Oliveri Solutions Pty Ltd warrants to you, the first person
who has purchased and used the unit (“you”) that
this unit is free from defects due to faulty material and
workmanship in accordance with the conditions set out
in this document.This warranty is provided to you in
addition to your rights at law,including but not limited to
your rights under the Trade Practices Act 1074 (Cth) and
applicable legislation in your Australian State or Territory.
What this warranty covers:
This warranty covers defects due to faulty material and
workmanship of the unit supplied to you:
• For a period of 6 years from the date of purchase in
respect of the entire unit, excluding the Replaceable
Elements.The Replaceable Elements are consumable
components and all parts of the unit which can be
replaced including but not limited to the filter or water
treatment cartridge if there is a defect in the filter or
cartridge.This does not include the replacement of
the filter or cartridge to extend the life of the filter or
cartridge. The life of the filter cartridge is affected by
water quality, usage and water pressure.The warranty
only extends to the original purchaser of the unit.
What this warranty does not cover:
This warranty does not cover the unit or a Replaceable
Element of the unit where:
• The defect, fault or failure is attributable, or
substantially attributable to misuse, abuse, accident,
misapplication, neglect, freezing, oxidizing agents
(including but not limited to chlorine, ozone,
chloramines and other related components) or act of
God.
• The unit has been in conditions which do not conform
to the recommended design guidelines or has been
operated in a manner which is contrary to Oliveri
Solutions Pty Ltd’ printed instructions.
PRODUCT
SPECIFICATION
• Usage: For mains cold water
only.
• Temperature Range: 2-38ºC
• Min.-Max. Working pressure
70-500 kPa
• Service Flow Rate: 6.3 Lpm*
• Capacity: 56,700 litres*
• Rating: 1 micron nominal
• Removes/reduces
Chlorine, cysts, giardia,
cryptosporidium, bad taste
and odours, and all particles
down to one micron in size.
• Filter Change: Annually or
sooner if flow rate becomes
inconveniently slow.
• This filter does not remove
fluoride.
• Inhibits limescale buildup in
water using appliances.
Hot Water Line Cold Water Line
Kitchen Mixer Tap
8
3
P
L
U
M
B
I
N
G
T
A
P
E
7
The cartridge can be installed
horizontally or vertically
1
6
2
Existing
Cistern Tap
(not supplied)
4
5
• The unit has not been installed in accordance with
Oliveri Solutions Pty Ltd’ printed instructions and has not
been installed in compliance with all applicable laws,
regulations and industry standards.
• The unit has not been used in accordance with the
manufacturer’s instructions.
• The unit does not meet the conditions for use described
in the owners manual or performance data sheet for
this unit.
• You use accessories or components which do not meet
Oliveri Solutions Pty Ltd’ specifications as set out in the
Owners Manual.
• The defect,fault or failure is due to normal wear and
tear.
• The defect, fault or failure has occurred where the unit
has been used reasonably or has reached its serviceable
life.
• The serial or model number label of the unit is
removed or defaced.
• The unit is serviced, modified, altered or repaired
by an unauthorized or unqualified person.
How to make a claim under this warranty:
To make a claim under this warranty you must contact
Oliveri Solutions Pty Ltd within 21days of the defect, fault
or failure occurring. Oliveri Solutions Pty Ltd’ warranty
Contact number is 1300137465. At the time of repair or
replacement under your warranty claim you must provide
to Oliveri Solutions Pty Ltd:
• Proof that you purchased the unit from an authorized
retailer or dealer within the warranty time; and
• A copy of a certificate which certifies that the unit was
installed in compliance with our printed installation
instructions and all applicable laws, regulations and
industry standards. Oliveri Solutions Pty Ltd will only pay
for repair or replacement upon receipt of proof of your
purchase showing the date of purchase.
Limitation of Liability of Oliveri Solutions Pty Ltd
under this warranty: Where a warranty exists or
is implied by law, Oliveri Solutions Pty Ltd liability is
limited (to the extent that it can be limited) to repair or
replacement of the faulty Replaceable Element or the
unit or an equivalent unit. Oliveri Solutions Pty Ltd may,
in its discretion, choose whether it shall repair or replace
any unit or Replaceable Element or Oliveri Solutions Pty
Ltd may choose to pay to you the cost of replacing the
Replaceable Element or the unit or the cost of having
the unit repaired. To the extent permitted by law, Oliveri
Solutions Pty Ltd assumes no liability whatsoever and
disclaims all liability for direct, indirect or consequential
loss, or special, general or other damage or expense
caused by or arising out of:
• Any failure to install or use the unit in accordance with
the Manufacturer’s Instructions, the Installation and
Operating Manual or Oliveri Solutions Pty Ltd’ printed
instructions; or
• The purpose for which you are purchasing the unit.
You acknowledge that the quality of water supplied and
your water usage rate and influent water pressure may
vary seasonally or over a period of time.
In addition to this water characteristics can differ if the
unit is relocated or the environment changes.
You acknowledge that Oliveri Solutions Pty Ltd does
not know your requirements and cannot and does not
warrant that the unit is fi
t for the purpose for which you
intend to use the unit or is appr
opriate for the purpose for
which you intend to use the unit. Oliveri Solutions Pty Ltd
does not authorize others to assume any obligation on its
behalf even if you inform them of the purpose for which
you intend to use this unit.
W
ARNING
Oliveri Solutions Pty Ltd does not recommend
making alterations to your existing plumbing to
accommodate this filter system. If you wish to modify
existing plumbing you must comply with AS 3500 and use
a licensed plumber. Where internal water pressure exceeds
860 kPa a Watermark approved Pressure Limiting Valve
must be installed prior to the filter system.
WARNING The contaminants or other substances
removed or reduced by this water treatment system are
not necessarily in your water supply. Do not use with
water that is microbiologically unsafe or of an unknown
quality without disinfection before or after the system.
IMPORTANT This filter is designed to be used with mains/
city water supplies.
Use of this system may increase the bacterial content of
water unless supplementary treatment is provided.
CAUTION Safely isolate the water supply prior to installing
the filter system to avoid injury and property damage.
IMPORTANT NOTICE The Oliveri Solutions Pty Ltd
FS5010-LF Inline Water Filtration System filters water
down to 1 micron. The filter’s very fine mechanical and
chemical filtering process removes chlorine, dirt and many
other potential contaminants. When water is filtered so
finely it can absorb part of everything it comes into
contact with. This can cause taste and odour issues.
Accordingly, you may find that with new kitchen tapware
the braided flex hose supplied with the new kitchen tap
has a rubber internal. This rubber internal may, in some
instances, cause taste and odour issues when the filtered
water first comes into contact with the hose.
Should this occur then flush the filtered water through
the hose over a period of time to remove taste and odour
issues.
Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have all the goods
repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Refer to oliveri.com.au for warranty details.
Product Specifications: The unit must only be used for a potable
water source and with cold water (with a temperature range
between 2 and 38° C).
TOOLS REQUIRED
FOR INSTALLATION
• Philips Head Screwdriver
• Adjustable Wrench
• Tape Measure
• Pencil
WARRANTY
* Subject to water quality,
water pressure and usage
Owner’s Manual
FS5010-LF
1 Head assembly with Mounting Bracket
2 Filter Cartridge
3 Mounting Screws
4 Dual Check Valve
5 Pex Hose 650mm – 1/2” female to 3/8”
male with sealing o-ring
6 Brass Hex Nipple 3/8” male to 1/2” male
with sealing o-ring
7 Horizontal Stabilizing Bracket
8 Plumbing Tape
INSTALLATION INSTRUCTIONS
WARNING: For correct operation of this system it
is essential to observe the instructions below.
IMPORTANT NOTES
• When installing this filter system in a new home
or kitchen please ensure that the cold water lines
under the sink are flushed to remove all debris
within the pipes, before installation of the water
filter system.
• This Water Filtration System should be installed
in accordance with any local Water Authority by-
laws. Australian Standard AS3500
• Where water pressure exceeds 500 kPa, and/or
your home is subject to water hammer, a suitable
pressure limiting valve must be installed prior to
connection to the filter system.
1. Open Carton and Inspect Parts.
Parts included – refer installation diagram
Item No.
Head Assembly with Mounting Bracket 1
Filter Cartridge 2
Mounting Screws 3
Dual Check Valve 4
Pex Hose 650mm – ½” female to 3/8”
male with sealing o-ring 5
Brass Hex Nipple 3/8” male to ½”
male with sealing o-ring 6
Horizontal Stabilizing Bracket 7
Plumbing Tape 8
2. Ensure that the cold water at mains supply is
turned off
Where an existing tap and connections are already
installed - after you have turned off the mains cold
water at the mini cistern tap, open the kitchen /
mixer tap and release any water pressure.
Unscrew the braided flex hose from the existing
cold water line mini cistern tap or isolation valve.
Clean the ½” male water connection thread.
3. Undersink Mounting Position
As you will note from the associated diagram,
this Inline Filter System can be installed in either
the horizontal or vertical position. Horizontal is
preferable.
a) Horizontal Position
Measure 460mm horizontally, and mark the
mounting location for the side of the Filter Head
Assembly and end of the filter cartridge. Make
sure there is adequate space to avoid crimping the
water line flex hoses. Also make sure your chosen
location offers easy access for future cartridge
changes and installation of the stabilizing support
bracket. (item 7).
b) Vertical Installation
Measure 460mm from the base of the cabinet (or
shelf), and mark the mounting location for the top
of the Filter Head Assembly. Make sure that there
is adequate space to avoid crimping the water line
flex hoses. Also make sure your chosen location
offers easy access for future cartridge changes.
4. Important - If necessary you can easily change
the direction of the flow of water through
the inlet and outlet of the filter system. You
will notice on the head assembly that the
inlet is shown by the word “IN” and the outlet
is shown by the word “OUT”. To change
direction, simply remove the four (4) screws
that hold the mounting bracket to the head
assembly and replace/refit the mounting
bracket in the opposite direction. This allows
flexibility when choosing the desired location
for your filter system.
a) Take the Pex Hose 3/8” male connection (item
5) and screw this connection to the inlet side
of the Filter Head Assembly (item 1). This
hose fitting has a sealing o-ring and does not
require plumbing tape or compound to be
applied to create the seal (do not use).You
will notice on the head assembly that the inlet
is shown by the word “IN” and the outlet is
shown by the word “OUT”.
b) Take the Brass Hex Nipple with o-ring (item 6)
and screw this connection into the outlet side
of the filter head (item1). This brass fitting
has a sealing o-ring and does not require
plumbing tape or compound to be applied to
create the seal (do not use).
IMPORTANT: Plumbing tape and/or sealing
compounds shall not be used as item 5 and
item 6 have a sealing o-ring. Use of thread
tape or sealing compounds may result
in damage to the filter head resulting in
product failure and water leaks and will
void the product warranty if used.
c) Securely mount the Filter Head Assembly
(item 1) on the cabinet wall using two of the
mounting screws (item 3) provided. The filter
head will be installed vertically or horizontally
depending upon your desired location.
9. Install Filter Cartridge (item 2)
a) Hold Filter Head (item 1) firmly with one hand.
b) Align cartridge notches with filter head.
c) Insert Filter Cartridge (item 2) and push into
filter head assembly (item 1).
d) Turn it to the right (about 1/4 turn) until it stops.
10. Flush the Filter Cartridge
a) Turn water supply back on at either the mains
or at the cold water mini cistern tap.
b) At this stage check for leaks and fix if
necessary
c) Turn kitchen tap on and flush the filter
cartridge for at least 2–3 minutes. Collect
water in container and use for garden etc.
NOTE – Flushing the filter cartridge is important
to remove air from the system and any loose
carbon powder. At first the water may appear
cloudy due to compressed trapped air in the filter
and hoses. However the cloudiness will disappear
over time and with use.
NOTES
1) This installation must comply with all applicable
state and local regulations.
2) Do not use with water that is microbiologically
unsafe or of an unknown quality without
disinfection before or after the system.
3) When storing filtered water in a refrigerator please
ensure the container has an air tight seal.
5. Connect Dual Check Valve – (item 4)
IMPORTANT – It is a legal requireme nt unde r
Australian Plumbing Standards for a Dual Check
Valve to be installed. If this part is not installed,
all warranties are null and void. Refer to the
NCC Volume 3, The Plumbing Code of Aust ralia
for the requirements of backflow prevention.
a) Apply plumbing tape (item 8) to the ½” male
water connection cistern tap fitting before
screwing on the dual check valve (item 4).
b) Also apply plumbing tape (item 8) to the ½”
male connection on the outlet of the dual
check valve. Wrap tape in direction of the
threads to ensure a tight fit and avoid leaks.
6. Attach Pex Hose (item 5)
Connect the ½” female end of the Pex Hose
(item 5) - to the ½” male end of the Dual Check
Valve (item 4) as shown in the diagram.
7. Attach Filtered Water to Cold Water Line of
Kitchen Tap
Take the braided flex hose that is attached to the
kitchen tap and screw the ½” female end of the
braided flex hose onto the hex nipple (outlet side
of filter head).
8. For Horizontal Installations – Install Stabilizing
Bracket (item 7)
Where the system is installed horizontally the unit
requires support at the base of the filter cartridge
with the Stabilizing Bracket (item 7). Locate the
bracket (item 7) in a position that allows three
important functions;
a) Firstly, the bracket needs to be located so the
Filter Cartridge can be removed when it is
replaced. Suggested location is at the base of
the filter cartridge.
b) The bracket must be level with the filter head
– so that the filter cartridge sits in a level
horizontal position.
c)
Finally, the bracket needs to be screwed
into the cabinet using the two remaining
mounting screws (item 3) and set in a manner
whereby the bottom of the bracket supports
the water filled filter cartridge horizontally.
W AT ER D R I NKI N G SYS T E M S
OWNER’S MANUAL
Performance Data
INLINE WATER FILTRATION FILTER SYSTEM
Model No. FS5010-LF
IMPORTANT NOTICE:
Read this performance data sheet and compare the capabilities of this
unit with your actual water treatment needs.
FEATURES
Filters water through any mixer tap.
Provides quality filtered water without compromising on flow rate.
Easy installation and space saving design.
Compatible with any bench top including solid surface.
Suitable for vertical or horizontal installation to maximise cupboard space.
Finely filters to 1 micron and polishes mains water to a premium quality for:
• Drinking
• Cooking
The latest carbon block filtration technology absorbs:
• Dirt
• Rust
• Chlorine
• Bad tastes
• Odours
• Cysts (e.g. giardia & cryptosporidium).
Maintains healthy minerals and salts as well as fluoride.
Helps to prevent the build up of limescale in water using appliances.
Simple, easy to change cartridge replacements.
• Tea & coffee
• Washing fruits & vegetables
*Tested using flow rate=0.5gpm; pressure=60psig; pH=7.5 ± 0.5; temp=20
o
C ± 2.5
o
C
Reduction Minimum Average
Max. Permissible
Substance Influent Challenge Product Water
Requirements Concentration Concentration
Requirements Reduction
Standard 42 Aesthetic Effects
Chlorine 2.0mg/L±10% 5ppm ≥50% - 95%
Particulate at least 10,000 - ≥85% - 99%
Nominal particles/mL
<1um
Standard 53 Health Effects
Cyst Minimum 50,000/L - 99.95% 99.99% 99.99%
N/A
N/A
N/A
Check for compliance with state and local laws and regulations. Product performance is
dependant upon incoming water conditions. This drinking water system must be maintained
according to the manufacturer’s instructions, including replacement of cartridge.
AS3497
Lic.WM-032108
IAPMO R&T OCEANA
This appliance meets the domestic water treatment
appliance Standards AS/NZS3497 for the following
water treatment processes:
WARNING: FOR CORRECT OPERATION OF THIS APPLIANCE IT IS ESSENTIAL TO OBSERVE THE
MANUFACTURER’S INSTRUCTIONS.
NB: Inhibits limescale buildup in water using appliances - as tested by the manufacturer.
CLASS TREATMENT TYPE PASS
I.
II. II (a)
II (b)
II (c)
III.
IV.
V.
Microbiological Status
Bacteriostatic
Microbiological Treatment
Bacteria Removal
Virus Removal
Protozoa Removal
Turbidity and Particulate
Reduction
Taste and Odour Reduction
Chemical Treatment
FUNCTION
Will stop bacteria increasing but will
not stop them unless II (a) is passed.
Will remove or inactivate bacteria.
Will remove or inactivate virus.
Will remove or inactivate
Cryptosporidium and Giardia.Will not
remove or inactivate bacteria and virus
unless II (a) and II (b) is passed.
Reduces cloudiness
Reduces tastes and odours
Decreases carbon chemicals
and chlorine
INLINE WATER FILTRATION SYSTEM
FS5010-LF
ASSEMBLED IN THE
U.S.A FROM U.S.A.
& IMPORTED PARTS
Replacement Cartridge: FR5910
FS5010-LF
* Cartridge life and capacity will vary according to water pressure, water quality and usage.
HEALTH CLAIM PERFORMANCE CLASSIFIED BY NSF:
This system has been tested according to NSF/ANSI 42 and 53 for the reduction of the substances listed below.
The concentration of the indicated substances in water entering the system was reduced to a concentration less
than or equal to the permissable limit for water leaving the system, as specified in NSF/ANSI 42 and 53.
OPERATING SPECIFICATIONS:
• Capacity: 56,700 litres* • Temperature: 2-38
O
C
• Pressure Requirement: 70-500 kPa • Flow Rate: 6.3 litres per minute.
GENERAL INSTALLATION REQUIREMENTS:
• Space required: 460mm x 225mm (allows space for cartridge replacement)
• Install cartridge vertically or horizontally with stabilizing support bracket.
• Flush new cartridge at full flow for 2–3 minutes until air is purged.
SPECIAL NOTICES:
• Installation instructions, parts and service availability, and standard warranty are included with the product
when shipped.
• This drinking water system must be maintained according to manufacturer’s instructions, including replacement
of filter cartridges.
• Do not use with water that is microbiologically unsafe, or of unknown quality without adequate disinfection
before or after the system.
• Flush system for 1 minute after period of non-use exceeding 7 days.
• The contaminants or other substances removed or reduced by the water treatment system are not necessarily
in your water.
• Check for compliance with state and local laws and regulations.
NOTICE OF REQUIRED MAINTENANCE:
This product contains consumable components, including the filter cartridge, which must be replaced at regular
intervals to ensure safe and effective operation. Water filter systems have a limited lifespan and may fail
unexpectedly if not properly maintai
ned.
• You must replace the cartridge every 57,500 litres or 6–12 months, which ever occurs first; or whenever
you detect a decrease in flow or change in taste or odour.
• DO NOT exceed 12 months under any circumstances.
Failure to replace the filter cartridge within the recommended interval constitutes improper maintenance and misuse
of the product will void the product warranty and may result in:
• Reduced performance,
• Degradation or fail
ure of the cartridge as particulates accumulate within the mechanism, or
• Unintended water discharge, leakage, or product damage.
To reduce risk of damage:
• Regularly inspect the system for leaks, wear, or deterioration.
• Use a drain pan connected to a suitable drain or fitted with a leak detector where damage could occur.
• Turn off the water supply upstream if the system will be unatt
ended for extended periods.
Register your system to receive cartridge replacement reminders and important product notifications.
To the extent permitted by law, the manufacturer accepts no liability for any loss or damage arising from the failure
to maintain the product in accordance with these requirements or the manufacturer's instructions.
Register online at oliveri.com.au/support/product-care/product-registration or scan the QR code in this manual.
Keep your contac
t details up to date to ensure you receive timely alerts.
Failure to register may result in missed maintenance reminders. Owner is responsible for timely cartridge replacement
and system maintenance.
Distributed by:
Oliveri Solutions Pty Ltd
Regency Park, SA, 5010
51 Naweena Rd,
08 8348 6444
oliveri.com.au
Scan QR code for product registration
and cartridge replacement alerts.
PR-P-OLIOMFS5010-LF
