Scope of delivery
First, check whether the device is complete and is not damaged.
If in doubt, do not operate the device and contact your service center.
The scope of delivery includes:
• 1 medisana Digital Personal Scale PS 200
• 1 Instruction manual
Requirements for correct measurement results
• Always weigh yourself in the same conditions.
• Measure at the same time of day.
• Stand upright and calm.
• It is best to take the measurement in the morning, after showering or
bathing, with dry foot.
Insert/change batteries
Before putting your digital scale into operation, insert one 3V lithium
cell CR2032 battery int the device. Open the battery compartment
2
on the underside of the device and insert the batteries. Pay attention to
the polarity (illustration in the battery compartment). Replace the battery
compartment cover and push it in so that it clicks into place. Change the
batteries if the battery change symbol “Lo” appears on the display
1
or if
nothing is shown on the display after the unit has been operated.
Initialise scale
Make sure that the scale is on firm and level ground. If you want to
weigh yourself, but have moved the scale immediately before, you must
first initialise the scale. Briefly press the middle of the scale surface with
your foot. The display will show “0.0”. When the scale has turned off,
it is ready for the “step-on” function. If the scale hat not been moved
beforehand, this process is omitted.
Simple weighing
1. Stand on the scale and stand still. The device switches on
automatically and the display
1
briefly shows 0.0kg.
2. Your weight will be measured, flashes twice and is then finally
displayed.
3. Step down off the scale. The scale switches off automatically after
approx. 10 seconds.
Change the unit of weight
Press your foot on the middle of the surface of the scales shortly to
activate the device. Then press button
3
until the unit you wish is shown.
Error messages
Err = The scale is overloaded. Lo = The battery is weak and needs to
be replaced.
If your scale does not work as desired, check the following before
contacting the service center
• Check that the battery has been correctly inserted
• Check that you have selected the correct weight unit.
• Check whether The scale is standing freely on a firm and level surface.
It must not touch a wall or another object.
• Repeat the weighing process.
• Any treatment or diet for people who are underweight or overweight
requires the qualified advice of a professional (doctor, dietician).
• Risk of tipping over! Do not place the scale on an uneven surface.
Never step onto a corner of the scales. When weighing yourself, do
not stand on one side or the edge of the scales.
• Risk of slipping! Do not stand on the scale with wet feet. Do not stand
on the scale wearing socks.
• Use the device only according to its intended purpose as specified in
the instruction manual. The warranty will be invalidated if the device
is used for purposes other than those for which it is intended.
• The scale has been manufactured for domestic use. It is not suitable
for commercial use in hospitals or other medical institutions.
• Do not use the device if it is not working correctly, if it has been
dropped or has fallen into water or has been damaged.
• The scales have a measuring range up to 180 kg, 396 lb / 28 st 4 lb.
Do not overload the scales.
• Place the scales on a firm, level base. Soft, uneven surfaces are
unsuitable for the measuring process and lead to incorrect results.
• Do not use the scale in a location where extremely high temperatures
or humidity may occur.
• Keep the scale away from water.
• Handle the scale with care. The scale must not be subjected to
impacts or vibration. Do not drop the scale.
• Stand carefully on the scale. Do not jump or hop onto the standing
area. This could lead to defects of the weighing mechanism.
• Do not attempt to dismantle the scale, otherwise the warranty will
be invalidated. This unit contains no user-maintainable or user-
replaceable parts.
• Do not attempt to repair the device yourself in the event of a
malfunction since this will invalidate the warranty. Repairs should only
be carried out by authorised service centres.
Battery safety instructions
• Do not disassemble batteries!
• Remove discharged batteries from the device immediately! Increased
risk of leakage!
• Avoid contact with skin, eyes and mucous membranes! If battery
acid comes in contact with any of this parts, rinse the affected area
with copious amounts of fresh water and seek medical attention
immediately!
• If a battery has been swallowed seek medical attention immediately!
• Insert the batteries correctly, observing the polarity!
• Always keep the battery compartment well closed!
• Remove the batteries from the device if it is not going to be used for
an extended period!
• Keep the batteries out of the reach of children!
• Do not re-charge the batteries! There is a risk of explosion!
• Do not short-circuit the device! There is a risk of explosion!
• Do not throw into a fire! There is a risk of explosion!
• Store unused batteries in the packaging and not near metal objects to
avoid a short circuit!
Read the instruction manual carefully before using this
device, especially the safety instructions, and keep the
instruction manual for future use. Should you give this
device to another person, it is vital that you also pass
on these instructions for use.
GB Safety instructions
WARNING
Make sure that children do not play with the packaging
foils. Risk of suffocation!
In the course of constant product improvements,
we reserve the right to make technical and design changes.
Warranty and repair conditions
In case of warranty please contact your specialist shop or the service
centre directly. If you need to return the device, please indicate the
defect and enclose a copy the purchase receipt.
The following warranty conditions apply:
1. All medisana products are guaranteed for one year from the
date of purchase. The date of purchase is to be proven in case of
warranty by the purchase receipt or invoice.
2. Defects due to material or manufacturing defects shall be
eliminated free of charge within the warranty period.
3. A warranty service does not extend the warranty period for either
the equipment or any replacement parts.
4. The following are excluded from the guarantee:
a. any damage caused by improper handling, e.g. by non-
observance of the instruction manual.
b. Damage due to repair or intervention by the purchaser or
unauthorised third parties.
c. Transport damage that has occurred on the way from the
manufacturer to the consumer or when sending it to the service
centre.
5. Liability for direct or indirect consequential damages caused by the
device is also excluded if the damage to the device is recognised
as a warranty case.
DE/GB
1
Display
2
Battery Compartment (on underside)
3
Unit key (on underside) for kilograms
(kg) pounds (lb) stones (st)
Standing area
Legend:
This instruction manual belongs to this
device. The instruction manual includes
information on the initial start-up and
handling. Read this instruction manual
completely. Failure to follow these
instructions may result in serious injury
or damage to the equipment.
WARNING!
These warnings must be followed to pre-
vent possible injury to the user.
LOT number
Manufacturer
Packaging is recyclable or can be recycled into raw materials.
Please dispose of unwanted packaging material properly. If you
notice any transport damage while unpacking, please contact
your dealer immediately.
Cleaning and care
Never use aggressive cleaning agents or stiff brushes. Clean
the scale only with a soft, slightly damp cloth. Never use harsh
detergents or alco-hol. No water should enter the device. Only use
the device again when it is completely dry.
Instructions for disposal
This device must not be disposed of with domestic waste.
Metals are reusable or can be recycled into raw materials.
Dispose of a device that is no longer needed at a collection
point in your town/city so that it can be disposed of in an
environmentally friendly way. Please contact your local
authority or retailer with regard to disposal procedures. Remove the
battery before you dispose of the device. Do not dispose of spent
batteries in domestic waste, rather in special waste or at a battery
collection point at your retailer!
Technical specifications
Name and model no. : medisana Digital Personal Scale PS 200
Voltage supply : 3V lithium cell CR2032
Measuring range : up to 180 kg / 396 lb / 28 st 4 lb
Graduation : 0.1 kg / 0.2 lb / ¼ lb
Dimensions : approx. 280 x 280 x 20 mm
Weight : approx. 1.3 kg
Article no. : 48845
EAN no. : 40155 88 48845 0
GB Unit and controls
48845_PS 200_manual_GB_202206_L1
1
2
3
Digital Personal Scale
PS 200
Unit E&F, 31/F, YHC Tower, 1 Sheung Yuet Road,
Kowloon Bay, Kowloon, Hong Kong
