Magnetic
WirelessCar
Charger
User Manual
① 取出产品及所有配件，把吸盘垫底部保护膜撕掉，粘贴在任意平
整的表面。
④ 将无线充电器调节至合适的角度，把带有磁吸无线充电功能
的手机放置在连接好电源的车载无线充电器上，充电板会自动吸
附对位并开始为手机充电。
③ 把数据线取出，用弯曲的一端充电头插入产品C口，另一端连
接车充头并插入汽车点烟器插座。
② 将无线充电产品底部保护膜撕掉，粘贴在已经安装好的吸盘垫顶
部光滑面。
FCC警告
配件清单
规格参数
安装步骤
1、请勿挤压或碰撞。
2、请勿自行拆卸或投入火中、水中,避免造成短路漏电。
3、请勿在严重高温、潮湿或腐蚀性环境下使用无线充电器，避免损坏
电路出现漏电现象。
4、请勿与带磁条或者芯片的磁卡 (身份证、银行卡等) 放置太近,避免
造成磁卡失效。
5、请保持植入医疗设备 (心脏起搏器、植入性耳蜗等) 与无线充电器之
间的距离至少为20cm,以避免对医疗设备造成潜在干扰。
6、应看管好儿童,以确保他们不将无线充电器当成玩具来玩,以避免不
必要的意外。
注意事项
* 说明书涉及图片均为示意图， 最终产品以实物为准。
内含：无线充电器、吸盘垫、车充头、数据线、用户手册。
感谢您购买本产品！
本产品是一款车载手机无线充电器，可充当车载手机支架
并延长手机的续航时间，让您轻松体验数码产品的无限乐趣。
使用本产品前请认真阅读本手册并妥善保存，以备查阅。
车载无线充电器×1 吸 盘垫×1
车载磁吸无线充电器
用户手册
输入: 5V⎓3A, 9V⎓3A, 12V⎓2.5A, 15V⎓2A
输出: 25W MAX
工作频率: 115-205kHz, 360kHz
接收距离: ≤3mm
电力转换: ≥70%
规格尺寸: φ62×44.5mm
产品重量: 130g
Input: 5V⎓3A, 9V⎓3A, 12V⎓2.5A, 15V⎓2A
Output: 25W MAX
Frequency: 115-205kHz, 360kHz
Charging distance: ≤3mm
Conversion: ≥70%
Size: φ62×44.5mm
N.W.: 130g
车充头×1 数 据线×1
1. Do not squeeze or collisions.
2. Do not disassemble or throw into fire or water, to avoid causing
a short circuit leakage.
3. Do not use wireless charger in severely hot, humid or corrosive
environments, to avoid circuit damage and occurs leakage
phenomenon.
4. Do not place too close with magnetic stripe or chip card (ID card,
bank cards, etc.) to avoid magnetic failure.
5. Please keep the distance at least 20cm between implantable
medical devices (pacemakers, implantable cochlear, etc.) and the
wireless chargers, to avoid potential interference with the medical
device.
6. To take care of the children, to ensure that they won't play the
wireless charger as a toy, to avoid unnecessary accidents.
① Remove the product and all accessories, tear off the protective film
at the bottom of the suction pad and stick it on any flat surface.
② Tear off the protective film at the bottom of the wireless charging
product and stick it on the smooth surface at the top of the already
installed suction pad.
③ Take out the data cable, insert the curved end of the charging head
into port C of the product, and connect the other end to the car
charger and insert it into the car ignition socket.
④ Adjust the wireless charger to the appropriate angle, place the
mobile phone with the magnetic wireless charging function on the
connected and powered-on vehicle wireless charger, and the
charging plate will automatically align and start charging the phone.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception,which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with a minimum distance of 20 cm between the
radiator and your body.
NotesFCC Warning
List of Accessories
Specification
Installation steps
* All the pictures involved in the manual are schematic diagrams.
The final product shall be subject to the actual item.
Included: wireless charger, suction pad, car adapter, power cable, user manual.
Thank you for purchasing this product!
This product is a magnetic wireless car charger. It can serve as a
vehicle-mounted mobile phone holder and extend the battery
life of the phone, allowing you to enjoy the unlimited fun of
digital products with ease.
Before using this product, please read this manual carefully and
keep it properly for future reference.
Wireless car charger×1 Suction pad×1
Car adapter×1
本设备符合FCC规则第15部分规定， 操作受以下两个条件的约束：
(1)本设备不得造成有害干扰；
(2)本设备必须接受收到的任何干扰，包括可能导致意外操作的干扰。
任何未经合规责任方明确批准的更改或修改都可能导致用户操作设备
的权力失效。
注意：根据FCC规则第15部分规定，本设备已经过测试，并符合B类数字
设备的限值要求。 这些限制旨在提供合理的保护，防止住宅安装中的
有害干扰。 本设备会产生并使用射频能量，如果未按照说明安装和使
用，可能会对无线电通信造成有害干扰。 但是不能保证在特定安装中
不会发生干扰。如果本设备确实对无线电或电视接收造成有害干扰（可
通过关闭设备再打开来确定），我们鼓励用户尝试通过以下一种或多种
措施来纠正干扰：
• 重新定向或重新定位接收天线。
• 增加设备和接收器之间的分离。
• 将设备连接到与接收器连接的电路不同的电路上的出口。
• 咨询经销商或经验丰富的广播/电视技术人员寻求帮助。
FCC辐射暴露声明
该设备符合针对不受控制环境规定的FCC辐射暴露限值。
在安装和操作此设备时，应确保与散热器的距离至少为20厘米，且避免
靠近身体。
* 本产品同时支持对不带磁吸功能的无线充电设备进行充电。
* This product also supports charging wireless charging devices that do not
have magnetic suction function.
Power
cable×1
65.0 mm
90.0 mm
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Note: The Grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. such modifications could void the user's authority to operate the equipment
The device has been evaluated to meet general RF exposure requirement.
To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20 cm between the radiator and your body, and fully supported by the operating and installation configurations of the transmitter and its
antenna(s).
