T1
Hygrometer Thermometer
User Manual
1
Get More Information
Scan the QR code for multi-language manuals and more.
Scan for multi-language manuals and more product support.
Scannen Sie nach mehrsprachigen Handbüchern und mehr Produktsupport.
Numérisez pour obtenir des manuels multilingues et plus d'assistance sur les produits.
Scansione per manuali multilingue e maggiore supporto al prodotto.
Busque manuales en varios idiomas y más asistencia sobre productos.
2
Temperature And Humidity Eects
Temperature & Humidity may often be ignored however they do have a
significant impact on individual's well-being, comfort, health and safety
as well as your property. High humidity may lead to an increase in household
air pollutants especially the biological contaminants such as molds, bacteria,
viruses and dust mites; cold, low humidity may cause nosebleeds, skin
and respiratory irritations, dyspnea, static electricity and etc.
3
Important
Do not use the detector in wet conditions for extended periods to ensure
accurate measurements.
Do not cover the vents of the detector and do not allow lint to enter the
detector or the sensor may not function properly.
If the battery level shows , please charge the detector in time to avoid
being aected during use (it can also recharge when switched o).
Children should only use this device under adult supervision. Keep packaging
materials, such as plastic bags and plastic wrap, out of the reach of children
as they present a choking hazard.
Do not dismantle the unit yourself. In the event of a defect, contact your
dealer instead, who will liaise with the service center and, if necessary, send
the device in for repair.
★
★
★
★
★
4
Overview
① Time*
⑤ Mode button
⑧ Battery level & charging status
⑩ USB port
⑬ Temperature and humidity detection port
② Buzzer status ③ Temperature level
⑥ Power button
⑨ Humidity level color bar
⑪ Magnetic back
④ Humidity level
⑦ Bluetooth
⑫ Vents
⑭ Bracket
*The time can be switched to a 12 or 24-hour time system.
5
Specifications
Temperature*
Measuring range: -10-60°C (14-140
℉)
Resolution: 0.1°C (0.1℉), Accuracy: ±0.5°C (±0.9℉)
Measuring range: 0-99% RH
Resolution: 1% RH, Accuracy: ±3% RH
Humidity
Dimension
Battery Capacity
90*68*18mm / 3.5*2.7*0.7 (inches)
800mAh
Battery Life
About 210 Days
Input
5V/1A
Display
Segment code screen 3.3 inches
Weight About 110g
Operation Environment
-10-60°C/0-90%RH
Model
T1
*When the product is charged, the temperature will have an error of ±0.5°C, and it will recover in about 10 minutes
after full change.
When the temperature measurement environment suddenly changes, and the temperature dierence is large, it
may takes 3 to 5 minutes adaptation time.
Note: The above data are from Temtop Laboratory.
1 )
Press and hold for 3s to turn on/o the monitor.
2 ) Click to switch the buzzer on/o.
b. Mode button
1)
Press and hold
2s to switch between the temperature unit (°F/°C).
2) Click to switch the time display mode (12-hour or 24-hour).
6
Note: Press and hold and simultaneously for 2 seconds to display the maximum and
minimum temperature and humidity from the current time to 0:00 the next day.
a. Power button
Button & Display
c. Buzzer switch Icon
Displayed: Buzzer sound on the device is turned on.
Not displayed: The buzzer sound is turned o.
1) The buzzer chirps once when the buzzer function is turned on (APP operation is synchronised).
2) When the buzzer is switched on, the buzzer sounds twice when the comfort level is lowered.
d. Bluetooth Icon
Displayed: Bluetooth icon is displayed when connected.
Not displayed: Bluetooth icon is not displayed when disconnected.
e. Battery Level and Charging Status
7
1)When the battery is displayed as empty, please charge it in time, and the
charging icon will be displayed when charging.
2)When the battery power is extremely low, the battery icon will flash 3 times
and then shut down.
Note:
Data is refreshed every 5 seconds when there are large changes in temperature and humidity
and every 10 seconds in all other cases.
8
Colour Bar Grade Reference
Red represents lower humidity levels
(＜30%)
Blue represents higher humidity levels
(＞ 60%)
Green represents good humidity levels
(30%~60% )
Note: The colour bar on the product represents humidity only, for temperature colour
bar please see App.
Humidity threshold level indication
(Bracket included)
9
Multiple Mounting Choices
Bluetooth Connection
1. Temtop App
Please search Temtop on App Store or Google Play,
or simply scan the QR code below to download the app:
10
2. Add Device
a.
137
31
Add Device
Start adding devices by clicking the ‘+’ sign on the home page of the Temtop application.
b.
Enable your phone's Bluetooth with the app, which will automatically detect Temtop
devices in range of Bluetooth. Please select the Temtop device you wish to add and click
the Add button.
If you have problems connecting your device, bring the device close to your mobile phone and
make sure they are close enough to make a successful Bluetooth connection.
11
√
√
T1_908642791462510634
42
T1_908642791462510634
42
3. APP Main Functions
• Access real-time measurement data.
• View historical data curves.
• Data storage and export.
• Calibrate the device.
• Change device parameter preferences and much more...
Note:
1)When using the app, make sure your device is within the Bluetooth range. Please avoid moving too
far away from the device.
2)
Due to the upgrading and updating of Temtop APP, the actual operation may be slightly dierent
from the above description, please follow the current guidelines within Temtop APP.
12
Change device name
Please enter a new device name
T1_Temtop
9/50
CANCEL OK
Q: Why can't I receive the verification code when I sign up for an APP account?
A:
①
Q: Why can't the APP connect to the device?
A:
FAQ
Q: Why is the temperature high when charging?
A: The temperature and humidity sensor is located inside the product. When charging,
a large amount of heat will be generated, causing the actual temperature of the
product to rise.
13
①
②
③
②
Please check the advertisement mails and spam mails, your mailbox may automatically.
classify the CAPTCHA mails into advertisement mails and spam mails.
Google Mail, Outlook, and other major mailboxes are recommended.
Make sure your phone and device are in the same room and as close to the device as possible.
Try restarting the device or connecting with another phone.
If the issue is still not resolved, please contact our customer service for further support.
FAQ
14
Q: Why does my T1 screen keep showing “ ” segments? Is it broken?
A: The screen shows “ ” segments because the device is in upgrade mode. The continuous
display of “ ” is due to an incomplete software upgrade from the last attempt. Please
log
in to the Temtop app and go to " OTA Upgrade " in device management to complete
the software upgrade.
15
Detector x 1
USB cable x 1
User manual x 1
Bracket or accessories set x 1
