1. Technical data
Power supply:
3V
Battery:
CR2032
Current consumption:
Max 25mA
Operating frequency:
433.92 MHZ
Dimension:
100 x 45 x 18mm
Range:
up to 50m
The range provided by the manufacturer is variable, depending on the conditions of the environment in which
the device operates. Factors that influence range include building structure, signal interference from other
devices, and so on.
2. Device description
LED diode
Control button
Batteries may contain components that cause health damage or serious environmental damage. Used
batteries should be disposed of in specially marked containers.
Store used and discharged batteries out of reach of children.
If the battery compartment does not close securely, stop using the product and keep it out of the reach of
children. If you suspect that batteries may have been swallowed or placed inside any part of the body, consult
a doctor immediately.
3. Programming / pairing
For specific operations, please refer to the motor, control box and receiver manual.
SVR02 Remote control
FCC Caution:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
