WAN LAN
Hello, I’m here.
Follow me to extend your Wi-Fi network.
Powerline
1
* Image may differ from
actual product.
B
Press the Pair button for 1 second.
The Power LED starts blinking.
When the Powerline LED is on
and stable, it’s done.
Internet
Adapter TL-PA4020P Extender TL-WPA4530
2
Plug the powerline devices into the wall sockets
near each other and on the same electrical circuit.
Connect the adapter to a LAN
port of the router using an
Ethernet cable.
* If the Power LED does not blink, press it again.
Press the Pair button for 1 second.
The Power LED starts blinking.
A
Pair the powerline devices.
* A red Powerline LED indicates poor signal strength, move the extender to another location.
Find the Wi-Fi Info Card in the package, and then relocate the powerline extender
to a new location. Connect to the Wi-Fi using the SSID and password on the card.
within 2 minutes
Tips:
You can add more powerline devices to
the existing powerline network by pairing
these devices.
3. When the Wi-Fi LED blinks quickly for
3 seconds, and then stays on, it’s done!
Note: The wireless settings can also be configured
through the powerline extender's web interface or
through the tpPLC mobile app. You can download
the app from the App Store or Google Play, or simply
scan the QR code. To learn more information, visit
www.tp-link.com.
* TL-WPA4530 copys by default both 2.4GHz and 5GHz
wireless settings at the same time. If it fails to copy
both, your router may be only able to clone one band
at a time. Please check your router manual for support.
2. Within 2 minutes, press the Wi-Fi button for 1 second.
Q1. How do I reset my powerline extender?
A. With the extender powered on, use a pin to press and hold the Reset button until all LEDs turn off. When all LEDs
start on again, the reset process is complete.
Q2. How to troubleshoot if there is no Internet connection in my powerline network?
A1. Make sure all adapters and extenders are on the same electrical circuit.
A2. Make sure all Powerline LEDs are on. If not, pair your adapters and extenders again.
A3. Make sure all hardware connections are correctly and securely connected.
A4. Check if you have an Internet connection by connecting the computer directly to the modem or router.
Q3. What can I do if a successfully-paired extender does not reconnect after being relocated?
A1. Make sure all powerline devices are on the same electrical circuit.
A2. Pair it again with another adapter or extender, and make sure the Powerline LED is on before relocating it.
A3. Check for possible interference, such as washers, air conditioners or other household appliances that may be
too close to one of the powerline adapters or extenders.
Frequently Asked Questions
For passthrough powerline devices.For non-passthrough powerline devices.
Attention
Wall Outlet
Power Strip
Wall Outlet
Power Strip
WPSWAN LAN
WPS
©2015 TP-LINK 7106505526 REV1.0.0
If your router supports WPS, you can follow the steps below to automatically copy the router's wireless settings
(SSID and password) to the powerline extender.
Copy Wireless Settings from Router to Extender
1. Plug in the powerline extender near your
router. Press the WPS button on your router.
Button Legend
Press to turn all LEDs on or off. Press for 5 seconds until all LEDs are off and then
on again to reset the powerline extender to the
factory defaults.
Press to pair powerline devices. Refer to Step 3
on the front page for instruction.
Press to copy the wireless settings from the router
to the powerline extender.
Press for 5 seconds to turn Wi-Fi on or off.
Wi-Fi LEDs: indicates the 2.4GHz Wi-Fi network,
and indicates the 5GHz Wi-Fi network.
Press for 8 seconds until the Powerline LED is
off to leave the powerline network.
