SNEEZE GUARD
ASSEMBLY INSTRUCTIONS
EHDG-SG Series
CONTENTS
ASSEMBLE THE SNEEZE GUARD
SNEEZE GUARD ASSEMBLED ON ROLLER GRILL
• 1 Curved Shield
• 2 Side Panels
• 1 Cross-Brace
• 2 Screws [#6]
• 2 Acorn Nuts [#6]
• 4 Brackets:
2 Front, Lt & Rt
2 Rear, Lt & Rt
• EHDG-5SG Fits EHDG-5R
• EHDG-7SG Fits EHDG-7R
• EHDG-11SG Fits EHDG-11R
a) Loosen the frame screws located on inner sides of roller
grill above rollers. Use these to mount the sneeze guard
brackets to the top of roller grill.
b) Slide sneeze guard side panels into front bracket and slot
on rear bracket. Repeat on other side.
c) Slide the curved shield into slot on rear bracket.
x2
x1
x1
x2
x2
Assemble on Hot Dog Roller Grill
www.wincous.com
973-295-3899 | [email protected]
DO NOT OVERTIGHTEN SCREWS.
Overtightening causes stress points in the
glass, leading to cracking/breaking.
CAUTION
x2
front
a)
b)
c)
d) Attach cross-brace to top of curved shield and at corners
of side panels. Secure with screws and nuts provided.
x2
rear
d)
Sneeze guard must be assembled on top of roller grill.
