IMPORTANT SAFETY INSTRUCTIONS
General Safety
Operation Safety
Electricity Safety
Cleaning Instructions
Do not use the appliance near flammables and
combustibles.
Do not cover the air inlet and outlet while
in operation.
When using electrical appliances, basic precautions should always
be followed to reduce the risk of fire, electric shock, and injury to
persons, including the following:
1. Read all instructions before using this appliance.
2. Children should be supervised to ensure that they do not play with the appliance. Cleaning and maintenance shall not be performed by children
without supervision.
3. Use the appliance as described in the user manual only. Any other use not recommended in the user manual may cause fire, electrical shock, or
personal injury.
4. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
1. Place the appliance on a flat, dry surface before use.
2. Do not immerse in water or any other liquids.
3. Do not use the appliance until the base is installed.
4. Do not insert your fingers, pencils, or any other objects into the grilles while in operation.
5. Do not aempt to repair or modify any electrical or mechanical functions on the appliance. All servicing should be performed by qualified personnel only.
1. Make sure that the voltage of your electricity supply is the same as that indicated on the appliance.
2. Always unplug before cleaning or leaving the appliance unused for a long period of time. Keep your hands dry when plugging/unplugging.
3. Do not operate any fan with a damaged cord or plug. Discard the fan or return to an authorized service facility for examination and/or repair.
4. Do not run the cord under carpeting. Do not cover the cord with throw rugs, runners, or similar coverings. Do not route the cord under furniture or appliances.
Arrange the cord away from traic area and where it will not be tripped over.
5.
WARNING: To reduce the risk of fire, electric shock or injury to persons, do not use replacement parts that have not been recommended by the
manufacturer (e.g. parts made at home using a 3D printer).
6.
WARNING: To reduce the risk of fire or electric shock, do not use this fan with any solid-state speed control device.
7.
WARNING: If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
8. The appliance shall not be modified by users, such as by adding supplemental filters to the appliance.
9. Exclusive for models that include a power adapter in their package contents: The appliance is only to be used with the power adapter provided with the
appliance. Turn o the appliance before plugging in.
10. Exclusive for models that don't include a power adapter in their package contents: This product employs overload protection (fuse). A blown fuse indicates an
overload or short-circuit situation. If the fuse blows, unplug the product from the outlet. Replace the fuse as per the user servicing instructions and check the
product. If the replacement fuse blows, a short-circuit may be present and the product should be discarded or returned to an authorized service facility for
examination and/or repair.
11. Exclusive for models that don't include a power adapter in their package contents: This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does
not fit, contact a qualified electrician. Do not aempt to defeat this safety feature.
1. Always turn o and unplug the appliance before cleaning.
2. Gently wipe o the dust with a soft, dry cloth.
3. Use a soft, dry cloth or a coon-tipped swab to remove any dust from the air inlet.
4. DO NOT use cleaning agents.
5. DO NOT use abrasive scrubbers.
6. Fire or electrical shock hazard. DO NOT immerse the main unit in water. Never allow water to get inside the appliance.
7. Except for cleaning, any servicing should be performed by an authorized service representative.
8. Store in a cool, dry area and keep the cable out of high-traic areas to avoid tripping hazards.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20
cm between the radiator & your body. This transmier must not be co-located or operating in conjunction with any other antenna or transmier.
FCC Statement
Baery Replacement
1. Remove the baery cover in the direction indicated by the arrow.
2. Replace with two new AAA 1.5V baeries. Make sure that the positive (+) and negative (-) terminals are positioned correctly.
3. Push the baery cover back into place.
DREO CUSTOMER CARE
FOR HOUSEHOLD USE ONLY
READ AND SAVE THESE INSTRUCTIONS
12-MONTH LIMITED WARRANTY
What is Covered
DREO warrants to you that your product will be free from original defects in materials and workmanship for a period of twelve (12) months from the date of your purchase, when you
use your product for intended purposes in accordance with this user manual.
Please retain your proof of purchase. If you do not retain your proof of purchase, your warranty will start two (2) months from the date of manufacture printed on your product label.
ANY IMPLIED WARRANTIES RELATING TO YOUR PRODUCT, INCLUDING BUT NOT LIMITED TO THE WARRANTY OF MERCHANTABILITY AND THE WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF THE LIMITED WARRANTY SET FORTH ABOVE AND ARE OTHERWISE DISCLAIMED.
THIS LIMITED WARRANTY SHALL BE THE SOLE REMEDY OF THE PURCHASER OR USER OF THE PRODUCT, AND DREO SHALL NOT BE LIABLE FOR AN ALLEGEDLY DEFECTIVE OR
DAMAGED PRODUCT EXCEPT TO REPAIR OR REPLACE IT IN ACCORDANCE WITH THIS LIMITED WARRANTY. DREO WILL NOT BE LIABLE FOR SPECIAL, INCIDENTAL, INDIRECT,
CONTINGENT, OR CONSEQUENTIAL DAMAGES OR LOSSES OF ANY NATURE THAT YOU MAY INCUR IN CONNECTION WITH YOUR PURCHASE OR USE OF YOUR PRODUCT.
Some jurisdictions do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above limitations or
exclusions may not apply to you. This limited warranty gives you specific legal rights, and you also may have other rights which vary from jurisdiction to jurisdiction.
Warranty Limitations and Exclusions
Limited Remedies
If your product fails because of an original defect in material and/or workmanship during the warranty period, DREO will repair or replace (in DREO’s sole discretion) your product.
To obtain warranty service on your product, contact us at [email protected] or at (888) 290-1688 (available from Monday-Friday, 9:00 AM-5:00 PM PST/PDT) for further
instructions.
IN THE EVENT OF AN ORIGINAL DEFECT IN MATERIAL AND/OR WORKMANSHIP, TO THE EXTENT PERMITTED BY LAW, THE REMEDIES SET FORTH IMMEDIATELY ABOVE ARE YOUR SOLE
AND EXCLUSIVE REMEDIES.
What is Not Covered
This limited warranty only applies to the original purchaser of your product and is non-transferable. This warranty is only valid if your product is used in the country in which you
originally purchased it. In addition, this warranty will not apply, and DREO will not be liable for any costs, damages, or repairs, in connection with any of the following:
Any service and customer support that DREO provides to you under this limited warranty will not extend the duration of this limited warranty.
• Accidents or use of your product with inappropriate force;
• Damage or destruction caused by wrong voltage or unstable electric current;
• Normal wear and tear;
• Careless operation or handling, misuse, abuse, neglect, and/or failure to maintain or use your product in accordance with this user manual;
• Any partially or completely altered, modified and/or dismantled products;
• Reduction in baery discharge time due to baery age or use (as applicable);
• Products with altered or removed serial numbers;
• Clearing any blockages from the product;
• Purchases from retailers and distributors not authorized by DREO to sell this product;
• Defects caused by or resulting from damages from shipping or handling by any third party not authorized by DREO to ship or handle your product; or
• Defects caused by or resulting from repairs, service, improper maintenance, or alteration to your product or any of its components by anyone other than a repair person
authorized by DREO.
WARNING
- Replace with new baeries of the same type when replacement is required.
- Remove the baeries when the remote control is unused for a long period of time.
- Do not aempt to destroy or dismantle the baeries.
- Do not dispose of the baeries in a fire as baeries may explode or leak.
- Chemical burn hazard. Keep baeries away from children.
- Do not mix old and new baeries. Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, nimh, etc.) baeries.
- Always purchase the correct size and grade of baery most suitable for the intended use.
- Replace all baeries of a set at the same time.
- Clean the baery contacts and also those of the device prior to baery installation.
- Remove used baeries promptly.
- Non-rechargeable baeries are not to be recharged.
CHOKING HAZARD - Small parts. Not for children under 3 years.
1
3
2
Rev_EN_1.0
Reach out to us, it's easy!
(Mon - Fri, 9:00 am-5:00 pm PST/PDT)
(888) 290-1688
www.dreo.com
DREO PTE. LTD.
1 COLEMAN STREET, #05-05, THE ADELPHI, SINGAPORE 179803
1. Grasp plug and remove from the receptacle or other outlet device. Do not unplug by pulling on cord.
2. Open fuse cover. Slide open fuse access cover on top of aachment plug towards blades.
3. Remove fuse carefully. Push the fuse from the other side to remove the fuse.
4. Risk of fire. Replace fuse only with 5 Amp. 125 Volt fuse.
5. Close fuse cover. Slide closed the fuse access cover on top of aachment plug.
User Servicing Instructions (Fuse)
This appliance features a fused safety plug that protects against overload or short-circuit situations. If
the fuse blows, please cut o power and follow the below instructions or consult a qualified electrician.
4
2
3
5
1
The remote control has no RF circuit.
WARNING
Risk of fire. Do not replace the aachment plug.
Contains a safety device (fuse) that should not be removed.
Discard the product if the aachment plug is damaged.
Hold for 5 seconds to start Wi-Fi connection seings.
Tip: The icon will keep flashing when pairing.
Now you can control the appliance on your app!
Tip: To restart network setup, hold again for 5 seconds.
产品名称｜Product name
材质印刷与
技术要求
DR-HTF028S_美规UG
20260817
Dove
Joan
1：1
Manrope
单页尺寸：160*130 mm
总长：390MM
图纸设计禁止修改，尺寸以实际刀模图为准
尺寸｜Size
比例｜scale
设计师
｜
Designer
审核｜Audit
日期｜Date
设计版本号
Rev_V0_EN
字体｜Fonts
审核
1、 备注信息图层为非印刷区域，展示印刷物料基础信息。
2、 刀板线、备注工艺、尺寸层展示印刷工艺部分。
3、 画面信息层展示印刷展示图片与文字。
图层使用规范：
*电子文档为Adobe Illustrator制作
文件格式：model规格类目日期.AI （为可编辑原始文档）
文件格式：model规格类目日期.pdf （为文件转曲不可编辑文档）
裁切线
正折线
反折线
出血位
粘胶区域
材质: 157G铜版纸双面覆哑膜
印刷要求: 双面彩色印刷，图稿清晰、不开裂、不发皱。
对折要求: 上下风琴折页
色值要求：蓝 C90 M70 Y0 K0
折页压痕线
LED Display & Control Panel
When using the appliance for the first time, remove the wraps and aach the parts by following the steps below.
User Guide
Smart Tower Fan
562S (2nd. Gen.)
Model No.: DWTF28S
Rated Power: 35W
Input: 120V~ 60Hz
Scan to read the full
user manual
Match the arched cutout with
the arched support on the base.
Then, hook them together.
Press down on the edges to snap
the two base halves together.
Thread the cord through the
center hole and aach the base to
the fan boom.
Intersect the two base halves
diagonally.
Make sure the arrows on both the base and
the fan boom are aligned.
Turn the base clockwise until it clicks into place.
1 2 3
4
5
6
7
Thread the cord through the REAR cord keepers
on your preferred side, then set the fan upright.
Faster response.
Excellent customer support.
Hassle-free returns.
Professional product guidance.
Exceptional after-sales experience.
Only DREO experts
give all the support
you need
Reach out to us, it’s easy!
Mon - Fri, 9:00 am-5:00 pm PST/PDT
(888) 290-1688
www.dreo.com
Working Modes
Press
Press
CAUTION
Do not operate the tower fan if the base has not been installed.
Make sure to thread the cord through all rear cord keepers.
Normal Mode
The fan runs at a fixed speed.
Power
• Touch to turn the fan on or o.
Natural Mode
Fan speed goes up and down intermiently to replicate
the natural breeze.
Sleep Mode(Mute Auto On)
Balances comfort and noise by automatically decreasing
the fan speed as you fall asleep.
Speed decreases once every 30 minutes, two times at
most per use.
Auto Mode
Fan automatically increases speed when the room
temperature is higher and decreases speed when the
temperature is lower.
Custom Mode(Available in the DREO app)
Customize the fan speed to your preference.
Look for "Smart
Tower Fan 562S
(2nd. Gen.)" when
connecting your
new appliance.
*To learn more, please visit www.dreo.com
1
3
4
Connecting to the DREO App
2
Launch the DREO app and sign in or create an account.
Tip: Verify your email address to continue.
Tap + Add Device and select Smart Tower Fan 562S
(2nd. Gen.).
Tip: Enable Bluetooth and plug in the appliance.
Scan the QR code
to download the
DREO app.
Search "DREO" on
Google Play or the App
Store.
OR
Mode
• Switch between Normal/Natural/Sleep/Auto mode.
• Long press for 3 seconds to mute/unmute.
Increase
• Increase fan speed (1-12 levels).
Decrease
• Decrease fan speed (1-12 levels).
Timer
• Select to set a timer (0-12h).
Oscillation / Wi-Fi Connection
• Sweep airflow horizontally (90°).
• Long press for 5 seconds to start network settings
and device pairing.
Note: Long press and for 10 seconds to restore factory seings.
C
l
i
c
k
160mm
130mm
