Ucard 2
Access control terminal
IP65
password
Card
Product Introduction:
Ucard 2 is a high-performance, high-reliability card
access control device with slim design.
Application scenarios:
Schools, communities, office buildings, hotels, shopping
malls, shops, public service places, etc.
Product Features:
⚫ Industrial-grade design & stable
performance
⚫ Capacitive touch buttons
⚫ With doorbell function
⚫ Built-in EM & Mifare card
⚫ Equipped with three-color indicator
light
⚫ Waterproof design, strong environmental
adaptability
⚫ Support single machine/IoT use
⚫ Small size, easier to install
Universal Ubiquitous Co., Ltd.
Add: Floor 24-26, Building 3, Wantong Center,
Jingxing Road, Hangzhou City, Zhejiang Province,
CHINA 311121
Tel: +86-13764564383
Web: www.uni-ubi.com
Technical Parameters:
Ucard 2
interface
Serial
communication
interface
1 channel RS- 485
Relay output
1 relay output
Wiegand
interface
1 Wiegand 26/34/50/66 output, 1 Wiegand input
Signal input
3- way signal input, support switching
Signal output
1 signal output
Network
Interface
1 10/100M adaptive network port
Reset Button
1 reset button
Card swipe
module
Built-in EM & Mifare card
Tamper switch
1
speaker
- in, 1 x 1.5 W speaker
Function
Identifying
patterns
Card, password, card + password
Number of
cards
30,000
Identify records
200,000
Remote
upgrade
support
Deployment
Public network, local area network
Software
Support
Offline interface, Ustar, Ustar-Cloud
System Parameters
operating
system
Linux
CPU
Dual core ARM Cortex-A7, RISC-V MCU
NPU
1.2 Tops support INT8/ INT16
Storage
capacity
Memory 128MB, Storage GB
General parameters
Operating
temperature
-10 ℃ ~ 60 ℃
Universal Ubiquitous Co., Ltd.
Add: Floor 24-26, Building 3, Wantong Center,
Jingxing Road, Hangzhou City, Zhejiang Province,
CHINA 311121
Tel: +86-13764564383
Web: www.uni-ubi.com
Storage
temperature
-20℃~60℃
Operating
humidity
10%~90%
Protection level IP 65
power supply DC 12V/2A
Power
consumption
Max. 1 5W
Device size Wall mount:60*188*25mm
Installation
Wall Mount
Product size (unit: mm): 60*188*25
RF exposure statement
This equipment complies with the FCC radiation exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
FCC Warning
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—
Reorient or relocate the receiving antenna.
—
Increase the separation between the equipment and receiver.
—
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—
Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
