BN68-25143B-01
1
2
3
4
0.98 inches
(25 mm)
Unpacking and
Installation Guide
Scan this QR code
with your smart
phone to see
helpful videos.
65″- 75″55″
Power Cable Holder-Cable
Samsung
Smart Remote /
Battery (AAA) x2
Simple User Guide /
Remote control guide /
Regulatory Guide
5 6
7
8
55QN8*H
48.2 inches
(1224.0 mm)
27.9 inches
(708.0 mm)
2.0 inches
(52.0 mm)
29.3 inches
(744.0 mm)
30.3 inches
(769.0 mm)
8.6 inches
(218.0 mm)
54.6 inches
29.1 lbs
(13.2 kg)
29.8 lbs
(13.5 kg)
65QN8*H
56.8 inches
(1442.9 mm)
32.7 inches
(831.2 mm)
2.0 inches
(52.0 mm)
34.1 inches
(867.1 mm)
35.1 inches
(892.1 mm)
10.1 inches
(256.8 mm)
64.5 inches
37.9 lbs
(17.2 kg)
38.8 lbs
(17.6 kg)
75QN8*H
65.6 inches
(1666.6 mm)
37.7 inches
(957.8 mm)
2.1 inches
(52.3 mm)
39.1 inches
(993.8 mm)
40.1 inches
(1018.8 mm)
12.6 inches
(319.8 mm)
74.5 inches
50.7 lbs
(23.0 kg)
51.8 lbs
(23.5 kg)
* : 0~9, A~Z
VESA
x (mm) (mm)
x 4
(mm)
(inches)
(inches)
(inches)
55QN8*H 300 x 200 18-20
+
M8 1.25 7.7 18.2 12.3
65QN8*H 400 x 300 18-20
+
M8 1.25 10.6 20.5 10.3
75QN8*H 400 x 300 18-20
+
M8 1.25 11.6 24.9 14.3
* : 0~9, A~Z
: Wall-Mount Bracket
