MTB12
WaterproofReplaceable
BatteryTag
Datasheet
01
Version: 001
PRODUCT INTRODUCTION
MTB12 is a replaceable battery Bluetooth tag designed for asset tracking
applications. It features a compact form factor, enabling fast deployment on
various equipment and logistics carriers. Despite its small size, it balances
protection, battery life, and wireless communication performance, making it
suitable for warehousing, logistics, and tool management scenarios.
The device supports Bluetooth Advertising and positioning applications,
serving as a data acquisition node in asset management systems to enable
asset status identification and location tracking, improving management
efficiency. With stable signal coverage, MTB12 meets mid-to-long range
identification requirements and is suitable for large-scale asset deploy-
ments.
The product adopts a replaceable battery design, allowing quick on-site
maintenance and battery replacement, which helps extend service life and
reduce maintenance costs. It also supports IP67 protection. The device
supports wireless installation, enabling flexible deployment in indoor and
outdoor environments, and is suitable for long-term tracking and manage-
ment of pallets, turnover boxes, tools, and various production assets.
MTB12 features IP67 protection, effectively preventing dust ingress and exposure to rain. It is suitable for warehousing,
logistics, and certain outdoor asset management scenarios. Reliable protection helps reduce failures and replacements
caused by environmental factors, improving overall system reliability.
KEY FEATURES
PRODUCT VALUE
IP67 protection,
suitable for harsh
environments
Replaceable battery
design, reducing
maintenance cost
Compact design
with stable signal
coverage
IP67 Protection for Harsh Environments
MTB12 adopts a replaceable battery design, enabling quick on-site maintenance. Combined with low power consumption, it
supports long-term standalone operation. When the battery is depleted, only the battery needs to be replaced instead of the
entire device, significantly reducing replacement and maintenance costs. It is suitable for long-term fixed deployments and
helps improve overall ROI.
Replaceable Battery Design, Lower Maintenance Cost
MTB12 has a compact structure, allowing easy installation on pallets, turnover boxes, and various tools, adapting to differ-
ent asset types. With optimized wireless communication performance, it provides stable coverage for identification, meeting
mid-to-long range asset tracking requirements and improving deployment flexibility and system efficiency.
Compact Design with Stable Signal Coverage
67
02
Version: 001
APPLICATION SCENARIOS
MTB12 can be deployed on pallets, turnover boxes, and various logis-
tics carriers to help track inventory distribution and asset flow. In
dynamic warehouse environments with frequent location changes or
fast operations, it reduces manual searching and verification, improving
inbound, sorting, and outbound efficiency. Its compact design enables
flexible installation across different warehouse assets, supporting
various operational models and layouts.
Warehousing & Logistics | Inventory Flow and
Operational Efficiency
In manufacturing and construction scenarios, MTB12 can be applied to
tools and auxiliary equipment to support resource allocation and usage
status identification, improving on-site operational efficiency. By assist-
ing in tracking tool usage locations and movement, it helps reduce
redundant allocation and idle resources, optimizing production and
construction workflows.
Industrial Tools | On-site Operation and Resource
Allocation
MTB12 can be deployed on production equipment or critical assets to
support structured inspection processes. In scenarios with widely
distributed equipment or frequent inspection tasks, it enables mainte-
nance personnel to quickly identify inspection targets and coverage,
improving execution efficiency. It also helps establish clearer mainte-
nance workflows, enhancing standardization and overall management
transparency.
Equipment Maintenance | Inspection and Mainte-
nance Support
PRODUCT SPECIFICATIONS
03
Version: 001
BASIC PARAMETERS
Model
Chip
Bluetooth Version
Material
Color
Dimensions (L × W × H)
Weight
Protection Rating
Battery
Battery Life
Operating Temperature
Operating Humidity
Tx Power
Advertising Interval
Advertising Range
LED
Button
APP
Installation
Connectivity
OTA
MTB12
Low-power Bluetooth chip
BLE 5.0
PC
White
41.6*25.6*6mm
8g
IP67
225mAh Replaceable Battery
Up to 5 years (default settings: INFO frame only, 0 dBm, 4000 ms)
-20℃ ~ 60℃
0% ~ 95% RH(non-condensing)
-54~4dBm(not configurable after factory)
100ms~10s(not configurable after factory)
Up to 150 m (open environment)
1*blue LED
None
BeaconSETPlus App(view only)
Double-sided tape / mounting hole
Non-connectable
Not supported
Note: A factory water resistance test report for IP67 is available.
ADVERTISING PARAMETERS
NOTES
The device operates in Advertising mode after power-on and is non-connectable.
All firmware settings are configured during manufacturing.
To extend battery life, it is recommended to select lower Tx Power and longer Advertising Interval before shipment.
Operation outside the specified temperature range may damage the device.
For further inquiries, please contact the sales or technical support team.
●
●
●
●
04
Version: 001
DEVICE OPERATIONS
Power-on
Remove the insulation tab to power on; the blue LED stays on for 3 s. No need to remove the battery holder when remov-
ing the tab.
Power off
Remove the battery to power off.
Advertising Check
Use the BeaconSET Plus App to check if the device is advertising.
ON
OFF
Type / Channel
iBeacon
INFO
Combination
Field
UUID
Major
Minor
Measured Power
Tx power
Interval(ms)
MAC Address
Battery Level
Device Name
Tx power
Interval(ms)
Temperature
Battery Level
MAC Address
Tx power
Interval(ms)
E2C56DB5-DFFB-48D2-B060-D0F5A71096E0
0
0
-59dBm
0 dBm
1000ms
Factory Assigned
System default
MTB12
0 dBm
4000ms
Temperature Data
System default
Factory assigned
0 dBm
4000ms
Value
PS: MTB12 supports optional sensor configurations based on requirements.
If no sensor is mounted, the INFO frame is enabled by default.
If an ACC sensor is mounted, the INFO frame is enabled by default; when motion is detected, the iBeacon frame is triggered
with a 1 s Advertising Interval for 10 s.
If a temperature sensor is mounted, the Combination frame is enabled by default.
CERTIFICATIONS
Note: Certification numbers are available upon request. For additional certifications, please contact our sales team.
BATTERY SAFETY PRECAUTIONS
Replacement of a battery with an incorrect type that can defeat a safeguard;
Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion;
Leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage
of flammable liquid or gas;
A battery subjected to extremely low air pressure that can result in an explosion or the leakage of flammable liquid or gas.
CAUTION
Risk of fire or explosion if the battery is replaced by an incorrect type
●
●
●
●
05
Version: 001
DEPLOYMENT INSTRUCTIONS
Double-sided Tape Mounting
The surface should be smooth and dry, such as ceramic,
glass/epoxy, acrylic, PBT, ABS, PC, or rigid PVC.
Recommended Surface
Clean the surface
before mounting.
Apply the tape and press firmly for 5 seconds,
then repeat several times.
Installation Steps
PACKAGING INFORMATION
Quantity
Net Weight
Gross Weight
Dimensions
70PCS
567g
649g
305*110*72mm
700pcs
5.76kg
7kg
320*235*400mm
Items
Outer CartonInner Box
06
Version: 001
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
FCC warning:
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority
to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposureconditionwithoutrestriction.
www.minewstore.com
www.minew.com
info@minew.com
SHENZHEN MINEW TECHNOLOGIES CO., LTD.
07
Version: 001
Statement of Rights:
Disclaimer:
DECLARATION
The contents of this manual belong to the Manufacturer of Minew Technologies Co., LTD, Shenzhen, and are protected by
Chinese laws and applicable international conventions related to copyright laws. The contents can be revised by the company
according to the technological development without prior notice. Anyone, companies, or organizations cannot modify the
contents and cite the contents of this manual without Minew's permission, otherwise, Violators will be held accountable
according to law.
Minew team reserves the right to the final explanation of the document and product differences. And it is not responsible for
liability of property or personal injury with the wrong operation if users develop related products without checking the techni-
cal specifications of this manual.
QUALITY ASSURANCE
The factory has already obtained the certification of ISO9001 Quality System. Each product has been strictly tested (tests
include transmission power, sensitivity, power consumption, stability, aging, etc.).
Warranty Period: 12 months from the date of shipping (Battery and other accessories excluded).
