Sencor SVC 8330BK 4AAAA Bagged Vacuum Cleaner EcoPower User Manual

SVC 8310BK 4AAAA EcoPower

SVC 8330BK 4AAAA EcoPower

BAGGED VACUUM CLEANER

Translation of the original manual

SVC 8310BK 4AAAA EcoPower

SVC 8330BK 4AAAA EcoPower

9 8 7 6 5 4 3 1 2

28 29 30

B1 B2

C1 C2

- 1 -

10/2024

2024, .

Bagged Vacuum Cleaner

User Manual

Important Safety Instructions

READ CAREFULLY AND STORE FOR FUTURE USE.

• This vacuum cleaner may be used by children

8 years of age and older and by persons with physical

or mental impairments or by inexperienced persons,

if they are properly supervised or have been informed

about how to use this vacuum cleaner in asafe manner

and understand the potential dangers. Children must

not play with the vacuum cleaner. Cleaning and

maintenance performed by the user must not be

performed by unsupervised children. Keep the vacuum

cleaner and its accessories out of reach of children that

are younger than 8 years of age.

• This vacuum cleaner is designed for use in households,

offices and similar types of areas. Do not use in industrial

surroundings.

• Do not expose the vacuum cleaner to direct sunlight and

do not place it near an open fire or appliances that are

asource of heat.

• Before connecting the power cord to apower socket,

check that the technical details on the vacuum

cleaner’srating label match the electrical voltage in the

socket.

• Make sure the power cord is not touching ahot surface or

sharp objects.

SÁČKOVÝ VYSAVAČ

- 2 -

10/2024

2024, .

• Do not submerge the vacuum cleaner under water or any

other liquid and do not rinse it under running water.

• Before turning on the vacuum cleaner, make sure that the

dust bag is inserted inside and that the inflow micro-filter

and the outflow HEPA filter are installed in their place.

• When the vacuum cleaner is running, ensure that the air

outlets and the suction opening are not blocked.

• Do not use the vacuum cleaner to vacuum the following

items:

– smouldering cigarettes, burning items, matches or

embers;

– water and other liquids;

– flammable or volatile materials;

– sharp items, e.g. broken glass, needles, pins, etc.;

– flour, wall plaster, cement and other building materials;

– larger pieces of paper or plastic bags, which can easily

block the suction opening.

• Vacuuming of some types of floors or floor surfaces can

create aelectrostatic discharge, which presents no danger

to the user.

• Do not place the suction nozzle or tube against any parts

of the face.

• Always turn off the vacuum cleaner and disconnect it from

the power socket when leaving it without supervision, after

finishing using it and before cleaning it.

• Disconnect the power cord from the power socket by

pulling on the plug, never pulling on the cord. Otherwise,

this could damage the power cord or the socket. Hold the

power cord in your hand when winding it up.

- 3 -

10/2024

2024, .

• In the event that the power cord is damaged, it must

be replaced by an authorised service centre or by

asimilarly qualified person, this will prevent the creation

of adangerous situation. It is forbidden to use the vacuum

cleaner if it has adamaged power cord.

• Do not use the vacuum cleaner if it is not working

correctly, if it has been damaged or has been submerged

in water. Do not repair the vacuum cleaner yourself or

make any adjustments to it. Have all repairs performed

at an authorised service centre. By tampering with the

appliance, you risk voiding your legal rights arising from

unsatisfactory performance or quality warranty.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

EXPLANATION OF SYMBOLS PLACED ON THE PRODUCT OR INTHE ACCOMPANYING DOCUMENTATION

This product meets all the basic requirements of the applicable EU directives.

This symbol on products or original documents means that used electric or electronic products must not be added to ordinary municipal

waste.

Safety class for electrical shock protection:

Class II – Electrical shock protection is provided by double or heavy-duty insulation.

- 4 -

10/2024

2024, .

• Thank you for purchasing our SENCOR product; we hope it will serve

to your satisfaction.

• Before using this appliance, please familiarise yourself with the user

manual, even if you are already familiar with using similar types of

appliances. Use the appliance only as described in this user manual.

Keep the manual for future reference.

• It is recommended to keep the original packaging, packing material,

receipt and confirmation of the extent of the seller’sliability or warranty

certificate at least for the duration of the legal right of defective

performance or quality guarantee. When transporting the appliance,

we recommend packaging it again in the original box provided by the

manufacturer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DESCRIPTION OF THE VACUUM CLEANER AND ITS ACCESSORIES

A1 Automatic power cord winding

button

A2 Filter handle

A3 Electronic suction power

control

A4 Lid of storage area for dusting

brush and crevice nozzle

A5 Full dust bag indicator

A6 Lock for lid of storage area

A7 Flexible hose connection hole

A8 Top cover lock

A9 Integrated handle

A10 On/Off button of the vacuum

cleaner

A11 Groove for the horizontal

parking position

A12 Rubber-coated rear travel

wheel

A13 Front rotating travel wheel

A14 Groove for the vertical parking

position

A15 Removable grill of the outflow

HEPA filter

A16 Washable outflow HEPA filter

is placed behind the grill.

A17 Dust bag*

A18 Dust bag holder

A19 Grill of the inflow micro-filter

A20 Washable inflow micro-filter

is placed in the grill.

A21 Flexible hose

A22 XXL telescopic metal tube

A23 Floor nozzle with an

extensible brush and DEEP

cleaning and EASY cleaning

switch

A24 Flap for extending and

retracting the brush

A25 Long flexible crevice nozzle

A26 Dust brush (located in the

vacuum cleaner)

A27 Gravel nozzle (located in the

vacuum cleaner)

A28 Mini turbo brush

A29 Turbo brush (SVC 8330BK

model only)

A30 Parquet floor nozzle

(SVC 8330BK only)

Note:

One disposable synthetic dust bag is included with the

product. Synthetic dust bags last longer, are more durable

and provide better filtration than standard paper bags.

Note:

The dusting brush and crevice nozzle are stored in the

storage area under the lid.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INTENDED USE OF THE ACCESSORIES

• The universal floor nozzle with an extensible brush A23 is intended for

all floor types. Extend the brush when vacuuming smooth hard floors,

and retract it when vacuuming carpets. To extend and retract the

brush, use flap A24 on the floor nozzle. Floor nozzle also has aswitch

for extending out atravel roller. This switch is located in the centre

of the floor nozzle and it has two positions - deep cleaning and easy

cleaning. The deep cleaning position (the travel roller is retracted) is

ideal for deep and thorough vacuuming of carpets. The easy cleaning

position (the travel roller is extended) makes movement over the

vacuumed surface easier. We recommend to slightly lift up the floor

nozzle when you wish to switch to the easy cleaning position.

• Parquet floor nozzle A30 ensures perfect yet gentle vacuuming of

smooth hard surfaces, thanks to the 100% natural bristle brush. You

can vacuum scratch-sensitive floors such as wooden and floating

floors, tiles, linoleum, etc.

• Turbo brush A29 and mini turbo brush A28 are great helpers for

removing pet hair, hair etc. and are also suitable for vacuuming hard-

to-reach areas. You can use it not only at home, but alsoinyour car.

Quickly and effectively remove hair, animal hair andother dirt from car

seats, upholstery, pillows andother textile surfaces.

• The long flexible crevice nozzle A25 serves to vacuum very hard-to-

reach places anywhere in your car.

• The crevice nozzle A27 can be used for vacuuming hard-to-reach

places and the dusting brush A26 is used for vacuuming various types

of furniture.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PREPARING FOR USE

• Make sure that the dust bag, inflow micro-filter and outflow HEPA filter

are properly installed.

• Insert the end of the flexible hose into the hole A7 and turn it

clockwise to secure it in place.

Note:

For removal, turn the end of the hose anticlockwise and pull

it out of the hole A7.

• Attach the telescopic tube on to the handle of the flexible hose. Slide

the ring that is located on the telescopic tube towards the handle

of the flexible hose to release the extension lock on the telescopic

tube. After releasing the lock, set the length of the tube by sliding its

extensible part in or out. When the ring is released, it will lock in at the

set length.

• Select the type of accessory you want to use and attach it to the free

end of the telescopic tube. The accessory can be attached directly to

the flexible hose handle.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

USING THE VACUUM CLEANER

• Pull on the power plug to wind out the required length of the power

cord and connect it to apower socket.

Attention:

The yellow mark on the power cord indicates the

approaching end of its length, and the red mark

indicates the complete end of its length. Do not

attempt to pull the power cord past this mark.

• To start the vacuum cleaner, press button A10. Suction power can

be set using the electronic control A3 or the mechanical flap on the

handle of the flexible hose.

• When you have finished using the vacuum cleaner, turn it off by

pressing button A10 and disconnect the power cord from the power

socket. To wind the power cord back into the vacuum cleaner, press

and hold button A1 until its entire length is wound up. Gently hold the

power cord with one hand while winding it up.

Note:

If the power cord is not wound up completely, release

button A1, and pull the power cord out of the vacuum

cleaner by approximately 50 cm and then try again to

wind it up.

PARKING POSITION OF THE VACUUM CLEANER

• When not using the vacuum cleaner, you may put it in the parking

position. For the horizontal parking position, slide the stopper on the

nozzle A23 or into the groove A11, see fig. B1.

Bagged Vacuum Cleaner

User Manual

- 5 -

10/2024

2024, .

• For the vertical parking position, first set the shortest length of the

telescopic tube. Then put the vacuum cleaner into avertical position

and slide the stopper on the nozzle into the groove A14, see fig. B2.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

MAINTENANCE AND CLEANING

• Before cleaning it, always make sure that the vacuum cleaner is

turned off and disconnected from the power socket.

Changing the dust bag

• The red coloured indicator A5 signals the need to replace the dust

bag.

• Release the lock A8 and tilt open the top cover of the vacuum cleaner.

Remove the used dust bag from the holder A18 and insert anew bag

intended for this type of avacuum cleaner in its place. After replacing

the bag, close the top cover of the vacuum cleaner. It will not be

possible to close the top cover of the vacuum cleaner unless the bag is

correctly inserted in the holder A18.

• If the dust bag is not replaced in time, the vacuum cleaner’ssuction

power will be reduced.

Cleaning and replacing the inflow micro-filter and the outflow HEPA filter

• Release the lock A8 and tilt open the top cover of the vacuum cleaner.

Slide the grill out of the vacuum cleaner and take the micro-filter out of

it. Rinse it under running lukewarm water and allow to dry naturally.

Then reinsert it and close the cover. In the event that the micro-filter is

showing signs of wear or it is heavily soiled, replace it with anew one.

• Release and remove the grill A15. Remove the HEPA filter from the

vacuum cleaner. In the case of light soiling, tap it out. We recommend

doing this away from living areas. In the event of greater soiling, wash

it under aweak current of running lukewarm water so that the water

washes the dirt out of the folds. Allow the HEPA filter to dry naturally,

then reinsert it and secure it in place with the grill. It is recommended

to replace the HEPA filter with anew one after 6 months of use.

• When filters are soiled, their effectiveness is reduced, so do not

neglect their cleaning.

Attention:

Before putting the filters back into the vacuum

cleaner, make sure that they are completely dry.

Cleaning Flexible Hose, Telescopic Tube and Accessories

• If the attachment is dirty, dismantle it from the vacuum cleaner and

remove any dirt (dust, hair, pet hair, etc.).

• To make it easier to remove the hair coiled on the rotary brush, you

can cut it with scissors.

Cleaning the Turbo Brush

• Release the latches on the sides of the turbo brush, see picture C1.

Remove the front cover and remove all dirt, hair, pet hair, etc. from the

rotary brush and the inner compartment. After cleaning, replace the

front cover and secure it with the locking latches. Press to release the

latches of the cover, which is located underneath the turbo brush, see

picture C2. Remove the cover and remove the dirt from the inside of

the turbo brush. Put the cover back in place. As soon as it is in place,

there is an audible click.

Cleaning the outer surface of the vacuum cleaner

• Clean the outer surface using adry or alightly dampened cloth. Then

wipe it thoroughly dry.

• For cleaning the vacuum cleaner, do not use steel wool, abrasive

cleaning products, solvents etc.

• Do not submerge the vacuum cleaner under water or any other liquid

and do not rinse it under running water.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TECHNICAL SPECIFICATIONS

Rated voltage range ...............................................................................220−240~V

Rated frequency ...........................................................................................50-60 Hz

Rated power input ..............................................................................................800 W

Electrical shock protection class ............................................................................... II

Noise level ....................................................................................................... 68 dB(A)

Dust bag capacity ........................................................................................................ 3l

HEPA filter efficiency class ....................................................................................H13

Length of the power cord ......................................................................................8 m

Operational radius ....................................................................................................11 m

The declared noise emission level is 68 dB(A), which represents alevel

Aof sound power with respect to areference sound power of 1 pW.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED

PACKAGING MATERIAL

Dispose of used packaging material at the location designated by the

municipality for waste disposal.

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT

For proper disposal and recycling of these products, deliver them to

designated collection points. Alternatively, in some European Union states

or other European countries the products can be returned to the local

retailer when buying an equivalent new product. By properly disposing of

this product, you help preserve valuable natural resources and contribute

to preventing potential negative impacts on the environment and human

health resulting from improper waste disposal. For further details, contact

your local authorities or the nearest collection point. Fines may be

imposed for improper disposal of this type of waste in accordance with

national regulations.

For Business Entities in European Union States

To dispose of electric or electronic equipment, request necessary

information from your retailer or supplier.

Disposal in Other Countries Outside the European Union

To dispose of this product elsewhere, request necessary information on

the correct disposal method from local authorities or your retailer.

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

We reserve the right to change the text and technical specifications.

Sencor SVC 8330BK 4AAAA Bagged Vacuum Cleaner EcoPower

Product's Documents

User Manual

Specifications

Sencor SVC 8330BK Questions and Answers
