8053-30
High Sierra
5000 mAh MagStand
Instruction Manual
Whats Included:
1 x 5000mAh Magclick Wireless Power Bank
1 x 30cm TPE Type-C to Type-C Charging Cable
•
•
WIRELESS POWER BANK
Functions:
Instructions:
Tech Specications:
Lanyard Hang Hole
Type-C Input/Output Port
Power Button
Magnetic Wireless Charging Surface
Built-in Powerbank Stand
LED Indicators
Charging the Power Bank:
Be sure the power bank is fully charged
before usage.
Insert the type-C tip of the included
cable into a certied AC adapter and
the other end into the Type-C Input port(2)
to begin charging.
The LED indicator(6) will ash WHITE
when the device is charging and will stop
once fully charged.
When the power bank is fast charging
there will be a GREEN indicator.
Once the power bank is fully charged,
remove the device from the power source.
Cable Charging Your Mobile Device:
Press the ON/OFF button(3) to turn ON the
power bank, then connect your device to
the Type-C port(2) using the appropriate
cable. Charging will begin automatically.
LED indicators will glow WHITE while
charging, and the green LED will appear
when fast charging is active.
The indicators will turn o once the power
bank is depleted.
The power bank will automatically shut o
after 32 seconds of inactivity, or you can
press the ON/OFF button twice to turn it
OFF manually.
Disconnect your device once it is fully
charged.
Wireless Charging Devices:
Place your wireless charging device on the
wireless charging surface(4).
The device will begin to charging
immediately and the wireless charging LED
will glow BLUE, and the green LED will
appear when fast charging is active.
Once fully charged, remove the device.
If your phone/device supports fast charging,
the LED will glow BLUE & GREEN at the
same time when wireless charging.
Wireless Charging with Magnetic Surface:
If your phone supports MagSafe, it will
securely align with the magnetic charging
surface(4).
The magnetic surface is compatible with
other devices, but the magnetic alignment
feature will only work with MagSafe-type
phones.
Note: When wireless charging, if the LED
indicator is ashing BLUE the device is either
NOT a wireless charging device or there is
an object between the device and charging
surface interfering with the charging process.
Built-in Powerbank Stand(5):
Fold out the built-in stand on the back of the
power bank to prop it up on a at surface.
Capacity: 5000mAh/3.85V/19.25Wh
Type-C Input: DC 5V/3A, 9V/2A, 12V/1.5A
(18W Max.)
Type-C Output: DC 5V/3A, 9V/2.22A,
12V/1.67A (20W Max.)
Wireless Output for Phone: 15W Max
1.
2.
3.
4.
5.
6.
1.
•
•
•
**
•
2.
•
•
•
•
•
3.
•
•
•
**
4.
•
•
**
5.
•
1.
2.
3.
4.
2 31
5
4
6
FCC Statement:
Note:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
This device may not cause harmful
interference, and
This device must accept any interference
received, including interference that may
cause undesired operation.
Warning:
Changes or modications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
1.
2.
Name of the Distributor:
Leedsworld Inc
Address of the Distributor:
400 Hunt Valley Road,
New Kensington,
PA 15068 USA.
FCC ID: 2A92I-AST-WR410
Model AST-WR410
Made in China
IC Statement:
This device contains licence-exempt transmitter
(s)/receiver(s)
that comply with Innovation, Science and
Economic
Development Canada’s licence-exempt RSS(s).
Operation is
subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference,
including
interference that may cause undesired operation of
the device.
L’émetteur/récepteur exempt de licence contenu
dans le
présent appareil est conforme aux CNR
d’Innovation,
Sciences et Développement économique Canada
applicables
aux appareils radio exempts de licence.
L’exploitation est
autorisée aux deux conditions suivantes:
(1) L’ appareil ne doit pas produire de brouillage;
(2) L’ appareil doit accepter tout brouillage
radioélectrique
subi, même si le brouillage est susceptible d’ en
compromettre le fonctionnement. Radio Frequency
Exposure
Statement for IC This equipment complies with IC
exposure
limits set forth for an uncontrolled environment.
This
equipment shall be installed and operated with
minimum
distance 10cm between the radiator & body. Cet
équipement
est conforme aux limites d’exposition IC dénies
pour un
environment non contrôlé. Cet équipement doit
être installé
et utilisé avec une distance minimale de 10cm
entre le
radiateur et la carrosserie.
CAN ICES-3 (B) / NMB-3 (B)
This Class B digital apparatus complies with
Canadian ICES-003.
(Cet appareil numérique de la Classe B conforme à
la norme NMB-003 du Canada).
CAN ICES-3 (B) / NMB-3(B)
This Class B digital apparatus complies with
Canadian ICES-003.
(Cet appareil numérique de la Classe B conforme à
la norme NMB-003 du Canada).
•
Safety Precautions:
WARNING-When using this product, basic
precautions should always be followed:
Read all the instructions before use.
Charge the power bank fully before initial use.
The unit’s full performance is achieved only after
2 or 3 completed charge and discharge cycles.
To reduce the risk of injury, close supervision is
necessary when the product is used near
children.
Do not expose the device to moisture.
Do not use the device in excess of its output
rating. Overload outputs above rating may result
in a risk of re or injury.
Do not use the device if damaged or modied.
Damaged or modied batteries may exhibit
unpredictable behavior resulting in re, explosion
or risk of injury.
Do not disassemble the device. Take it to a
qualied service person when service or repair is
required. Incorrect reassembly may result in a
risk of re or injury.
Do not expose the device to re or excessive
temperature. Exposure to re or temperatures
above 212℉ may cause explosion.
Have servicing performed by a qualied repair
person using only identical replacement parts.
This will ensure that the safety of the product is
maintained.
Do not overcharge Phone.Unit may get hot with
excessive use.Remove Phone when it is fully
charged.Never charge for more than 7 hours at a
time.
Attachments on the back of your phone
can impede the eectiveness of the wireless
charger, and lead to overheating. Please remove
attachments from the phone before charging on
this device.
The strong magnetic elds of neodymium
Magnets can damage items such as television,
Computer monitors, credit cards, bank cards,
Computers,diskettes and other data carriers, Video
tapes, mechanical watches, hearing aid, loud
speakers and VCRs. Pace-makers may be
Damaged or switched to “test mode” in the
presence of a strong magnetic force, if
pacemaker or other electronical body
implant is in use, keep a minimum of 3
feet distance.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
FCC RF warning statement:the device has been evaluated
to meet general RF exposure requirement , The device can
be used in portable exposure condition without restriction.
