READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
PLEASE LEAVE THESE INSTRUCTIONS WITH THIS UNIT FOR
THE OWNER.
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
IMPORTANT:
INSTALLER:
OWNER:
2-BOTT LE WINE COOLER
WINE COOLER
COS-24BIWCS
COS-24BIWCS-BK
Rev.2
5.01
USER & INSTALLATION
MANUAL
2
THANK YOU FOR YOUR PURCHASE
Thank you for your purchase. We know that you have many brands and
products to choose from and we are honored to know that you have decided
to take one of our products into your home and hope that you enjoy it.
COSMO Appliances are designed according to the strictest safety and
performance standard for the North American market. We follow the most
advanced manufacturing philosophy. Each appliance leaves the factory after
thorough quality inspection and testing. Our distributors and our service
partners are ready to answer any questions you may have regarding how to
install, use and care for your products. We hope that this manual will help you
learn to use the product in the safest and most effective manner.
Before using this product, please read through this manual carefully. Keep
this user manual in a safe place for future reference. Please ensure that other
persons using this product are familiar with these instructions as well.
If you have any questions or concerns, please contact the dealer from whom you
purchased the product, or contact our Customer Support at:
1-888-784-3108
Reach us online at:
www.cosmoappliances.com
3
TABLE OF CONTENTS
Wine Cooler Safety .......................................................................................... 4
Important Safety Instructions .......................................................................... 5
Before Loading & Plugging In .......................................................................... 7
Recommendations ............................................................................................ 8
Specifications ................................................................................................... 9
Installation Instructions .................................................................................. 10
Defrosting / Condensation ............................................................................. 12
Adjusting Wooden Shelves ............................................................................. 13
Reversibility of the Door ................................................................................. 14
Turning On Your Wine Cooler ......................................................................... 17
Display Operation Instructions ..................................................................... 19
Wine Serving Temperature Chart ................................................................. 20
Important Information About Temperature ................................................. 20
Cleaning Your Wine Cooler ........................................................................... 20
Power Failures ................................................................................................. 21
Troubleshooting Guide .................................................................................. 21
Warranty and Service .................................................................................... 23
4
WINE COOLER SAFETY
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on
your appliance. Always read and obey all safety messages.
WARNING
You can be killed or seriously injured if you don't
follow instructions.
This is the safety alert symbol.
This symbol alerts you to potential hazards that
can kill or hurt you and others.
All safety messages will follow the safety alert
symbol and either the word "WARNING" or
"CAUTION." These words mean:
CAUTION
A potentially hazardous situation which, if not
avoided, could result in minor or moderate
injury.
All safety messages will tell you what the potential hazard is, tell you how
to reduce the chance of injury, and tell you what can happen if the
instructions are not followed.
California Proposition 65 Warning
WARNING:
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
5
IMPORTANT SAFETY INSTRUCTIONS
• COSMO offers no guarantee for our
wine cooler if it is being used for any
purpose other than that for which it
was specifically designed. We cannot
be held responsible for any error in
this manual is not responsible or liable
for any spoil-age or damage to wines
or any other contents incidental or
consequential to possible defects of
the wine cooler.
• Warranty applies to the wine cooler
only and not to the content of the
COSMO wine cooler.
• This appliance can be used by
children aged from 8 years and above
and per-sons with reduced physical,
sensory or mental capabilities or lack
of experience and knowledge if they
have been given supervision or
instruction concerning use of the
appliance in a safe way and
understand the hazards involved.
Children shall not play with the
appliance. Cleaning and user
maintenance shall not be made by
children without supervision.
• Children should be supervised to
ensure that they do not play with the
appliance.
To reduce the risk of fire, explosion, electric shock, or injury when using your
wine cooler, follow these basic safety precautions:
• Please don’t put acidic items,
flammable and explosive goods into
wine cooler.
• THIS APPLIANCE IS INTENDED TO BE
USED IN HOUSEHOLD AND SIMILAR
APPLICATIONS SUCH AS:
1. Staff kitchen areas in shops, offices
and other working environments;
2. Farm houses and by clients in hotels,
motels and other residential type
environments
3. Bed and breakfast type
environments
4. Catering and similar non-retail
applications.
RISK OF CHILD ENTRAPMENT.
BEFORE
YOU THROW AWAY YOUR OLD WINE
CHILLER:
• Take off the doors.
• Leave the shelves in place so that
children may not easily climb inside.
• When disposing of the appliance, do
so only at an authorized
waste disposal center.
READ AND SAVE THESE INSTRUCTIONS
WARNING
DANGER
6
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of injury when
using your refrigerator, follow these basic
safety precautions:
For your safety observe the following
recommendations:
• This appliance contains a small
quantity of R600a refrigerant which is
environmentally friendly, but
flammable. It does not damage the
ozone layer, nor does it increase the
greenhouse effect.
• During transportation and
installation, ensure that the tubing of
the refrigerant circuit is not damaged.
• Avoid using or manipulating sharp
objects near by the appliances.
• Leaking refrigerant can ignite and
may damage the eyes.
• In the event any damage does occur,
avoid exposure to open fires and any
device which creates a spark.
Disconnect the appliance from the
main power.
• Thoroughly ventilate the room in
which the appliance is located for
several minutes.
• Notify Customer Service for necessary
action and advice.
• The room for installing the appliance
must be at least 35 cubic Foot per 8
grams of refrigerant. The refrigerant
quantity contained in this appliance is
noted on the Rating Plate of the
appliance.
• It is hazardous for anyone other than
an Authorized Service Person to carry
out servicing or repairs to this
appliance.
• Take off the doors.
• Leave the shelves in place so that
children may not easily climb inside.
• When disposing of the appliance, do
so only at an authorized waste
disposal center.
• Keep ventilation openings in the
appliance enclosure or in the built-in
structure clear of obstruction.
• Do not damage the refrigerant circuit.
• If you do not use the machine for a
long time, please unplug the power
plug from the socket or switch off the
power supply.
• Do not use extension cords or
ungrounded (two prong) adapters.
• If the supply cord is damaged, it must
be replaced by the manufacturer, Its
service agent or similar qualified
person in order to avoid hazard.
• Do not use mechanical devices or
other means to accelerate the
defrosting process, other than those
recommended by the manufacturer.
• Do not use electrical appliances inside
the food storage compartments of
the appliance, unless they are of the
type recommended by the
manufacturer.
• This appliance is not intended for use
by persons (including children) with
reduced Physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to
ensure that they do not play with the
appliance.
READ AND SAVE THESE INSTRUCTIONS
Allow 24 hours before switching on the wine cooler.
During this time we recommend that you leave the door open to clear any
residual odors.
Important: All models without front venting (air opening) are strictly for free
standing only. (See technical chart)
RECOMMENDATIONS:
The location you have selected for your wine cooler should:
• Be unencumbered and well ventilated.
• Be well away from any heat source and direct sunlight.
• Not be too damp (laundry, pantry, bathroom etc.).
• Have a flat floor.
• Have a standard and reliable electricity supply (standard socket to country
standards, linked to the ground), it is NOT recommended to use a multi-
socket or extension lead.
• Have a surge protector fitted to the electrical outlet.
• Away from the microwave oven. Certain microwave ovens do not have
wave interference shield. When placed within 1 meter vicinity of the wine
cabinet, they may affect the operation of the wine cabinet.
COSMO wine cooler should be placed where the ambient temperature is
proper. If the temperature is above or below this range, it will affect the
performance of the cooler. Placing in cold or hot temperature conditions
may cause cooler's temperatures fluctuating, and it will not reach the ideal
one.
GROUNDING INSTRUCTIONS:
COSMO wine cooler must be grounded in case of wire leakage. Grounding
reduces the risk of electrical shock. The wine cooler is equipped with a power
cord having a grounding wire and plug. The wine cooler plug must be
plugged into a properly affixed and grounded electrical outlet.
Note: In locations where there is frequent lightning, it is advisable to use
surge protectors. Improper use of the grounding plug can result in the risk of
electric shock. Consult a qualified electrician or service person if the
grounding instructions are not completely understood.
If the supply cord is damaged, it must be replaced by a qualified person in
order to avoid electrical hazard.
BEFORE LOADING & PLUGGING IN
7
• COSMO wine coolers are front venting but are not designed to be fully
integrated behind a joinery door.
• The units draws air from right of ventilation frame 110V from the rear and
expel through left of ventilation frame under the front door.
• COSMO wine coolers have a power switch located on the control panel so
power point location is not critical.
• The power cord is (78.5 “/ 2.0m) in length and is fixed on the right side at
the back when looking from front of cabinet.
• As with most appliances of today, the wine cooler has sensitive electronic
components which are susceptible to damage through lightning and
electricity supply faults. It is therefore advised to use a power surge
protector to avoid problems of this nature.
• Air vent on door must be provided for built-in wine coolers when a wood
door installed.
• In Hot climate zone, an air vent or grid, with a minimum ventilation size of
7” x 1.57” MUST be cut out at the rear top of the back partitioning or at the
top of either side of the partitioning, allowing cool fresh air full access to
flow into the 1 inch gap located at the rear of the cabinet. This air vent or
grid must not be opened on the same side as other appliances such as
ovens or an area that is sealed and without access to fresh cool air.
Failing to comply with the above specifications could result in WARRANTY void.
8
RECOMMENDATIONS
SPECIFICATIONS
9
DOOR TYPE: Stainless Steel Door Frame
ELECTRIC SUPPLY: 110V / 60Hz
NET CAPACITY: 147L
CABINET SIZE (WXDXH): 23.4"x 25.1" x 34.1"
NET WEIGHT: 95 lbs
23.43"[595mm]
23.03"[585mm]
20.95"[532
mm
]
34.06"[
865mm
]
33.47"[
850mm
]
4.76"[121mm]
22”
/560
m
m
3
4
.
6
4
”
/
8
8
0
m
m
2
3
.
8
1
”
/
6
0
5
m
m
0
.
7
8
”
/
2
0
m
m
TOP VIEW
Please follow the installation diagram when installing built-in wine coolers.
No less than the minimum installation dimension, or it will affect the venting
of cooler.
Unpacking your Wine Cooler
1.
Remove all packaging material. This includes the base and all adhesive tape
holding the wine cooler accessories.
2. Inspect and remove any packing, tape or printed materials.
3. Before connecting the wine cooler to power source, let it stand upright for
approximately 24 hours. This will reduce the possibility of a malfunction in
the cooling system from handling during transportation. The internal liquid
coolant needs to properly rest before use.
Leveling your Wine Cooler
Your COSMO wine cooler has 38mm adjustable leveling legs.
After properly placing your wine cooler in its final
position, you can level your wine cooler if there is
uneven flooring. Leveling legs can be adjusted by
turning them clockwise to raise your wine cooler
or by turning them counterclockwise to lower
your wine cooler.
Install the legs by screwing in the legs into the preset
screw holes.
(Please note that the leg on the hinge is designed to be shorter.)
44.68” /1135mm
INSTALLATION INSTRUCTIONS
10
COS-24BIWCS Model uses side anti-dew tube and Independent cooling system
Minimum space required for COS-24BIWCS Model
Install Limitations
Do not install your wine cooler in any location not properly insulated or
heated e.g. garage etc.
Select a suitable location for the wine cooler on a hard even surface away
from direct sunlight or heat source e.g. radiators, baseboard heaters, cooking
appliances etc. Any surface unevenness should be corrected with the leveling
legs located on the front and rear bottom corners of the wine cooler. Avoid
placing unit where there may be electrical
interference.
Note: To minimize the risk of
rusting, leakage and insulation
damage, avoid placing the unit in
a place where heavy moisture is
present. Under no circumstances
spill or directly apply water onto or
into the unit.
Proper Air Circulation
To assure your wine cooler works
at the maximum efficiency it was
designed for, you should install it
in a location where there is
proper air circulation and
electrical connections.
Allow enough space in the front of
the unit to open the door to 120°.
11
5
(23.81
mm
")
60
24.13"(613mm)
34.4 5"(875mm)
Your wine cooler is designed with “Auto-cycle” defrost system. During “Off-
cycle” the refrigerated surfaces of the wine cooler defrost automatically.
Defrost water from the wine cooler storage compartment drains
automatically and part of it goes into a drainage container, which is located
at the back of the wine cooler next to the compressor. The heat is transferred
from the compressor and evaporates any condensation that has collected in
the pan. Part of the remaining water is collected within the wine cooler for
humidity purposes.
This system enables the creation of the correct humidity level inside your wine
cooler required by the natural cork to maintain a long lasting seal.
Notes: The water collected by condensation, is therefore recycled. Under
extremely dry environmental conditions, you may have to add some water
into the water container provided with your wine cooler.
All units are equipped with a double glazed glass door that has a third
internal acrylic layer to minimize condensation on the glass door.
The wine cooler is not totally sealed; fresh air admission is permitted through
the drainpipe. Air is circulated through the cooler by means of a fan/fans
and the hollow shelves.
Notes: During the refrigerating cycle, heat is given off and disperses through
the external surfaces of the wine cooler. Avoid touching the surfaces during
those cycles
DEFROSTING / CONDENSATION
12
14
8
8
8
8
6
52
1 ”A” is shelf limit pin
2 ”B” is shelf Sliding wooden shelf installation
and taking instruction:
Shelf taking: According to below instruction
drawing to pull out the shelf to support bracket
1 , press two sides of sliding roller buckles and
pull out the shelf following the arrow mark 2 .
Adjusting and removing the shelves
For easy access to the storage content, you must pull the shelves
approximately 1/3 of its depth out of the rail compartment. These wine
cabinets, however, are designed with a notch on each side of the shelf tracks
to prevent bottles from falling.
When removing any of these shelves out of the rail compartment, tilt the shelf
as per the diagram and simply pull out, or push in the shelf until it sits on the
support brackets securely.
Shelf installation and removal
instruction:
According to below instruction drawing to
press one side of shelf limit pin 1 , extract and
remove the shelf from the other side of
support bracket 2, then take off the shelf
following the arrow mark 3 , Shelf installation
will be opposite with shelf removal.
ADJUSTING WOODEN SHELVES
13
Warning:
To avoid accidents during the process of changing the door, we recommend
that you get assistance. The glass door is heavy and may cause injury if
dropped.
• Depending on to the model and the type of handle your wine cabinet is
equipped with, you may have to rotate the door through 180 degrees.
• Depending on the
type of handle your wine cabinet is equipped with, the
door may not be reversible or may require that a left or right opening door
be ordered to change the opening side.
Steps to Reverse the Door
1. Remove the Bottom
Unscrew the two screws 1 holding the bottom hinge holder 2 in place (see
Figure 1).
Hold the glass door securely as you remove the screws to prevent it from
falling.
2. Remove the Metal Cap and Door:
Carefully remove the metal cap located on the top middle part of the door,
which is used for locking the door.
Gently pull the glass door downward to detach it from the top hinge.
Place the door on a soft, padded surface to prevent any damage.
3. Remove the Bottom and Top Hinge:
Remove the hinge holder 3 and bottom hinge 6 as well as the upper hinge 4
from the vent grill (see Figures 1 and 2).
Make sure to keep the screws and components in a safe place for reassembly.
4. Remove the Black Screw/Hole Plugs:
Use a flat-head screwdriver to gently remove the Screw/Hole Plugs on the top
and bottom left of the unit.
Place the new plugs given in the accessory bag over the screw holes on the
right-hand side where the door was installed prior to cover up the holes.
5. Install the Door on the Left Side:
After unscrewing the upper hinge 4 and bottom hinge 6 from the right-hand
side of the cabinet, attach them to the left-hand side 7 and 8 . To do this,
place the door onto the wine cooler's top hinge on the left-hand side. Align the
bottom hinge assembly with the designated position on the left side and
securely screw it in place.
Ensure the door is level before fully tightening the screws (see Figures 3 and 4).
REVERSIBILITY OF THE DOOR
14
6. Installing the Door Switch Press Plate and Metal Cap:
After completing all the previous steps, locate the door switch press
plate, which is currently positioned at the top middle part of the door.
Carefully unscrew the press plate and relocate it to the bottom of the
door. Secure it firmly by tightening the screws.
Then, take the metal cap that was removed earlier and attach it to the
new top middle part of the door to cover the hole. Ensure it is properly
secured.
Important Note: This step is crucial for the door switch to accurately
detect whether the door is open or closed after the hinge reversal.
Skipping this step may result in the door alarm malfunctioning.
Figure 1
Figure 2
Figure 3 Figure 4
15
Handle Installation Method
1. Take the handle out of the cabinet and remove the gasket on the inner
side of the door to access the screws already attached to the door.
2. Align the handle with the screws and tighten them securely using a
Phillips screwdriver.
3. Press the gasket back into place to complete the installation.
OPERATION ANOMALIES
Ensure that there is power to the
electrical supply plug by connecting
another electrical appliance to it.
Check fuse, if any. Make sure that
the door is closed properly.
If your wine cooler appears to be
malfunctioning, unplug it and
contact your after sales service. Any
intervention on the cold circuit
should be performed by a
refrigeration technician who should
carry out an inspection of the circuit
sealing system. Similarly, any
intervention on the electrical circuit
should be performed by a qualified
electrician
NOTES:
Any intervention performed by
a non-authorized technician
will lead to the warranty being
considered as null and void.
DOOR LOCK:
Your unit is provided with a lock and key combination. The keys are located
inside the plastic bag that contains the Owner’s Manual. Insert the key into the
lock and turn it to unlock the door.
To lock the door, insert the key into the lock and turn it the opposite direction,
making sure metal pin is engaged completely. Remove the key and place it in
a secure place for safekeeping.
16
Plug in and switch on the cooler. When you use the wine cooler for the first
time (or restart the wine cooler after having it shut off for a long time), there
will be a few degrees variance between the temperature you have selected
and the one indicated on the LED readout. This is normal and it is due to the
length of the activation time. Once the wine cooler is running for a few hours
everything will stabilize.
IMPORTANT:
If the unit is unplugged, power is lost, or turned off, wait 3 to 5 minutes
before restarting the unit. The wine cooler will not start if you attempt to
restart before this time delay.
Operating Noises:
To reach the desired temperature settings, Our wine coolers, like all wine
coolers operating with compressors and fans, may produce the following types
of noises. These noises are normal and may occur as follows:
1 - Gurgling sound - caused by the refrigerant flowing through the appliance’s
coils.
2 - Cracking/popping sounds - resulting from the contraction and expansion
of the refrigerant gas to produce cold.
3 - Fan operating sound - to circulate the air within the wine cooler.
An individual’s perception of noise is directly linked to the environment in
which the wine cooler is located, as well the specific type of models. Our wine
coolers are in line with international standards for such appliance. We will
always do its utmost to satisfy its customers but will not retake possession of
the goods due to complaints based on normal operating noise occurrences.
Loading Your Wine Cooler:
You may load your wine bottles in single or double rows while taking note of
the following:
- If you do not have enough bottles to fill your wine cooler, it is better to
distribute the load throughout the wine cooler so as to avoid “all on top” or “all
below” type loads.
- Do remove or relocate adjustable wooden shelves to accommodate larger
type of bottles or increase the capacity of the cooler by stacking the bottles up
when necessary. (See removing shelves)
- Keep smalls gap between the walls and the bottles to allow air circulation.
Like an underground cooler air circulation is important to prevent mold and
for a better homogeneous temperature within the cooler.
TURNING ON YOUR WINE COOLER
17
• Do not over load your wine cooler to facilitate air circulation.
• Do not stack more than 1.5 rows of standard 0.75L bottles per shelves to
facilitate air circulation
• Avoid obstructing the internal fans (located inside on the back panel of the
wine cooler).
• Do not slide the shelves outwards beyond the fixed position to prevent the
bottles from falling.
• Do not pull out more than one loaded shelf at a time as this may cause the
wine cooler to tilt forward.
• Do not cover the wooden shelves with alloy foil or other materials, as it will
obstruct air circulation.
• Do not move your wine cooler while it is loaded with wines. This might
distort the body of the wine cooler and cause back injury.
Types Of Regulation
Please note that depending on the loading and settings chosen it takes about
24 hours for the wine cooler to see the temperature stabilizing.
During this time LED seems to move erratically in particular. It is normal and
this process occurs whenever the setting is modified and/or whenever a large
amount of bottles are added to the cooler.
Temperature Settings:
• The LED displays by default the actual internal air temperature.
• The temperature of the power, before all Settings will be resumed after the
electricity to power the preset temperature
• The electrical board of all models comes with memory function.
• It is important to understand that there is a difference between the air
temperature inside the wine cooler and the actual temperature of the wine.
• You will need to wait approximately 12 hours before noticing the effects of
temperature adjustment due to the critical mass within a full wine cooler.
Once the temperature is set, it is strongly advised not to toy with it or adjust
frequently. The thermostat will maintain the temperature inside the wine
cooler within a +/- (2.5ºC / 36.5°F) range. But the thermal inertia of the
wine and the glass is such that within this temperature range, the actual
temperature of the wine will only fluctuate ( 0.5ºC to 1ºC )/(33 to 34°F)
WARNING
18
DISPLAY OPERATION INSTRUCTIONS
The temperature setting can be adjusted from 5℃
to 20
℃.
The temperature preset at the factory is 12℃
.
• After the unit is power on, press for 3 seconds to turn ON or OFF the unit.
• ℃/℉ switch: Press ℃/℉ button to change the temperature display between
Celsius and Fahrenheit.
• Press before adjust temperature. When press it first time, the display flashes
and shows the setting temperature. After 5 seconds it shows the measured
interior temperature. Press to increase the setting temperature and press
to decrease the setting temperature.
• 2-digit LED display to show setting temperature or actual interior temperature.
• Press to turn on or off. When open door, the light will be switched on
automatically.
• If there is no any operation with digital control for 3 minutes, it will be locked
• automatically. Press and in the same time for 3 seconds to unlock.
Setting The Temperature Controls
• You can set the temperature as you desire by pushing the “+”or “-”button.
When you push the two buttons for the first time, the LED readout will show the
original temperature set at previous time.
• The temperature that you desire to set will increase 1ºC if you push
the“+”button once, on the contrary the temperature will decrease 1ºC if you
push the “-” button once.
• To view the “set” temperature. (anytime) press and hold the
corresponding button for approximately 5 seconds, the “set” temperature will
temporarily “flash” in the LED display for 5 seconds.
Attention
• If the unit is unplugged, power lost, or turned off, you must wait 3 to 5
minutes before restart the unit. If first time use or longer absence of using,
the temperature will difference between setting and LED display temperature.
After running a period, the temperature will be reverting back.
°
C
°
F
19
WINE SERVING TEMPERATURE CHART
All wines mature at the same temperature, which is a constant temperature
set between 12ºC to 14ºC (54 to 57°F). The below chart is an indicative
temperature chart to indicate the best temperature for drinking purposes.
Champagne NV, Sparkling, Spumante
Dry White Semillon, Sauvignon Blanc
Champagne Vintage
Dry White Chardonnay
Dry White Gewürztraminer, Riesling, Pinot Grigio
Sweet White Sauternes, Barsac, Montbazillac, Ice Wine, Late Harvest
Beaujolais
Sweet White Vintage: Sauternes
White Vintage Chardonnay
Red Pinot Noir
Red Grenache, Syrah
Red Vintage Pinot Noir
Cabernet & Merlot: French, Australian, New Zealand
Chilean, Italian, Spanish, Californian, Argentinean,Vintage Bordeaux
(Room temperature not exceeding)
IMPORTANT INFORMATION ABOUT TEMPERATURE
Your wine cooler has been designed to guarantee optimum conditions for
storing and/or serving your wines. Fine wines require long and gentle
developments and need specific conditions in which to reach their full
potential.
All wines mature at the same temperature, which is a constant temperature
set between 12ºC to 14ºC (54 to 57°F) . Only the temperature of
“dégustation” (wine appreciation) varies according to the type of wines (see
“Wine Serving Temperature Chart” above). This being said and as it is for
natural coolers used by wine producers for long period of storage, it is not the
exact temperature that is important, but its consistency. In other words, as
long as the temperature of your wine cooler is constant between (12ºC to 14ºC)
(54 to 57°F) your wines will be stored in perfect conditions.
Not all wines will improve over the years. Some should be consumed at an
early stage (2 to 3 years) while others have tremendous aging capability (50
and over). All wines have a peak in maturity. Do check with your wine
merchant to get the relevant information.
CLEANING YOUR WINE COOLER
IMPORTANT: Always unplug the unit before cleaning or performing
maintenance. Never use harsh cleansers or scouring pads to clean any part of
the unit. Turn off the power, unplug the appliance, and remove all items
including shelves. Wash the inside surfaces with a warm water and baking
soda solution. The solution should be about 2 tablespoons of baking soda to a
quart of water. Wash the shelves with a mild detergent solution.
Wring excess water out of the sponge or cloth before cleaning control panels
or any electrical parts. Wash the outside cabinet with warm water and mild
liquid detergent. Rinse well and wipe dry with a clean soft cloth
6°C
8°C
10°C
10°C
10°C
10°C
13°C
14°C
14°C
16°C
16°C
18°C
20°C
20°C
43°F
46°F
5
0
°
F
5
0
°
F
50°F
50°F
55°F
57°F
57°F
61°F
61°F
64°F
68°F
68°F
20
POWER FAILURES
In the event of a power interruption, all previous temperature settings are
automatically preservation and it will revert to a preset temperature setting.
(See preset chart)
Most power failures are corrected within a short period of time. An hour or
two’s loss of power will not affect wine cooler’s temperatures. To avoid sudden
change of temperature while the power is off, you should avoid opening the
door. For longer period of power failure, do take steps to protect your wine.
Irrespective of the cause, if you notice either abnormal temperature or
humidity levels inside your wine cooler be reassured that only long and
frequent exposure to these abnormal conditions can cause a detrimental
effect on your wines.
Common problems may easily be solved, saving you the cost of a
possible service call. Please read carefully the instruction manual and
revert to troubleshooting guide chart.
PROBLEM POSSIBLE CAUSE
Wine cooler does not operate. Not plugged in.
The appliance is turned off.
The circuit breaker tripped or the fuse is
broken.
Wine cooler is not cold enough. Check the temperature control setting.
External environment may require
a higher setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
Turns on and off frequently. The room temperature is hotter than
normal.
A large amount of contents has been
added to the Wine cooler.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
TROUBLESHOOTING GUIDE
21
The light does not work. Not plugged in.
The circuit breaker tripped or a blown
fuse.
The bulb is out of order.
The light button is “OFF”.
Vibrations.
Check to assure that the Wine cooler
is level.
The Wine cooler seems to
make too much noise.
The rattling noise may come from the
flow of the refrigerant, which is normal.
As each cycle ends, you may hear
gurgling sounds caused by the flow
of refrigerant in your Wine cooler.
Contraction and expansion of the inside
walls may cause popping and crackling
noises.
The Wine cooler is not level.
The door will not close properly.
The door was reversed and not properly
installed.
The gasket is faulty. ( magnet or rubber is
spoiled)
The shelves are out of position.
22
LIMITED WARRANTY
WARRANTY AND SERVICE
TO RECEIVE WARRANTY SERVICE, YOUR PRODUCT MUST BE REGISTERED.
TO REGISTER AND REVIEW FULL WARRANTY DETAILS, VISIT:
WWW.COSMOAPPLIANCES.COM/WARRANTY
SCAN TO REGISTER
CUSTOMER SUPPORT
TO CHAT WITH US LIVE FOR ASSISTANCE, VISIT:
WWW.COSMOAPPLIANCES.COM/CHAT
SCAN TO CHAT
23
Correct disposal of this product:
This marking indicates that this appliance should not be
disposed with other household wastes. To prevent
possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources.
IMPORTANT
Do Not Return This Product To The Store
If you have a problem with this product, please contact COSMO Customer
Support at
+1 (888) 784-3108
DATED PROOF OF PURCHASE, MODEL #, AND SERIAL # REQUIRED FOR
WARRANTY SERVICE.
IMPORTANT
Ne pas Réexpédier ce Produit au Magasin
Pour tout problème concernant ce produit, veuillez contacter le service des
consommateurs Cosmo Customer Support au
+1 (888) 784-3108
UNE PREUVE D’ACHAT DATEE EST REQUISE POUR BENEFICIER DE LA GARANTIE.
IMPORTANTE
No regrese este producto a la tienda
Si tiene algún problema con este producto, por favor contacte el ayuda al
cliente COSMO al
+1 (888) 784-3108
(Válido solo en E.U.A.)
NECESITA UNA PRUEBA DE DE COMPRA FECHADA, NÚMERO DE MODELO Y DE
SERIE PARA EL SERVICIO DE LA GARANTÍA.
24
MEMO
25
MEMO
26
MEMO
27
Cosmo is constantly making efforts to improve the quality and
performance of our products, so we may make changes to our
appliances without updating this manual.
Electronic version of this manual is available at:
www.cosmoappliances.com
APPLIANCES
