*Images may dier from your actual product.
1 /
Remove the
Bracket
2 /
Charge the Doorbell
Before Use
Plug in the USB cable to charge your doorbell.
When you plug in the charger, the LED should
blink amber quickly for 3 seconds.
5 /
Install the Doorbell
*Preview video on the Tapo app to nd the desired installation location.
Option 1. Stick to a smooth wall Option 2. Mount to the wall
4 /
Installation
Tips
1. Install the doorbell on a at and clean wall.
2. The doorbell should be placed 1.2 m (4 ft)
above the ground.
3. Use the included 15° mounting wedge for a
more focused view from a specic side.
Without
Mounting Wedge
With
Mounting Wedge
With
Mounting Wedge
(Rotate 180°)
15°
4. Avoid placing the doorbell near a side wall in
view. If needed, use the mounting wedge to
reduce reected light from the wall to
improve night vision.
Note:
1. Charge the doorbell before use. This will take about
6.5 hours.
2. The USB charger is not provided.
3. Peel o the lm from the doorbell before use.
4. Warning: Do not tear o the silicone part by force as
it may aect the waterproof performance.
5. Keep the port rmly covered by the bracket when not
in use to ensure waterproof performance.
6. The doorbell may not power up after falling. Plug in
the USB charger to power it on again.
Video Doorbell Mini
Quick Start Guide
7100000225 REV1.0.0
15°
1. Attach the included adhesive to the bracket
or wedge. If you use the wedge to adjust the
angle, rst ax the bracket and the wedge
with the mounting wedge screws.
Note: The adhesive is for one-time use. Avoid
re-using the adhesive to ensure its adhesion.
Note: This is applicable with tile, glass, marble,
metal, stainless steel, and smooth wall surfaces.
2. Wipe the surface with a dry cloth, stick the
bracket (or bracket with wedge) with adhesive
to a clean wall, and press for 15 seconds to
ensure it’s rmly attached.
3. Attach the doorbell to the bracket, sliding down to
the bottom until it clicks into place.
Then tighten
the screw at the bottom to secure the doorbell.
OR
3. Attach the doorbell to the bracket, sliding down
to the bottom until it clicks into place.
Then
tighten the screw at the bottom to secure
the doorbell.
1. Stick the mounting template to the desired
mounting place. Drill two holes according to
the template.
2
.
Insert two anchors into the holes. Use the
mounting screws to ax the bracket (or
wedge with bracket if you use the wedge to
adjust the angle) over the anchors.
Note: When mounting to uneven walls, stick the foam
pad on the back of the bracket (or wedge if used).
3M
3M
3M
3M
Without
Mounting Wedge
With
Mounting Wedge
Φ=6 mm (15/64 in.)
(Optional)
Foam Pad
(Optional) Mounting Wedge
You can ip it upside down to
adjust the angle.
3 /
Set Up the
Doorbell
1. Get the Tapo app from the App Store or
Google Play, and log in.
OR
2. Press and hold the RESET button on the back
for 3 seconds to activate the doorbell. Tap
the button in the app and select your
model. Follow the app instructions to set up
your doorbell.
Press the top of the mounting bracket and push
down to separate it from the doorbell.
5V USB Charger
OR
Without
Mounting Wedge
With
Mounting Wedge
OR
Mounting Wedge
You can ip it upside down to
adjust the angle.
• Do not use damaged charger or USB cable to charge
the device.
• Do not use any other chargers than those
recommended.
• Do not use the device where wireless devices are not
allowed.
• Adapter shall be easily accessible.
• Use only power supplies which are provided by
manufacturer and in the original packing of this
product. If you have any questions, please don't
hesitate to contact us.
• Keep the device away from re or hot environments.
DO NOT immerse in water or any other liquid.
• Do not disassemble, repair or modify the product.
• Do not place near automatically controlled devices
such as re alarms. Radio waves emitted from this
product may cause such devices to malfunction
resulting in an accident.
• Observe restrictions on using wireless products in fuel
depots, chemical plants or when blasting operations
are in progress.
• Do not use liquid to clean the product. Only use a dry
cloth.
• Never put metal objects inside the product. If a metal
object enters the product turn o the circuit breaker
and contact an authorised electrician.
• This product is not intended to be used when providing
medical care. Consult the manufacturer of any
personal medical devices, such as pacemakers or
hearing aids to determine if they are adequality
shielded from external RF (radio frequency) energy.
• Do not use this product in health care facilities.
Hospitals or health care facilities may be using
equipment that could be sensitive to external RF
energy.
Safety Information
TP-Link hereby declares that the device is in compliance
with the essential requirements and other relevant
provisions of directives 2014/53/EU, 2009/125/EC,
2011/65/EU and (EU)2015/863.
The original EU declaration of conformity may be found at
https://www.tapo.com/support/ce/
TP-Link hereby declares that the device is in compliance
with the essential requirements and other relevant
provisions of the Radio Equipment Regulations 2017.
The original UK declaration of conformity may be found at
https://www.tapo.com/support/ukca/
• Do not place heavy objects on top of the product.
• When you leave the product unused for a long time
unplug the product from the power outlet.
• This product may interfere with other electronic products
such as TV, radios, personal computers, phones or other
wireless devices.
• Always follow the local waste and recycle laws when you
get rid of the used battery.
• Do not use the product if the casing has been broken.
Danger of electric shock.
• Never touch the product with wet hands.
• This equipment can be powered only by equipments that
comply with Power Source Class 2 ( PS2) or Limited
Power Source (LPS) dened in the standard of IEC
62368-1.
• The mounting height should not be higher than 2 meters.
• Operating Temperature: -20 °C ~ 45 °C (-4 °F ~ 113 °F)
CAUTION!
Avoid replacement of a battery with an incorrect type
that can defeat a safeguard.
Avoid disposal of a battery into re or a hot oven, or
mechanically crushing or cutting of a battery, that can
result in an explosion.
Do not leave a battery in an extremely high temperature
surrounding environment that can result in an explosion
or the leakage of ammable liquid or gas; Do not leave
a battery subjected to extremely low air pressure that
may result in an explosion or the leakage of ammable
liquid or gas.
Please read and follow the above safety information when
operating the device. We cannot guarantee that no
accidents or damage will occur due to improper use of the
device. Please use this product with care and operate at
your own risk.
?
Need some help?
Visit https://www.tapo.com/support/
for technical support, the user guide, FAQs,
warranty & more
©2025 TP-Link
Doorbell Appearance
4
IR LED
5
Ring Button
6
Status LED
2
Lens
9
USB Type-C Port
10
microSD Card Slot
1
Microphone
Motion Sensor (PIR)
3
Status LED Indication
Doorbell updating
Doorbell resetting
Ready for setup
Connecting to Wi-Fi
Connected to the cloud
Blinking red and green
Solid red
Blinking amber quickly
for 3 seconds
Blinking white quickly
Blinking red quickly
Blinking red slowly
Solid white
Solid amber Connected to Wi-Fi
Starting up
Charging the doorbell
How to Detach the Doorbell
from the Wall
Loosen the screw at the bottom of the bracket.
Hold the doorbell and pull it up to detach it from
the bracket.
6
7
1
2
3
4
5
8
9
10
7
Speaker
8
RESET Button
Press and hold for about 5s: Reset the doorbell
Insert a microSD card. Initialize it on the Tapo app for
local recording.
*microSD card not included
microSD
