Save These Instructions – For Household Use Only
Owner’s Manual
MODEL: YJ-803
When using electrical appliances, basic safety precautions
should always be followed. Do not use the PowerXL Air
Fryer™ until you have read this manual thoroughly.
Visit TristarCares.com for tutorial
videos, product details, and more.
Guarantee Information Inside
2 Power XL Air Fryer™
PowerXL Air Fryer
BEFORE YOU BEGIN
The PowerXL Air Fryer will provide you many
years of delicious family meals and memories
around the dinner table. But before you begin, it’s
very important that you read this entire manual,
making certain that you are totally familiar with this
appliance’s operation and precautions.
Model
Number
Supply
Power
Rated
Power
Capacity Temperature
YJ-803
AC 120V 60Hz 1000W 2 qt. (116 cu in.) 180° F–400° F (82° C–204° C)
Appliance Specications
Power XL Air Fryer™ 3
Table of Contents
IMPORTANT SAFEGUARDS 4
Parts & Accessories 6
Using the Control Panel 8
Instructions for Use 10
General Cooking Guidelines 12
Troubleshooting 13
Frequently Asked Questions 14
Cleaning & Storage 14
Money-Back Guarantee 15
4 Power XL Air Fryer™
IMPORTANT SAFEGUARDS
1. READ AND FOLLOW all instructions carefully.
2. NEVER immerse the Main Appliance Housing, which
contains electrical components and heating elements, in
water. Do not rinse under the tap.
3. THIS APPLIANCE IS NOT INTENDED FOR use by
persons with reduced physical, sensory, or mental
capabilities or lack of experience and knowledge unless
they are under the supervision of a responsible person or
have been given proper instruction in using the appliance.
This appliance is not intended for use by children.
4. TO AVOID ELECTRICAL SHOCK, do not put liquid
of any kind into the Main Appliance Housing containing
the electrical components.
5. THIS APPLIANCE HAS A POLARIZED PLUG
(one blade is wider than the other). To reduce the risk of
electric shock, this plug is intended to t into a polarized
outlet only one way. If the plug does not t fully into the
outlet, reverse the plug. If it still does not t, contact a
qualied electrician. Do not attempt to modify the plug
in any way.
6. MAKE SURE the appliance is plugged into a wall socket.
Always make sure that the plug is inserted into the wall
socket properly.
7. DO NOT use outdoors.
8. DO NOT place the appliance on the stove top.
Place on a at, horizontal surface with adequate space
for air ow.
9. TO PREVENT food contact with the heating elements,
do not overll.
10. DO NOT cover the Air Intake Vent or Hot Air Outlet Vent
while the appliance is operating. Doing so will prevent
even cooking and may damage the appliance or cause it
to overheat.
11. NEVER pour oil into the Basket. Fire and personal injury
could result.
12. WHILE COOKING, the internal temperature of the
appliance reaches several hundred degrees F.
To avoid personal injury, never place hands inside
the appliance unless it is thoroughly cooled down.
13. DO NOT use this appliance if the plug, the power cord,
or the appliance itself is damaged in any way.
14. IF THE POWER CORD IS DAMAGED, you must have it
replaced by the manufacturer, its service agent, or
a similarly qualied person in order to avoid hazard.
15. KEEP the appliance and its power cord out of the
reach of children when it is in operation or in the cooling
down process.
16. KEEP the power cord away from hot surfaces. Do not
plug in the power cord or operate the appliance controls
with wet hands.
17. NEVER connect this appliance to an external timer switch
or separate remote-control system.
18. NEVER use this appliance with an extension cord of
any kind. A short power-supply cord (or detachable
power-supply cord) is provided to reduce the risk of
becoming entangled in or tripping over a longer cord.
19. DO NOT let cord hang over the edge of table or
counter surfaces.
20. DO NOT operate the appliance on or near combustible
materials, such as tablecloths, paper towels, or curtains.
21. WHEN COOKING, do not place the appliance against
a wall or against other appliances. Leave at least 5 inches
of free space on the back and sides and above the
appliance. Do not place anything on top of the appliance.
22. DO NOT USE the appliance for any purpose other than
described in this manual.
23. THE USE OF ACCESSORY ATTACHMENTS
not recommended by the appliance manufacturer may
cause injuries.
24. NEVER operate the appliance unattended.
25. WHEN IN OPERATION, hot air and steam is released
through the Hot Air Outlet Vent. Keep your hands
and face at a safe distance from the Hot Air Outlet Vent.
Also avoid the hot steam and air while removing the
Basket and Fry Tray from the appliance.
26. THE APPLIANCE'S OUTER SURFACES may become
hot during use. The Basket and Fry Tray will be hot. Wear
oven mitts when handling hot components or touching
hot surfaces.
27. Before using your new appliance on any countertop
surface, CHECK with your countertop manufacturer or
installer for recommendations about using appliances on
your surfaces. Some manufacturers and installers may
recommend protecting your surface by placing a hot
pad or trivet under the appliance for heat protection.
WARNING
When using electrical appliances, always follow
these basic safety precautions.
PREVENT INJURIES! – CAREFULLY READ
ALL INSTRUCTIONS BEFORE USE!
Power XL Air Fryer™ 5
IMPORTANT SAFEGUARDS
CAUTION
Your manufacturer or installer may recommend that hot
pans, pots, or electrical appliances should not be used
directly on top of the countertop. If you are unsure, place
a trivet or hot pad under the appliance before using it.
28. DO NOT place your appliance on a cooktop, even if the
cooktop is cool, because you could accidentally turn the
cooktop on, causing a re, damaging the appliance, your
cooktop, and your home.
29. SHOULD THE APPLIANCE EMIT BLACK SMOKE,
unplug immediately and wait for smoking to stop. Allow
the appliance to cool and wipe out excess oil and
grease from the appliance.
30. Extreme caution must be used when moving an
appliance containing hot oil or other hot liquids.
31. USE EXTREME CAUTION when removing tray or
disposing of hot grease.
32. DO NOT clean with metal scouring pads. Pieces can
break off the pad and touch electrical parts, creating risks
of electric shock.
• Always operate the appliance on a horizontal
surface that is level, stable, and noncombustible.
• This appliance is intended for normal household
use only. It is not intended for use in commercial or
retail environments.
• If the appliance is used improperly or for
professional or semi-professional purposes or if it
is not used according to the instructions in the user
manual, the guarantee becomes invalid and the
manufacturer will not be held liable for damages.
• Always unplug the appliance after use.
• When the cooking time has completed, cooking
will stop and the fan will continue running for
10seconds to cool down the appliance.
• Let the appliance cool down for approximately
30 minutes before handling, cleaning, or storing.
• The appliance is equipped with an internal
microswitch that automatically shuts down the fan and
heating element when the Basket is removed.
Electric Power
The appliance should be operated on a dedicated
electrical outlet. If the electrical outlet is being used by
other appliances, your new appliance may not operate
properly.
Electromagnetic Fields
This appliance complies with all standards regarding
electromagnetic elds. If handled properly and
according to the instructions in this user manual, the
appliance is safe to use based on scientic evidence
available today.
Overheating Protection
Should the inner temperature control system fail, the
overheating protection system will be activated and the
appliance will not function. Should this happen, unplug
the appliance. Allow time for the appliance to cool
completely before restarting or storing.
Automatic Shut-Off
The appliance has a built-in shut-off device that will
automatically shut off the appliance when the cooking
time has completed. You can manually switch off the
appliance by turning the Time Control Knob to 0. The fan
will continue running for 10seconds to cool down the
appliance.
SAVE THESE INSTRUCTIONS – FOR HOUSEHOLD USE ONLY
This product can expose you to Bisphenol A, which is known
to the State of California to cause birth defects or other
reproductive harm. For more information, go to
www.P65Warnings.ca.gov.
For California Residents
WARNING:
6 Power XL Air Fryer™
Parts & Accessories
1. FRY TRAY
2. OUTER BASKET
3. EASY-GRIP HANDLE
4. MAIN APPLIANCE HOUSING
5. AIR INLET VENT
6. CONTROL PANEL
7. HOT AIR OUTLET VENT
8. POWER CABLE
4
5
6
8
7
NOTE: Unpack all listed contents from the
packaging. Contents vary by model. Please
remove any clear or blue protective lm on
the components before use.
*Removing bumpers is not recommended.
CAUTION: Appliance may be hot. Be careful not to touch the
appliance while in use. Keep the appliance away from other objects.
1
2
3
IMPORTANT: Please make sure that your PowerXL Air Fryer has been shipped with
the components that you ordered (some accessories may be sold separately). Check everything
carefully before use. If any part is missing or damaged, do not use this product. Contact the
shipper using the customer service number located on the back of this manual.
Power XL Air Fryer™ 7
Parts & Accessories
TOP VIEW FRONT VIEW
FRY TR AY
BACK VIEW
8 Power XL Air Fryer™
Using The Control Panel
1
2
3
Power XL Air Fryer™ 9
Using The Control Panel
1. Operating Light
The Operating Light will illuminate once the cooking
time and temperature have been set, indicating that
the appliance is powered on. Once the cooking time is
complete, the Operating Light will turn off.
2. Time Control Knob
Use the Time Control Knob to set the cooking time
(0–30 minutes). Setting the cooking time will begin the
cooking process.
3. Temperature Control Knob
Use the Temperature Control Knob to set
the cooking temperature (180° F–400° F).
Food Cook Times Temperature Time
French Fry 400° F (204° C) 15–20 mins.
Shrimp 325° F (163° C) 8–12 mins.
Cake 300° F (149° C) 20–30 mins.
Chicken 375° F (191° C) 20–25 mins.
Steak 400° F (204° C) 8–12 mins.
Fish 350° F (177° C) 10–15 mins.
Cooking Chart
Once you are familiar
with the appliance, you may
want to experiment
with your own recipes.
Simply choose the time
and temperature that suits
your personal taste.
10 Power XL Air Fryer™
Instructions for Use
1. Remove all the packaging material.
2. Remove any stickers or labels from the appliance.
3. Before initial use, wipe the inside and outside of
the appliance with a warm, moist cloth and mild
detergent. Handwash all cooking accessories.
4. Before cooking food, preheat the PowerXL Air
Fryer for a few minutes to allow the appliance
to burn off the protective coating of oil. Wipe
the appliance with warm, soapy water and a
washcloth after this burn-in cycle.
5. Place the appliance on a stable, horizontal, and
level surface. Do not place the appliance on
a surface that is not heat resistant. Ensure that
the appliance is used in an area with good air
circulation and away from hot surfaces and any
combustible materials. Do not place on the
stove top.
6. Place the Fry Tray in the Basket. Slide the Basket
into the appliance. If the Basket is placed
properly, it will click into place.
7. The PowerXL Air Fryer cooks using hot air. Do not
ll the Outer Basket with oil or frying fat.
8. Do not put anything on top of the appliance.
This disrupts the airow and affects the
cooking results.
1. Plug the appliance into a grounded wall socket.
2. Place the Fry Tray in the Outer Basket and push
down. Never use the Outer Basket without the
Fry Tray in place.
3. Place the ingredients in the basket. Never ll the
basket above the maximum ll line as this could
affect the quality of the end result or interfere with
the electric heating coils.
4. Insert the Outer Basket into the appliance. When
the Outer Basket and food is securely in place,
use the Temperature Control Knob to set the
cooking temperature.
5. Use the Time Control Knob to set the cooking
time.
6. The appliance will automatically turn on, run for
the full cooking cycle, and then shut off when the
cooking time is complete.
7. If the food is fully cooked, use tongs to remove
the food. If the food is not fully cooked, simply
slide the Outer Basket back into the appliance
and add a few minutes to the cooking time.
CAUTION: When removing food, DO NOT turn
the Outer Basket upside down because any
excess oil that has collected on the bottom of
the basket will leak onto the ingredients.
8. The appliance is instantly ready for preparing
more food.
Using the PowerXL Air Fryer
Before First Use
Power XL Air Fryer™ 11
Instructions for Use
Shaking
Tips
• Foods that are smaller in size usually require
a slightly shorter cooking time than larger foods.
• Large quantities of food only require a longer
cooking time than smaller quantities.
• Shaking smaller-sized foods halfway through
the cooking process ensures that all the pieces
are fried evenly.
• Adding a bit of vegetable oil to fresh potatoes
is suggested for a crispier result. When adding oil,
do so just before cooking and add only a small
amount onto the potato.
• Snacks normally cooked in an oven can also
be cooked in the PowerXL Air Fryer.
• Use premade dough to prepare filled snacks
quickly and easily. Premade dough also requires
a shorter cooking time than homemade dough.
• You can use the PowerXL Air Fryer to reheat
foods. Simply set the temperature and time to
however warm you want your food.
To ensure even cooking, some foods require shaking
during the cooking process. Remove the Basket from
the appliance. Gently shake the contents as needed
and place them back in the appliance to continue
cooking.
CAUTION: The Basket will be hot. Wear an oven mitt
during this procedure.
1. Place the Basket on a heat-resistant surface.
2. Shake the ingredients in the Basket.
3. Return the Basket to the appliance to finish
cooking.
12 Power XL Air Fryer™
General Cooking Guidelines
FOOD ITEM QUANTITY SHAKE TEMP COOK TIME
Adjustable Range (Increments)
COMMENTS
Thin Frozen Fries 1¼ cups YES 400° F/204º C 15–16 mins. (1 min.) -
Thick Frozen Fries 1¼ cups YES 400° F/204º C 15–20 mins. (1 min.) -
Homemade Fries 1¼ cups YES 400° F/204º C 10–16 mins. (1 min.) Add ½ tbsp. oil
Homemade Potato Wedges 1¼ cups YES 375° F/190ºC 18–22 mins. (1 min.) Add ½ tbsp. oil
Hash Browns 1 cup YES 375° F/190ºC 15–18 mins. (1 min.) -
Steak ¼ – 1.1 lb 375° F/190ºC 8–12 mins. (1 min.) -
Pork Chops ¼ – 1.1 lb 375° F/190ºC 10–14 mins. (1 min.) -
Hamburger ¼ – 1.1 lb 375° F/190ºC 7–14 mins. (1 min.) -
Sausage Roll ¼ – 1.1 lb 400° F/204º C 13–15 mins. (1 min.) -
Chicken Drumstick ¼ – 1.1 lb 375° F/190ºC 18–22 mins. (1 min.) -
Chicken Breast ¼ – 1.1 lb 375° F/190ºC 10–15 mins. (1 min.) -
Spring Rolls ¼ – ¾ lb YES 400° F/204º C 15–20 mins. (1 min.) Use oven-ready
Frozen Chicken Nuggets ¼ – 1.1 lb YES 400° F/204º C 10–15 mins. (1 min.) Use oven-ready
Frozen Fish Sticks ¼ – 1.1 lb 400° F/204º C 6–10 mins. (1 min.) Use oven-ready
Mozzarella Sticks ¼ – 1.1 lb 375° F/190ºC 8–10 mins. (1 min.) Use oven-ready
Cake 1 ¼ cups 320° F/160ºC 20–25 mins. (1 min.) Use baking tin
Quiche 1 ½ cups 360° F/182ºC 20–22 mins. (1 min.) Use baking tin/oven dish
Mufns 1 ¼ cups 400° F/204º C 15–18 mins. (1 min.) Use baking tin
Baked Goods 1 ½ cups 320° F/160ºC 20 mins. (1 min.) Use baking tin/oven dish
NOTE: Keep in mind that these settings are guidelines. Since ingredients differ in origin, size, shape,
and brand, we cannot guarantee the best settings for your ingredients.
Power XL Air Fryer™ 13
Troubleshooting
Symptom Possible Cause Solution
The PowerXL Air Fryer
does not work
The appliance is not plugged in. Plug the Power Cable into a wall socket.
You have not turned the appliance on
by setting the preparation time
and temperature.
Select the cooking temperature and then a
cooking time. The cooking process will begin
when the cooking time is set.
You have probably turned the appliance off. If you turn the
Time Control Knob to 0 while the appliance is cooking, you
will trigger the Auto Shut-Off mode.
Select the cooking temperature and then a
cooking time. The cooking process will begin
when the cooking time is set.
Food is not cooked
The Basket is overloaded. Use smaller batches for more even frying.
The temperature is set too low. Raise temperature and continue cooking.
Food is not fried evenly
Some foods need to be shaken during
the cooking process.
See "Shaking" section in "Instructions for Use".
Basket will not slide into appliance properly
The Basket is overloaded. Do not ll the Basket above the Maximum line.
The Fry Tray is not placed in the Basket correctly. Gently push the Fry Tray into the Basket.
White smoke coming from appliance
Too much oil is being used. Wipe down to remove excess oil.
The Basket has grease residue from the
previous operation.
Clean the Basket after each use.
French fries are not fried evenly
Potatoes are not prepped properly. Consult a recipe for potato type and prep.
Fries are not cut evenly. Cut fries thinner or reshape fries.
Fries are too crowded. Spread fries out or cook a smaller batch.
Potatoes are not rinsed properly during preparation. Pat dry to remove excess starch.
Fries are not crispy Raw fries have too much water.
Dry potato sticks properly before misting oil.
Cut sticks smaller.
Add a bit more oil.
14 Power XL Air Fryer™
Frequently Asked Questions
1. Can I prepare foods other than fried dishes
with my PowerXL Air Fryer?
You can prepare a variety of dishes, including steaks,
chops, burgers, and baked goods. See the PowerXL
Air Fryer Recipe Guide.
2. Is the PowerXL Air Fryer good for making or
reheating soups and sauces?
Never cook or reheat liquids in the appliance.
3. Is it possible to shut off the appliance at any time?
Turn the Time Control Knob to 0 to shut off the
appliance.
4. What do I do if the appliance shuts off while
cooking?
As a safety feature, the PowerXL Air Fryer has an
Auto-Shut-Off device that prevents damage from
overheating. Remove the Outer Basket and set it on a
heat-resistant surface. Allow the appliance to cool
down. Remove the Power Cable from the outlet. Once
cool, plug the Power Cable back into the socket. Restart
by inserting the Outer Basket into the appliance and
setting the cooking time.
5. Does the appliance need time to heat up?
If you are cooking from a cold start, add 3 minutes
to the cooking time to compensate.
6. Can I check the food during the cooking process?
You can remove the Basket at any time while cooking is
in progress. During this time, you can shake the contents
in the Basket if needed to ensure even cooking.
7. Is the PowerXL Air Fryer dishwasher safe?
Only the Fry Tray is dishwasher safe. The appliance
itself, which contains the heating coil and electronics,
should never be submerged in liquid of any kind or
cleaned with anything more than a warm, moist
cloth or nonabrasive sponge with a small amount
of mild detergent.
8. What happens if the appliance still does not
work after I have tried all the troubleshooting
suggestions?
Never attempt a home repair. Contact customer service
and follow the procedures set forth by the guarantee.
Failure to do so could render your guarantee null
and void.
Clean the PowerXL Air Fryer after each use. The Basket and
the Fry Tray are coated with a special nonstick surface.
Never use abrasive cleaning materials or utensils on
these surfaces.
1. Remove the Power Cable from the wall socket and
be certain the appliance is thoroughly cooled before
cleaning.
2. Wipe the outside of the appliance with a warm, moist
cloth and mild detergent.
3. Clean the Basket and the Fry Tray with hot water,
a mild detergent, and a nonabrasive sponge.
NOTE: The Fry Tray is dishwasher safe.
TIP: Should the Fry Tray contain difcult-to-remove food
particles, soak in hot, soapy water for 10 minutes.
NOTE: The rubber bumpers on the Fry Tray are part
of the Fry Tray and should generally not be removed.
However, if the rubber bumpers need to be cleaned,
they can be removed and reattached: To remove
the rubber bumpers, locate the capped end of the
bumpers and push the capped end off of the Fry Tray.
There will be some resistance, but keep pushing until
the rubber bumpers come off of the Fry Tray. Take
note of the slot on which the bumpers were sitting. To
reattach the rubber bumpers, align the hole in the rubber
bumpers with the slots from which the rubber bumpers
were removed. Slide the rubber bumpers all the way
back onto the slot on the Fry Tray.
4. Clean the inside of the appliance with hot water, a mild
detergent, and a nonabrasive sponge.
5. If necessary, remove unwanted food residue from
the heating element with a soft cleaning brush.
1. Unplug the appliance and let it cool down thoroughly.
2. Make sure all components are clean and dry.
3. Place the appliance in a clean, dry place.
Cleaning
Storage
Header
Power XL Air Fryer™ 15
90-Day Money-Back Guarantee
The PowerXL Air Fryer is covered by a 90-day money-back guarantee. If you are not 100% satised with your
product, return the product and request a replacement product or refund. Proof of purchase is required.
Refunds will include the purchase price, less processing and handling. Follow the instructions in the Return
Policy below to request a replacement or refund.
Replacement Guarantee Policy
Our products, when purchased from an authorized retailer, include a 1-year replacement guarantee if
your product or component part does not perform as expected, the guarantee extends only to the original
purchaser and is not transferable. If you experience an issue with one of our products within 1year of
purchase, return the product or the component part for replacement with a functionally equivalent new
product or part. The original proof of purchase is required, and you are responsible to pay to return the
appliance to us. In the event a replacement appliance is issued, the guarantee coverage ends six (6)months
following the receipt date of the replacement appliance or the remainder of the existing guarantee,
whichever is later. Tristar reserves the right to replace the appliance with one of equal or greater value.
Return Policy
If, for any reason, you would like to replace or return the product under the money-back guarantee, your
order number can be used as the return merchandise authorization number (RMA). If the product was
purchased in a retail store, return the product to the store or use “RETAIL” as the RMA. Return your product to
the address provided below for a replacement, which will incur no additional processing and handling fees,
or for the refund of your purchase price, less processing and handling. You are responsible for the cost of
returning the product. You can locate your order number at www.customerstatus.com. You can call customer
service at 973-287-5129 or email [email protected] for any additional questions. Pack the product
carefully and include in the package a note with (1) your name, (2) mailing address, (3) phone number,
(4) email address, (5) reason for return, and (6) proof of purchase or order number, and (7) specify on the
note whether you are requesting a refund or replacement. Write the RMA on the outside of the package.
Send the product to the following return address:
PowerXL Air Fryer
Tristar Products
500 Returns Road
Wallingford, CT 06495
If the replacement or refund request has not been acknowledged after two weeks, please contact
Customer Service at 973-287-5129.
Refund
Refunds requested within the money-back guarantee timeframe will be issued to the payment method
used at purchase if the item was purchased directly from Tristar. If the item was purchased from an
authorized retailer, proof of purchase is required, and a check will be issued for the item and sales tax
amount. Processing and handling fees are non-refundable.
Distributed by:
Tristar Products, Inc.
Faireld, NJ 07004
© 2021 Tristar Products, Inc.
Made in China
PXL-AF-2QT_IB_TP_ENG_V2_210322
We are very proud of the design and quality
of our PowerXL Air Fryer
TM
.
This product has been manufactured to the highest standards.
Should you have any questions, our friendly customer service staff
is here to help you.
For parts, recipes, accessories, and everything
PowerXL, go to tristarcares.com or scan this QR code
with your smartphone or tablet:
To contact us, email us at
or call us at 973-287-5129.
