32" OSCILLATING TOWER FAN
MODEL 1VAFT32
OWNER’S MANUAL
SAFETY & PRECAUTIONS
CONTINUEDCONTINUED
CONTENTS
INTENDED USE ................................................................................................................................................................. 3
IMPORTANT INSTRUCTIONS
....................................................................................................................................... 3
USAGE
.................................................................................................................................................................................. 5
CONTROL PANEL
............................................................................................................................................................ 6
IMPORTANT NOTE:
Read the manual carefully. Make sure to save this manual for future reference. Illustrations in this manual are
for explanatory purposes only, your actual product may look slightly dierent.
3
INTENDED USE
This product is intended for indoor residential and office use only, not for industrial or other commercial
applications. Use only with electrical wiring that is in good working order and that meets applicable codes
and ordinances. If you have any questions whether your wiring is adequate, consult a qualified electrician.
While using your fan, you should follow the IMPORTANT INSTRUCTIONS listed below. As part of those
instructions, we have used the word “WARNING” to indicate the level of hazard: WARNING indicates a hazard
which, if not avoided, could result in injury or death.
IMPORTANT INSTRUCTIONS
As with all electrical appliances, basic safety precautions should always be followed to reduce the risk of
electric shock, fire, or injury to persons, including the following precautions:
• Read all the instructions before using this fan.
• Use this fan only as described in this manual. Any other use not recommended by the manufacturer may
cause electrical shock, fire or injury to persons.
• Do not operate the fan with a damaged power cord or after the fan malfunctions or has been dropped in
any manner.
• Use of extreme caution is necessary when any fan is used by or near children, disabled persons or pets
and whenever the fan is left operating unattended.
• Do not place the fan on a small, unlevel, uneven or any surface which might allow fan to tip or fall.
• For proper operation, fan should be placed on a smooth, non-combustible, level surface.
• Always unplug fan when not in use, when moving from place to place, when assembling or disassembling
parts, and before cleaning.
• The use of attachments, not recommended or sold by the manufacturer, may cause hazards.
• Do not use outdoors.
• Do not use fan in window. Rain may cause electrical hazard (for non-window models).
• Do not operate the fan with blade guards or any safety device removed.
• Avoid the use of extension cords due to risk of fire. If an extension cord must be used, the cord must be
minimum 14 AWG and rated not less then 1875 watts.
• Do not run power cord under carpeting. Do not cover cord with throw rugs, runners or the like. Arrange
cord away from traffic area where it will not be tripped over.
• Do not insert or allow any object to enter any openings on the fan. Doing so may cause electric shock
and/or fire hazard. Avoid contact with moving parts.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with the appliance.
4
SAFETY & PRECAUTIONS
CONTINUEDCONTINUED
INTENDED USE
(Continued)
WARNING
WARNING
WARNING
WARNING
WARNING
Shock Hazard:
Use your fan only in dry environments. This fan is not intended for use in a bathroom, laundry area, or similar
locations, or near sinks, washing machines, swimming pools or other sources of water. Never locate fan
where it may fall into a bathtub or other water receptacle. Do not use in damp environments such as flooded
basements.
Hot Surfaces:
Do not touch fan motor when in use. This motor is hot when in use, to avoid burns, do not let bare skin touch
hot surfaces.
Fire Hazard:
Fans have arcing or sparking parts inside. Do not use near combustible materials or flammable gases or
sources of heat. DO NOT USE in areas where gasoline, paint or flammable materials are used or stored.
To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not insert or allow foreign
objects to enter any ventilation or exhaust opening as this may cause an electric shock, fire, or damage the
fan.
Electrical Shock Hazard:
Do not use with damaged cord or plug. Use with adequate electrical system that is up to code.
to Reduce the Risk of Fire or Electric Shock, do not use this product with any
solid-state speed control device.
to Prevent Electric Shock,this product has a polarized two prong plug (one
blade is wider than the other) that must be fully inserted in to a matching properly grounded outlet. This plug
is designed to fit a polarized outlet only one way. If the plug does not fit fully into the outlet,
reverse the plug. If the plug still does not fit, contact a qualified electrician. Do not attempt to defeat this
safety feature.
CAUTION
DO NOT operate any fan with a damaged cord or plug or after fan malfunctions, has been dropped or damaged in
any manner. Do not operate fan with a broken blade, safety cage or any visual imperfections. Disconnect power
before servicing.
DO NOT run power cord under carpeting. DO NOT cover cord with throw rugs, runners or the like. Arrange cord
away from traffic area where it will not be tripped over. Avoid the use of extension cords due to risk of fire. If an
extension cord must be used, the cord must be minimum 14 AWG and rated not less then 1875 watts. Do not use
an extension cord unless the plug can be completely inserted into its receptacle. Unplug the fan when not in use.
Do not operate fan with its ventilation obstructed.
5
USAGE
(Continued)
Fan Operation: Always operate the fan in the upright position following all instructions and recommendations
listed in this manual.
Fan Location: Place the fan in the area of the room that will provide proper fan cooling.
Fan Connection: Plug fan directly into 120 Volt A.C., 60 Hz wall outlet. Be sure plug fits tightly in outlet. A loose
connection may cause overheating and damage to the plug or fan.
Turning Fan On/O: Place fan on stable level surface. Plug fan into proper polarized outlet. To start the
fan, rotate top control dial to desired fan speed (1, 2 or 3). Rotate the dial clockwise for standard use and
counter-clockwise for oscillation use. See Control Panel below. Rotate top control dial again to OFF position to
discontinue use. Unplug fan when not in use.
Fan Speed And Oscillation: Rotate top control dial to desired fan speed (1, 2 or 3). Rotate the dial clockwise for
standard use and counter-clockwise for oscillation use. See Control Panel below.
NOTE: To prevent overloading a circuit, do not plug the fan into a circuit that is servicing other electrical
needs.
Fan Speed
With
Oscillation
Fan Speed
Without
Oscillation
6
SAFETY & PRECAUTIONS
CONTINUEDCONTINUED
CONTROL PANEL
(Continued)
Fan Base Assembly: Simple assembly is required to use this fan.
1. Rotate the base holder (F) o , which is at the bottom of the fan housing
2. Place the Rear base panel (B) between the fan housing (D) and base holder( F) ,in the right direction
3. Align the Rear base panel (B) and Front base panel (A) together
4. Put the base holder (F) back and tighten it to hold the base panels on the fan housing (D)
CARE AND MAINTENANCE
Cleaning: CAUTION-Before cleaning the fan be sure to disconnect power cord from the plug. Clean the grille
surface with a clean damp cloth. Do not use harsh chemical or abrasive cleaners. DO NOT IMMERSE THE FAN
OR ANY WIRES IN WATER. Replace front grille before fan use. Allow fan to dry completely before use. Periodic
grille cleaning with a vacuum will prevent dust build up. The motor is sealed and does not require any interior
maintenance, cleaning or lubrication.
Fan Location: Place the fan in the area of the room that will provide proper fan cooling.
Maintenance: The Internal motor bearings are permanently lubricated at the factory and do not require any
additional lubrication.
Repair: DO NOT OPERATE THE FAN WITHOUT THE GRILLE IN PLACE. DO NOT USE THE FAN IF IT HAS
MALFUNCTIONED OR BECOME DAMAGED IN ANY WAY.
Storage: Keep original carton for storage of the fan. Loosely coil the power cord to avoid damage during storage.
833-950-1185 | support@visionairproducts.com | www.visionairproducts.com
4560 West 160th Street
Cleveland, OH 44135
Printed in China | 0723_M079
For your records, staple your sales receipt
to this manual and record the following:
Date of Purchase:
____________________________________
Place of Purchase: ___________________________________
NOTE: Proof of purchase is required for all warranty claims.
NOTE: As a result of continual improvements, the design and
specications of the product within may dier slightly to the
unit illustrated on the packaging.
