1 Cell Image size: 277 mm
2 Cell Image size: 132 mm
3 Cell Image size: 83.666 mm
4 Cell Image size: 59.5mm
BN68-25141B-00
1
2
3
55”~85”
43”, 50
4 5
Scan this QR code
with your smart phone
to see helpful videos.
Scannez le code QR
à l’aide de votre télé-
phone intelligent pour
voir des vidéos utiles.
Unpacking and
Installation Guide
Guide de déballage
et d’installation
65″
43″- 50″ 55″- 65″
55″- 65″
‧
Power Cable
Câble d’alimentation
‧ Holder-Cable
Câble de retenue
‧ Remote Control /
Battery (AAA) x2
Télécommande /
Pile (AAA) x2
‧ Samsung Smart Remote /
Battery (AAA) x2
Télécommande
intelligente Samsung
/
Pile (AAA) x2
‧ Simple User Guide
Guide d’utilisation simple
‧ Remote control guide
Guide de la télécommande
‧ Regulatory Guide
Guide de réglementation
43″- 55″
QN7*H QN1EH
6
43QN7*H
38.0 inches
(965.5 mm)
22.0 inches
(559.4 mm)
1.0 inches
(25.7 mm)
24.2 inches
(614.7 mm)
7.8 inches
(198.4 mm)
42.5 inches
17.9 lbs
(8.1 kg)
18.5 lbs
(8.4 kg)
50QN7*H
44.0 inches
(1118.3 mm)
25.4 inches
(644.1 mm)
1.0 inches
(25.7 mm)
27.6 inches
(701.5 mm)
9.4 inches
(238.6 mm)
49.5 inches
24.5 lbs
(11.1 kg)
25.4 lbs
(11.5 kg)
55QN7*H
48.5 inches
(1232.1 mm)
27.9 inches
(708.8 mm)
1.0 inches
(25.7 mm)
30.2 inches
(768.1 mm)
9.4 inches
(238.6 mm)
54.6 inches
30.4 lbs
(13.8 kg)
31.3 lbs
(14.2 kg)
65QN7*H
65QN1EH
57.1 inches
(1450.9 mm)
32.7 inches
(831.8 mm)
1.0 inches
(25.7 mm)
35.0 inches
(890.0 mm)
10.6 inches
(270.4 mm)
64.5 inches
45.9 lbs
(20.8 kg)
47.0 lbs
(21.3 kg)
* : 0~9, A~Z
VESA
x (mm) (mm) x 4 (mm)
(inches)
(inches)
(inches)
43QN7*H 200 x 200 11-13
+
M8 1.25 7.4 15.1 6.8
50QN7*H 200 x 200 11-13
+
M8 1.25 8.2 18.1 9.4
55QN7*H 200 x 200 11-13
+
M8 1.25 10.5 20.3 9.6
65QN7*H
65QN1EH
400 x 300 11-13
+
M8 1.25 10.4 20.7 10.6
* : 0~9, A~Z
: Wall-Mount Bracket
: Fixation pour le support mural
43″ 50″ 55″- 65″
