G40 Patio Globe String Light with speaker
Play/Pause
Lighting control
TF Slot
Power Switch
Long press ON/OFF
① Short press for model switch off->model 1->model 2->model 3
② Long press to enter Music rhythm mode with lighting
③ Short press to exit while in music rhythm mode and back to last lighting mode
TWS Pairing：
① When two light strings are powered on and neither is connected to a mobile phone,
both are in Blue tooth mode.
② Double press the power button to enter TWS Pairing
③ After successful pairing, the connected light string is the master device and the other
is the slave device.
(1) After connecting the light string, the master device will act as the left channel and the
slave device will act as the right channel.
(2) Both devices will be synchronized. If one of them is executed, the other one will also
execute the action at the same time.
(3) Double press the power button again to exit TWS network, and then double press it
again to exit the mobile phone's Bluetooth.
(4) The TWS network will be automatically disconnected when switch to TF mode.
Removing the TF card will automatically switch to Bluetooth mode When
in TF card mode.
Inserting a TF card will automatically switch to TF mode Note: Built-in
music recognition
Short press for next song / Long press for Volume up
① Search device“MH G40 SPEAKER BULB”
② Pair it automatically
Power Indicator/Type-C input
Recommended power Adapter: 5V DC 2A
Short press for previous song /
long press for volume down
TF mode switch Short press for
TF/Bluetooth mode
Specifications: Speaker:
Rated Power
Voltage range
CCT
CRI
Lumen
Working Temp.
Storage Temp.
:
:
:
:
:
:
:
8W (light 2W+Speaker 6W)
DC 4.5~5.5V
2700K
Ra≥80
10lm per bulb
-10°C~50°C
-10°C~50°C
Working humidity
Storage
Net weight
Total Length
Shell material
IP grade
:
:
:
:
:
:
:
:
:
:
≤95%
Dry and ventilated place
897g
8m(control cable included)
ABS+PVC+copper+silicon+hemp rope
IPX4
Name
Sound Channel
TWS
Speaker
MH G40 SPEAKER BULB
Mixed stereo/stereo (TWS mode)
YES
4 Ohm 6w Φ50
:
:
:
:
Bluetooth Version
sound pressure level
Working range
TWS model range
5.1
82db
10m
8m
TF card supports audio formats : MP3/FLAC
LWS-OL-G40
G40 Patio Globe String Light with speaker
G40 Patio Globe
String Light with speaker
FCC WARNING
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.Any
changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.NOTE: This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications However, there is no guarantee that interference will not occur in a
particular installation.If this equipment does cause harmful interference to radio or television
reception,which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.To maintain compliance with
FCC's RF Exposure guidelines, This equipment should be installed and operated with minimum
distance between 20cm the radiator your body: Use only the supplied antenna.
