INSTRUCTION MANUAL
OL90-D059AW
Please read this manual before operating and save it for future reference. Every dehumidifier is covered with a 1-year free warranty offered by Hurrikan that
is automatically valid from the date of purchase. To extend the warranty or express any questions or concerns, please email us at [email protected]
NEW Version
COMMERCIAL DEHUMIDIFIER
CONTENT
1
2
3
4
5
6
7
8
.
.
.
.
.
.
.
.
CAUTIONS
PRODUCT DESCRIPTION
OPERATION
DRAINAGE
MAINTENANCE
TROUBLE SHOOTING
STORAGE & DISPOSAL
WARRANTY
Our Origin
The outbreak of COVID-19 in early 2020 brought an online shopping boom and a new lockdown lifestyle, consequently increasing the demand for large buildings for either storage or dwelling
needs. As a household dehumidifier manufacturer ourselves, we sensed the pressing need for commercial dehumidifiers that could maintain an appropriate humidity condition for good storage
or living. Therefore, we started to extend beyond producing household dehumidifiers into the commercial field, in an attempt to not only create a solution but to also challenge the monotonous
designs embodied by the existing commercial dehumidifiers.
To convey our message, we blended in a touch of creativeness into the appliances’ designs. We drew inspiration from luxury clothing, and therefore, elegance and boldness had become our antithesis
to appliances’ predominating tedious design. With the brand concept “sweep away the unwanted”, we hope to invigorate everyone not to be bothered by the depressing moments, but instead
to boldly overcome whatever that comes before us.
Our Style
Guided by our unique perspective, we challenge commercial dehumidifiers' predominant boring design, adopting boldness in our product design instead. Specifically, we hope to make our product
“sweep away the unwanted”by integrating high-performance components. Our Hurrikan is unique for achieving a balance between appearing elegant and being powerful. Hurrikan represents
a revolution: the brand transforms a field that was previously cumbersome into a stage for boldness, bringing new aesthetic standards to appliance design.
Our Logo
Hurricane is central to Hurrikan's product designs: it epitomizes nature's almighty force and symbolizes the perpetual pursuit of power, clearness, and relentlessness. Hurrikan's logo design thus
resembles tornado, bearing an elegantly modest but implicitly robust appearance. Hurricane as the design element also perfectly aligns with Hurrikan's ideal-to lead a vigorous, bold, and cleansed life.
HURRIKAN's STORY
Hurrikan is an American luxury home appliance and specialty retailer headquartered in New York City. In 2022, Hurrikan introduced the industry-leading commercial
dehumidifier as we know it today. We're proud to build on our legacy as the leader in dehumidifier traceability with responsibly sourced, expertly crafted dehumidifiers
that celebrate technology in all its forms.
Instruction Manual
OL90-D059AW
Cautions
1
OL90-D059AW
Instruction Manual
BEFORE YOU BEGIN
This commercial dehumidifier removes excess moisture from storage spaces and large buildings.
The environmentally friendly R32 is used as the refrigerant. R32 has no damaging influence on the ozone layer (ODP), has a negligible greenhouse effect (GWP), and is available worldwide.Because
of its efficient energy properties, R32 is highly suitable as a coolant for this product. Precautions must be taken into consideration due to the coolant's flammability.
IMPORTANT SYMBOLS
This instruction manual contains instructions and notes on the operation and use of this unit.
Do not use unofficial components or accessories that may result in a risk of fire, electric shock, or injury to people.
For your safety and benefit, please keep this manual handy for future reference.
THE FOLLOWING SHOULD ALWAYS BE OBSERVED FOR SAFETY
●
This appliance can be used by children older than eight, people with reduced physical, sensory, or mental capabilities, and people who lack experience and knowledge if they have been given
supervision or instruction concerning the use of this product in a safe way, and if they understand the hazards involved. Children shall not play with this appliance. Cleaning and maintenance
should not be done by children without supervision.
●
This appliance is designed to be used indoors, not outdoors.
●
This appliance is designed for using R32 (propane) gas as the designated refrigerant only.
●
The refrigerant loop is sealed. Only a qualified technician should attempt to service.
●
Do not discharge the refrigerant into the atmosphere.
●
R32 (propane) is flammable and heavier than air. It accumulates first in low areas but can be circulated by the fans.
●
If propane gas is present or even suspected, do not allow untrained personnel to attempt to find the cause.
●
The propane gas used in this appliance has no odor.
●
The lack of smell does not indicate a lack of escaped gas.
●
If a leak is detected, immediately evacuate all people from the indoor space. Ventilate the room and contact the local fire department to inform them about the propane leakage.
●
Do not let any person back into the space until qualified service technicians have arrived and informed that it is safe now to return to the space.
●
No open flames, cigarettes, or other possible sources of ignition should be used inside or in the vicinity of this appliance.
●
This appliance’s components are designed for propane and the non-incentive and non-sparking conditions. Components should only be replaced with identical parts.
●
FAILURE TO ABIDE BY THIS SAFETY WARNING LIST MIGHT RESULT IN AN EXPLOSION, DEATH, INJURY, OR PROPERTY DAMAGE.
This unit uses a flammable refrigerant.
If the refrigerant leaks or comes in contact with fire or a heating source,it will create harmful gas and there will be a risk of fire.
Read the INSTRUCTION MANUAL carefully before operation.
Service personnel are required to carefully read the INSTRUCTION MANUAL before operation.
Warning
Cautions
1
OL90-D059AW
Instruction Manual
IMPORTANT SAFETY TIPS
Your safety is the most important thing we concern!
WARNING:Please read the following tips carefully and fully understand them before operating your appliance.
OPERATIONAL PRECAUTIONS
WARNING: to reduce the risk of fire, electric shock, or injury to people or property:
●
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified people to avoid any hazard.
●
This appliance should be disconnected from its power source during service.
●
Always operate the unit from a power source of equal voltage, frequency, and rating as indicated on the product identification plate.
●
Always use a power outlet that is grounded.
●
Unplug the power cord when cleaning or when not in use.
●
Do not operate with wet hands. Prevent water from spilling onto the appliance.
●
Do not immerse or expose the unit to rain, moisture, or any other liquid.
●
Do not leave the unit running unattended. Do not tilt or turn over the unit.
●
Do not unplug while the unit is operating.
●
Do not unplug by pulling on the power cord.
●
Do not use an extension cord or an adapter plug.
●
Do not put objects on the unit.
●
Do not climb or sit on the unit.
●
Do not insert fingers or other objects into the air outlet.
●
Do not touch the air inlet/outlet.
●
Do not operate the appliance if it is dropped, damaged, or showing signs of product malfunction.
●
Do not clean the appliance with any chemicals.
●
Ensure the unit is far away from fire, inflammable, or explosive objects.
●
The unit shall be installed in accordance with national wiring regulations.
●
Do not use means other than those recommended by the manufacturer to accelerate the defrosting process or to clean.
●
The appliance shall be stored in a room without continuously operating sources. (for example: open flames, operating gas appliances, or operating electric heaters.)
●
The appliance shall be stored in the way that prevents mechanical damage.
●
Do not piece or burn the unit, even after use.
●
Be aware that refrigerants may not have odor.
●
Pipework shall be protected from physical damage and shall not be installed in an unventilated space that is smaller than 4 m².
●
Comply with national gas regulations.
●
Keep any required ventilation openings clear of obstruction.
●
The appliance shall be stored in a well-ventilated area where the room size corresponds to the room area as specified for operation.
Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certificate from an industry-accredited assessment
authority, which authorizes their competence to handle refrigerants safely in accordance with an industry-recognized assessment specification.
Servicing shall only be performed as recommended by the manufacturer.
Maintenance and repair that require the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of flammable refrigerants.
WARNING
WARNING
Cautions
1
OL90-D059AW
Instruction Manual
SAFETY PRECAUTIONS ON SERVICING
Please follow these warnings when servicing an appliance with R32.
1. Area safety check
Prior to beginning work on systems containing flammable refrigerants, safety checks are necessary to minimize the risk of ignition. Prior to repairing the refrigerating system, the following precautions
shall be complied.
2. Work procedure
Work shall be undertaken under a controlled procedure so as to minimize the risk of exposure to a flammable gas or vapor during the process.
3. General work area
All maintenance staff and others working in the local area shall be instructed on the nature of work being carried out. Work in confined spaces shall be avoided. The area around the workspace
shall be sectioned off. Ensure that the conditions within the area have been made safe by the control of flammable material.
4. Checking for the presence of refrigerant
The area shall be checked with an appropriate refrigerant detector prior to and during the work, to ensure the technician’s awareness of potentially flammable atmosphere. Ensure that the leak
detection equipment used is suitable for use with flammable refrigerants, i.e. no sparking, adequately sealed or intrinsically safe.
5. Presence of fire extinguisher
If any high-temperature operation is to be conducted on the refrigeration equipment or any of its associated parts, appropriate fire extinguishing equipment shall be available to hand. Have a
dry powder or CO2 fire extinguisher adjacent to the charging area.
6. No ignition sources
Don’t carry out work in relation to a refrigeration system that is exposed to any pipework that contains flammable refrigerant using any sources of ignition in order to avoid the risk of fire or explosion.
All possible ignition sources, including cigarette, should be kept far away from the site of installation, repairing, removing, and disposal. Prior to work, ensure that the surrounding area has no flammable
hazard or ignition risks, and the "No Smoking" sign shall be displayed.
7. Ventilated area
Ensure that the area is open or adequately ventilated before breaking into the system or conducting any high-temperature operation. Please keep ventilation during the process. The ventilation
should safely disperse any released refrigerant and preferably expel it externally into the atmosphere.
8. Refrigeration equipment check
When electrical components are being changed, they shall be suitable for the purpose and be aligned with the correct specification according to the maintenance and service guidelines. If you
encounter any problem, please feel free to consult the manufacturer for assistance. The following checks shall be applied to installations using flammable refrigerants:
-The charge size is in accordance with the room size within which the refrigerant-containing parts are installed.
-The ventilation machinery and outlets are operating adequately and are not obstructed.
PRODUCT DESCRIPTION
2
OL90-D059AW
The dehumidifier is used to remove excessive moisture from the air. The resulting reduction in relative humidity protects buildings and their contents from the adverse effects of excess humidity.
2.1 FEATURES
2.2 PARAMETERS
A 24-hour timer for automatic
operation time setting
Child Lock preventing
unwanted injuries
Air Filter for
dust removal
Quiet fan for
quiet operation
Refrigerant/Charge
Low Side Pressure
High Side Pressure
BCSC
Compressor Input
Fan Motor Power
R32/10.41oz
260psi
550psi
15A
RLA:9.95A/LRA:51A
1.22A/0.185HP
Model
Power Supply
Rated Input Current
MAX Input Current
OL90-D059AW
115V~60Hz
8.5A（80℉/60%RH）
9.9A（86℉/80%RH）
Dehumidification
Capacity
109Pints/D（80℉/60%RH）
190Pints/D（86℉/80%RH）
296Pints/D（90℉/95%RH）
Powerful and Efficient
moisture removal
Two drainage methods:
Continuous & Automatic/Pump
Humidity Monitor showing
current air humidity
Temperature Monitor showing
current ambient temperature
Instruction Manual
PRODUCT DESCRIPTION
2
OL90-D059AW
Control panel
Front shell
Top shell
Air outlet
Handle
Right shell
2.3. PRODUCT DISPLAY
Left shell
Handle
Power cord
Back shell
Instruction Manual
Back wheels(no foot brake)
Front wheels(with foot brake)
Drain hole for
automatic/pump drainage
Drain hole for
continuous drainage
OPERATION
3
OL90-D059AW
3.1. BUTTONS
Power
Press this button to turn the unit on/ off. The operation indicator will light up when the unit is on.
Timer
When the timer is off, press this button to activate the timer, where the set time is shown as flashing on the left side of the LED control panel. Press the Up or Down button to increase
or decrease the timer within a 24-hour time frame. When the timer is on, press this button to see the remaining set length of operation time, and press this button again to cancel the timer.
Lock/Pump
A quick press of this button will turn on/off the automatic/pump drainage. A long press (3 seconds) of this button will turn on/off the child-lock function. A long simultaneous press of this
button and the Timer button will activate automatic/pump drainage enforceably, immediately draining away all water collected in the pump’s water tank (automatic/pump drainage
usually only starts draining when the tank is full).
UP
Each press of this button will increase the set humidity level/timer by 5 %/1 hour within the range of 20-90%/0-24 hours.
Press the Up and Down button simultaneously to switch between the Celsius and Fahrenheit unit for ambient temperature display.
DOWN
Each press of this button will decrease the set humidity level/timer by 5 %/1 hour within the range of 20-90%/0-24 hours.
Press the Up and Down button simultaneously to switch between the Celsius and Fahrenheit unit for ambient temperature display.
“ ”“ ”
“ ”
“ ”
“ ”
“ ” “ ”
Instruction Manual
Down Up Power Lock/Pump Timer
OL90-D059AW
: Set/Ambient humidity level (displays
“FL” when pump's water tank is full)
: Timer
: Dehumidifying state is on
: Set humidity level has been reached
: Fan
: Ambient temperature
: Child lock
: Water Full Indicator
: Defrosting Indicator
: Pump (flashes when the pump is
draining)
3.2. INDICATORS
OPERATION
3
NOTE:
The dehumidifier will beep for 5 times and shut down automatically when pump's water tank is full, and will resume working when the tank is emptied.
Instruction Manual
OL90-D059AW
DRAINAGE
4
1. Continuous Drainage
●
Remove the rubber stopcock blocking the drain hole for continuous drainage. Plug a PVC drain hose into this hole to enable continuous drainage. You may connect the other end of the hose to
any drainage area you desire.
WARNING: the end of the hose should not be submerged in water to prevent it from being blocked or damaged.
2. Automatic/Pump Drainage
●
Use the rubber stopcock to block the drain hole for continuous drainage.
●
Remove the rubber stopcock blocking the drain hole for automatic/pump drainage. Plug a PVC drain hose into this hole to enable automatic/pump drainage. You may connect the other end of
the hose to any drainage area you desire.
●
Press the “Lock/Pump” button to activate automatic/pump drainage. The Pump indicator will light up. The dehumidifier will start draining when the pump’s tank is full. (NOTE: a simultaneous
press of the “Lock/Pump” button and “Timer” button will make the dehumidifier start draining regardless of the tank’s condition)
WARNING: the end of the hose should not be submerged in water to prevent it from being blocked or damaged.
Instruction Manual
Down Up Power Lock/Pump Timer
OL90-D059AW
MAINTENANCE
5
5.1. CLEANING
1. Body Cleaning
Use a soft and slightly moist cloth to clean the dehumidifier’s body. Do not use cleanser, steel balls, chemically treated dust-proof cloth, gasoline, benzene, thinners, or other chemical solvents in
case of damage or distortion.
WARNING: Before cleaning or conducting maintenance, please turn off and unplug the machine to avoid the risk of electrocution.
2. Filter Cleaning
●
Loosen the two screws located at the bottom of the dehumidifier’s front shell. Push the front shell downward to separate it from the machine’s body.
●
Take the filter out of the front shell.
●
Use a vacuum cleaner to gently absorb the dust on the filter’s surface.
●
If the filter is dirty, wash it with water and a soft detergent, and dry it thoroughly afterwards.
●
Put the filter back in the front shell. Push the front shell upward to attach it back to the machine’s body.
●
Tighten the two screws located at the bottom of the dehumidifier’s front shell.
WARNING: It is strongly advised to rinse the filter every two weeks. Any dust blocking the filter will potentially affect the machine’s functionality.
5.2. LOCATION
1. Place the appliance on a firm and horizontal surface.
2. Never install the appliance at a place that could be subject to:
●
Heat sources such as radiators, heat registers, stoves or other products that produce heat.
●
Possible splashing of oil or water
●
Direct sunlight
●
Mechanical vibration or shock
●
Excessive dust
●
Lack of ventilation, such as cabinet or bookcase
●
Uneven surface
SCREW SCREW
Instruction Manual
TROUBLE SHOOTING
6
OL90-D059AW
1. Functioning Temperature: 41°F ≤ Ambient Temperature ≤ 100°F
When the ambient temp is lower or higher than the functioning temp, the dehumidifier stops functioning.
When 41°F ≤ Ambient temperature ≤ 61°F, the compressor automatically defrosts at intervals; during defrosting, the compressor stops and the fan keeps running.
2. Before Calling for Service
Before contacting the customer service, please review the following troubleshooting list that includes common problems that are not the result of a defect in workmanship or materials.
WARNING:
If the Water Full indicator is always on, there may be a malfunction in the machine. Please seek technical support from professionals.
If anything unexpected happens, please turn off and unplug the machine immediately, and seek technical support from certified electrical engineers.
Problem Probable Cause Solution
Power cord not connected properly Make sure the power cord is properly plugged into the machine and a power source.
Water Full Indicator On (Pump’s water tank is full) Make sure the pump’s tank is properly drained.
Ambient Temperature too high/low (protection mechanism triggered) Make sure the machine is under proper temperature (41 ~ 100 °F)
Filter Clogged Wash the filter thoroughly as instructed
Intake vent or discharge duct obstructed Remove any object blocking the intake vent or discharge duct.
Refrigerant leaked Contact customer service for repairment
No Air Intake Filter Clogged Wash the filter thoroughly as instructed
Water leaking Drain hose blocked Remove any obstruction from the hose’s end
Machine tilted or being upside down Make sure the machine is standing upright
Filter Clogged Wash the filter thoroughly as instructed
Error Code ‘E1’ Temperature/Humidity sensor problem Change the sensor
Error Code ‘E2’ Temperature sensor problem Change the sensor
Error Code ‘CL’ When the ambient temperature drops below 41°F, this error code will appear, and the compressor and fan will shut down.
Error Code ‘CH’ When the ambient temperature is above 100°F, this error code will appear, and the compressor and fan will shut down.
Error Code ‘LO’ When the ambient humidity drops below 20%, this error code will appear, and the compressor and fan will shut down.
Error Code ‘HI’ When the ambient humidity is above 95%, this error code will appear, but the compressor and fan will keep operating.
Error Code ‘E4’ Water is full or the pump is malfunctioning. Drain out water or contact customer service for repairment.
Not Working
Humidity Level
not Dropping
Loud Noise
Instruction Manual
STORAGE & DISPOSAL
7
OL90-D059AW
7.1. STORAGE
If you are not going to use the appliance for an extended period of time (more than a few weeks), it is best to clean and dry it completely before preserving the appliance in a ventilating, dry, corrosive
gas-free, and safe indoor space.
The appliance must be kept in an upright position when in storage.
Note: Activating automatic/pump drainage enforceably can quickly dry the appliance.
7.2. DISPOSAL
Do not dispose of electrical appliances as unsorted municipal waste. Instead, use designated collection facilities.
Contact your local government for information regarding the available disposal collection system.
Instruction Manual
WARRANTY
8
OL90-D059AW
8.1. WARRANTY BRAND CARD
Nous certifions l'authenticité de cet article et confirmons qu'il a été soumis au contrôle qualité
le plus exigeant. Sa haute qualité est un symbole de la belle réputation de la Marque.
Vous avez été couvert par une garantie d'un an offerte par Hurrikan, qui est automatiquement
valable à compter de la date livraison. Si vous avez des inquiétudes ou souhaitez étendre la
garantie à 2 ans, veuillez envoyer un e-mail à Hurrikan à suppor[email protected].
Protection To Fix Card
We certify the authenticity of this item and confirm that it has been subjected to the most
exacting quality control. Its high quality is a symbol of the fine reputation of this trademark.
One-year warranty offered by Hurrikan will be in effect automatically since the date of delivery.
If you want to extend the warranty to two years or have any other concerns, please don’t
hesitate to contact us through email at [email protected].
Instruction Manual
WARRANTY
8
OL90-D059AW
8.2. HURRIKAN ONE-YEAR LIMITED WARRANTY POLICY SUMMARY
Each Hurrikan product is covered with a 1-year warranty, starting from the date of delivery. Under this limited warranty, Hurrikan warrants that each Hurrikan product you purchase will be free from
any material and workmanship defects under normal use, and products experiencing this type of defects are guaranteed free repairment during the warranty period. Such warranty provision is
in addition to rights provided under local consumer laws. Products malfunctioning due to non-manufacturing damage or improper usage are not covered under this warranty, and will face service
fee for repairment. Repairment service options are dependent on the country from which the service is requested, and may be restricted to the original country of purchase. International shipping
fee might apply, depending on the location.
To obtain the warranted repairment, please fill out this warranty card and contact [email protected] with a photo/scanned version of the card. You might be required to provide more purchase
details, depending on the case. If you wish to extend the warranty or express any questions or concerns, please also email [email protected].
8.3. WARRANTY CARD
Product Name Hurrikan Dehumidifier Model No. OL90-D059AW
Purchase Site
Date of Purchase
Customer Name
Address
Tel. No. Email
Invoice No.
Warranty Period
1 year
Instruction Manual
Please read this manual before operating and save it for future reference. Every dehumidifier is covered with a 1-year free warranty offered by Hurrikan that
is automatically valid from the date of purchase. To extend the warranty or express any questions or concerns, please email us at [email protected]
COMMERCIAL DEHUMIDIFIER
