Quick Installation Guide
Images are for demonstration only.
1 Product Overview
1910013921 REV1.0.1©2025 TP-Link
USB Type-C 3-in-1 Hub
For connecting to
your host device.
USB-C Connector
For unidirectionally
charging your host
device when connected
to a PD charger.
PD 3.0; Up to 100W
* Does not support data
transfer.
USB-C PD (Power
Delivery) Port*
Up to 4K@60Hz
(backward compatible)
HDMI® Port
USB 3.0;
Up to 5 Gbps data transfer
USB-A Port
Input
PD: 5V/3A, 9V/3A, 12V/3A,
15V/3A, 20V/5A
Plug and Play on
Windows, macOS,
iPadOS, iOS, ChromeOS,
Linux, and Android.
Supported Systems
USB-C Connector: 5V/3A
Note: The ports’ actual performance may vary based on
your host device specications.
USB-C Connector
USB-C Port
Tips:
2. If you need to connect a PD charger to the
hub’s USB-C PD port, please:
A) Notice that it only has the charging
function and is input only.
B) Use an original or certied PD charger to
charge your host device. The output of
the PD charger should meet the input
specications of the USB-C PD port.
This hub supports the Plug and Play feature. Plug
the USB-C connector into your host device, then
plug in your external peripheral into the
corresponding port of the hub.
2 Using the Hub
1. When not in use, please unplug or remove
the external peripherals from the hub rst,
and then unplug the hub from your host
device.
Note: A PD charger (not included) is not required. If you wish to use a PD
charger to charge your host device, please refer to Tips (2B).
This is a class B product. In a domestic environment, this
product may cause radio interference, in which case the user
may be required to take adequate measures.
CE Mark Warning
Product Name: USB Type-C 3-in-1 Hub
Model Number: UH3020C
Responsible party:
TP-Link Systems Inc.
Address: 10 Mauchly, Irvine, CA 92618
Website: http://www.tp-link.com/us/
Tel: +1 626 333 0234
Fax: +1 909 527 6804
E-mail: [email protected]
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide
FCC Compliance Information Statement
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV technician
for help.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received,
including interference that may cause undesired operation.
TP-Link hereby declares that the device is in compliance
with the essential requirements and other relevant
provisions of directives 2014/30/EU, 2011/65/EU,
2009/125/EC and (EU)2015/863.
The original EU declaration of conformity may be found at
https://www.tp-link.com/en/support/ce/
TP-Link hereby declares that the device is in compliance
with the essential requirements and other relevant
provisions of the Electromagnetic Compatibility
Regulations 2016.
The original UK declaration of conformity may be found at
https://www.tp-link.com/support/ukca/
Safety Information
• When the product has a power button, the power button
is one of the ways to shut o the product; when there is
no power button, the only way to completely shut o
power is to disconnect the product or the power adapter
from the power source.
• Do not attempt to disassemble, repair, or modify the
device. If you need service, please contact us.
• Keep the device away from water, re, humidity or hot
environments.
• This equipment can be powered only by equipments
that comply with Power Source Class 2 (PS2) or Limited
Power Source (LPS) dened in the standard of IEC
62368-1.
Recycling
This product bears the selective sorting symbol for
Waste electrical and electronic equipment (WEEE).
This means that this product must be handled
pursuant to European directive 2012/19/EU in
order to be recycled or dismantled to minimize its
impact on the environment.
User has the choice to give his product to a competent
recycling organization or to the retailer when he buys a
new electrical or electronic equipment.
The terms HDMI, HDMI High-Denition Multimedia Interface, HDMI
trade dress and the HDMI Logos are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc.
Operating Temperature: 0°C~40°C (32°F~104°F),
Storage Temperature: -40°C~60°C (-40°F ~140°F)
Industry Canada Statement
CAN ICES-3 (B)/NMB-3(B)
Any changes or modications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
Note: The manufacturer is not responsible for any radio or
TV interference caused by unauthorized modications to
this equipment. Such modications could void the user’s
authority to operate the equipment.
We, TP-Link Systems Inc., has determined that the
equipment shown as above has been shown to comply
with the applicable technical standards, FCC part 15.
There is no unauthorized change is made in the
equipment and the equipment is properly maintained and
operated.
Issue Date: 2025-01-20
For technical support, replacement services, user guides, and
more, please visit https://www.tp-link.com/support, or simply
scan the QR code.
安全諮詢及注意事項
• 請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。
• 清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進
行清潔。
• 注意防潮，請勿將水或其他液體潑灑到本產品上。
• 插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵
塞或覆蓋開口。
• 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放
在密閉位置中。
• 不要私自拆開機殼或自行維修，如產品有故障請與原廠或代理商聯繫。
RECYCLING
This product bears the selective sorting symbol for Waste
electrical and electronic equipment (WEEE). This means that
this product must be handled pursuant to European
directive 2012/19/EU in order to be recycled or dismantled
to minimize its impact on the environment. User has the
choice to give his product to a competent recycling
organization or to the retailer when he buys a new electrical
or electronic equipment.
Indoor use only
DC voltage
AC voltage
Energy eciency marking (level VI)
Polarity of output terminals
Class II equipment
Operator’s manual
Caution
Explanation of the symbols on the product label
Symbols may vary from products.
Note: The product label can be on the product and its I.T.E. power supply.
Pb
PCB
單元
外殼
塑料组件
○ ○
Cd
○
○
○
○
g
○
○
○
CrV
○
○
○
○
PBB
○
○
○
○ ○
PBDE
○
○
○
○
配件及其他
備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百
分比含量超出百分比含量基準值
Note 1：“Exceeding 0.1 wt %” and “exceeding 0.01 wt %”
indicate that the percentage content of the restricted
substance exceeds the reference percentage value of
presence condition.
備考2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基
準值。
Note 2：“○” indicates that the percentage content of
the restricted substance does not exceed the percentage of
reference value of presence.
備考3.〝�〞係指該項限用物質為排除項目。
Note 3：The “�” indicates that the restricted substance
corresponds to the exemption.
