QUICKSTART GUIDE
Carton Contents
Connection Sockets
Installation Notes
PowerZone® Connect PRO • 2000.2/2000.2D
• Amplifier unit
• Rack Mount Ears (Fitted) x 2
• Mains power cable
• Input connector x 2
• GPIO socket connector
• Output connector x 2
• Adhesive rubber feet x 4
• Document pack
• High or low impedance speaker connection options can
be selected independently for each output channel via the
PowerZone® Control web app. (Default is Hi-Z @ 70V)
• Analog input sensitivity can be adjusted independently for each
channel via the PowerZone® Control web app.
• S/PDIF digital audio I/O routing can be configured via the
PowerZone® Control web app.
• GPIO (General Purpose Input/Output) options can be configured
via the PowerZone® Control web app.
• Optional Audinate Dante® interface for integration with audio over
IP (AoIP) networks and installations.
• Ensure that rack or other confined installation does not restrict the
airflow required for safe and reliable operation of the equipment.
It is important to ensure that the 40°C maximum operating
temperature for the equipment is not exceeded.
*Product shown as an example is PowerZone
®
Connect PRO 2000.2D
1. Network Control
2. Dante
®
(optional)
3. Configurable GPIO
4. Configurable S/PDIF Audio I/O
5. Audio Inputs:
Balanced: Euroblock
Unbalanced: RCA Phono
6. Configurable Speaker Outputs
7. Power Input
1
2
3 4 5 6 7
SONANCE-PZC-PRO-2U-QSG-FINAL-052126.inddc 1SONANCE-PZC-PRO-2U-QSG-FINAL-052126.inddc 1 21/05/2026 09.5921/05/2026 09.59
QUICKSTART GUIDE
PowerZone® Connect PRO • 4000.4/4000.4D
Carton Contents Installation Notes
• Amplifier unit
• Rack Mount Ears (Fitted) x 2
• Rear Support Bracket x 2
• Mains power cable
• Input connector x 4
• GPIO socket connector
• Output connector x 4
• Adhesive rubber feet x 4
• Document pack
Connection Sockets
• High or low impedance speaker connection options can
be selected independently for each output channel via the
PowerZone® Control web app. (Default is Hi-Z @ 70V)
• Analog input sensitivity can be adjusted independently for each
channel via the PowerZone® Control web app.
• S/PDIF digital audio I/O routing can be configured via the
PowerZone® Control web app.
• GPIO (General Purpose Input/Output) options can be configured
via the PowerZone® Control web app.
• Optional Audinate Dante® interface for integration with audio over
IP (AoIP) networks and installations.
• Ensure that rack or other confined installation does not restrict the
airflow required for safe and reliable operation of the equipment.
It is important to ensure that the 40°C maximum operating
temperature for the equipment is not exceeded.
*Product shown as an example is PowerZone
®
Connect PRO 4000.4D
1. Network Control
2. Dante
®
(optional)
3. Configurable GPIO
4. Configurable S/PDIF Audio I/O
5. Balanced Audio Inputs: Euroblock
6. Unbalanced Audio Inputs: RCA Phono
7. Configurable Speaker Outputs
8. Power Input
1 3 4 5 6 8
2 7
SONANCE-PZC-PRO-2U-QSG-FINAL-052126.inddc 2SONANCE-PZC-PRO-2U-QSG-FINAL-052126.inddc 2 21/05/2026 09.5921/05/2026 09.59
QUICKSTART GUIDE
PowerZone® Connect PRO 2000.2/2000.2D • 4000.4/4000.4D
Wireless Network Control Connection
Wired Network Control Connection
1. Connect the PowerZone® Connect PRO amplifier to mains power using the supplied mains cable and wait for the
front panel WiFi indicator to illuminate green.
2. Use a mobile, laptop or desktop device to search for available WiFi networks. Connect to ‘Sonance PZcP (model)
(serial number)’ using the password, ‘password’. The amplifier serial number can be found on its rear panel.
3. Open a mobile, laptop or desktop device web browser and enter the following IP address: 192.168.4.1. The amplifier
configuration web interface will open in the browser to enable amplifier configuration as required.
It is strongly recommended that the PowerZone® Connect PRO amplifier WiFi password is changed
following initial wireless connection.
1. Connect the PowerZone® Connect PRO amplifier Network Control socket through a network switch, or directly to
a laptop or desktop device.
2. Connect the PowerZone® Connect PRO amplifier to mains power using the supplied mains cable and wait for the
front panel Network indicator to illuminate green to indicate that the amplifier has network connectivity.
3. The PowerZone® Connect PRO amplifier’s network settings are configured for DHCP from the factory. The network
router will automatically assign the amplifier an IP address for seamless network connection (a network scanning app
can identify the IP address if needed).
4. Download and launch the PowerZone® Control Center desktop application from the Sonance website.
5. The PowerZone® Connect PRO amplifier’s name and serial number will be automatically detected and displayed in
the PowerZone® Control Center (e.g., “Sonance PZcxxxx xxxx-xxxx”).
6. In PowerZone® Control Center, choose the PowerZone® Connect PRO amplifier you want to configure. For detailed
setup instructions, refer to the PowerZone® Connect PRO manual.
It is highly recommended to secure the amplifier’s LAN settings with a password by navigating to
Settings > Security.
A mobile, laptop or desktop device with Wi-Fi functionality and a web browser is required.
A laptop or desktop device with Ethernet functionality and a web browser is required.
Support
A full user manual that includes information on
installation, mounting accessories and amplifier
operation is available via the QR code or online at:
sonance.com/powerzone-connect-pro
SONANCE-PZC-PRO-2U-QSG-FINAL-052126.inddc 3SONANCE-PZC-PRO-2U-QSG-FINAL-052126.inddc 3 21/05/2026 09.5921/05/2026 09.59
SAFETY INSTRUCTIONS
PowerZone® Connect PRO 2000.2/2000.2D • 4000.4/4000.4D
This symbol is intended to alert the user to the presence
of uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufcient magnitude to
constitute a risk of electric shock to persons.
Ce symbole a pour but d’attirer l’attention de l’utilisateur sur la
présence, à l’intérieur du boîtier de l’appareil, d’une «tension
dangereuse» non isolée, qui pourrait être sufsamment puissante
pour représenter un risque d’électrocution pour les personnes.
AVIS
RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
1. Veuillez lire ces instructions.
2. Conservez ces instructions.
3. Respectez tous les avertissements.
4. Suivez toutes les instructions.
5. N’utilisez pas cet appareil près de l’eau.
6. Nettoyez uniquement avec un chiffon sec.
7. N’obstruez pas les ouïes de ventilation. Installez l’appareil en respectant
les instructions du fabricant.
8. Éloignez l’appareil des sources de chaleur: radiateurs, bouches de
soufage, fours et autres (y compris les amplicateurs).
9. Pour réduire le risque d’électrocution, le cordon d’alimentation doit être
connecté à une prise de courant avec une mise à la terre de protection.
10. Respectez le dispositif de protection de mise à la terre de la prise
secteur. Une prise polarisée est équipée de deux ches, l’une plus large
que l’autre. Une prise avec borne de terre est équipée de deux ches et
d’une borne de terre. La che large, ou la borne de terre, est garante de
votre sécurité. Si la che secteur fournie avec l’appareil ne correspond
pas à la prise secteur de votre installation, faites remplacer cette
dernière par un électricien.
11. Disposez les câbles de sorte qu’ils ne puissent pas être piétinés, coincés
ou pincés; une attention toute particulière doit être accordée au niveau
des prises secteur et de l’embase secteur de l’appareil.
12. Ne débranchez pas l’appareil en tirant sur le cordon. Utilisez la che.
13. Débranchez cet appareil du secteur lors des orages ou des longues
périodes d’inutilisation.
14. Conez toute réparation à un technicien qualié. L’intervention d’un
technicien est nécessaire dans les cas suivants: le cordon d’alimentation
ou la prise secteur sont endommagés, des corps étrangers ou du liquide
se sont introduits dans l’appareil, l’appareil a été exposé à la pluie ou à
l’humidité, l’appareil montre des signes de dysfonctionnement ou est
tombé.
15. Le coupleur de l’appareil, ou la che secteur, est le dispositif de
déconnexion du secteur et doit rester facilement accessible après
l’installation.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation opening. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. To reduce the risk of electrical shock, the power cord shall be connected to a
mains socket outlet with a protective earthing connection.
10. Do not defeat the safety purpose of the polarized or grounding type plug.
A polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
11. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
12. Do not unplug the unit by pulling on the cord, use the plug.
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15. The appliance coupler, or the AC Mains plug, is the AC mains disconnect
device and shall remain readily accessible after installation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
©2026 Sonance. All rights reserved. Sonance and PowerZone are registered trademarks of Dana Innovations. Due to continuous product improvement, all features
and specifications are subject to change without notice. For the latest Sonance product specification information visit our website at www.sonance.com.
SONANCE • 991 Calle Amanecer • San Clemente, CA 92673 USA • Phone: (949) 492-7777 Technical Support: (949) 492-7777 • www.sonance.com •
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
This symbol is intended to alert the user to the presence
of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
Ce symbole a pour but d’attirer l’attention de l’utilisateur sur la
présence, dans la documentation qui accompagne l’appareil,
d’instructions importantes relatives à son utilisation et sa
maintenance (entretien).
Class 2 Câblage
Haute tension exposée sur les bornes des haut-parleurs. Toucher
les bornes ou le câblage non isolés peut entraîner une sensation
désagréable
Class 2 Wiring
Exposed high voltage on the speaker terminals. Touching the
uninsulated terminals or wiring may result in an unpleasant sensation
Important Safety Instructions
FCC Compliance
Consignes de sécurité importantes
This equipment must be earthed
