Bluetooth Voice-Controlled Headset with
Mesh Intercom System
F1s
QUICK START GUIDE
Customer Service Email：support@asmaxworld.com
1
For detailed electronic instructions,
please scan the QR code.
Profile
Thank you for choosing the ASMAX voice-controlled
Bluetooth helmet intercom. Please read this guide carefully
before using the device.
F1s Youtube
Video Instruction
Firmware Update
Instruction Video
2
ASMAX WORLD APP
You can configure more features on your ASMAX device
through the ASMAX WORLD app. Scan the QR code or
download it from the Google Play Store or Apple App Store.
ASMAX WORLD
App
Web:www.asmaxworld.com
asmaxworld
3
Package Contents
F1s Main Unit Mounting Base Speaker Unit 3M Glue Plate
Metal Clamp Hybrid
Microphone
Wired
Microphone
Type-C Cable
Clean Pack Speaker Pads Velcro for
Speaker
Velcro for
Wired Mic
Velcro for
Hybrid Mic
Microphone
Sponge
Spare 3M User Manual
4
Main Unit
Note:
The headset can fully charge within 50mins (The Charging time maybe
changed due to charging environment)
Do not use a charger with an output more than 15V to charge the
device.
Volume +
Volume -
Intercom Button
Function Button
LED Indicator
Type-C Charging Port
5
Quick Operation
Function Wakeword
MAX
Answer
Offline Commands
(If the main unit or phone is
offline, MAX can only use
offline commands.)
Power
On/Off
/ /
For
Music
Control
Hi Max
OK/Here/
Coming
Music On
Hi Max
Pause Music
For
Playback
Control
Hi Max
Previous Track
Hi Max
Next Track
For
Volume
Control
Hi Max
Volume Up
Hi Max
Volume Down
For
Phone
Control
Hi Max
Answer The Phone
Hi Max
Hang Up
For
Phone
Pairing
Hi Max
Phone Pairing
For
Intercom
Hi Max
Group Mesh
Hi Max
Free Mode
Hi Max
Group Mode
Hi Max
End Intercom
ASMAX has two operation modes: Smart Voice and Button Control.
You can choose the one that suits your habits.
When connected to the ASMAX World App and the internet, the
main unit supports smart voice operations such as navigation,
sending messages, making and receiving calls, and playing music.
When not connected to the internet, the main unit can still control
the device using built-in local voice commands.
2s
6
Function Wakeword
MAX
Answer
Offline Commands
(If the main unit or phone is
offline, MAX can only use
offline commands.)
For Radio
Hi Max
OK/Here/
Coming
Radio On
Hi Max
Turn Off The Radio
Hi Max
Previous Station
Hi Max
Next Station
For ASMAX
Mode
Hi Max
Group MAX
Hi Max
MAX Mode
For
Microphone
Control
Hi Max
Unmute Microphone
Hi Max
Mute Microphone
7
Online Commands
（ If MAX is paired with a phone and the phone is online, just say
“Hi MAX” to control any commands supported by Siri or Google
Assistant.）
What's the weather like today
Set an alarm at nine o'clock
Turn on music player
Turn on Asmax World APP
Navigate to my home
Call Berry
Other commands of Siri/ Google Assistant that support
8
RF EXPOSURE STATEMENT
This equipment complies with the FCC and ISED radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Cet équipement est conforme aux limites d'exposition aux rayonnements de la FCC et de
l'ISED établies pour un environnement non contrôlé. Cet émetteur ne doit pas être co-
localisé ou fonctionner en conjonction avec une autre antenne ou un autre émetteur.
FCC WARNING
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
IC WARNING
This device contains licence-exempt transmitter(s) that comply with Innovation, Science
and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme
aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes:
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
