Samsung V-NAND SSD
9100 PRO
2025 Data Sheet
Revision 2.0
Data Sheet
SAMSUNG PROPRIETARY
Revision 2.0
2
LEGAL DISCLAIMER
SAMSUNG ELECTRONICS CO., LTD. RESERVES THE RIGHT TO CHANGE PRODUCTS, INFORMATION AND
SPECIFICATIONS WITHOUT NOTICE.
Products and specifications discussed herein are provided for reference purposes only. All information discussed
herein may change without notice and is provided on an “AS IS” basis, without warranties of any kind. This
document and all information discussed herein remain the sole and exclusive property of Samsung Electronics Co.,
Ltd. No license of any patent, copyright, mask work, trademark or any other intellectual property right is granted
under this document, by implication, estoppels or otherwise. Samsung products are not intended for use in life
support, critical care, medical, safety equipment, or similar applications where product failure could result in loss
of life or personal or physical harm, or any military or defense application, or any governmental procurement to
which special terms or provisions may apply. For updates or additional information about Samsung products,
contact your nearest Samsung representative. All brand names, trademarks and registered trademarks belong to
their respective owners.
COPYRIGHT © 2025
This material is copyrighted by Samsung Electronics Co., Ltd. Any unauthorized reproductions, use or disclosure of
this material, or any part thereof, is strictly prohibited and is a violation under copyright law.
TRADEMARKS & SERVICE MARKS
The Samsung logo is the trademark of Samsung Electronics Co., Ltd. All other company and product names may be
trademarks of the respective companies with which they are associated.
For more information, please visit www.samsung.com/ssd and www.samsungssd.com.
To download the latest software & manuals, please visit www.samsung.com/samsungssd
Data Sheet
SAMSUNG PROPRIETARY
Revision 2.0
3
TECHNICAL SPECIFICATIONS
Samsung SSD 9100 PRO
Usage Application
Client PCs, PlayStation
®
5
Interface
PCIe
®
5.0 x4, NVMe™ 2.0
Hardware
Information
Capacity
1)
1TB
2TB
4TB
8TB
Controller
Samsung in-house Controller
NAND Flash Memory
Samsung V-NAND TLC
Cache Memory
1GB LPDDR4X
2GB LPDDR4X
4GB LPDDR4X
8GB LPDDR4X
Dimension
2)
1TB/2TB/4TB : Max 80.15 x Max 22.15 x Max 2.38 (mm)
8TB : Max 80.15 x Max 22.15 x Max 3.88 (mm)
Form Factor
M.2 (2280)
Performance
(Up to.)
3) 4) 5)
Sequential Read
14,700 MB/s
14,700 MB/s
14,800 MB/s
14,800 MB/s
Sequential Write
13,300 MB/s
13,400 MB/s
13,400 MB/s
13,400 MB/s
QD 256
Thread 32
Ran. Read
1,850 KIOPS
1,850 KIOPS
2,200 KIOPS
2,200 KIOPS
Ran. Write
2,600 KIOPS
2,600 KIOPS
2,600 KIOPS
2,600 KIOPS
Power
Consumption
Active
6)7)
(Avg.)
Read
7.6 W
8.1 W
9.0 W
10.5 W
Write
7.2 W
7.9 W
8.2 W
8.8 W
Idle
(Typical)
PS3(APST on)
4.0 mW
4.8 mW
6.5 mW
9.3 mW
PS4 (L1.2)
3.3 mW
4.0 mW
5.7 mW
8.6 mW
Reliability
Temp.
Operating
0°C to 70°C
(Measured by S.M.A.R.T. Temperature Proper airflow recommended)
Non-Operating
-40°C to 85°C
Humidity
5% to 95% non-condensing
Shock
Non-Operating
1,500G(Gravity), duration: 0.5ms, 3 axis
Vibration
Non-Operating
20~2,000Hz, 20G
MTBF
1.5 million hours
Warranty
8)
TBW
600 TB
1,200 TB
2,400 TB
4,800 TB
Period
5 years limited
Supporting
Features
TRIM (Required OS support), Garbage Collection, S.M.A.R.T
Data Security
AES 256-bit Full Disk Encryption, TCG/Opal V2.0, Encrypted Drive (IEEE1667)
1)
1GB = 1,000,000,000 bytes by IDEMA. A certain portion of capacity may be used for system file and maintenance use, thus the actual available capacity
may differ from the labeled capacity.
2)
The 8TB model complies PCI-SIG
®
D5 standard specification. Please check the specifications of the host device before installation.
3)
9100 PRO is backward compatible with PCIe 4.0 x4 and 3.0 x4.
4)
Sequential and random performance measurements are based on FIO 3.33. Performance may vary based on SSD’s firmware version, system
hardware & configuration. Test System: AMD Ryzen 9 7950X 16-Core Processor [email protected], DDR5 4800MHz 16GBx2, OS-Ubuntu 22.04.2,
Chipset-ASRock-X670E-Taichi.
5)
Sequential and random write performance was measured with Intelligent TurboWrite technology being activated. Intelligent TurboWrite operates only
within a specific data transfer size. For detailed information, please contact your local service center.
6)
Active power consumption is measured on FIO 3.33 with AMD Ryzen 5 7600 6-Core Processor [email protected], DDR5 4800MHz 16GBx2, OS-Ubuntu
22.04.3 LTS, Chipset-ASUS ProArt X670E-CREATOR WIFI STCOM.
7)
Sufficient power is required for the stable operation of high-capacity SSDs, including the host device. To minimize system errors, please ensure the host
device’s power consumption requirements are met.
8)
All documented endurance test results are in compliance with JESD218 Standards. Please visit www.jedec.org for detailed information on JESD218
Standards. TBW means Terabytes Written, Warranty provides coverage for the stated time period or the TBW, whichever comes first. Please refer to the
detailed warranty statement here at http://www.samsung.com/samsungssd
Data Sheet
SAMSUNG PROPRIETARY
Revision 2.0
4
PRODUCT LINEUP
Density
Model Name
Box Contents
Model Code
1TB
(1,000GB*)
MZ-VAP1T0
Samsung SSD 9100 PRO 1TB
Warranty Statement
MZ-VAP1T0BW
MZ-VAP1T0B/AM
2TB
(2,000GB*)
MZ-VAP2T0
Samsung SSD 9100 PRO 2TB
Warranty Statement
MZ-VAP2T0BW
MZ-VAP2T0B/AM
4TB
(4,000GB*)
MZ-VAP4T0
Samsung SSD 9100 PRO 4TB
Warranty Statement
MZ-VAP4T0BW
MZ-VAP4T0B/AM
8TB
(8,000GB*)
MZ-VAP8T0
Samsung SSD 9100 PRO 8TB
Warranty Statement
MZ-VAP8T0BW
MZ-VAP8T0B/AM
* GB: 1GB = 1,000,000,000 bytes. The actual usable capacity may be less than the labeled capacity.
For more information, including but not limited to the warranty provided for this product, and to download the latest
software & manuals, please visit www.samsung.com/ssd and www.samsungssd.com.
TEST CONFIGURATION
Below you will find a list of system configurations Samsung used to obtain the results reported in this Data Sheet.
Performance/power data was measured with the SSD as a secondary drive in a fan cooling desktop system.
Read/Write Performance
Power Consumption
Interface
PCIe 5.0 x4
PCIe 5.0 x4
OS
Linux Ubuntu 22.04.2
Linux Ubuntu 22.04.3 LTS
CPU
AMD Ryzen9 7950x 16-Core Processor
AMD Ryzen 5 7600 6-Core Processor
Memory
DDR5 4800MHz 16GBx2
DDR5 4800MHz 16GBx2
Chipset
ASRock-X670E-Taichi
ASUS ProArt X670E-CREATOR WIFI STCOM
Test Program
FIO 3.33
FIO 3.33
Data Sheet
SAMSUNG PROPRIETARY
Revision 2.0
5
Revision History
Revision
Number
Description
Revision Date
1.0
Initial Release
January, 2025
2.0
Update Information of the 8TB Capacity
September, 2025
