Wi-Fi User Manual
Models:
ITAC08-LSA23
ITAC10-LSA23, ITAC10-LSB24
ITAC12-LSA23, ITAC12-LSB24
ITAC14-LRB24
www.impecca.com
This description is applied to Air Conditioners wi
th Wi-Fi function. Please read the manual carefully
before using the product and keep it for future reference.
v. 0.7
14
Step 3
Step 1
Operation
Steps
Step 4
Step 2
Step 5
Registration
Account
Download and
Install APP
Operation
Items
Login
Activate APP
Select Add Device /
Window AC to control
YES
YES
New Account
YES
YES
YES
NO
YES
Re-install APP
(registered before)
YES
YES
Registered Device will remain.
Operation guideline. Please take below simple guideline instruction as reference.
Note If you registered the account and added device before, when you re-install the APP again and login,
the added device will remain .
FCC Caution (FCC ID: 2AJCLTWAC-TYWFS/2ANDL-WBR3)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
The distance between user and device should be no less than 20cm.
Let's get start!
Step 6
Press ECO button on
R
emote Control 6 times,
the unit will display app,
and connect
YES
Registered Device will remain.
CONTENTS
Wi-Fi Module specification and basic information ..............................................1
Download and Install the App.............................................................................2
Activate APP.........................................................................................................3
Registration.........................................................................................................4
Login....................................................................................................................6
Add device........................................................................................................8
Air conditioner control.......................................................................................10
Account management........................................................................................28
Trouble Shooting...............................................................................30
1. Minimum specifications on a Smart phone:
Android 5.0 version or higher
IOS 9.0 version or higher
Wi-Fi Module specification and basic information
1
2. Basic parameters for Wi-Fi module
2.400 - 2.500GHz
Protocol stack support
IEEE 802.11 b/g/n(channels 1-14)
Network frequency
Parameters
IPv4/IPv6/TCP/UDP/HTTPS/TLS/MulticastDNS
Security support
WEP/WPA/WPA2/AES128
Details
Standards of WLAN
Network type support
STA/AP/STA+AP
Download and Install the App
2
Note:
Please enable the permissions of Storage/Location/Camera for this APP when installing.
Otherwise it will have some problems when operating.
For Android smart phone
Method1: Please scan the QR code with a browser scanner, download and install the APP.
Method2: Open the Google "Play Store" on your smart phone and search
"SmartLife-SmartHome" , ownload and install the APP.
For IOS smart phone
Method1: Please scan the QR code and follow the tips to get into "AppStore", download
and install the APP.
Method2: Open the Apple "AppStore" on your smart phone and search
"SmartLife-SmartHome" , download and install the APP.
SmartLife-SmartHome
1. Launch the APP "SmartLife-SmartHome" on your smart phone.
3
Activate APP
2. Method1:Tap button "Scan" and scan the right Activate QR code
Method2: Tap "or Enter Activation Code" in bottom of the screen,
then enter the activate code and tap "CONFIRM".
SmartLife-SmartHome
Activate QR code and activation code
Note Without the QR code or activation code,
you can't active the APP and using it,
please keep them safe.
Scan
Scan the activation QR code
from instructions or device
or Enter Activation Code
or Enter Activation Code
CANCEL
CONFIRM
******
The first time the app is used, it will need activating.
Registration
1.If you don't have any account please tap button "Register".
2.Read the Privacy Policy and tap "Agree".
4
3.Tap">" and choose the country.
4.Enter your e-mail address.
5.Tap the button "Obtain verification code".
Log in with existing account
Privacy Policy
......................................................
......................................................
......................................................
......................................................
......................................................
......................................................
......................................................
......................................................
......................................................
..................................................
Privacy Policy
Disagree
Agree
#
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
Country Choosed
A
Afghanistan
Albania
Algeria
Angola
Argentina
Armenia
Australia
Search
enter your e-mail address here
Search the country or slide the
screen up/down to find
and choose the Country.
<
Register
Resister
>
*********** X
<
I Agree User agreement and Privacy Policy
Obtain verification code
Registration
6.Enter the verification code you received from e-mail.
7.Set the Password with 6-20 characters including characters and numbers.
8.Tap "Done".
5
Set Password
6-20 characters for password, including character, numbers
******
<
Login
Login
1.Tap "Log in with existing account".
2.Enter your registered account and password.
3.Tap "Log in" button.
Log in with existing account
Register
Done
Enter verification
code
* * * * * *
<
Verification code is sent to your email:
*****@****,Resend(55s)
Login
******* >
***********
<
Login means that you agree with User Agreement and
Privacy Policy
Log in
******
Forgot password
enter the password
enter your account(e-mail) here
Living Room
Master Bedroom
Second Bedroom
Dining Room
Kitchen Study Room Porch
Balcony Kids Room Closet
Login
The first time the APP is used, Create family is needed:
4.Tap "Create family".
5.Make name for the family.
6.Set the location.
7.Choose default rooms or add new rooms.
8.Tap "Done" and "Completed".
Turn on your smart life
Create family
Log out
#
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
Family Name
<
Add family
Done
Family Location Set location >
Smart devices in rooms:
Living Room
Master Bedroom
Second Bedroom
Dining Room
Kitchen
Study Room
Add Room
You can change the room settings anytime
My home
choose the recommended room
or make a new room, then tap
Done.
Room Name
<
Add Room
Done
Recommended
*******
6
#
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
Allow Smart Life to access this device's
location?
ALLOW ONLY WHILE IN USE
ALLOW ALL THE TIME
DENY
CANCEL
CONFIRM
Note:
The app can open the map on your
phone and you can set the location
where you are.
Family created successfully
View family Completed
Login
7
Forgot the password
If you forgot the password or you want to reset the password, operate as below:
1.Tap "Forgot password".
2.Enter your account(e-mail address) and tap button "Obtain verification code".
3.Enter the verification code received by your e-mail.
4.Set the new password and tap button "Done".
Login
******* >
Email address
<
Log in
Password
Forgot password
Forgot password
****** >
*********** X
<
Obtain verification code
Enter verification
code
Verification code is sent to your email:
***********,Resend(55s)
* * * * * *
<
Set Password
6-20 characters for password, including character, numbers
******
<
Done
Login means that you agree with User Agreement and
Privacy Policy
8
1.Power on the indoor unit, no need to launch the air conditioner.
2.Click "+" in the upper right corner of the "Home" screen or tap "Add device" on the room which has
no device.
3.Tap the "Window Type Air conditioner" logo.
4.Input the password of the Wi-Fi which the same as your smart phone connected, then tap "Next".
5.Choose "CF Mode" on the right corner, then follow the instruction on page before or screen to reset
the Wi-Fi module, then tap "Next".
6.You can see the percent rate of connecting process, at the same time
PP","SA","AP" shining in turn on the indoor display.
"PP" means "Searching the router"
"SA" means "connected to the router"
"AP" means "connected to the server"
Add device
There are 2 modes CF(Quick connection) and AP(Access Point) for adding device.
CF mode
CF Mode
Reset the device first.
Next
Cancel
Confirm the device is reset.
Resetting Devices
<
Add Device
<
Device added
successfully
Sample1
Done
enter
password
<
Add Manually
Auto Scan
Dehumidifier
Air Conditioner
(BT+Wi-Fi)
Fresh Air
Purifier
Split Air
Conditioner
Window Type
Air Conditioner
Portable Air
Conditioner
Security
Camera
Swimming
Pool H/P
Adding device...
Cancel
Ensure that the device is powered on.
2%
Scan
devices.
Register on
Cloud.
Initialize the
devices.
<
Welcome Home
Set your home location for more
information
All Devices Living Room
Master
...
Add Device
Home Me
Work office
<
No devices
Select 2.4 Ghz
Wi-Fi Network and
enter password
Next
Cancel
2.4GHz 5GHz
*******
Password
9
Add device
Select 2.4 Ghz
Wi-Fi Network and
enter password
Next
Cancel
2.4GHz 5GHz
*******
Password
AP Mode
Reset the device first.
Next
Cancel
Confirm the device is reset.
Resetting Devices
<
AP Mode
Reset the device first.
Method1:When there is a DISPLAY key on the
remote control, press the DISPLAY key 6 times
in the time of 8 seconds; when there is no
DISPLAY key on the remote control, press the
ECO key 6 times in the time of 8 seconds until
the device beeps twice and the LCD screen
show AP .
Next
Cancel
Confirm the device is reset.
Resetting Devices
<
Method2:Press the General key 9 times in the
time of 8 seconds until the device beeps twice
and the LCD screen show AP .
CF Mode
AP Mode
Default
1.Power on the indoor unit, no need to launch the air conditioner.
2.Click "+" in the upper right corner of the "Home" screen
or tap "Add device" on the room which has no device.
3.Tap the "Window Type Air Conditioner" logo.
4.Input the password of the Wi-Fi which the same as your smart
phone connected, then tap "Next".
5.Choose "AP Mode" on the right corner, then follow the instruction on
page before or screen to reset the Wi-Fi module, then tap "Next".
6.Read the instruction carefully and tap "Connect now".
7.In the network setting screen, select "SmartLife-****", and tap" ".
8.You can see the percent rate of connecting process, at the same time
"PP","SA","AP" shining in turn on the indoor display.
"PP" means "Searching the router"
"SA" means "connected to the router"
"AP" means "connected to the server"
There are 2 methods to add the device.
2-AP mode
<
Add Manually
Auto Scan
Dehumidifier
Air Conditioner
(BT+Wi-Fi)
Fresh Air
Purifier
Split Air
Conditioner
Window Type
Air Conditioner
Portable Air
Conditioner
Security
Camera
Swimming
Pool H/P
<
WLAN
AVAILABLE NETWORKS
SmartLife-****
office wifi
WIFI1
<
Add Device
<
Device added
successfully
Sample1
Done
<
Welcome Home
Set your home location for more
information
All Devices Living Room
Master
...
Add Device
Home Me
Work office
<
No devices
enter
password
<
Connect phone to device s
wifi hotspot
Connect now
1.Please connect your phone to the hotspot
shown below
Wi-Fi
Home
5G
Guest
4G
12:30
<
SmartLife-XXXX
2.Return to this app and continue adding
devices
Confirm hot spot connecton,next
Adding device...
Cancel
Ensure that the device is powered on.
2%
Scan
devices.
Register on
Cloud.
Initialize the
devices.
Air conditioner control
The device control screen will pop up automatically after adding the device.
The device control screen will pop up manually by tapping the device name on the home screen.
<<
my home
+
>
Set your home location, get more
information
Welcome home
V
All Devices
Living Room
room
Master Bed
...
Home
Me
Sample1
Sample2
Turned off
Already On
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
77
Cool
0
Note:
There are two different control forms base on different software or Wi-Fi module firmware.
Please read the manual carefully base on the real control interface.
72
F
Set Temperature
Timer
Function
Fan
Mode
Sample2
<
10
Control form1
Control form2
11
Air conditioner control
72
F
Set Temperature
Timer
Function
Fan
Mode
Sample2
<
Turn ON/OFF the
air conditioner
Device details
and management
Increase the
setting temperature
Decrease the
setting temperature
The main control interface
Back to the
Home screen
Indicator of
setting temperature
Selected Mode/Fan speed/
Functions indicator
Control form1
Air conditioner control
Control form1-Mode setting
1.Tap Mode to pop up the Mode screen.
2.Select one of the mode Feel/Cool/Heat/Dry/Fan.
3.Tap anywhere around the setting temperature to cancel the Mode setting.
72
F
Set Temperature
Timer
Function
Fan
Sample2
<
Mode
FanDry
Feel
Cool Heat
Mode
Control form1-Select fan speed
72
F
Set Temperature
Timer
Function
Sample2
<
Mode
Fan
Fan
Med Low Auto
High
1.Tap Fan to pop up the Fan screen.
2.Select one of the fan speed High/med/Low/Auto.
3.Tap anywhere around the setting temperature to cancel the selection.
12
Air conditioner control
Control form1-Function setting
1.Tap Function to pop up the Function screen.
2.Select one of the functions Sleep/Turbo/ECO.
3.Select UP-DOWN/LEFT-RIGHT for auto swing with direction of UP-DOWN/LEFT-RIGHT.
4.Tap anywhere around the setting temperature to cancel the Function setting.
72
F
Set Temperature
Timer
Fan
Sample2
<
Mode
Control form1-Timer adding
1.Tap Timer to pop up the Add Timer screen.
2.Tap Add Timer.
13
Function
UP-DOWN
LEFT-RIGHT
Turbo
Sleep
ECO
Function
72
F
Set Temperature
Timer
Function
Fan
Mode
Sample2
<
WLAN
<
Add Timer
Add timer
Air conditioner control
Control form1-Timer adding
3.Select the time, select the repeat days and Timer on/off.
4.Select the Mode/Fan speed/Function and select the setting temperature for Timer on.
5.Tap Save to add the timer.
14
Hour setting
Minute setting
Mode setting
Fan Speed
setting
Weekly setting
Timer cancel
Timer submit
Temperature
setting
Timer ON/OFF
setting
Cancel Add Timer Save
15 10
14 09
13 08
12 07
16 11
17 12
18 13
Timer Off
Timer On
Mode
Fan
Set Temperature
Function
Cool
Auto
72 F
<
<
<
<
Cancel Add Timer Save
15 28
14 27
13 26
12 25
16 29
17 30
18 31
Select days to use Smart Mode
Timer Off
Mon
Tues
Wed Thur Fri Sat Sun
Timer On
Control form1-Timer Management
WLAN
<
Add Timer
Add timer
Timer accuracy is -/+ 30 seconds
12:20
Once
Timer:Off
12:20
Mon, Tue, Wed, Thurs
Timer: On 61 Cool Turbo UP-DOWN
1.Tap the bar of timer to edit the Timer like the Timer adding process.
2.Click the switch to enable or disable the Timer.
3.Holdind the bar of Timer about 3seconds and pop up the Remove Timer screen,
tap CONFIRM and remove the Timer.
Remove Timer
Remove the timer?
CANCEL CONFIRM
Timer on
Timer off
Air conditioner control
15
Back to the
Home screen
Name of the device
Current mode
Increase the
setting temperature
Decrease the
setting temperature
Power on/off
Selected Functions
indicator
Note: it may appear slightly different ,
depending on the air conditioner model.
Example as below:
Tips
Different background for
different mode:
Cool/Heat/Dry/Fan/Auto
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
77
Cool
0
Fan Speed
Swing Flow
Eco Sleep
Mode
Timer
Turbo
Function Buttons
Control form2
The main control interface
Air conditioner control
1.Tap the Mode button.
2. There are 5 modes on the Mode screen, tap one button to
set the Air conditioner working mode.
3.Tap the X button to back the main control screen.
4.The mode and background will change on the screen.
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
77
Cool
0
Back
Sample1
77
Cool
0
Cool
Dry
Fan
Heat
Auto
Mode
X
Note: please read the details of each mode
in the user manual to control more comfortable.
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
77
Cool
0
1.Tap the Fan speed button.
2.Choose your desired fan speed and tap it.
3.Tap the X button to back the main control screen.
4.The selected fan speed indicator will appear on the screen.
Back
Sample1
77
Cool
0
Turbo
Mid-High
Mid
high
Fan Speed
X
Mid-Low
Mute
Auto
Low
Mode Fan Speed
Cool
Fan
Dry
Heat
Auto
All speeds
All speeds
All speeds
All speeds
16
Note: Fan Speed screen may appear slightly different ,
depending on the air conditioner model.
Example as below:
Mid
high
Fan Speed
X
Auto
Low
Note:
Fan Speed can't be adjusted on Dry mode .
Control form2-Mode setting
Control form2-Fan speed selection
Air conditioner control
1.Tap the Precision Air Flow button or Swing Flow button.
2.Choose your desired air flow and tap it.
3.Tap the X button to back to the main control screen.
4.The selected air flow indicator will appear on the screen.
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
77
Cool
0
17
ON/OFF
Sample1
77
Cool
0
Fan Speed
Swing Flow
Eco Sleep
Mode
Timer
Turbo
Left-Right Flow
Note: The Main control screen and Air Flow screen may appear slightly different ,
depending on the air conditioner model.Example as below:
Get verification code
< Precision Air Flow
Up-Down Flow Control Left-Right Flow Control
Downwards
Swing
Up-Down
Swing
Upwards
Swing
Middle Fix
Top Fix
Upper Fix
Lower Fix
Bottom Fix
< Precision Air Flow
Up-Down Flow Control Left-Right Flow Control
Right
Swing
Left-Right
Swing
Left
Swing
Middle
Swing
Center-Left
Swing
Center-Right
Swing
Wide
Swing
Center-Right
Fix
Left fix
Center-Left
Fix
Middle Fix
Right Wide
Angle Fix
Right Fix
Whole
Anger Fix
Left Wide
Angle Fix
Back
Sample1
77
Cool
0
Swing Flow
X
Up-Down
Left-Right
Note: For some models without auto Left-Right wind, If you active it, you will hear a beep,but no any actions.
Control form2-Air Flow control
Air conditioner control
1.For Eco function, just tap the button to activate the function, the button will be lighting
and the indicator will appear on the screen.
2.Tap again to disable the function.
3.Temperature controlled for some air conditioner model:
In Cooling mode, the new setting temperature will 78 .
In heating mode, the new setting temperature will 77 .
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
77
Heat
0
18
ON/OFF
Sample1
72
Cool
0
Fan Speed
Swing Flow
Eco Sleep
Mode
Timer
Turbo
Note: The Main control screen and ECO control method may appear slightly different ,
depending on the air conditioner model.Example as below:
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
78
Cool
0
Mode
ECO enabled
Cool
Fan
Dry
Heat
Auto
Yes
Yes
ECO is disabled on Fan/ Dry/Auto mode .
Note:
ECO is disabled on Turbo/Sleep mode too
for some air conditioner model.
ECO
Low
Control form2-ECO function
Air conditioner control
1.Tap the Sleep button.
2.Choose your desired sleep mode and tap it.
3.Tap the X button to back to the main control screen.
4.The selected sleep mode indicator will appear on the screen.
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
77
Heat
0
19
ON/OFF
Sample1
72
Cool
0
Fan Speed
Swing Flow
Eco Sleep
Mode
Timer
Turbo
Note:
The Main control screen may appear slightly different ,depending on the air conditioner model.
Example as below:
Mode
Sleep enabled
Cool
Fan
Dry
Heat
Auto
Yes
Yes
Note:
Sleep is disabled on Turbo/Sleep mode too
for some air conditioner model..
Sleep
Low
Sleep is disabled on Fan/ Dry/Auto mode .
Sample1
77
Cool
0
Sleep
X
Standard
Child
The aged
Sample1
77
Cool
0
Sleep
X
Child
The aged
Standard
Control form2-Sleep function
Air conditioner control
1.Tap the Timer button.
2.Tap + in the upper right corner of the Timer main screen.
3.Choose the Time/Repeat/Switch OFF then tap Save.
4.The timer(off) will appear on the Timer main screen.
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
77
Cool
0
< Timer
No Timer
< Timer
19 27
20 28
22 30
23 31
Save
21 : 29
Repeat Monday.... >
Switch OFF>
Once
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Cancel Repeat Confirm
20
Slide up or down
to select time
Tap repeat > then tap your desired
repeat days or Once, then tap
Confirm your selection.
< Timer
21:29
OFF, Weekday
ON
Cancel Switch Confirm
OFF
Tap Switch > then slide the
screen to choose ON
and Confirm.
Control form2-Timer(on) setting
Air conditioner control
1.Tap the Timer button.
2.Tap + in the upper right corner of the Timer main screen.
3.Set the Time/Repeat Date/Switch(ON)/Temperature/Mode/
Fan speed/Air Flow as your desired and then tap Save.
4.The timer will appear on the Timer main screen.
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
77
Cool
0
< Timer
14 17
15 18
17 20
18 21
Save
16 : 19
Repeat Monday.... >
Switch ON>
Temperature 77 >
Mode Cool>
Fan Speed Mid>
Precision Air Flow Up-Down Swing>
Slide up or down
to select time
21
Once
Monday
Tuesday
Wednesday
Thursday
Friday
Saturday
Sunday
Cancel Repeat Confirm
Tap repeat > then tap your desired
repeat days or Once, then tap
Confirm your selection.
< Timer
ON
Cancel Switch Confirm
OFF
Tap Switch > then slide the
screen to choose ON
and Confirm.
16:19
ON,Cool,Mid,Up-Down Swing ,M...77
< Timer
21:29
OFF, Weekday
Tap Temperature/Mode/Fan Speed/
Air Flow > one by one then set as your
desired as mentioned on the previous
chapter and tap Confirm the setting.
04:30
OFF
21:29
OFF, Weekday
04:30
OFF
Control form2-Timer(off) setting
Air conditioner control
1.Change the Timer setting:
Tap anywhere of the timer list bar except the switch bar to get into the Timer
setting screen, change the setting and then tap save.
2.Enable or Disable the Timer:
Tap the left of the switch to disable the Timer.
Tap the right of the switch to enable the Timer.
3.Delete the Timer:
Slide the list bar of the Timer from right to left until Delete button appear,
then tap delete.
< Timer
16:19
ON,Cool,Mid,Up-Down Swing 77 ,M...
21:29
OFF, Weekday
04:30
OFF
22
< Timer
16:19
ON,Cool,Mid,Up-Down Swing ,M...77
21:29
OFF, Weekday
04:30
OFF
Slid left to disable the Timer.
Slid right to enable the Timer.
< Timer
16:19
ON,Cool,Mid,Up-Down Swing ,M...77
29
kday
04:30
OFF
Delete
Control form2-Timer management
Air conditioner control
1.Tap the More button to operate additional functions if it appears on the screen.
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
77
Cool
0
23
Note: The appearance maybe different , some icons
will be hidden if the air conditional do no have this
function or do not enable on the current mode.
< More
Buzzer
Anti-Mildew
Display
Health
Reservation
GEN Mode
Electricity
Monitoring
Self-diagnosis
Electricity
Management
2. Tap the to switch on/off the indoor LED display. " "
Display
3. Tap the to switch on/off the buzzing if it is available on the screen." "
Buzzer
Note:
Some air conditioner model
don't have the more button.
4. Tap the " " button to activate the Anti-Mildew function, if it is available on the screen.
After AC turning off , it will start drying , reduce residual moisture and prevent mould, after function
finish, it will automatically turn off.
Anti-Mildew
Health
5. Tap the " " button to switch on/off the healthy function, if it is available on the screen.
It activate the antibacterial ioniser function.This function only for models with the ioniser generator.
Control form2-More functions
6. Tap the "GEN Mode" button, if it is available on the screen.
In this Mode, you can choose one of the three levels of current.
The air conditioner will maintain proper current to save energy.
GEN Mode
GEN Mode
X
LV1
LV3
LV2
30%
80%
50%
24
Air conditioner control
7. Tap the "Electricity Monitoring" button if it is available on the screen.
In this function, you can monitor the air conditioner electricity consumption.
Electricity monitoring
2019-03-11
DAY Month Year
2019-03-10 2019-03-11
0 kwh
Total Electricity
Consumption
0.14 kwh
Total Electricity
Consumption
4.6 hour
Running time statistics
0 hour
Running time statistics
13:00 14:00 15:00 16:00 17:00 18:00 19:00
(Kwh)
0.032
0.024
0.016
0.008
0
Electricity monitoring
2019-03
DAY Month Year
2019-02 2019-03
0.13 kwh
Total Electricity
Consumption
0.32 kwh
Total Electricity
Consumption
10.83 hour
Running time statistics
4.33hour
Running time statistics
03-09 03-10 03-11 03-12 03-13 03-14 03-15
(Kwh)
0.16
0.12
0.08
0.04
0
Electricity
Monitoring
You can tap this button to
pop up the calender then
select the date.
8. Tap the " " button, if it is available on the screen.
Check the details of the Self-Cleaning function on User Manual.
9. Tap the "8 Heat" button , if it is available on the screen.
This function help keep the room temperature over 8 .
Check the details of the 8 Heat function on User Manual.
Self-Cleaning
8 Heat
Control form2-More functions
10.Tap the "Reservation" button , if it is available on the screen.
You can set the time, repeat day, temperature, mode, fan speed, air flow as you desired
and then tap Save to activate the function.
The air conditioner will automatically reach your settings at the appointment time.
< Reservation
14 17
15 18
17 20
18 21
Save
16 : 19
Repeat setting Monday.... >
Temperature >
Mode Cool>
Fan Speed Mid>
Precision Air Flow Up-Down Swing>
77
< Reservation
16:19:00
ON,Cool,Mid,Up-Down Swing ,M...77
After the reservation is set up, the air conditioner
will automatically reach your set requirement at your
appointment time.
Reservation
25
Air conditioner control
11.Tap the "Self-diagnosis" button, if it is available on the screen.
The air conditioner will automatically diagnosis itself and indicate the Error code
and the problem instructions if possible.
Self-diagnosis
48%
Checking
Cancel
48
OK
Self-diagnosis
100%
Complete
Error code: E0
Indoor and outdoor
communication failure
Self-diagnosis
Control form2-More functions
12. Tap the " " button if it is available on the screen.
13. Tap the " " button if it is available on the screen.
In this function, the air conditioner will blow soft airflow through the micro holes on the deflector.
Photosensitive
Soft Wind
This function allow the air conditioner to turn on/off the display automatically according to the
light intensity.
Air conditioner control
ON/OFF
Fan Speed
Precision
Air Flow
More
Eco Sleep
Mode
Timer
Sample1
77
Cool
0
Tap on control form1 or tap ... on control form2 , get into the device details screen.
Here you can get some useful information and sharing the device to other accounts.
Check the following pictures and instructions carefully.
26
72
F
Set Temperature
Timer
Function
Fan
Mode
Sample2
<
Control form2Control form1
<
Details of device
Information
Remove Device
Supported Third-part Control
Others
Modify Device Name *** >
Device Location Dining Room >
Check Device Network Check Now >
Device Sharing >
Device Info >
Feedback >
Check for Firmware Update >
Tap to change the device
location to another room
Tap to check the network status
Tap to got the instruction for connecting the
amazon alexa or Google Assistant voice controller
Tap to check the Virtual ID/Wi-Fi name/IP address
MAC address/Time Zone/Wi-Fi single strength
Feed back the problems or some
suggestions to the APP administrator.
Check and update the firmware
Tap to remove the device and the
device will be reset automatically
once be deleted.
Tap to check the network status
Tap to sharing the device to other account
Device details and management
Air conditioner control
<
Details of device
Information
Remove Device
Supported Third-part Control
Others
Modify Device Name *** >
Device Location Dining Room >
Check Device Network Check Now >
Device Sharing >
Create Group >
Device Info >
Feedback >
Check for Firmware Update >
Device details and management
How to share the devices to other accounts?
1. Tap "Device Sharing" and pop up Device Sharing screen.
2. Tap "Add Sharing".
3. Select the region and enter the account which you want to sharing.
4. Tap "Completed", the account will appear on your sharing list.
5. The received sharing members should hold pressing the home screen and slide
down to refresh the device list, the device will appear on the device list.
<
Details of device
Adding sharing
It is recommended to set permanent resident as family
member to control the device Family Settings
<
Add Sharing Completed
Region China +86 >
Account
number
***********
<
Details of device
Adding sharing
It is recommended to set permanent resident as family
member to control the device Family Settings
Sharing List
Alias name1
************
Hold the bar about 3s
then you can delete the
sharing account.
27
<<
my home
+
>
Set your home location, get more
information
Welcome home
V
All Devices
Living Room
room
Master Bed
...
Home
Me
Sample1
Sample2
Turned off
Already On
Hold on and slide down to
refresh the device list
Account management
28
<<
my home
+
>
Set your home location, get more
information
Welcome home
V
All Devices
Living Room
room
Master Bed
...
Home
Me
Sample1
Sample2
Turned off
Already On
Profile
Nick name >
Account******
Message Center >
Help Center >
More Services >
Settings >
Home Management >
Home
Me
Account Profile setting
Profile
Profile Picture >
Account Security >
Time Zone Universal >
Nickname ******** >
Select a picture for the
account from local album
Edit name
Cancel Save
Account one
Select the time zone
Change the nick
name of your account
Account Security
Phone Number ********
Change Login Password >
Deactivate Account >
Location China
<
Pattern Unlock
Change Pattern Password >
Change the password
like reset password on page7
Please carefully to
deactivate the account
for all data will be deleted.
Set a pattern password
for launching the APP
Tap the switch to enable
or disable the Pattern password
Account management
Home(Family) management
29
<<
My Home
+
>
Set your home location, get more
information
Welcome home
V
All Devices
Living Room
room
Master Bed
...
Home
Me
Sample1
Sample2
Turned off
Already On
Profile
Nick name >
Account******
Message Center >
Help Center >
More Services >
Settings >
Home Management >
Home
Me
Home Management
My Home >
My Office >
<
Add family
1.Tap the name of home at the left upper corner of the Home Screen and select the Home Management.
Or tap Me and tap Home Management.
2. Tap one of the families in the family list and get into Family Settings screen.
<
Family settings
Family members
Room Management 2 rooms >
Family Location >
Family Name My Home >
Remove Family
Add Menber
Nick name >
Account******
Tap to rename the family name
Tap to get into Room Management
Open the map automatically
then you can set the location
Add other account into this
family to control the device
Remove the Family
from your account
Home Management >
My Home
My Office
Tap to set a name and
select picture for the
family member
Note:
Tap "Add family"
and refer to page 6
to add a new family
3.Set the family as the following indicators.
30
Trouble Shooting
Notice
1. For technical update, there is maybe deviation of the actual items from what is on the manual. We
express our apologies. Please refer to your actual product and APP.
2. Smart air conditioner APP can be altered without notice for quality improvement and also be deleted
depending on the circumstances of manufacturing firms .
3. In case Wi-Fi signal strength is weakened, smart App may be disconnected. So make sure the indoor
unit near to wireless router.
4. DHCP server function should be activated for wireless router.
5. The internet connection may fail because of a firewall problem. In this case, contact your internet
service provider.
6. For smart phone system security and network setting, make sure Smart air conditioner APP is trusted.
Description
Analysis of cause
Air conditioner
can't be configured
successfully
1. Check the mobile connected WLAN router SSID and password is correct;
2. Check whether there are additional settings of WLAN router as shown below.
1) Firewall by router itself or by PC
2) MAC address filtering
3) Hidden SSID
4)DHCP server
Reboot WLAN router, mobile device and air conditioner (WLAN module) and connect air
conditioner by CF mode again. Before rebooting, check nobody has already connected to
same air conditioner.
1. When air conditioner (WLAN module) is rebooted and app
displays Device remove, ignoring this confirmation will lead to mobile
device losing control permission of the air conditioner.
You will need to connect the air conditioner by CF mode again.
2. In case of power failure, mobile device will lose control permission of air
conditioner for 3 minutes after power failure. (Notification will now show
up on the mobile device.)
If you cannot control the app (air conditioner) even after power restored,
you will need to connect the air conditioner by CF mode again.
Mobile can't control
air conditioner
1. App display Air conditioner Device offline. Please check the following conditions.
1)The air conditioner has been reconfigured.
2)Air conditioner out of power.
3)Router out of power.
4)Air conditioner can't connect to router.
5)Air conditioner can't connect to network through the router.
6)Mobile device can't connect to network.
2. After adding the device, it disappears in device list .
Hold and slide down to refresh the device list. If it has no change, shut down the app and start again.
Mobile can't find air
conditioner
