Kalley Black Z1 Smart Phone
Quick Start Guide
1. BEFORE USING
The phone is a Dual SIM mobile that allows you to use two mobile networks.
Insert SIM cards and SD card
1) This machine supports standard Nano card hot-swappable, in the power-on state,
when you insert the Nano card, the phone can automatically identify. Insert the
thimble into the thimble hole and press inward, the card tray pops out. Take out
the card tray, play the Nano card with chip facing down into the corresponding
card slot. Then put the card tray into the phone. Make sure that it is correctly
inserted.
2) To have additional storage for your images, videos, music and files, you can
purchase a memory card and install it in your device. Insert the thimble into the
thimble hoe and press inward, the card tray pops out. Put the SD card with chip
facing downwards into the corresponding card slot, and put the card tray into the
phone.
✓ Note: SD card can be used as internal storage.
Option : Notification Center--> Tap the notice to set up-->Use for portable storage ->Next
->Done(For transferring files and media between devices)
✓ Note:
• Do not remove the cards while the device is transferring data. Doing so may cause
data to be lost or damage to the cards and device.
• The SIM cards and SD card are small parts. Please keep them away from children to
avoid swallowing the card by accident.
• Please do not touch the metal surface of SIM and SD card and keep them away fro
m electromagnetic field to avoid damaged data.
Charge the Battery
Charge the battery before using it. Connect the USB cable to the USB power adaptor,
and then plug the end of the USB cable into the USB Port.
2. GETTING STARTED
Basic Function
• Turn on the phone
Press and hold the power key for a while to turn on the phone.
• Turn off the phone
Press the power button and the volume up button simultaneously until the menu bar
appears. Choose “Power off’’ to turn off the phone.
• Restart the phone
Press the power button and the volume up button simultaneously until the menu bar
appears. Then select "Restart" to restart the phone.
• Lock the screen
Option 1: Press the power key to turn off the screen and lock it
Option 2: The screen will auto lock if you don't use the phone for a while.
• Unlock the screen
Press the power key, and then slide to top for unlocking.
3. COMMUNICATION & CONNECTION
Make a call
• Touch the phone icon on the Home screen.
• Enter the phone number you want to dial.
• Touch the phone icon to dial the number that you entered.
Send a Message
You can use this phone to exchange text messages and multimedia messages with
others. The messages from the same contact will be grouped into one
conversation list. So you can see your entire message history with a person
conveniently.
WLAN
WLAN is a wireless networking technology that can provide internet access at
distance of up to 100 meters, depending on the WLAN router and your
surroundings. You can configure the WLAN as follow:
• Settings-->Wi-Fi to turn it on.
The device scans for available WLAN networks and displays the names of those it
finds.
Tap one of the listed networks and enter the password, if asked to join in.
4. WARNING
The power supply type is QC13AU-N, output is 9V/2A. The device is restricted to indoor
use only when operating in the 50-60 Hz frequency range.
Emergency call
If any emergency arises, dial 112/911 (or other emergency call number) for
emergency help.
Due to the nature of cellular networking, the success of emergency call is not
guaranteed.
FCC Warning:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue.
Device types Smart Phone (FCC ID: 2AEPIBLACKZ1) has also been tested
against this SAR limit. This device was tested simulation typical 10mm to body.
To maintain compliance with FCC RF exposure requirements, the use
accessories that maintain a 10mm separation distance between the user's
body and the device. The use of accessories should not contain metallic
components in its assembly. The use of accessories that do not satisfy these
requirements may not comply with FCC RF exposure requirements, and
should be avoided.
