ASSEMBLY INSTRUCTIONS
WalStor
®
Wall Grid Shelving
CAUTION
INSPECT CONTENTS IMMEDIATELY AND FILE CLAIM WITH DELIVERING
CARRIER FOR ANY DAMAGE. SAVE YOUR BOX AND ALL PACKING MATERIALS.
YOU ARE RESPONSIBLE FOR DAMAGE TO YOUR UNIT IF RETURNED IMPROPERLY PACKED.
EG10093 Revised 02/24
Before assembly, please note:
• Wall Grid Shelving is used in conjunction only with the optional wall mat of
Eagle’s WalStor
®
Modular Wall System.
• A secure means of fastening WalStor
®
, prior to mounting Wall Grid Shelving,
must be utilized. EAGLE GROUP WILL NOT BE HELD RESPONSIBLE FOR
CONSEQUENCES DUE TO IMPROPER INSTALLATION.
(End)
1) Unpack the wall grid shelf.
2) On wall mat, determine location of wall grid shelf.
(Note: allow for shelf length and 9˝ shelf height.)
3) Hook the rear of the wall grid shelf over the wall
mat wires (see below).
wall grid
shelf
wall mat
wire
