Mix-N-Serve
™
MODEL:
MNS
WARMER/MIXER
05578
for purchasing this Butter Warmer. This easy to clean
dispenser features a magnetic impeller which continually
stirs to keep melted butter uniform.
WARM, MIX & SERVE BUTTER—BETTER!
Thank You
Page 2
WARMER LID
ITEM #00350470
LID 05608
KNOB
05609
STIR BAR ASSEMBLY
05607
MAGNET
05573
VESSEL ASSEMBLY
05557
BUTTER SPIGOT
ITEM #000335124
FAUCET
05574
PLASTIC COVER
ITEM #00350469
COVER ASSEMBLY KIT
05615
(FOR SERIES PRIOR TO 11F, USE 05595)
BASE
Replacement
FOOT with Screw
81058
C-RING
05576
PARTS FOR 05578
WING NUT
05575
Page 3
Replacement
FOOT with Screw
81058
FAUCET ASSEMBLY
Rotate wing nut counterclockwise to secure faucet
tightly onto shank.
INSTALL FAUCET
5
INSERT CUP SEAT
1
into faucet.
INSTALL TOP
2
onto faucet. Rotate clockwise to secure.
INSTALL WING NUT
3
onto vessel shank.
INSTALL C-RING
4
into shank groove.
TIP: Lubricate threads with a small amount
of clean water.
IMPORTANT: Do not over-tighten.
This may strip threads and cause faucet
to loosen and leak.
WASH ALL PARTS PROPERLY
BEFORE EVERY USE.
See page 6.
Page 4
UNIT SETUP
WASH ALL PARTS PROPERLY
BEFORE EVERY USE.
See page 6.
PRESS SWITCH
to the “ON” position.
5
PLUG CORD into power source.
4
ENSURE FAUCET IS SECURED
to shank of vessel.
See page 3 for FAUCET ASSEMBLY
1
INSERT STIR BAR ASSEMBLY
INTO VESSEL & CLOSE COVER
3
TIP: If solid butter is added,
typical recovery time is 1 hour
per pound of butter.
PLACE VESSEL
WITH PREHEATED BUTTER
INTO BASE
2
Page 5
UNIT TAKE-DOWN
PRESS SWITCH to the “OFF” position.
1
DISASSEMBLE FAUCET
Take apart all three pieces.
(Remove wingnut & C ring only if
necessary for cleaning.)
6
EMPTY ANY REMAINING
BUTTER
from vessel. Properly dispose butter
or pour into a storage container.
4
UNPLUG CORD
CAUTION- HOT
Allow unit to cool before continuing or use
proper care with hot surfaces.
2
IMPORTANT:
PREVENT DRIPPING
Disassemble and clean faucet daily.
REMOVE FAUCET
Rotate wing nut clockwise to remove faucet
5
OPEN COVER,
REMOVE VESSEL
& LID
3
Page 6
CLEANING
WARNING-
ELECTRICAL SHOCK COULD OCCUR
• Electrical components of unit could be
damaged from water exposure or any liquid.
• Never immerse unit into water or any liquid.
• Never use any water jet or pressure sprayer
on unit.
• Ensure unit is “OFF” and unplugged.
CAUTION- HOT
Allow unit to cool before cleaning.
CLEAN EXTERNAL SURFACES
• Wipe daily with a clean damp cloth.
• Dry with a clean soft cloth.
• Glass and surface cleaners approved for use
in food contact areas may be used.
SAFETY
WARNING-
ELECTRICAL SHOCK COULD OCCUR
This unit must be earthed or grounded.
This requires all three prongs (terminals) on cord
plug to be plugged into power source.
According to food and safety regulations, most
foods must be stored and/or served at certain
temperatures or they could become hazardous.
Check with local food and safety regulators for
specic guidelines.
Be aware of the product you are serving and the
temperature the product is required to maintain.
Server Products, Inc. can not be responsible for the
serving of potentially hazardous product.
RINSE fully with clear water.
2
DRY
Air dry faucet parts fully.
Dry stainless steel with clean, soft cloth.
4
CLEAN
1
After disassembling, thoroughly clean all
washable parts with soap and hot water.
SANITIZE
3
all parts according to local sanitization
requirements. All parts in contact with
food must be sanitized.
Page 7
• A mildly abrasive nylon or brass brush may
be used to remove any stubborn food or
mineral deposits on interior surfaces of unit.
• Fully rinsing and drying all parts can help
prevent corrosion. Elements and minerals in
tap water can accumulate on stainless steel
parts and create corrosion.
• Do not use abrasive, caustic or ammonia
based cleansers.
• Do not use products containing acids,
alkalines, chlorine, or salt. These agents can
corrode stainless steel.
• Do not use metal scrapers or cleaning pads
that could scratch surfaces.
This unit is constructed of
stainless steel— one of the best
materials for food serving and
storage.
If you notice corrosion beginning on any stainless
steel surface, you may need to change the
cleansing agent, sanitizing agent, or the cleaning
procedures you are using.
CARE OF STAINLESS STEEL
WIRING
UNIT 05578 | SERIES 11F | 120V | USA
1 2 3
7
8
10
Cord Assembly
Bushing, Strain Relief
Thermal Cut-Out
Wire Assembly 4"
3
4
1
2
Snap-In Rocker Switch
Motor Gear
Wire Assembly 8"
7
5
6
Thermostat
Wire Assembly 8"
Heating Element
10
8
9
4 5
4 6
9
BLACK
WHITE
GREEN
Page 8
Manual #01719_RevG_Mix-n-Serv 012925
GENERAL SERVICE,
REPAIR OR RETURNS
FAUCET LEAKS?
• Fully disassemble and clean faucet daily.
• Inspect the faucet threads. If they have become
stripped, replace faucet components.
See page 2 for part numbers.
Before sending any item to Server Products for service,
repair, or return, contact Server Products customer
service to request a Return Authorization Number.
Merchandise must be sent to Server Products with this
number. Service is extremely prompt. Typically, units
are repaired and ship out within 48 hours of receipt.
Merchandise being returned for credit must be in new
and unused condition and not more than 90 days
old and will be subject to a 20% restocking charge.
Electrical parts (thermostats, heating elements, etc.)
are not returnable.
Servicing Cord: Specic tools are required for safe and
proper power supply cord removal and installation. If
cord must be replaced, only a representative of the
OEM (original equipment manufacturer) or a qualied
technician may replace cord. Cord must meet code
designation H05 RN-F requirements.
TROUBLESHOOTING
UNIT DOES NOT HEAT?
• Ensure cord is securely plugged in.
• Ensure unit is on.
• Ensure thermostat lock is set correctly.
• Ensure power is available from source.
• Do not allow any of the electrical components
to get wet. Moisture may cause the unit to
trip breaker or GCFI. If moisture is suspected,
discontinue use. Allow unit to fully air dry.
SERVER PRODUCTS
LIMITED WARRANTY
This Server product is backed by a two-year
limited warranty against defects in materials and
workmanship. See Server-Products.com for details.
NEED HELP?
Please be prepared with your Model, P/N and
Series located on the lid or base of the unit.
Example:
Chat with us!
262.628.5600 | 800.558.8722
Server Products Inc.
3601 Pleasant Hill Road
Richfield, WI 53076 USA
MODEL
XXXX
P/N
#####
SERIES
##X ##X
