REVISED BULLETIN
SERVICE PARTS LIST
MILWAUKEE ELECTRIC TOOL CORPORATION
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
BULLETIN NO.
STARTING
SERIAL NO.
WIRING INSTRUCTION
DATE
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
CATALOG NO.
54-06-2240
M18™ RADIUS™ COMPACT SITE LIGHT W/ FLOOD MODE
2144-20
J65A
Dec. 2017
0
00
EXAMPLE:
Component Parts (Small #)
Are Included When Ordering
The Assembly (Large #).
2
3
1
2
3
5
6
4
5
6
5
8
7
5
8
MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. Lisbon Road, Brookeld, Wisc. 53005
Drwg. 1
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 44-06-0001 Main Lens & Handle Assembly (1)
2 --------------- Main Lens & Handle (1)
3 --------------- M4 x 18 PH T20 Torx Screw (4)
4 14-38-0002 Right Lens Cover Kit (1)
5 --------------- M3.5 x 1.27 PH T10 Torx Screw (4)
6 --------------- Right Lens Cover (1)
7 14-38-0001 Left Lens Cover Kit (1)
8 --------------- Left Lens Cover (1)
9 12-20-2140 Service Nameplate (Not Shown) (1)
10 10-20-1066 Warning Label (Not Shown) (1)
FIG. NOTES
9, 10 A clean, dry surface is essential for proper performance for any
adhesive system. The area intended for application of any
adhesive label or nameplate must be prepared by cleaning with
isopropyl alcohol. The solvent is to be applied with a clean, lint
free applicator and the surface allowed to dry before applying the
label or nameplate.
