanheater.

● Useasoft,cleancloththatwillnotscratchthesurfacewhendusting.

● Useacleansoftclothdampenedwithwarmwatertocleanthereplacesurface.

D0NOTusehouseholdorabrasive cleaners,astheseproductsmaydamagethesurface.

● Whencleaningtheglassviewingscreenuseanon-abrasivedampclothwithliquidcleanerorsoftsoap

ifnecessary;Don NOTusecleaningpowdersoranyothersubstancewithabrasives

sincethesesubstanceswillscratchglass.

● Undernocircumstancesshouldthisproductbeoperatedwithabrokenorchippedglasspanel.

● Donotstrikeorslamtheglass.

● Intheeventthatyourapplianceisstainedorotherwisedamagedduringuse,werecommendthatyoucall

aprofessionaltoit.

● Whennotinusepleaseunplugthecordfromtheoutlettopreventanydamageoraccidents.

Troubleshooting

Problem

Solution

Checkthattheunitisfullypluggedinto

astandard120Voutlet.

Pressthepowerbuttononthecontrolpanel.

Theunitdoesnotturnon.

Theunitison,butthereisnoameeffect. Openthebackpanelstocheckiftheame

spindlehas fallenofffromthespindlemotor.

Thereisavisibleameeffect,buttheheater

doesnot continuetoblowwarmairafterrepeatedly

turningontheheater.

Turnon/offtheheaterbuttonseveraltimesto

makesure itisinthe“ON”position.

Theheaterdoesnotwork,butthepower

andheaterswitchesareinthe“ON”position.

Turnallswitchestothe“OFF”positionandunplug

the unitfromthewalloutletfor5minutes.

After5minutesplugtheunitbackintothewalloutlet,

andoperateas normal.

Makesurethatnoobjectsareblockingtheair

ventsonthetopandonthefrontofyourreplace.

Changetheremotebattery.

Operateremotetransmitterataslowmeasuredpace.

Presstheremotecontrolbuttonswithanevenmotion

andgentlepressure.

Repeatedlypressingbuttonsinrapidsuccessionmay

causethetransmittertomalfunction.

Standclosertoyourreplace.

Removeobjectsthatmayblockyourremotecontrol's

abilitytocommunicatewithyourreplace.

Remotecontrolisnotworking.

ROVSUN SF105B-18R 23'' High 1400W 120V Electric Fireplace Inserts with APP & Remote

Product's Documents

User Manual

Specifications

ROVSUN SF105B-18R Questions and Answers

Related Products

ROVSUN XQB70-168 2.3 Cu.Ft. Automatic Top-Load Washer Machine

ROVSUN SF413-23A 18" Wide 1400W 120V Electric Fireplace Insert Log with Remote & WiFi Control

ROVSUN SF413-23A 18" Wide 1400W 120V Electric Fireplace Insert Log with Remote & WiFi Control

Legend Flame EF321 LegendFlame Jaden 28" W x 22" H Electric Fireplace Insert with Front Trim Kit, Fire Crackling Sound, 750W/1500W Heater, Remote Control

Legend Flame EF265 LegendFlame Carl 39" W Electric Fireplace Insert , Fireplace Heater 750/1500W, Fire Crackling Sound, Remote Control…

Legend Flame EF264 LegendFlame Carl 35" W Electric Fireplace Insert , Fireplace Heater 750/1500W, Fire Crackling Sound, Remote Control…
