EXCLUSIVELY FOR FIAT TOPOLINO
SPECIAL EDITION MAGFLUX
User Guide
SAFETY AND CARE INSTRUCTIONS
INTRODUCTION
FEATURES
SPECIFICATIONS SET UP
EVERYTHING YOUR MONSTERLINO
NEEDS FOR THE ADVENTURE
ATTACH YOUR SPEAKER
IMPORTANT
ATTACH THE LANYARD
HOW TO CHARGE
AT A GLANCE
PAIR TO YOUR SMARTPHONE
WIRELESSLY
TROUBLESHOOTING
WIRELESS CONNECTIONS
KEY FUNCTIONS
CONNECT TWO SPEAKERS FOR
TRUE WIRELESS STEREO + LIGHT SYNC
AUDIO & MUSIC CONTROLS
CALL CONTROLS
To protect your hearing, avoid listening at high volume levels
for extended periods of time.
Lower the speaker volume before starting audio playback.
Use this product only as intended.
Do not attempt to open, modify, or disassemble the speaker.
This product contains a built-in rechargeable lithium-ion
battery that is not replaceable.
Dispose of the product according to your local regulations
and recycling guidelines.
Battery performance may decrease over time or in extreme
temperatures.
Fully charge the speaker before storing it for extended
periods.
Disconnect the charging cable once the speaker is fully
charged.
Wireless performance may be aected by obstacles,
wireless interference, or distance from your device.
Do not expose the speaker to excessive heat, direct sunlight,
moisture, or freezing temperatures.
Do not leave the speaker inside a hot vehicle for extended
periods.
Do not use the produ
ct near water or allow it to become wet.
or abrasive cleaners.
03-D-60G-US
This product is not a toy. Keep out of reach of small children
unless supervised.
Please read all instructions before using this product and keep
this guide for future reference.
Thank you for choosing the Monsterlino Special Edition MagFlux
speaker, created exclusively for FIAT Topolino.
Designed for everyday adventures, Monsterlino delivers powerful
wireless sound in a compact magnetic speaker that easily
attaches to compatible smartphones and magnetic surfaces.
Enjoy music, calls, and customizable RGBIC lighting eects
wherever you go. For an even bigger experience, pair two speakers
together using True Wireless Stereo and Color Sync technology.
Please read this guide before using your speaker to ensure the best
performance and safe operation.
Wireless audio streaming
Compact magnetic portable speaker
RGBIC multicolor lighting eects
Built-in microphone for calls
USB-C fast charging
MicroSD card playback support
True Wireless Stereo (TWS) pairing
Color Sync lighting between two speakers
Includes magnetic adapter rings and lanyards
Charging Input: 5 V / 1 A
Output: 5 W
Battery Capacity: 500 mAh
Charging Time: Approx. 2 Hours
Playback Time: Up to 6.5 Hours
(50% volume)
USB Cable Length: 39.37 in / 1 meter
MicroSD Card Support: Up to 32 GB
RGBIC Passive Bass Radiator
Speaker
Microphone
Volume Down / Previous Track
Multi-Function Power Button
Volume Up / Next Track
MicroSD Card Slot
USB-C Charging Port & LED Indicator
Lanyard Attachment Slot
Magnetic Attachment Surface
Lanyard
USB-C Charging Cable
Magnetic Adapter Ring (Not Shown)
Travel Pouch (Not Shown)
Remove all accessories from the package
Fully charge the speaker before first use.
Power on and pair the speaker wirelessly.
Attach and enjoy
USB-C Charging Cable
Magnetic Adapter Rings
Lanyards
Travel Pouch
User Manual
Connect the included USB-C cable to the speaker.
Connect the other end to a USB power source or compatible
USB adapter (not included).
The LED indicator beside the USB-C port will illuminate red
while charging.
The LED indicator will turn o once charging is complete.
NOTE: When the battery level drops below 5%, the speaker will
announce “Low Battery.”
Insert the thin loop of the lanyard through the speaker’s
lanyard slot.
Pull the larger end of the lanyard through the loop.
Tighten securely.
Monsterlino features a built-in magnetic surface designed for
quick and convenient attachment to compatible magnetic
surfaces and devices.
NOTE: The magnetic adapter ring is designed for one-time
installation.
Always confirm the speaker is securely attached before use.
If attached directly to a smartphone or phone case, remove the
ring before using a wireless charger. Failure to do so may cause
overheating or damage.
The magnetic adapter ring is intended for use with standard
phone cases only.
Use only on clean, flat, compatible surfaces.
The magnetic adapter ring is not intended for use with
wireless charging.
The speaker can attach directly to compatible magnetic
smartphones and magnetic phone cases.
For additional magnetic support, the included magnetic
adapter ring can be applied to compatible surfaces or
phone cases.
Using the Magnetic Adapter Ring
Clean the desired surface thoroughly before application.
Remove the protective film from the adhesive side of the
adapter ring.
Carefully position the ring and press firmly into place.
NOTE: Some accessories are packed underneath the inner tray
insert. Be sure to remove and check all packaging materials
before discarding the packaging.
True Wireless Stereo (TWS) allows both Monsterlino speakers to
play together for enhanced stereo sound and Color Sync
technology.
To Connect Two Speakers:
Once connected, both speakers will play synchronized stereo audio
and lighting eects.
To Exit TWS Mode: Triple-press the Multi-Function Power Button
again on either speaker.
Your smartphone will remain connected to one speaker
wirelessly
Power on both speakers.
Place the speakers next to each other.
Triple-press the Multi-Function Power Button on either
speaker.
Wait for the confirmation tone indicating TWS pairing is
complete.
Open your smartphone’s wireless settings and connect to
“Monsterlino.”
To Disconnect : Disconnect the speaker through your
smartphone’s wireless settings.
If the speaker does not connect:
Make sure the speaker is powered on and charged.
Confirm wireless is enabled on your smartphone.
Move the speaker closer to your device.
Restart your smartphone and try again.
NOTE: You can also play audio directly from a MicroSD card
(up to 32 GB, sold separately).
Press and hold the Multi-Function Power Button to turn on
the speaker.
The speaker will power on and automatically enter wireless
pairing mode.
Audio prompts and indicator sounds may be heard during
startup, pairing, and connection.
Open your smartphone's wireless device settings
Select “Monsterlino” from the list of available devices.
Once connected, you will hear a confirmation prompt.
Power On/O: Press and hold the Multi-Function Power Button.
Change Accent Lighting: Double-press the Multi-Function Power
Button to cycle through lighting modes:
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a r
esidential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
The device has been evaluated to meet general RF exposure
requirement. The device can be
used in portable exposure condition without restriction.
This device may not cause harmful interference.
This device must accept any interference received, including
interference that may cause undesired operation.
You may hear a power-o prompt or sound eect.
Rainbow Flow
Ambient Fade
Red Pulse
Blue Pulse
Green Pulse
Play/Pause: Press the Multi-Function Power Button once.
Previous Track: Double-press the volume Down button (-).
Next Track: Double-press the volume Up button (+).
Decrease Volume: Press the volume Down button (-).
Increase Volume: Press the volume Up button (+).
The speaker must be connected to your smartphone wirelessly
to make or receive calls.
Answer or End a Call: Press the Multi-Function Power
Button once.
Reject a Call: Press and hold the Multi-Function power button
for 2 seconds.
NOTE: You will hear an audio alert when receiving an incoming call.
