Wireless Bluetooth 2D Scanner
5380
KEY FEATURES
● Low power consumption, high performance
● Comprehensive reading of all mainstream 1-D, 2-D code
● Quickly read the bar code on the phone screen
● Supports RS232 interface and USB interface
● Cross laser Aimer automatically lights up to facilitate quick align-
ment of the bar code to be solved
�D / �D High speed scan Big vision Fast decoding Screen scan
Customized
Motion tolerance
2M/S
1.5M
Large battery Drop
Ingress Protection
IP54
Mechanical
Performance
Dimension
Weight
Power Supply/ Electric Current
Resolution
1280 p(H) x 1080 p(V)
Light Source Aimer: Red Cross Laser ; illumination: 4000K White LED
Field of View
40°(H) x 34°(V)
Scan Angle Pitch ±65° Yaw 360° Roll ±60°
Environment
Symbology
Operating Temperature
32°F ~ 122°F / 0°C ~ 50°C
1D
2D
Code 128, Code 39, Code 93, EAN-8, EAN-13, UPC-E, UPC-A, GS1-128,
Codabar, Interleaved 2 of 5, GS1 DataBar
Endurance Time
11H
Charging Time
Support fast charging, the whole charging time is 2.5H,
and the single battery charging time is 2H
Wireless Technology
Bluetooth 5.0, SPP
5380
Specifications
Intelligent identification,
smart vision,
industrial vision sensor provider
All specification and
designs are subject
to change without notice.
V.04.20260205
TEL：���-���-����
E-MAIL:[email protected]om
WEB: www.isuperlead.com
ADD: SuperLead Headquarters Building, �� Fujingtian Road,
Suzhou Industrial Park, Suzhou City, Jiangsu Province
Suzhou SuperMax Smart System Co.,Ltd.
Symbol Contrast
≥25%
Interface RS232, USB COM, USB HID Keyboard, USB POS
Motion Tolerance
2m/s
Working Distance 100m
Drop
Withstand drop 1.5m on concrete
Humidity
5% ~ 95%RH, no condensation
Ingress Protection
IP54
Ambient Light Immunity 86,000 Lux.
PDF417, QR Code, Micro QR, Data Matrix
Storage Temperature
-40°F ~ 158°F / -40°C ~ 70°C
188mm x 90mm x 70mm
262g
3.7 VDC / 2600mA
5380
Specifications
Intelligent identification,
smart vision,
industrial vision sensor provider
All specification and
designs are subject
to change without notice.
V.04.20260205
TEL：���-���-����
E-MAIL:[email protected]om
WEB: www.isuperlead.com
ADD: SuperLead Headquarters Building, �� Fujingtian Road,
Suzhou Industrial Park, Suzhou City, Jiangsu Province
Suzhou SuperMax Smart System Co.,Ltd.
Typical Depth of Field
Code 39 (3.13 mil) 45mm-120mm
Lens SR
Code 39 (3.9 mil) 35mm-150mm
Code 39 (5.13 mil) 40mm-240mm
Code 39 (20 mil) 25mm-650mm
UPC-A (13 mil) 30mm-450mm
PDF (6.88 mil) 10mm-260mm
DM (10 mil) 10mm-260mm
QR (20 mil) 10mm-470mm
Dimension (unit: mm)
93
103
134
94
134
103
90
70
94
191
103
70
134
191
172
94
�mm-��mm
�mm-��mm
��mm-��mm
��mm-���mm
�mm-��mm
��mm-���mm
�mm-���mm
�mm-��mm
HD
Federal Communications Commission (FCC) Statement.
This device complies with part 15 of the
FCC Rules. Operation is subject to the following two
conditions:
(1)
This device may not cause harmful interference, and
(2)
this device must accept
any interference received,
including interference that may cause undesired operation.
Note: This equipment has been
tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide Reasonable
protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the
user is encouraged to try to correct the interference by one or
more of·1
the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications made to this device not expressly approved by
may void the FCC authorization to operate this device.Note: The manufacturer is not responsible
for any radio or TV interference caused by
unauthorized modifications to this equipment. Such
modifications could void the user’s authority
to operate the equipment.
RF
exposure
statement:
The device has been evaluated to meet general RF exposure requirement. The device can be
used in portable exposure condition without restriction.
