3
4
5
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.Any changes or modications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. lf this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Radiation Exposure Statement
This device complies with FCC radiation exposure limits set forth for an
uncontrolled environment and it also complies with Part 15 of the FCC RF Rules.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
2
Charging instructions Useful diagram
Table of Toxic and Hazardous
Substances or Element
English
PARAMETER
Mode
PBE1020
Battery
Lithium Polymer
Wireless charging schematic diagram
Battery Capacity
10000mAh/3.85V/38.5Wh
Type-C Input
5V 3A /9V 2A/12V 1.5A 18W(Max)
15W (Max)/10W/7.5W/5W
Size
1
Click to turn on the LED power indicator light. Without load, the light
will automatically go o in about 35 seconds.
Warnings
Product Manual
Wrapping paper
Packing box
Electronic parts
Battery
PCB
Plastic
indicates that said hazardous substance in all af the homogeneous
materials for this part is below the limit requirement of SJ/T11363-2006.
Indicates that said hazardous substance contained in at least one of the
homogeneous materials used for this part is above the limit
requirement of SJ/T11363-2006.
X
Name of Hazardous Substance
if the battery is not replaced properly, there will be a risk of explosion, if it is replaced
with the wrong model of battery pack, there will be a risk of re or explosion, and it can
only be replaced with the same type or equivalent type of battery.
The battery must not be exposed to environments such as sunlight, re roasting, or
similar excessive heat.
When using, it should be placed in a place that is easy to dissipate heat, and should not
be placed at the head of the bed, on the bedding, in the package or other environments
that are not easy to dissipate heat.
Avoid rainwater and other liquid erosion, and avoid infants and young children from
cantact and play.
Do not use this product in a high temperature or humid environment or leave it idle:
Do not expose to the sun.
The temperature range of this product: 0°C~25°C: (lt is recommended not to work in an
environment higher than 25°C, and it is recommended not to work in an environment
below 0°C.))
The storage temperature range of this product: -5°C~35°C, it cannat be left for a long
time above the ambient temperature of 35°C.
Do not cover or obscure this product with paper or other objects to avoid hindering the
heat dissipation and cooling of this product.
Do not use this product unattended.
Do not drop, vibrate, knock, impact, or squeeze this product vigorously.
Do not short circuit the positive and negative electrodes of the input or output of the
product, To avoid re from equipment or external obiects.
Please check that the output voltage of the charger matches this product before using
this product, To avoid preduct damage.
If the voltage of the charger does not match, it will cause the power bank to be
overloaded,causing smoke, re and other dangers.
Please unplug the charger after each full charge of the power bank.
lf the power bank has abnormal conditions such as odor, heat, discoloration,
deformation, night leakage and other abnormalitiles during use; Please deactivate it
immediately.
The battery should not be disassembled, impacted, squeezed or thrown into the re.
Do not continue to use if severe buige occurs, Do not place in a high temperafure
evirenment.it is forbidden to use it afterimmersion.
The time when the product is in contact with the product indicator light should not
exceed 1 minute.
Dispose of it properly when disposed of.
The product should be placed on the desktop when used, and the contact time shouid
be less than 10s if it needs to be used in contact with the human body.
If the skin gets on the battery liquid, wash it immediately with tap water and seek
medical attention promptly.
Pb PBB PBDECd Hg Cr(VI)
Wireless Charging
108.48*67.78*23.55mm
5V 3A /9V 2.22A/12V 1.67A/5V 4.5A/10V 2A 20W(Max)
Type-C o ut put
PBE1020 10000mAh
JUCANI Wireless Charging POWER BANK
