DIMENSIONAL RENDERINGS
Model No. Height Width Depth
Model No. Height Width Depth
C3FHSINK
C3FHSINK
Cutout Dimensions for Island
Overall Product Dimensions
10"
C3FHSINK INSTALL GUIDE
25 1/4"
TOP VIEW
COUNTERTOP
OVERHANG
SINK
OPENING
1 1/4"
CUTOUT WIDTH
FRONT VIEW
OPENING
HEIGHT
10"
INCLUDING
COUNTERTOP
DOORS / DRAWERS
OPENING WIDTH
OPENING
HEIGHT
1
1
/2" MIN
CUTOUT WIDTH
27
1
/2
"
20
5
/8"
10
7
/8"
30"
27
1
/2"
20
5
/8"
27
1
/2"
CFHSINK comes with a standard drain, p-trap and single supply faucet.
A drain and strainer is also included with the sink
When the CFHSINK is located in an area with humidity and ice is placed inside, the cooler can "sweat" on the exterior of the box. Be aware that even with
the drain in, this sweat could drop into your cabinet.
The faucet included is a single hose cold water only and uses 7/8" opening. The opening can be increased to 1 3/8" to accommodate a faucet with hot and
cold lines.
Install Notes:
