GARMINCATALYST
™
2
Racetrack DrivingPerformanceOptimizer
Owner's
Manual
Table of Contents
Getting Started................................. 4
Installation....................................... 5
Installing a Memory Card...................5
Formatting the Memory Card...........5
Removing the Memory Card............ 5
Installing the Polarizing Filter on the
Camera..........................................5
Removing the Polarizing Filter from
the Camera..................................6
Mounting Considerations.................. 6
Installing the Camera on Your
Windshield..................................... 7
Connecting the Camera to Vehicle
Power............................................8
Turning On the Device Manually.......... 9
Turning Off the Device Manually.......9
Pairing a Wireless Headset or Car
Stereo........................................... 9
Device Overview............................. 10
Using the Touchscreen....................10
Home Screen................................ 10
Status Bar Icons......................... 11
Starting a Drive Session................. 12
Race Timer................................... 12
Pausing a Drive Session.................. 13
Adding a Track.............................. 13
Adding a Track Configuration........... 14
Selecting a Vehicle or Driver Profile....14
Reviewing Drive Sessions on Your
GarminCatalyst
™
2 Device.............. 15
Settings..........................................16
Audio Settings............................... 16
Disconnecting a Wireless Headset or
Stereo.......................................16
Video Settings............................... 16
System Settings.............................16
Device Settings..............................16
Resetting Data and Settings.......... 17
GarminCatalyst
™
App..................... 18
Pairing Your Device with the
GarminCatalyst
™
App......................18
GarminCatalyst
™
App Overview.........18
Transferring Drive Sessions to the
GarminCatalyst
™
App......................19
Reviewing Drive Sessions in the
GarminCatalyst
™
App......................19
Session Summary....................... 20
Viewing Session Videos in the
GarminCatalyst
™
App...................20
Comparing Sessions....................21
Saving a Session Video................ 21
Deleting Sessions........................21
Reviewing and Comparing Laps in the
GarminCatalyst
™
App......................22
Viewing Opportunities..................... 22
Viewing Track Information............... 22
Adding or Editing a Driver Profile
Name.......................................... 22
Adding or Editing a Vehicle Profile..... 22
Adding Friends to the GarminCatalyst
™
App............................................. 23
Sharing Your Card with the
GarminCatalyst
™
App......................23
Changing the Units of Measure in the
GarminCatalyst
™
App......................23
Vault Storage................................. 24
Subscribing to Vault........................24
Sharing a Video............................. 24
Disabling a Shared Video Link........ 24
Removing a Video from the Vault.......24
Device Information......................... 25
Viewing E-label Regulatory and
Compliance Information.................. 25
Specifications............................... 25
Charging the Device........................25
Device Maintenance....................... 26
Garmin
®
Support Center................... 26
Software Updates...........................26
Updating Software with the
GarminCatalyst
™
App...................26
Updating Software with Garmin
Express
™
................................... 26
Device Care...................................27
Cleaning the Outer Casing.............27
Cleaning the Touchscreen.............27
Cleaning the Camera Lens............ 27
Restarting the Device...................... 28
Troubleshooting............................. 29
My device is not acquiring satellite
signals.........................................29
My device does not pair with my phone
or tablet....................................... 29
The device does not charge in my
vehicle......................................... 29
My camera feels warm while it is
operating......................................29
My video recordings are blurry.......... 29
Appendix........................................ 30
Data Management..........................30
Memory Cards............................30
Connecting the Device to Your
Computer.................................. 30
Disconnecting the USB Cable.........30
Purchasing Accessories.................. 30
Getting Started
WARNING
See the Important Safety and Product Information guide in the product box for product warnings and other
important information.
This device is intended only for recreational use on a racetrack. Never use this device on public roadways.
Failure to follow this warning may result in an accident causing property damage, serious personal injury, or
death. You are responsible for using this device in a safe and prudent manner.
The first time you turn on your device, it guides you through the initial setup steps with on-screen prompts. You
should complete these steps before using the device for the first time.
1 Install the device in your vehicle (Installation, page5).
2 Turn on the device, and follow the on-screen instructions.
3
Pair your device with the GarminCatalyst
™
app on your phone or tablet (Pairing Your Device with the
GarminCatalyst
™
App, page18).
4 Update your device software (Software Updates, page26).
For the best experience, you should keep the software on your device up to date. Software updates provide
changes and improvements to privacy, security, and features.
4 GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
Getting Started
Installation
Installing a Memory Card
To record video, you must install a compatible memory card (Memory Card Specifications, page30). A memory
card is included with some device models.
1 Insert the memory card
1
into the slot
2
.
2 Press it in until it clicks.
Formatting the Memory Card
The camera requires a memory card formatted using the exFAT file system. You can use the camera to format
your card using this file system.
You must format a brand new memory card if it is not formatted using the exFAT file system.
NOTE: Formatting the memory card deletes all videos and data on the card.
1 Connect the camera to power.
2 Swipe left to open the menu.
3 Select Settings> Device> Format Memory Card.
4 Keep the camera connected to power until the formatting is complete.
Removing the Memory Card
NOTICE
Removing the memory card while the device is turned on can result in a loss of data or damage to the device.
1 Turn off the device.
2 Press the card in until it clicks.
3 Release the card.
The card ejects from the slot.
Installing the Polarizing Filter on the Camera
The camera comes with a polarizing filter to help reduce glare from your windshield.
NOTICE
Do not rotate the polarizing filter while it is installed on the camera, because doing so could damage the camera
lens.
1 Position the filter so the line on the outer rim is facing up.
Installation
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
5
2 Place the filter firmly onto the camera lens.
3 Verify the line on the outer rim of the filter
1
is facing up and the Garmin
®
logo on the filter is right side up.
After installing the polarizing filter, you should update the Camera Lens Cover video setting to ensure the best
quality video footage (Video Settings, page16).
Removing the Polarizing Filter from the Camera
You can remove the polarizing filter for night races or races with low light.
1 Firmly grip the camera in one hand and the polarizing filter in the other hand.
2 Pull the filter away from the camera.
After removing the polarizing filter, you should update the Camera Lens Cover video setting to ensure the best
quality video footage (Video Settings, page16).
Mounting Considerations
WARNING
When installing the device in a vehicle, do not place the device where it obstructs the driver’s view of the road or
interferes with vehicle operating controls, such as the steering wheel, foot pedals, or transmission levers. Do not
place the device unsecured on the vehicle dashboard. Do not place the device in front of or above any airbag.
The camera affixes to the windshield using the included adhesive mount. The adhesive mount is difficult to
remove after it is installed. You should carefully consider the mounting location before you install the mount.
● Do not mount the camera in a location that interferes with the driver's view of the road.
● You should choose a mounting location that provides the camera a clear view of the road ahead.
● You should choose a mounting location that is as high as possible on the center of the windshield.
● If you have a rearview mirror, you should place the camera below the rearview mirror.
6
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
Installation
● You should verify the area of the windshield in front of the camera is cleared by the windshield wipers.
● You should avoid placing the camera behind a tinted area of the windshield.
NOTE: If necessary, you can position the device to the left or right of the rearview mirror as long as it is mounted
close to the center of the windshield. Always observe the on-screen alignment instructions before each drive
session (Starting a Drive Session, page12).
Installing the Camera on Your Windshield
NOTICE
The adhesive mount is intended for a long-term installation and can be difficult to remove. You should carefully
consider the mounting location before you install the mount.
Before you can install the adhesive mount onto your windshield, you should review the windshield mounting
considerations (Mounting Considerations, page6).
For the best results, the ambient temperature should be from 21° to 38°C (from 70° to 100°F) while installing the
camera on your windshield. The adhesive may not bond correctly if the temperature is outside this range. If you
need to install the camera at lower temperatures, you must clear all snow, ice, and moisture from the windshield
and warm the windshield using the vehicle defroster before installing the camera.
The camera attaches to the windshield using the included adhesive mount.
1 Clean the inside of the windshield using water or alcohol, and a lint-free cloth.
The windshield must be free of dust, wax, oils, or coatings.
2 Hold the camera in the desired mounting location on the windshield, and verify the camera has a clear,
unimpeded view.
3 After you have selected a mounting location with a clear view, remove the protective film from the mount
adhesive.
4 Position the mount over the mounting location.
TIP: The adhesive is extremely sticky. Avoid touching the adhesive to the windshield until the mount is
properly positioned.
5 Press the mount firmly onto the windshield, and maintain pressure for 30 seconds.
This helps to ensure the mount adhesive has proper contact with the windshield.
Installation
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
7
Connecting the Camera to Vehicle Power
1 Plug the power cable into the USB-C
®
port on the camera.
2 Route the power cable to your vehicle power outlet.
NOTICE
You should power the camera using the included vehicle power adapter and avoid using a vehicle USBport.
A vehicle USBport may not provide enough power for reliable camera operation.
The included lightweight power cable is designed to be routed out of sight. To hide the power cable, route it
behind the vehicle trim along the windshield, doorframe, or dash.
8
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
Installation
3
Plug the GarminCatalyst
™
2 power cable into the included vehicle power adapter.
4 Plug the vehicle power adapter into the power outlet in your vehicle.
5 If necessary, turn on the vehicle ignition switch to provide power to the power outlet in your vehicle.
The camera turns on.
Turning On the Device Manually
When the device is connected to an ignition-switched power outlet, it turns on automatically when you turn on
the vehicle.
Press .
The device turns on.
Turning Off the Device Manually
NOTE: When the device is connected to an ignition-switched power outlet, it turns off automatically when you
turn off the vehicle.
1 Hold for 3 seconds.
2 Select Off.
Pairing a Wireless Headset or Car Stereo
You can pair a wireless headset or stereo with your GarminCatalyst
™
2 device to hear coaching tips and audible
lap times as you drive.
1 Place your GarminCatalyst2 device and your headset or stereo within 10m (33ft.) of each other.
2 On your GarminCatalyst2 device, swipe the screen left to open the menu.
3 Select Settings> Audio> Add Bluetooth Audio.
4 On your headset or stereo, enable Bluetooth
®
technology and make it visible to other Bluetooth devices.
5 On your GarminCatalyst2 device, select OK, and select your headset or stereo from the list of devices.
6 Follow the on-screen instructions to complete the pairing process.
Installation
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
9
Device Overview
1
Press to turn the device on.
Hold for 3 seconds to turn the device off.
Press to return to the previous page.
2
Press to scroll through menus or pages.
3
Press to scroll through menus or pages.
4
Press to choose an option in a menu.
Using the Touchscreen
● Tap the screen to select an item.
● Drag or swipe your finger across the screen to pan or scroll.
Home Screen
1
Video footage remaining
Displays the video footage remaining on the installed memory card.
2
Status bar
Select an icon to view more information (Status Bar Icons, page11).
3
Time
Displays the current time.
4
Swipe the screen left to open the device menu.
5
Select to start a drive session (Starting a Drive Session, page12).
10 GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
Device Overview
Status Bar Icons
The status bar is located at the top of the home screen. The status bar icons display information about features
on the device. You can select some icons to change settings or view additional information.
GPS signal status. Select to view location accuracy and acquired satellite information.
Bluetooth
®
audio connection status. Select to view the Bluetooth audio settings.
Driver profile. Select to switch driver profiles or vehicles.
Battery charge level.
Device Overview GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
11
Starting a Drive Session
Before you can start a drive session, your device must acquire satellite signals. You can select in the status
bar to check the current signal strength and accuracy.
1 From the home screen, select Drive.
2 Select a track.
3 If necessary, select a track configuration.
4 Align the camera so the bottom of the rectangle
1
is aligned with the front of your vehicle's hood or fenders,
and the camera is centered on a distant object straight in front of your vehicle, and select Done.
5 Select an option:
● To change your driver profile, select > Switch Profiles.
● To change your vehicle profile, select > Vehicle.
● To configure lap timer settings, select , and select Delta Timer or Lap Timer Display.
● To change your track conditions, select Session Settings, and select , , or .
● To change your audio configuration, select Session Settings, and select your audio connection.
● To enable or disable audio recording, select Session Settings> Record Camera Audio.
6 Select Start.
7 Start driving.
The timer starts automatically when you cross the starting line. Video recording starts when your vehicle
reaches 40km/h (25mph).
Race Timer
As you drive, the device keeps track of your progress and gives you audible coaching tips over your paired
headset or stereo (Pairing a Wireless Headset or Car Stereo, page9). The race timer keeps track of your lap
number and shows your best lap times.
12
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
Starting a Drive Session
1
LAST LAP
Displays the most recent lap time during the current session.
2
TODAY'S BEST
Displays the best lap time for the current day.
TIP: You can change the Delta Timer setting in the driver profile menu to change this field.
3
Delta timer
Displays the time difference between the current lap and the best lap during the current session.
4
LAP
Displays the current lap number.
5
Session timer
Displays the total time of all laps in the current session.
6
STOP
Select to end the current session.
Pausing a Drive Session
You can pause a drive session that is already in progress. When you pause a drive session, the device stops
recording audio and video and stops recording some race data. This is useful if your vehicle breaks down on the
track, or if you make a long pit stop.
When you come to a stop, the device automatically pauses the drive session. If you make a long pit stop, the lap
will not be factored in to the overall session statistics.
1 Stop the vehicle, or select STOP.
2 Select an option:
● To stop the drive session and save session data, select Save.
● To continue the drive session, select Resume.
The session automatically resumes when you begin driving again.
Adding a Track
You can add a track that is not already loaded on your device. The device uses your GPS location and your
vehicle's movements to create a map of the track.
1 Select Drive> Add a Track.
2 Align the camera so the bottom of the rectangle is aligned with the front of your vehicle's hood or fenders,
and the camera is centered on a distant object straight in front of your vehicle, and select Done.
3 If necessary, adjust your driver profile and session settings.
4 Select Start.
5 Start driving.
After you exit the pit area and enter the track, you must drive in a straight line for at least 0.5 seconds at a
minimum of 55 mph (90 km/h), and complete one full lap.
6 Select END after you have completed the drive session.
7 Select Save.
You can adjust the starting position using the GarminCatalyst
™
app after you synchronize your drive session
(Transferring Drive Sessions to the GarminCatalyst
™
App, page19).
Starting a Drive Session
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
13
Adding a Track Configuration
You can add additional configurations for tracks that are stored on your device.
1 Select Drive.
2 Select a track.
3 Select Add a Track Configuration.
4 Align the camera so the bottom of the rectangle is aligned with the front of your vehicle's hood or fenders,
and the camera is centered on a distant object straight in front of your vehicle, and select Done.
5 If necessary, adjust your driver profile and session settings.
6 Select Start.
7 Start driving.
After you exit the pit area and enter the track, you must drive in a straight line for at least 0.5 seconds at a
minimum of 55 mph (90 km/h), and complete one full lap.
8 Select END after you have completed the drive session.
9 Select Save.
You can adjust the starting position using the GarminCatalyst
™
app after you synchronize your drive session
(Transferring Drive Sessions to the GarminCatalyst
™
App, page19).
Selecting a Vehicle or Driver Profile
Before you can select a vehicle or driver profile, you must pair your device with the GarminCatalyst
™
app on
your phone or tablet (Pairing Your Device with the GarminCatalyst
™
App, page18), and create a profile using the
GarminCatalyst app (Adding or Editing a Driver Profile Name, page22).
TIP: If you haven't configured a driver profile using the GarminCatalyst app, you can use the Guest profile.
1 From the home screen, swipe the screen left to open the menu.
2 Select an option:
● To change your driver profile, select > Switch Profiles.
● To change your vehicle profile, select > Vehicle.
3 Select a vehicle or driver profile.
14
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
Starting a Drive Session
Reviewing Drive Sessions on Your GarminCatalyst
™
2 Device
WARNING
Do not review any drive sessions while driving. Failure to pay attention to your surroundings and road conditions
can result in serious personal injury or death.
The device records detailed information about each drive session. You can view the results of each drive
session on your device. The device prompts you to review each drive session automatically at the end of each
session.
1 From the home screen, swipe the screen left to open the menu.
2 Select Review.
3 Select a track.
4 If necessary, select a track configuration and a drive session.
The device displays your lap times and variance information for the drive session. You can select Laps to view
additional details about each lap.
TIP: You can review drive session videos, opportunities, and detailed metrics in the GarminCatalyst app on your
paired phone or tablet
(GarminCatalyst
™
App, page18).
Reviewing Drive Sessions on Your
GarminCatalyst
™
2 Device
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
15
Settings
From the home screen, swipe the screen left and select Settings.
Audio: Sets audio options for your paired headset or stereo (Audio Settings, page16).
Video: Sets options for video footage recorded using the GarminCatalyst
™
2 device (Video Settings, page16).
Brightness: Sets the screen brightness.
Mobile Device: Allows you to manage wireless connections with phones or tablets using the GarminCatalyst
app.
System: Sets the system language and units of measure (System Settings, page16).
Device: Displays device regulatory information, license information, and memory card format options (Device
Settings, page16).
Audio Settings
NOTE: Before you can access the audio settings menu on your GarminCatalyst
™
2 device, you must pair your
device with a compatible headset or stereo (Pairing a Wireless Headset or Car Stereo, page9).
From the home screen, swipe the screen left and select Settings> Audio.
Test Audio: Plays a recording to test audio functionality on your paired headset or stereo.
Bluetooth Audio: Sets the Bluetooth
®
audio output.
Volume: Sets the volume level on the paired headset.
Delay Correction: Allows you to set a correction of up to 2 seconds if there is a delay in your Bluetooth audio.
Audible Lap Times: Enables or disables lap time updates that are audible through your headset or stereo.
Disconnecting a Wireless Headset or Stereo
1 Swipe the screen left to open the menu.
2 Select Settings> Audio> Bluetooth Audio.
3 Select the name of your headset or stereo.
4 Select an option:
● To temporarily disconnect the headset or stereo, select Disconnect.
● To unpair the connected headset or stereo, select Forget.
Video Settings
From the home screen, swipe the screen left and select Settings> Video.
Record Session Videos: Enables the device to record session videos to the installed memory card.
True Track Positioning: Enables the device to use multiple inputs to determine the location of the vehicle on the
race track.
Camera Lens Cover: Sets the camera to account for a polarized lens cover or a clear cover when recording
video.
Record Camera Audio: Enables the camera to record audio during a session.
Format Memory Card: Formats the installed memory card and deletes all information saved to the card,
including recorded sessions and saved videos.
System Settings
From the home screen, swipe the screen left and select Settings> System.
Voice Language: Sets the voice language.
Text Language: Sets the language for text displayed on the screen.
Speed Units: Sets the unit of measure for speed.
Distance Units: Sets the unit of measure for distance.
Time Format: Sets the display format for the time.
Auto-Off: Sets options to turn off the device automatically if it is not used for a period of time.
Device Settings
From the home screen, swipe the screen left and select Settings> Device.
Regulatory: Displays e-label regulatory and compliance information.
About: Displays hardware and software version information.
EULAs: Allows you to view the end-user license agreements (EULAs).
16
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
Settings
Software Licenses: Displays software license information.
Format Memory Card: Formats the installed memory card and deletes all information saved to the card,
including recorded sessions and saved videos.
Reset Device: Allows you to clear your recorded sessions, driver profiles, vehicle profiles, and custom tracks,
and to restore all settings to default values.
NOTE: Videos stored on the memory card are not deleted when resetting the device.
Resetting Data and Settings
The device offers several options for deleting your user data and resetting all settings to the factory default
values.
1 From the home screen, swipe the screen left to open the menu.
2 Select Settings> Device.
3 Select an option:
● To remove all information, including recorded sessions and saved videos from the installed memory card,
select Format Memory Card.
This option does not delete any user data.
● To delete all user data and reset all settings to the factory default values, select Reset Device.
This option deletes all user data from the device, including your recorded sessions, driver profiles, vehicle
profiles, and custom tracks. Videos stored on the memory card are not deleted. User data stored in the
GarminCatalyst
™
app is not deleted.
Settings
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
17
GarminCatalyst
™
App
The GarminCatalyst app is required to view videos and performance data recorded from your GarminCatalyst2
device. You can review lap times, session summaries, opportunities, and annual driving activity metrics. You can
download the GarminCatalyst app from the app store on your phone or tablet, or go to garmin.com/catalystapp
for more information.
Pairing Your Device with the GarminCatalyst
™
App
The first time you turn on your GarminCatalyst2 device, it presents you with a QR code to pair it with the
GarminCatalyst app on your phone or tablet. If you skip this step during initial setup, you can start the pairing
process at a later time.
1 From the home screen on your GarminCatalyst2 device, swipe to the left to open the menu.
2 Select Settings> Mobile Device> Add New Mobile Device.
3 Scan the QR code with your phone or tablet to download and install the GarminCatalyst app and start the
pairing process.
GarminCatalyst
™
App Overview
1
Device connection
status
Displays the connection status and session data transfer progress of your paired
GarminCatalyst2 device.
NOTE: The device connection status does not appear unless the app is actively connected
to the device.
2
Driver profile
Displays the current driver profile.
3
Driver profile metrics
Displays the recorded driving metrics for the current driver profile.
18 GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
GarminCatalyst
™
App
4
Recorded drive
sessions list
Displays the list of available drive sessions that have been transferred to the app. You can
select a drive session to view detailed information and videos from the drive session.
5
Sessions
Select to review drive sessions stored in the app.
NOTE: This tab is selected by default when you open the GarminCatalyst app.
6
Tracks
Select to view and search for available tracks and track configurations in the
GarminCatalyst app.
7
Friends
Select to view metrics from friends and leaderboard positions.
8
Profile
Select to view and edit your driver profile and vehicle profile.
Transferring Drive Sessions to the GarminCatalyst
™
App
After you pair your GarminCatalyst2 device with the GarminCatalyst app, the device sends session information
to the app automatically using Bluetooth
®
technology. You can open the app and transfer videos from the device
to the app using a direct Wi‑Fi
®
connection.
1 Open the GarminCatalyst app on your phone or tablet.
The GarminCatalyst app prompts you to import video using a direct wireless network connection.
2 Select an option:
● To start importing video using a direct Wi‑Fi connection, select Start.
● To import video at a later time, select Import Video Later.
The session transfer progress
1
appears at the top of the GarminCatalyst app screen.
Reviewing Drive Sessions in the GarminCatalyst
™
App
WARNING
Do not review any drive sessions while driving. Failure to pay attention to your surroundings and road conditions
can result in serious personal injury or death.
Before you can review drive sessions in the GarminCatalyst app, you must import session information from
your GarminCatalyst2 device (Transferring Drive Sessions to the GarminCatalyst
™
App, page19).
The device records detailed information about each drive session. You can view the results of each drive
session individually or compare data with another session.
1 From the GarminCatalyst app, select the Sessions tab.
2 Select a drive session.
GarminCatalyst
™
App GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
19
Session Summary
1
Overview
Displays a summary of the data recorded during the selected session.
2
Laps
Select to view detailed lap information for the selected session.
3
Graphs
Select to view graphs of data recorded during the selected session.
4
Track map
Displays a map of the track used in the selected session.
5
Session information options
Select an option to view additional details about the selected session.
6
Session summary information
Displays a summary of data recorded during the selected drive session.
Viewing Session Videos in the GarminCatalyst
™
App
Before you can view recorded videos in the GarminCatalyst app, you must transfer your videos from your
GarminCatalyst2 device (Transferring Drive Sessions to the GarminCatalyst
™
App, page19).
1 From the GarminCatalyst app, select the Sessions tab.
2 Select a drive session.
3 Select Video.
The optimal lap video plays by default. You can select different laps and lap segments using the options on the
screen.
20 GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
GarminCatalyst
™
App
Session Videos
1
Lap and segment numbers.
2
A map of the track. The position of your vehicle is marked with a dot.
3
The speed of the vehicle.
4
Lap timer information.
5
A traction circle. The dot moves to indicate the direction and strength of G-force.
Comparing Sessions
WARNING
Session comparison allows drivers to compare sessions between different vehicles and is intended for use by
experienced high-speed drivers only. Modifying driving behavior based on the performance of a different vehicle
could result in an accident involving property damage, personal injury, or death.
You can compare the results of two drive sessions. This can help you to see areas of improvement between two
sessions or compare the results between different vehicles on the same track.
NOTE: You can only compare sessions that use the same track and track configuration.
1
From the GarminCatalyst
™
app, select the Sessions tab.
2 Select a drive session.
3 Select > Compare With My Other Sessions.
4 Select a session.
Saving a Session Video
Before you can save recorded videos in the GarminCatalyst
™
app, you must transfer your videos from your
GarminCatalyst2 device (Transferring Drive Sessions to the GarminCatalyst
™
App, page19).
You can save your session videos to your mobile device's storage to make them accessible to other
applications.
1 From the GarminCatalyst app, select the Sessions tab.
2 Select a drive session.
3 Select Video.
4 If necessary, select a lap or lap segment.
5 Select Save Video.
6 Follow the on-screen instructions to select a save location.
Deleting Sessions
You can delete drive sessions to clear space on your phone or tablet. You cannot recover deleted drive
sessions.
1
From the GarminCatalyst
™
app, select the Sessions tab.
GarminCatalyst
™
App GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
21
2 Select a drive session.
3 Select > Delete Session.
Deleting Session Videos
You can delete drive session videos to clear space on your phone or tablet. Deleting videos does not delete
other session information.
1 From the GarminCatalyst
™
app, select Profile> > Video Storage.
2 Select one or more video files.
3 Select Delete.
Reviewing and Comparing Laps in the GarminCatalyst
™
App
The Laps page lets you review and compare data recorded for each lap. You can compare any two laps from the
same session.
1 From the GarminCatalyst app, select the Sessions tab.
2 Select a session.
3 Select Laps.
4 Select a lap.
A diagram of the track and your track position for the lap appears on the screen.
5 Select an option:
● To view a video of the lap, select Video.
● To compare the current lap with another lap, select Compare with:, and select a lap.
● To view graphs of recorded statistics, select Select Graphs, and select one or more graph options.
Viewing Opportunities
During a drive session, the device analyzes your performance and records opportunities for improvement.
Opportunities are coaching tips that help you decrease your lap time. The opportunity page enables you to
review opportunities and offers tips for improvement.
1
From the GarminCatalyst
™
app, select the Sessions tab.
2 Select a drive session.
3 Select Opportunities.
4 Select an option:
● To cycle through opportunities, select or .
● To view additional details about opportunities, select Braking, Apex, or Speed.
● To view available opportunities by track segment, select Segment.
Viewing Track Information
You can view information and statistics about all race tracks that are available in the GarminCatalyst
™
app.
1 From the GarminCatalyst app, select the Tracks tab.
2 Select the search bar.
3 Enter all or part of a track name.
Suggested track names appear below the search bar.
4 Select a track.
Adding or Editing a Driver Profile Name
The first time you use the GarminCatalyst
™
app, the app walks you through creating a driver profile. You can edit
your driver profile at any time.
1 From the GarminCatalyst app, select Profile.
2 Select , and enter a new name.
Adding or Editing a Vehicle Profile
1
From the GarminCatalyst
™
app, select Profile> Vehicles.
2 Select an option:
● To add a vehicle profile, select Add a Vehicle.
22 GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
GarminCatalyst
™
App
● To edit a vehicle profile, select a vehicle.
3 Select a field to enter information about your vehicle.
4 If necessary, select Add Tires, and add information about your tires.
5 Select Done.
Adding Friends to the GarminCatalyst
™
App
You can add friends to the GarminCatalyst app and share lap times and session information. Friends can send
you their contact information using a QR code on their phone or a link in an email or text (Sharing Your Card with
the GarminCatalyst
™
App, page23).
Select an option:
● To add a contact from a link generated by the GarminCatalyst app, select the link sent to you from your
friend's GarminCatalyst account.
● To add a contact from a shared QR code, open the GarminCatalyst app and select Friends> Scan a
Driver Code, and scan your friend's driver code.
Sharing Your Card with the GarminCatalyst
™
App
1 From the GarminCatalyst app, select Friends> Share My Card.
2 Select an option:
● To share your card using a QR code, allow your friend or contact to scan the QR code on your screen.
● To send your friend a contact request, select Share, and select an app or contact to share the request.
● To send a direct link, select Copy Link, and paste the link into a message to your friend or contact.
Changing the Units of Measure in the GarminCatalyst
™
App
You can customize the units of measure displayed in the GarminCatalyst app.
1 From the GarminCatalyst app, select Profile> > Units.
2 Select the units of measure for each category.
GarminCatalyst
™
App GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
23
Vault Storage
NOTE: This feature requires an active Vault subscription. Vault features are not available for all countries.
You can upload, manage, and share recorded videos on a secure, online storage drive using the Vault. With
a paid subscription, the GarminCatalyst
™
app uploads optimal and best lap videos to the Vault automatically
while it is connected to a Wi‑Fi
®
network.
You can purchase a Vault subscription from the GarminCatalyst app on your phone or tablet (GarminCatalyst
™
App, page18).
Subscribing to Vault
You can purchase a Vault subscription to store your videos in a secure online storage drive.
1 From the GarminCatalyst
™
app on your phone or tablet, select Profile> > Vault Access.
2 Select Subscribe Now.
3 Follow the on-screen instructions.
Sharing a Video
Before you can share videos, you must purchase a Vault subscription.
You can upload a video to the Vault and share it on the leaderboard.
1
From the GarminCatalyst
™
app on your phone or tablet, select the Sessions tab.
2 Select a session.
3 Select Video> Save Video> Upload to Vault.
Disabling a Shared Video Link
You can disable a link to a video that you previously shared from the Vault. When you disable a shared video
link, the video is set to private and the shared link and passcode are disabled.
1
From the GarminCatalyst
™
app on your phone or tablet, select Vault.
2 Select a video, and select Disable Link> Continue.
Removing a Video from the Vault
1
From the GarminCatalyst
™
app on your phone or tablet, select Vault.
2 Select a video, and select Remove From Vault> Continue.
24
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
Vault Storage
Device Information
Viewing E-label Regulatory and Compliance Information
1 From the settings menu, swipe to the bottom of the menu.
2 Select Device> Regulatory.
Specifications
Operating temperature range From -20° to 70°C (from -4° to 158°F)
Charging temperature range From 0° to 60°C (from 32° to 140°F)
Wireless frequency 2400 – 2483,5 MHz: < 20 dBm
5150 – 5250 MHz: < 16 dBm
EU SAR < 0,96 W/kg trunk, < 0,96 W/kg limb
Input voltage From 4.75 to 5.25Vdc, 2A
Battery type Rechargeable lithium-ion
Battery life Up to 45 min.
Charging the Device
NOTE: This Class III product shall be powered by an LPS power supply.
You can charge the battery in the device using any of these methods.
● Connect the device to vehicle power.
● Connect the device to an optional power adapter accessory, such as a wall power adapter.
You can purchase an approved Garmin
®
AC-DC adapter suitable for home or office use from a Garmin dealer
or www.garmin.com. The device may charge slowly when connected to a third-party adapter.
Device Information
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
25
Device Maintenance
Garmin
®
Support Center
Go to support.garmin.com for help and information, such as product manuals, frequently asked questions,
videos, and customer support.
Software Updates
For the best experience, you should keep the software on your device up to date. Software updates provide
changes and improvements to privacy, security, and features.
You can update your device using two methods.
●
You can update your device using the GarminCatalyst
™
app on your paired phone or tablet (recommended).
This option allows you to update your device conveniently without connecting it to a computer.
●
You can connect the device to a computer and update it using the Garmin Express
™
application
(garmin.com/express).
Updating Software with the GarminCatalyst
™
App
When a software update is available, the GarminCatalyst app downloads it automatically. The next time you
connect to your GarminCatalyst2 device, the app prompts you to send the update to your device.
1 Turn on your GarminCatalyst2 device.
2 Open the GarminCatalyst app on your phone or tablet.
3 From the GarminCatalyst app, select Send Update.
4 Follow the on-screen instructions in the GarminCatalyst app to install the software update on your device.
Updating Software with Garmin Express
™
You can use the Garmin Express application to download and install the latest software updates for your device.
1 If you do not have the Garmin Express application installed on your computer, go to garmin.com/express
and follow the on-screen instructions to install it (Installing Garmin Express
™
, page27).
2 Open the Garmin Express application.
3 Connect your device to your computer using a USB-C
®
cable that is capable of transferring data.
The small end of the cable connects to the USB-C port
1
on your GarminCatalyst
™
2 device, and the large
end connects to an available USBport on your computer.
4 From your GarminCatalyst2 device, select Connect to Computer.
TIP: If you do not see the prompt to connect to your computer, you can select Connect to Computer from the
settings menu on your device.
5 In the Garmin Express application, click Add a Device.
The Garmin Express application searches for your device and displays the device name and serial number.
6 Click Add Device, and follow the on-screen instructions to add your device to the Garmin Express application.
When setup is complete, the Garmin Express application displays the updates available for your device.
26
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
Device Maintenance
7 Select an option:
● To install all available updates, click Install All.
● To install a specific update, click View Details, and click Install next to the update you want.
The Garmin Express application downloads and installs the updates onto your device.
8 Follow the on-screen instructions during the update process to finish installing updates.
For example, during the update process, the Garmin Express application may instruct you to disconnect and
reconnect your device.
Installing Garmin Express
™
The Garmin Express application is available for Windows
®
and Mac
®
computers.
1 On your computer, go to garmin.com/express.
2 Select an option:
● To view the system requirements and verify the Garmin Express application is compatible with your
computer, select System Requirements.
● To install on a Windows computer, select Download for Windows.
● To install on a Mac computer, select Download for Mac.
3 Open the downloaded file, and follow the on-screen instructions to complete the installation.
Device Care
NOTICE
Avoid dropping your device.
Do not store the device where prolonged exposure to extreme temperatures can occur, because it can cause
permanent damage.
Never use a hard or sharp object to operate the touchscreen, or damage may result.
Do not expose the device to water.
Cleaning the Outer Casing
NOTICE
Avoid chemical cleaners and solvents that can damage plastic components.
1 Clean the outer casing of the device (not the touchscreen) using a cloth dampened with a mild detergent
solution.
2 Wipe the device dry.
Cleaning the Touchscreen
1 Use a soft, clean, lint-free cloth.
2 If necessary, lightly dampen the cloth with water.
3 If using a dampened cloth, turn off the device and disconnect the device from power.
4 Gently wipe the screen with the cloth.
Cleaning the Camera Lens
NOTICE
Avoid chemical cleaners and solvents that can damage plastic components.
You should clean the camera lens regularly to improve the quality of recorded video.
1 Wipe the lens with a non-scratch lens cloth, optionally dampened with isopropyl alcohol.
2 Allow the lens to air dry.
Device Maintenance
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
27
Restarting the Device
You can restart your device if it stops functioning.
Hold the power button for 10 seconds.
28 GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
Device Maintenance
Troubleshooting
My device is not acquiring satellite signals
● Install all available software updates.
● Take your device out of parking garages and away from tall buildings and trees.
● Remain stationary for several minutes.
My device does not pair with my phone or tablet
The phone or tablet is too far away from your device.
● Bring your phone or tablet within range of your device.
The phone or tablet is already paired, but is non-functional.
● If your phone or tablet is already paired but is not connecting to the device, turn off Bluetooth
®
technology on
your phone and turn it back on.
Your device was recently reset and contains old pairing information.
● If you recently reset your device, you must forget or delete the pairing information from both your phone's
Bluetooth settings and your GarminCatalyst
™
2 device.
Scanning the QR code from your phone's camera app did not start the pairing process.
1 On your GarminCatalyst2 device, swipe the screen left, and select Settings> Mobile Device> Add New
Mobile Device.
A QR code appears on the GarminCatalyst2 screen.
2 On your phone or tablet, open the GarminCatalyst app, and select Profile> > Add Device.
3 On your phone or tablet, select an option:
● Scan the QR code displayed on the GarminCatalyst2 screen.
● Select your device from the list.
4 Follow the on-screen instructions to complete the pairing and setup process.
The device does not charge in my vehicle
● Verify you are using a compatible power cable or charger supplied by Garmin
®
.
● Verify the vehicle is turned on and is supplying power to the power outlet.
● Verify the interior temperature of the vehicle is within the charging temperature range indicated in the
specifications.
● In the vehicle fuse box, verify the fuse for the vehicle power outlet is not broken.
My camera feels warm while it is operating
Garmin
®
cameras are designed for the automotive environment. It is normal and expected for the products to
become warm or hot and remain safe for use in warm climates with full sun exposure. The temperature of the
device itself can exceed the specified maximum operating ambient temperature for the device and remain safe
for use. Always follow the device use and care instructions contained in the product manual.
My video recordings are blurry
● Clean the camera lens (Cleaning the Camera Lens, page27).
● Clean the windshield in front of the camera.
● Verify the area of the windshield in front of the camera is cleared by the windshield wipers, and move the
device, if necessary.
Troubleshooting
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
29
Appendix
Data Management
The device has a memory card slot for additional data storage.
NOTE: The device is compatible with Windows
®
7 and newer, and Mac
®
OS 10.4 and newer.
Memory Cards
You can purchase memory cards from an electronics supplier. Memory cards can be used to store video
footage and data from your drive sessions.
Memory Card Specifications
The camera requires a memory card with these specifications. Go to garmin.com/dashcamcards to view a list
of recommended memory cards.
Type microSDHCor microSDXC
Capacity From 32 to 512 GB
Speed class Class 10 or higher
File system exFAT
Connecting the Device to Your Computer
You can connect the device to your computer using a USB-C
®
cable.
1 Plug the USB-C cable into the port on the device.
2 Plug the other end of the cable into a port on your computer.
3
On your GarminCatalyst
™
2 device, swipe the screen left to open the menu.
4 Select Settings> Connect to Computer.
Depending on your computer operating system, the device appears as either a portable device, a removable
drive, or a removable volume.
Disconnecting the USB Cable
If your device is connected to your computer as a removable drive or volume, you must safely disconnect your
device from your computer to avoid data loss. If your device is connected to your Windows
®
computer as a
portable device, it is not necessary to safely disconnect the device.
1 Complete an action:
● For Windows computers, select the Safely Remove Hardware icon in the system tray, and select your
device.
● For Apple
®
computers, select the device, and select File> Eject.
2 Disconnect the cable from your computer.
Purchasing Accessories
● Optional accessories are available at garmin.com or from your Garmin
®
dealer.
30
GarminCatalyst™2
Racetrack DrivingPerformanceOptimizer
Owner's Manual
Appendix
support.garmin.com
© 2026 Garmin Ltd. or its subsidiaries
Garmin
®
and the Garmin logo are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. GarminCatalyst
™
and Garmin
Express
™
are trademarks of Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin.
Apple
®
and Mac
®
are trademarks of Apple Inc, registered in the U.S. and other countries and regions. The Bluetooth
®
word mark and logos are owned by
the Bluetooth SIG, Inc., and any use of such name by Garmin is under license. microSD
®
is a trademark of SD-3C. USB-C
®
is a registered trademark of USB
Implementers Forum. Wi‑Fi
®
is a registered trademark of Wi-Fi Alliance. Windows
®
is a registered trademark of Microsoft Corporation in the United States and
other countries.
February 2026 GUID-9592B201-210B-4F3A-9081-7F876CC81A25 v1
