GB
Instruction manual
Heat pad XL HP 650
Device and controls
1
Power LED
2
Slider control
Do not use the heated cushion when it is
folded!
Do not puncture the heated cushion
Not suitable for children under 3 years!
Only use the heated cushion indoors!
The heat pad can be cleaned in a
gentle wash cycle at max. 30°C!
Do not bleach!
Do not dry the heated cushion in a tumble
drier!
Do not iron the heated cushion!
Do not dry clean!
IMPORTANT!
Non-observance of these instructions
can result in serious injury or damage
to the device.
WARNING
These warning notes must be observed to
prevent any injury to the user.
CAUTION
These notes must be observed to prevent
any damage to the device..
NOTE
These notes provide useful additional infor-
mation on the installation or operation.
Protection category II
LOT number
Manufacturer
Explanation of symbols
Power supply
• Before connecting the device to your power supply, please ensure that
the supply voltage stated on the rating plate is compatible with your mains
supply.
• The control switch should not be covered or placed on or below the pad
while the unit is in operation.
• Keep the mains lead away from hot surfaces.
• Never carry, pull or turn the heat pad by the mains lead and do not let the
lead get tangled.
• Never touch a device that has fallen into water. Unplug the unit from the
mains outlet immediately.
• The controls and leads must not be exposed to any kind of moisture.
• The heat pad may only be operated with the control unit (HP650)
supplied.
For special people
• Do not use the heat pad on children or persons who are disabled, asleep
or insensitive to heat (persons who cannot react on overheating).
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
• Children shall not play with the appliance.
• Children below the age of 3 years are not allowed to use this device,
because they are not able to react on overheating.
• The heat pad must not be used by young children over the age of 3 years,
unless the control unit has been adjusted accordingly by its parents or
legal guardians and unless the child has been well instructed how to use
the control unit properly.
• Should you have any concerns about health issues, consult your doctor
before using the heat pad.
• Do not use the heat pad on parts of the body that are swollen, injured or
inamed.
• Should you experience persistent pains in the muscles and joints, please
inform your doctor. Persistent pains can be a symptom of serious illness.
• If you wear a pacemaker, please be aware that the electromagnetic elds
emanating from this electric product may, under certain circumstances,
interfere with the functions of your pacemaker. Therefore, ask your doctor
and the manufacturer of the pacemaker for advice before using this
product.
• If you experience any pain or discomfort while using the unit, stop using it
immediately.
• The appliance can be used by children older than 3 years and younger
than 8 years under supervision and with the control always set to
minimum temperature value.
• The cable and control unit of the appliance can give rise to risks of
entanglement, strangulation, tripping or treading if not correctly arranged.
The user shall make sure that excess ties and electric cords shall be
arranged in a safe way.
Operating the device
• Only use the device for its intended use as in the instruction manual.
• If misused, all guarantee rights shall become null and void.
• Carefully check the heat pad before each use, if you notice wear or
damage.
• Do not use if you notice wear, damage or signs of improper use on the
heat pad, the switch or the cables or if the device is not working.
• Do not fold or crease the heat pad during use.
• Neither pierce the pad with, nor attach safety pins or other spiky or sharp
objects to the pad.
• Never use the pad unsupervised.
• The device is only for private use and is not to be used in hospitals.
• Do not fall asleep while the heat pad is switched on. Prolonged use of the
heated cushion at a high setting could lead to skin burns.
• Do not cover the pad with any other cushions.
• Do not sit on the heat pad. Instead, rest the pad on or against the part of
the body to be treated.
• Do not use the heat pad when wet and only use it in dry environments
(not in the bathroom or similar environments).
Maintenance and cleaning
• You are only permitted to clean the unit. To avoid hazards, never repair
the device yourself. Contact the customer service.
• Cleaning and user maintenance shall not be made by children without
supervision.
• If the power supply cable is damaged, it may only be replaced by
medisana, an authorised dealer or by qualied personnel in order to avoid
hazards.
• A damaged power supply cable must be replaced with a power cable of
the same type.
• If a fault occurs, do not attempt to repair the unit yourself. Repairs must
only be carried out by an authorized specialist dealer or other suitably
qualied personnel.
• When storing the heat pad, allow it to cool down before laying out at in a
clean and dry place.
• Do not store the device with any objects covering or resting on top of it in
order to avoid sharp crinkles.
Scope of supply
Please check rst of all that the device is complete and is not damaged in
any way. In case of doubt, do not use the it and contact your dealer or your
service centre.
The following parts are included:
• 1 medisana Heating pad XL HP 650 with removable switching unit
• 1 Instruction manual
If you notice any transport damage during unpacking, please contact your
dealer without delay.
WARNING
Please ensure that the polythene packing is kept away from
the reach of children!
Risk of suffocation!
Operating
Make sure, the connection cable of the control unit is properly connected to
the plug of the heat pad. Plug the unit into the mains outlet and move the
slider control
2
from position 0 to position 1. The power LED
1
will light up
in green.
After a few minutes you will be able to feel the pad getting noticeably
warmer. If you require a higher temperature setting, move the switch to the
next positions 2 or 3 or the maximum heat setting, position 4. If the heat
pad gets too hot for you, move the slider back to position 3, 2 or 1. After a
short time, the heat pad will cool down.
The heat pad may cool down after a short period of time. This is normal. The
fast re-heating according to the setting will follow immediately.
To switch the unit off, move the switch back to position 0. The power LED
1
will go out, indicating that the unit is switched off. Unplug the unit from the
mains outlet.
Move the switch to position 1 for any continuous use. The heat pad will
switch off automatically after approx. 90 minutes of continuous use.
To switch it back on again, move the slider switch to position 0 and then back
to the desired heat setting.
Unplug the unit from the mains outlet once you have nished using it.
Troubleshooting
If there is no function at all after switching on the heat pad (power LED
1
shows no light), please check if the mains plug is correctly plugged in the
mains outlet. If this is the case, the heat pad is defect. Please do not use the
heat pad and contact the service center.
Cleaning and maintenance
• Before cleaning the pad, unplug it from the mains outlet and let it cool
down for at least ten minutes.
• The heat pad is equipped with a removable control unit (HP 650).
• Unplug the control unit from the heat pad by pulling out the connection
cable from the plug on the heat pad.
• The heat pad can be cleaned dry (with a soft brush) or as described in the
instructions on the product label.
• Never use strong detergents or hard brushes.
• To dry, lay the pad at on a moisture-absorbent towel or mat.
• Only use the blanket again once it is completely dry.
• Reconnect the control unit to the heat pad in the correct manner.
• You should untangle the cable from time to time.
• Store the unit in a clean and dry place, laid out at with nothing covering
or resting on top of it.
Disposal
This product must not be disposed of together with domestic
waste. All users are obliged to hand in all electrical or electronic
devices, regardless of whether or not they contain toxic
substances, at a municipal or commercial collection point so
that they can be disposed of in an environmentally acceptable
manner. Consult your municipal authority or your dealer for
information about disposal.
Technical specications
Name and model:
Power supply:
Heat output:
Automatic switch-off:
Dimensions approx.:
Weight approx.:
Operating conditions:
Storage conditions:
Art. number:
EAN number:
medisana Heating pad XL HP 650
220-240V~, 50/60 Hz
100 watts
after approx. 90 minutes
45 x 35 cm
0.5 kg
Only use in dry rooms according to this user
manual
Laid out at, clean and dry
48840
40155 88 48840 5
In accordance with our policy of continual product improvement,
we reserve the right for technical and design changes without notice.
Warranty and repair terms
Please contact your dealer or the service centre in case of a claim under the
warranty. If you have to return the unit, please enclose a copy of your receipt
and state what the defect is.
The following warranty terms apply:
1. The warranty period for medisana products is one year from date of
purchase. In case of a warranty claim, the date of purchase has to be
proven by means of the sales receipt or invoice.
2. Defects in material or workmanship will be removed free of charge
within the warranty period.
3. Repairs under warranty do not extend the warranty period either for the
unit or for the replacement parts.
4. The following is excluded under the warranty:
a. All damage which has arisen due to improper treatment, e.g. non-
observance of the user instructions.
b. All damage which is due to repairs or tampering by the customer or
unauthorised third parties.
c. Damage which has arisen during transport from the manufacturer to
the consumer or during transport to the service centre.
d. Accessories which are subject to normal wear and tear.
5. Liability for direct or indirect consequential losses caused by the unit are
excluded even if the damage to the unit is accepted as a warranty claim.
medisana GmbH
Carl-Schurz-Str. 2
41460 NEUSS, GERMANY
IMPORTANT INSTRUCTIONS.
RETAIN FOR FUTURE USE.
GB Safety instructions
48840_HP 650_manual_GB_202207_L2
