EN
CORDLESS FOOD CHOPPER
Translation of the original manual
SCB 9000WH
SCB 9001GY
SCB 9000WH
SCB 9001GY
A
2
3
5
7
6
8
1
9
4
1110
B
2
3
1
- 1 -
06/2023
2023, .
EN Cordless food chopper
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
• This appliance may not be used by children. Keep the
appliance and its power cord away from children.
• The appliance may be used by persons with reduced
physical, sensory or mental capabilities or with alack of
experience and knowledge, if they are supervised or have
been instructed to use the appliance in asafe manner and
understand the potential dangers.
• Children must not play with the appliance.
• Cleaning and maintenance performed by the user must
not be performed by unsupervised children.
• In the event that the power cord is damaged, have it
repaired at aprofessional service centre to prevent causing
adangerous situation. It is forbidden to use the appliance if
it has adamaged power cord.
WARNING
Incorrect use may lead to injuries.
- 2 -
06/2023
2023, .
Electrical safety
• Before connecting this appliance to an electrical power socket, make sure that the voltage stated on its rating label corresponds to the voltage in
your power socket.
• Connect the appliance only to aproperly grounded socket. Do not use an extension cord.
• Fully unwind the power cord before using it.
• Do not connect and disconnect the power cord and adapter to and from the power socket with wet hands.
• Ensure that the adapter plug contacts do not come into contact with water or any other liquid. If precisely this happens, carefully dry the power plug
before using it again.
• Do not disconnect the appliance from the power socket by pulling on the power cord. This could damage the power cord or the power socket.
Disconnect the power cord from the power socket by pulling on the plug.
• Do not place heavy items on the power cord. Make sure the power cord does not hang over the edge of atable or that it is not touching ahot
surface or sharp objects.
• Keep the power cord and adapter dry.
• If the power cord or the adapter is damaged, it must be replaced by the manufacturer, its service technician or by asimilarly qualified person, as
this will prevent adangerous situation from arising. It is forbidden to use adamaged power cord or adapter.
• Do not wind the power cord around the appliance.
• Always turn off the appliance and disconnect it from the power socket when not using it, when leaving it without supervision and before removing
or replacing accessories, and before cleaning, maintenance or storage.
• The appliance is equipped with abuilt-in long-life battery that can only be removed at aprofessional service centre. Never attempt to remove it
from the appliance yourself.
Attention:
Never disassemble the appliance for the purpose of removing the battery. Never short circuit the appliance or throw it into afire.
Incorrect use, risks releasing toxic substances or causing afire or explosion.
• Do not repair the appliance yourself or make any adjustments to it. Have all repairs or adjustments of the appliance performed at an authorised
service centre. Tampering with the appliance during the warranty period may void the warranty.
• To prevent the risk of injury by electrical shock, never submerge the motor unit and its power cord in water or any other liquid, or wash these parts
under running water.
• Always turn off the appliance and disconnect it from the power socket when you have finished charging it.
• If the appliance falls into water, under no circumstances continue using it, but rather hand it over to an authorised service centre for inspection.
• This appliance is designed for household use. Do not use it for commercial purposes or for other purposes for which it is not intended.
Safety during use
• This appliance is designed for household use and is intended for chopping ingredients.
• Do not use the appliance in an industrial environment or outdoors. Do not use it for any other purposes than those intended.
• The appliance is intended for domestic use and similar locations such as:
- kitchens in stores; offices and other workplaces;
- in agriculture;
- for guests of hotels, motels and other similar locations;
- in bed and breakfast establishments.
• This appliance is not intended to be operated using an external timer switch or aremote control system.
• Use the appliance and its accessories in accordance with the instructions contained in this user'smanual.
• Only use the appliance with the original accessories that came with it.
• Before every use, check the selected accessory for damage. Never use the appliance with adamaged accessory.
• Do not place the appliance or its accessories on an electric or gas stove or in its vicinity, on the edge of atable or on an unstable surface. Only place
the appliance on an even, dry and stable surface.
• Do not expose the appliance and its accessories to the outdoor environment, extreme temperatures, direct sunlight, excessive humidity or
excessively dusty environments.
• Do not place the appliance and its accessories near heaters, open fires or other sources of heat.
• Make sure that the appliance is correctly assembled before putting it into operation.
• Do not touch moving rotating parts during operation. Otherwise, this could result in injury.
- 3 -
06/2023
2023, .
• Thank you for purchasing aSENCOR brand product and we hope that
you will be happy with it.
• Prior to using this appliance, please read the user'smanual
thoroughly, even in cases, when one has already familiarised
themselves with previous use of similar types of appliances. Only use
the appliance in the manner described in this user’smanual. Keep this
user'smanual in asafe place where it can be easily retrieved for future
use. In the event that you hand this appliance over to somebody else,
make sure to also include this user'smanual.
• Carefully unpack the appliance and take care not to throw away any
part of the packaging before you find all its parts. We recommend
saving the original cardboard box, packaging material, purchase
receipt and responsibility statement of the vendor or warranty card for
at least the duration of the legal liability for unsatisfactory performance
or quality. In the event of transportation, we recommend that you pack
the appliance in the original box from the manufacturer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE APPLIANCE
A1 Low speed button
A2 High speed button
A3 Motor unit
A4 Lid
A5 Chopping bowl, volume
500ml
A6 Washer with pin for blade unit
A7 USB slot
A8 Battery power level indicator
A9 4-blade chopping blade
assembly
A10 USB power cable
A11 Power cable adapter
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B1 High battery capacity
indicator
B2 Medium battery capacity
indicator
B3 Low battery capacity indicator
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
PURPOSE OF USE
• The chopper is suitable for chopping tougher ingredients such as nuts,
herbs, cheeses, fruit and vegetables in their raw state or even well
diced meat. It is suitable for preparing purée and baby food.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEFORE FIRST USE
• Thoroughly wash the chopping bowl, lid and blade assembly using
warm water and neutral kitchen detergent. Then rinse them with clean
water and allow them to dry naturally or dry them out their using
awiping cloth.
Warning:
When cleaning the blade assembly, be very careful
not to injure yourself on its sharp edges.
• Clean the motor unit using only adampened cloth. At the same time,
ensure that water does not enter into the unit, especially into the speed
control buttons. Do not submerge any of these parts in water, do not
clean them under running water or place them in adishwasher.
• Only clean the power cord and adapter using adry wiping cloth, never
wash with water.
CHARGING THE BATTERY
• To ensure the best possible performance, we recommend to fully
charge the appliance before first use. Acomplete charge takes up to
5 hours.
• Insert the smaller end of the power cord into the USB socket in the
top part of the motor unit and the larger end into the supplied power
adapter. Then insert the power adapter into apower socket.
• During the charging process, indicators on the motor unit will flash
depending on the charge status. The meaning of the light signals is
the following:
Indicator (fig. B) Battery capacity
All indicators are flashing Low (less than 33 % capacity)
Indicator B3 is lit, and indicators
B1 and B2 are flashing
Medium (33-65 % capacity)
Indicators B2 andB3 are lit,
indicator B1 is flashing
Medium (66-99 % capacity)
All indicators are lit The battery is fully charged
• The lifetime of the battery is up to 300 cycles. The actual number
of cycles, however, will differ depending on the load placed on the
chopper and the ingredients that are processed. For example, with
frequent use of the high speed level, the battery will discharge faster.
RECOMMENDATIONS FOR EXTENDING THE LIFETIME OF THE
BATTERY
• In order for the battery to serve you as long as possible, charge,
use and store the appliance in adry environment at an ambient
temperature of 15-35 °C. Lower or higher temperatures have
anegative impact on the lifespan of the battery.
• When the appliance is not used for an extended period of time, charge
it at least once every 6 months.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ASSEMBLY AND DISASSEMBLY
Attention:
Before assembling/disassembling the chopper, the
motor unit must be turned off and disconnected from
the power cord.
When handling the blade assembly or the chopper,
be very careful not to injure yourself on the sharp
cutting edges.
• Place the chopping bowl on an even and stable surface.
• Assemble the blade assembly: It consists of two parts, the top and
bottom chopping blades. Hold the top chopping blades by the middle
part and seat them on to the bottom blades from above, and then turn
them in one direction or the other so that both parts fit into each other.
For afirm connection of both parts, hold the bottom chopping blades
with one hand and use the other hand to hold the top chopping blades
and turn them anticlockwise until they lock into place.
• Place the chopper on to the central pin on the bottom of the bowl and
only then insert the ingredients. Do not fill the chopping bowl past the
maximum level mark.
• Put the lid on the chopping bowl and turn it so that the tabs on the
bowl slide into the grooves on the lid.
• Then put the motor unit on to the lid. Indicators B1 to B3 will start
flashing, which means that the unit is ready for use.
• To remove them proceed in the reverse sequence to their assembly.
EN
Cordless food chopper
User'smanual
- 4 -
06/2023
2023, .
OPERATION
Note:
You may detect aslight odour when the appliance is used
for the first time. That is normal and this odour will go away
with further use.
• To start the appliance, press and hold down the low (I) or high (II)
speed button.
Attention:
The maximum continuous operating time of the
appliance is 1 minute. Then allow it to cool down for
approximately 10 minutes. When using the appliance
to blend sticky or harder ingredients, interrupt
operation already after 30 seconds.
• As soon as the ingredients are processed, release the speed button
and wait for the chopper to come to astop. Only then remove the lid
with the motor unit from the chopping bowl.
AUTOMATIC ANTI-OVERLOADING FUNCTION
• The appliance has an automatic anti-overloading function. In the event
that the motor unit is overloaded, e.g. due to the ingredients being too
tough or hard, indicators B1 to B3 will simultaneously flash five times
and then the unit will turn itself off. If this happens, allow the appliance
to rest for at least 15 minutes and adjust the amount and/or size of the
ingredients. Only then continue using the appliance.
BATTERY CAPACITY INDICATOR
• The battery will start discharging when the appliance is used. Its
capacity is shown using indicators B1 to B3 follows:
Indicator Battery capacity
All indicators are lit High
Indicators B2 and B3 are lit
Medium
Indicator B2 is lit
Low
Indicator B3 is flashing
The battery is almost flat
ADVICE AND TIPS
• Before chopping, remove hard parts such as fruit stones or bones
from the processed ingredients. This will prevent damaging the blade
assembly.
• To make chopping easier, cut hard ingredients into small pieces.
QUICK GUIDE TO PROCESSING INGREDIENTS
• The food processing times provided below are only areference. The
actual processing time depends on the size of the ingredients, their
amount and the required final consistency. If the required consistency
is not achieved during the maximum operating time of the appliance,
you may continue processing the food after the appliance has cooled
down.
INGREDIENTS AMOUNT
SPEED
SETTING
PROCESSING
TIME
Meat 300 g (I) to (II) 30 s
Fruit and vege-
tables
200 g (I) to (II) 15 s
Hard and semi-
hard cheeses
150 g (II) 10 s
Hard baked goods 100 g (I) to (II) 20 s
Nuts with shells
removed
100 g (II) 15 s
Herbs 50 g (I) to (II) 10 s
CLEANING AND MAINTENANCE
Warning:
When cleaning the blade assembly, be very careful
not to injure yourself on its sharp edges.
Do not use solvents, abrasive cleaning products, etc.
for cleaning the appliance. Otherwise the surface coat
of the appliance may be damaged.
• Before cleaning, the appliance must be turned off and disconnected
from the power cord.
• Disassemble the appliance into its individual parts. Thoroughly wash
the blade assembly, the lid and the chopping bowl in warm water and
neutral kitchen detergent. Then rinse them with clean water and allow
them to dry naturally or dry them out thoroughly using awiping cloth.
• Wipe the motor unit with adry or slightly dampened cloth. Make sure
that water does not enter into speed control buttons.
• Only clean the power cord and adapter using adry wiping cloth, never
wash with water liquids or other liquids.
• Never dry parts of the appliance over heat sources such as wood
stoves, electric or gas stoves, etc.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
STORAGE
• When you have finished using the appliance and have cleaned it,
place it and its accessories in aclean, dry place out of children'sreach.
Keep the stored appliance and its accessories away from extreme
temperatures, direct sunlight and excessive humidity and do not store
it in an overly dusty environment.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TECHNICAL SPECIFICATIONS
Power Adapter:
Input ................................................................ 100-240 V~ 50/60 Hz, 0.5 AMax
Output .......................................................................................5.0 V
2.0 A, 10 W
Unit:
Battery ................................................................................... 11,1 VLi-Ion, 2000 mAh
Rated Input ........................................................................................ 5.0 V
, 2.0 A
Work Power .........................................................................................................200 W
Electrical shock protection class ............................................................................... II
Noise level ....................................................................................................... 85 dB(A)
The declared noise emission level of the appliance is 85 dB(A), which
represents alevel Aof acoustic power with respect to areference acoustic
power of 1 pW.
Explanation of technical terminology
Safety class for electrical shock protection: Class II – Electrical
shock protection is provided by double or heavy-duty insulation.
Changes to text and technical parameters are reserved.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
- 5 -
06/2023
2023, .
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF
USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your
municipality.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DISPOSAL OF USED BATTERIES
Prior to handing over the appliance at aspecialised collection facility, it is
necessary to ensure that the built-in battery is removed. Battery removal
will be performed at the authorised service centre. In the event that the
product has been disassembled for the purpose of ecological disposal
then it must not be reassembled.
This symbol indicates that the used battery does not
belong in ordinary municipal waste. Hand over the used
battery to designated collection points for proper disposal.
Correct disposal of the battery will help prevent negative
impacts on the environment and human health.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to
dispose of this product, request the necessary information
about the correct disposal method from the local council or
from your retailer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that
used electric or electronic products must not be added to
ordinary municipal waste. For proper disposal, renewal and
recycling, hand these appliances over to determined
collection points. Alternatively, in some European Union
states or other European countries you may return your
appliances to the local retailer when buying an equivalent
new appliance. Correct disposal of this product helps save
valuable natural resources and prevents potential negative effects on the
environment and human health, which could result from improper waste
disposal. Ask your local authorities or collection facility for more details. In
accordance with national regulations penalties may be imposed for the
incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electrical or electronic equipment, ask your
retailer or supplier for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this
product, request the necessary information about the correct disposal
method from the local council or from your retailer.
This product meets all the basic requirements of EU
directives related to it.
FAST ČR, a.s.
U Sanitasu 1621
CZ-251 01 Říčany
www.sencor.eu
