VS2201 / VS2202
FUNCTIONS — VS2201/ VS2202
PRODUCT FEATURES — VS2201/ VS2202
IMPORTANT SAFETY NOTICE & TIPS HELPFUL HINTS
OPERATION MANUAL — VS2201/ VS2202
PACKAGE CONTENTS
TECHNICAL SPECIFICATION
TROUBLESHOOTINGTIPS ON BAG/ROLL CUTTER
STORAGE GUIDECLEANING AND MAINTENANCE
①
Unplug the appliance before cleaning.
Wipe the outer surface with a soft soapy cloth. Wipe away
any food or liquid on the vacuum chamber with paper towel.
Dry the appliance thoroughly before using it again.
Do not immerse the appliance in water or other liquids.
Prevent water or other liquids from entering the AC power
port on the appliance.
Do not clean the appliance with abrasive cleaning agent
to avoid damaging the surface.
②
③
④
⑤
Please read the user manual carefully before using and follow the safety
instructions.
1. Check if the Voltage indicated on the appliance is corresponding to the local mains voltage before
you connect the appliance.
2. Do not operate the appliance with a damaged power cord or plug. Do not operate the appliance if
it malfunctions or is in any way damaged. If the cord or the appliance is damaged, it must be
returned to an authorized service center for repairing.
3. To disconnect, unplug the power cord from the electrical outlet. Do not disconnect by pulling on cord.
4. Do not use an extension cord with the appliance.
5. If the supply cord is damaged, contact the manufacturer, or its service agent or similarly qualified
person to buy it in order to avoid a hazard.
6. When it is not in use or to be cleaned, unplug cord from the power outlet.
7. Do not use the appliance on wet or hot surfaces, or near heat source.
8. Do not immerse any part of the appliance, power cord or plug in water or other liquids.
9. A short power cord is provided to reduce the risks of becoming entangled in a long cord or tripping over.
10. Use accessories or attachments recommended by the manufacturer only.
11. Use the appliance for its intended use only. Household use only.
12. Closely supervise children when using any electrical appliance. Do not allow the appliance to be
used as a toy.
13. CAUTION: HOT SURFACE. DO NOT TOUCH.
14. Wait for 60 seconds before using it again.
15. To reduce the risk of electric shock, this product has a polarized plug (one blade is wider than the
other). This plug is intended to fit in a polarized outlet only one way. If the plug does not fit fully
in the outlet at the beginning, reserve the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet. Do not change the plug in any way.
1. Do not overfill the bag. Always leave at least 6-8cm between bag contents and top of the
bag.
2. Clean the opening end of the bag inside and outside. Flattern the bag opening.
3. When vacuum packaging a large item, to prevent wrinkles in the seal, gently stretch bag
flat before placing it into the vacuum chamber.
4. Make sure the bag is dry. It will be difficult to make a tight seal if the bag is wet.
5. For best results, perishables still need to be frozen or refrigerated after vacuum sealing
process.
6. When you are vacuum sealing items with sharp edges (such as dry spaghetti, silverware,
etc.), protect the bag from punctures by wrapping the item in soft cushioning material,
such as a paper towel. You may use a canister instead of a bag.
7. When using canisters, always leave 2.5 cm / 1 in of space at the top of canister.
8. Pre-freeze fruits vegetables before vacuum sealing for the best results.
9. Allow the appliance to cool for 1 minute between uses to avoid activating overheating
protection.
10. If you are not sure whether your bag was sealed properly,simply reseal the bag.
11. For best results, use bags and canisters produced by the manufacturer.
12. Microwave: Don't heat sealed food in microwave.
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.
-60kPa -80kPa
Room Temperature (25±2℃)
Bread
Rice/ Flour
Tea Leaves
3-6 Months
1-2 Days
3-5 Months
5-6 Months
＞1 year
6-8 Days
＞1 year
＞1 year
Storage Life with Our
Vacuum Sealing Accessory
In the Freezer (-16~-20℃)
Meats
Seafood and Fish
3-5 Months
3-5 Months
1 Year
1 Year
Storage Life with Our
Vacuum Sealing Accessory
Cooked Meats
In the Refrigerator (5±2℃)
Meats
Seafood and Fish
Vegetables
Eggs
4-6 Days
Normal Storage Life
Normal Storage Life
Normal Storage Life
2-3 Days
1-3 Days
3-5 Days
10-15 Days
10-14 Days
8-9 Days
4-5 Days
7-10 Days
30-50 Days
Storage Life with Our
Vacuum Sealing Accessory
Peanuts/ Beans
NO. Description
Description
SpecificationQtyImage
BACK
Vacuum Sealer
AC Power Cord
Accessory Hose
1
5 pcs(20x30cm)
1 roll(20x200mm)
Bag
Roll
1
1
1
2
3
4
5
Item Number
VS2201/ VS2201
Rated Voltage
�
AC100-120V
�
AC220-240V
Rated Frequency
50Hz - 60Hz
Rated Power
110W
Sealing time
6-12 seconds
Vacuum Level
Dimensions
372*144*72MM (L*W*H)
Net weight
1.20 kg
Gross weight
1.55 kg
FRONT
210mm
94mm
③ VAC & SEAL BUTTON
②
SEAL BUTTON
④
STOP BUTTON
① DRY/ MOIST FOOD SETTING BUTTON
INDICATOR LIGHTS
⑤
It will take longer time to seal moist food than dry food.
The indicator light will be illuminated when the corresponding
function selected.
Close the cover, press it to vacuum the bag and seal it. (Wait for
60s between uses to allow appliance to cool down)
During any working status, press STOP button to stop current
processing immediately.
The indicator light will be illuminated when VAC/VAC SEAL/SEAL/VAC
& PULSE working.
VAC & PULSE BUTTON
⑥
This button has two uses:
1. Press to vacuum canister/wine stopper with accessory hose.
2. Press and hold it to manually control the vacuum process and then
press the Seal button to seal the bag after vacuuming.
Close the cover, press the SEAL button if you only want to seal the
bag. (Wait for 60s between seals to allow appliance to cool down)
③ Air is removed from the bag, but now re-entered.
②
Appliance is plugged in, but cannot vacuum.
④
Note:
① Nothing happens when the power cord is plugged into appliance.
A. Make sure the power cord is not damaged.
B. Make sure the power cord is correctly plugged into the electrical outlet and appliance.
A. Check if there is a hole or puncture on the bag. It may be punctured by sharp items. Use a new
bag if necessary.
B. Check the sealing seam. Any wrinkle along the sealing seam may cause air re-entering. If yes,
simply cut the sealed edge and re-seal.
C. If there is moisture or liquid at the opening end , cut the bag and wipe it away. Then choose MOIST
FOOD setting and reseal.
D. If the food has been stored for a long time and the bag is full of gases, it may spoil and suggest
to discard.
1. To prevent the appliance from overheating, allow it to cool for 60 seconds between uses. Keep the
lid open to accelarate heat dissipation.
2. If the bag melts, the sealing strip may be overheated. Allow the appliance to cool for 60 seconds
before using it again.
3. For the best preservation, do not reuse the bags after storing raw meats, fish or greasy foods. Do
not reuse the bags after simmering or microwaving.
A. Ensure the lid is properly closed.
B. Ensure the opening end of the bag is correctly placed into the vacuum chamber.
C. Check if the bag is punctured.
D. Check if the foam sealing gasket is deformed or damaged.
③ VACUUM NOZZLE
②
SEALING FOAM GASKET
④
VACUUM CHAMBER
① SILICONE CONTACT BAR
SEALING STRIP
⑤
Work with silicone sealing gasket to make optimal sealing.
An airtight chamber for vacuuming.
Work with silicone contact bar for sealing function.
⑦
BUILT-IN CUTTER
Close the upper lid cover, pull out the desired bag length, hold
the bag with one hand, and slide the bag cutter across the roll
to obtain the desired bag length.
Vacuum view window - Allows the user to see the correct
position of the bag in the vacuum Chamber.
TRANSPARENT WINDOW
⑥
Objective to ensure vacuum chamber is airtight so the bag can be
vacuumed properly.
This is used for removing air from bags / canisters / bottles.
Do not block the vacuum nozzle when vacuuming a bag. Accessory
hose is required when vacuuming a canister or bottle.
① SILICONE CONTACT BAR
② SEALING FOAM GASKET
③ VACUUM NOZZLE
④ VACUUM CHAMBER
⑤ SEALING STRIP
Close the upper lid cover, pull out the desired bag length, hold the bag
with one hand, and slide the bag cutter across the roll to obtain the
desired bag length.
NTC Thermistor-temperature sensor:
Smartly monitor the temperature of the appliance. Protection mode
will be activated automatically when overheat , with lights flash and
operation unavailable. The appliance is back to normal working once
cooled and the lights stop flashing.
①
DRY/ MOIST FOOD SETTING BUTTON
⑤ INDICATOR LIGHTS
⑥ VAC & PULSE BUTTON
②
SEAL BUTTON
③ VAC & SEAL BUTTON
④
STOP BUTTON
If several lights flasing at the same time after continuous working, overheating
protection activated. Please wait for 5-10 minutes for cooling down and the
appliance will be back in normal mode.
1. Put the open end of bag into vacuum
chamber.
2. Close the lid and press on both end of
the lid. You will hear a “clicking” sound if
the lid is properly clocked.
3. a. Press VAC SEAL if you want to vacuum
& seal the bag.
b. Press SEAL button if you want to seal
the bag only
c. Press VAC/PULSE to vacuum
canister/wine stopper with accessory hose.
d. Press and hold VAC/PULSE to manually
control the vacuum process and then press
the SEAL button to seal the bag.
4. When SEAL indicator Light turns
off, process completed. Press unlock
button at both ends to open the lid and
remove the sealed bag.
⑥ BUILT-IN CUTTER
⑦ TRANSPARENT WINDOW
1
3
4
2
