E S S E N T I A L S FOR LIFE
User
Manual
MODEL
GGSTF105TB
V 1.1 | 0526
Tower Fan
2
Welcome Congratulations on purchasing
your new Tower Fan!
The Sôlt brand is proudly
distributed within Australia
by Residentia Group Pty Ltd.
Please refer to the warranty card at the rear of this manual
for information regarding your product’s parts and labour
warranty, or visit us online at www.residentia.group
At Residentia Group, we are customer obsessed and our
Support Team are there to ensure you get the most out
of your appliance. Should you want to learn more about
your Tower Fan features, and importantly taking care
of your appliance when cleaning, our Support Team are
here to help.
You can use our online Support Centre at anytime by
visiting http://support.residentiagroup.com.au, or you can
contact us via calling us on 1300 11 HELP (4357).
It is important that you read through the following use and
care manual thoroughly to familiarise yourself with the
installation and operation requirements of your appliance
to ensure optimum performance.
Again, thank you for choosing an Sôlt appliance and we
look forward to being of service to you.
Kind Regards,
The Residentia Team
Residentia Group
—
Head Office.
165 Barkly Ave
Burnley
Victoria 3121
Australia
—
ACN.
600 546 656
—
Online.
residentia.group
Sôlt
—
Online.
www.solt.house
—
Instagram.
/solt.house
—
Facebook.
/solt.appliances
3
Sôlt recommends the use of original spare parts. When contacting our customer service team,
please ensure that you have the following information at hand (which can be found on your
appliances’ rating plate).
— Model Number
— Serial Number
T . 1300 11 4357 | E. support@residentiagroup.com.au
Customer Care
Contents 2 Welcome
4 General Instructions
5 Your Tower Fan
6 Assembly Instructions
7 Operating Instructions
8 Aromatherapy Option
9 Maintenance and Cleaning
10 Technical Specifications
12 Purchase Details
14 Warranty Information
4
CONDITIONS OF USE
• Indoor use only.
• This appliance is intended to be used in
household and other residential type of
environments only.
SAFETY INSTRUCTIONS
• Before using the appliance, carefully read the
instructions in this manual.
• The manufacturer is not responsible if an
incorrect installation and use causes injuries and
damages.
• Always keep the instructions with your appliance
for future reference.
WARNING: To prevent any damages to your
and others’ life or property, you have to follow
the safety notes.
CHILDREN & VULNERABLE PEOPLE SAFETY
WARNING: Risk of suffocation, injury
or permanent disability.
• This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• Keep all packaging away from children.
• The remote control contains batteries. Keep
batteries away from children. Swallowing
batteries may result in serious injury or death.
INSTRUCTIONS FOR SAFE OPERATION
• Do not use the appliance unless fully assembled
with the base securely attached.
• Do not place the fan on uneven surfaces, carpet
edges, bedding or unstable flooring where the
appliance may tip over.
• This appliance must be used in accordance
with Australian household electrical safety
expectations.
• Never insert fingers, pencils, or any other foreign
object through the grille when fan is running.
• Disconnect fan when moving from one location
to another.
• Be sure fan is on a stable surface when
operating to avoid overturning.
• Do not use outdoors, in bathrooms, near open
windows during rain, or in damp environments.
• Never insert objects into air outlets.
• Disconnect before cleaning, moving or storage.
• Do not operate with a damaged cord or plug.
• Place on a stable, level surface.
• Do not use with external speed controllers or
timers unless supplied with the product.
• Essential oils and fragrances may damage
plastic components over time. Only use small
amounts on the supplied fragrance pad.
• Do not use heated oils, diffuser oils, or
alcohol-based fragrances
INSTALLATION
• Remove all the packaging.
• Do not assemble or use a damaged appliance.
• Keep packaging away from children and dispose
of electrical products through local e-waste
collection facilities.
ELECTRICAL CONNECTION
WARNING: Caution, risk of fire and electrical shock!
• DO NOT use the fan near a window, rain may
create electrical hazard.
• Operate from a 220–240V~, 50–60Hz
power supply.
• If the supply cord is damaged, it must be
replaced by manufacturer or its service agent or
a similarly qualified person in order to avoid a
hazard.
• To ensure your safety, power plug must be
inserted into an earthed three-pole socket.
Check carefully and make sure that your socket is
properly and reliably earthed.
• To protect against the risk of electrical shock, do
not immerse the unit, cord or plug in water or
other liquid.
• When the appliance is not in use and before
cleaning, unplug the appliance from the outlet.
MAINTENANCE & CLEANING
WARNING: Risk of injury or damage to the unit.
• Prior cleaning unplug the fan.
• Do not disassemble or open the rotor guard to
clean the rotor blades.
• When the appliance is not in use and before
cleaning, unplug the appliance from the outlet.
• Clean the appliance with a moist soft cloth.
Only use mild soaps and thoroughly remove
soap film with a dry cloth.
• Do not use abrasive products, abrasive cleaning
pads, solvents or metal objects.
• Do not use gasoline, thinner or similar products
as a cleaner.
• Do not allow water or any other liquid into the
motor housing or interior parts.
WARNING
Only authorised technicians can carry out repairs.
Note: Your appliance requires little maintenance.
If you are experiencing issues, do not try to resolve
the issue or fault by yourself. If you appliance
requires maintenance:
• Power off the appliance using the Power button.
• Switch off the appliance at the power outlet
and remove the plug.
• Contact our customer service team.
PRODUCT DISPOSAL
• Disconnect the appliance from the mains supply.
• Cut off the mains cable and discard it.
• Dispose of used batteries at a safe disposal
drop off.
General Instructions
5
1
5
3
2
4
Note: The images in this user manual are for explanatory purposes only.
Your Tower Fan may appear slightly different.
PRODUCT OVERVIEW
1. Control Panel
2. Remote Receiver
3. Tower Fan Body
4. Aromatherapy Compartment (Rear)
5. Base Assembly
Included by not shown:
• Remote Control
• Power Cord
Your Tower Fan
6
STEP 1
Take out the Tower Fan Body and the Base assembly parts from the box.
STEP 2
Join the base halves and secure with the 2 base clamps and the supplied screws
STEP 3
Fix the Tower Fan Body on the Base and check that the fan is upright and stable before connecting power.
IMPORTANT: During first use, you may notice a slight odour for a short period. This is normal and may
occur as manufacturing residues dissipate during initial operation. The odour will reduce and disappear
with continued use.
Assembly Instructions
l Never insert fingers, pencils or any other objects through the grille when fan is running.
l Disconnect fan before cleaning.
l Make sure fan is on a stable surface when operating to avoid chance of overturning.
l Do not use fan in a window. Rain may cause an electrical hazard.
l Do not operate in the presence of explosive and/or flammable fumes.
l Do not place fan or any parts near an open flame, cooking or other heating appliances.
l Do not operate any appliance with a damaged cord or plug, after the appliance malfunctions
or has been dropped or damaged in any manner.
l Do not let cord hang over table or counter or touch hot surfaces.
l To disconnect, grip plug and pull from wall outlet. Never yank on cord.
l Always use on a dry surface.
l This product is intended for household use only and not for commercial or industrial use.
l Do not use fan near curtains, plants, window treatments, etc.
POWER CORD SAFETY TIPS
1. Never pull or yank on the cord or the appliance.
2. To insert plug, grasp it firmly and guide it into outlet.
3. To disconnect appliance, grasp plug and remove it from outlet.
4. Before each use, inspect the power cord for cuts and/or abrasion marks. If any are found, this
indicates that the appliance should be serviced and the power cord replaced. Please return it
to our Service Department or to an authorized service representative.
5. Never wrap the cord tightly around the appliance, as this could cause the appliance to fray and
break.
DO NOT OPERATE APPLIANCE IF THE POWER CORD SHOWS ANY DAMAGE, OR WORKS
INTERMITTENTLY AND STOPS WORKING.
IMPORTANT: During the first few minutes of initial use, a slight odor may be noticeable. This is
normal and will quickly disappear.
ASSEMBLY INSTRUCTIONS
Firmly clamp the left chassis with the right chassis, then coordinate the position of fan body with
that position of the base , and fix the screws of the chassis clamp and chassis with a screwdriver.
OPERATING INSTRUCTIONS
Important: This appliance is for household use and may be plugged into any 230V AC electrical
outlet (ordinary household current). Do not use any other electrical outlet.
Before using the fan， open the Aromatic Censer ， then put in a few drops of perfume on the
Aromatherapy cotton tablets. After install the fan，it can work with generating fragrance.
Left/Right Base Bass Clamps (×2)
ST4×12
(8PCS)
7
CONTROL PANEL
The buttons on the Control Panel body
(On/Off, Speed, Mode, Swing, Timer) are the
same functions as the corresponding buttons
on the Remote Control.
1. LED Display Screen: Here is where temperature,
timer and mode settings will be displayed.
2. Speed: Choose between Low (F1), Medium (F2)
and High (F3) fan speeds.
3. Mode: Press this button to choose between
Normal/Natural (AL) and Sleep (SP) wind modes.
Normal (AL): The wind remains a constant flow.
Natural (AL): Variable wind patterns that
simulates the wind outdoors.
Sleep (SP): A low, constant wind speed ideal for
a cool, long night’s sleep.
4. On/Off: This button will power the Tower Fan
on and off.
5. Swing (Oscillation): After the Tower Fan is
powered on, press the Swing button to select
oscillation mode.
6. Timer: Press the Timer Button to program
the Fan to power off automatically between
1–24hrs.
Display Auto-Off: If no buttons are pressed for
5 minutes, the display screen will automatically
turn off. Press any button to wake the display
back up.
REMOTE CONTROL
Operating the Remote Control
• Point the Remote Control at the receiver
on the Tower Fan body and press the desired
function button.
• The batteries must be removed from the
Remote Control before it is scrapped and that
they are disposed of safely.
Note: Only use 2×AAA manganese or alkaline
batteries.
• On/Off: This button will power
the Tower Fan on and off.
• Speed: Choose between Low
(F1), Medium (F2) and High (F3)
fan speeds.
• Mode: Press this button to
choose between Normal/
Natural (AL) and Sleep (SP)
wind modes.
• Swing (Oscillation): After the
Tower Fan is powered on,
press the Swing button to
select oscillation mode.
• Timer: Press the Timer Button
to program the Fan to power
off automatically between
1–24hrs.
• Status: Change the
temperature, timer and
mode settings.
BATTERY WARNING
• Do not dispose of batteries in fire.
Batteries may explode or leak.
• Do not mix old and new batteries.
• Do not mix alkaline, standard (carbon-zinc)
or rechargeable (nickel-cadmium) batteries.
Note:
The images in this user manual
are for explanatory purposes only.
Your Tower Fan and Remote Control may appear
slightly different.
Operating Instructions
1
2 3 4 5 6
5. : Oscillation function
REMARK:No operation of the fan after 5 minutes
，，
the display will turned off.（Press any
button can light up it）
REMOTE CONTROL VIEW:
1.Remote control, please use 2XAAA batteriers.
2. The remote control power button is labelled as such.
CARE AND CLEANING
This appliance requires little maintenance and contains no user serviceable parts. Do not try to fix
it yourself. Refer it to qualified service personnel if servicing is needed.
The fan is permanently lubricated and will not require additional lubrication for the life of the fan.
TO CLEAN: Before cleaning, turn fan off and unplug from electrical outlet. Wipe off excess dust
with a lint-free cloth. To ensure adequate air circulation to the motor, keep vents located at the
rear of the motor housing free from dust accumulation. A vacuum cleaner hose can be used to
clean these vents. Do not immerse fan in water or any other liquid.
TO STORE: Make sure to disassemble and clean the fan before storing. Retain the original
packaging for the purpose of storing the fan. Always store fan in a dry place. Never store it while it
is still plugged in. Never wrap the cord tightly around the fan, and do not put any stress on the
cord where it enters the fan housing, as it could cause the cord to fray and break.
SPECIFICATIONS
Watts(W)
Volts
45W
220V-240V~50-60Hz
1. ”ON/OFF” Main power button
2.“SPEED” Low（F1），Med(F2)，High(F3) wind speed for selection
3.“Timer”
Setting timer from 1-24 hours
4.“SWING”
Oscillation function
5.“Mode” Normal/Natural（AL）/Sleep(SP) mode for selection
6.“STATUS” Switching of temperature ， timer，mode.
8
Your Sôlt tower fan includes an integrated aromatherapy compartment and with a fragrance pad
designed to gently distribute fragrance into the airflow during operation.
Adding fragrance can help create a more comfortable and personalised indoor environment while
circulating air throughout the room. Depending on the fragrance selected, you may choose to create a
fresher atmosphere for everyday use or a more relaxing environment for reading, winding down in the
evening, or general home comfort.
To use the aromatherapy function:
1. Power the fan OFF and disconnect from the power outlet.
2. Open the aromatherapy compartment at the rear.
3. Apply 2–5 drops of your preferred water-based or fan-suitable fragrance onto the supplied
fragrance pad.
4. Reinsert the fragrance pad securely into the compartment.
5. Operate the fan normally.
As air passes through the fan, a light fragrance may be dispersed into the surrounding area.
For best performance
• Begin with a small amount of fragrance and increase only if required.
• Stronger airflow settings may increase fragrance distribution.
• Replace or refresh the fragrance pad periodically to maintain performance.
• Store fragrance products separately from the appliance.
IMPORTANT
• Use fragrance on the supplied pad only.
• Do not pour liquids directly into the fan housing or air outlet.
• Do not saturate the pad excessively, as excess liquid may affect surrounding components.
• Do not use oils, liquids or products that are flammable, corrosive or produce residue.
• If fragrance causes discomfort, switch off the appliance and remove the pad before continued use.
Note: Fragrance performance can vary depending on room size, airflow setting and fragrance
concentration. This function is intended to provide light ambient scenting and is not designed as a
dedicated aroma diffuser.
Aromatherapy Option
Aromatherapy
compartment
Fragrance
Pad
9
MAINTENANCE AND SERVICE
• This appliance is designed with no user-serviceable parts and requires minimal upkeep.
• Do not attempt to perform repairs yourself. Contact qualified service professionals for any required
maintenance.
• The fan is permanently lubricated and does not need any additional lubrication for its entire lifespan.
CLEANING INSTRUCTIONS
• Always turn the fan off and unplug it from the electrical outlet before cleaning.
• Use a lint-free cloth to remove any excess dust from the surfaces.
• To maintain proper air circulation to the motor, ensure the vents at the back of the motor housing are
clear of dust build-up. These vents can be cleaned using a vacuum cleaner hose attachment.
• Do not immerse the fan in water or any other liquid.
STORAGE GUIDELINES
• Before storing the fan, ensure it is completely disassembled and cleaned.
• Save the original packaging to store the fan.
• Always keep the fan in a dry location.
• Never store the fan while it is plugged in.
• Do not wrap the cord tightly around the fan. Avoid putting any stress on the cord where it connects to
the fan housing, as this can cause the cord to fray and break.
DISPOSAL
• This product must not be disposed of via normal household waste after its service life, but must be
taken to a collection station for the recycling of electrical and electronic devices. The symbol on the
product, the operating instructions or the packaging indicate such disposal procedures. The materials
are recyclable in accordance with their respective symbols. By means of re-use, material recycling or
any other form of recycling old appliances you are making an important contribution to the protection
of our environment. Please ask your local council where your nearest disposal station is located.
Maintenance and Cleaning
10
Technical Specifications
Below outlines the technical specifications for your Tower Fan.
Model GGSTF105TB
Dimensions (W × D × H mm) 300 × 300 × 1013 mm
Net Weight 3.7kg
Rated Power 45W
Power Supply 220-240V~, 50Hz
11
This page
is intentionally
left blank
12
For future reference, please record the following information which can be found
on the rating plate and the date of purchase which can be found on your sales invoice.
STORE DETAILS
STORE NAME
|
ADDRESS
|
TELEPHONE
|
PURCHASE DATE
|
PRODUCT DETAILS
MODEL NO.
|
SERIAL NO.*
|
Purchase Details
13
Attach your receipt
to this page
14
Warranty Information
WARRANTY TERMS & CONDITIONS
TOWER FAN
This document sets out the terms and conditions
of the product warranties for Residentia Group
Appliances. It is an important document. Please
keep it with your proof of purchase documents in a
safe place for future reference should you require
service for your Appliance.
1. IN THIS WARRANTY
(a) ‘acceptable quality’ as referred to in clause
10 of this warranty has the same meaning
referred to in the ACL;
(b) ‘ACL’ means Trade Practices Amendment
(Australian Consumer Law) Act (No.2) 2010;
(c) ‘Appliance’ means any Residentia Group
product purchased by you accompanied by
this document;
(d) ‘ASR’ means Residentia Group authorised
service representative;
(e) ‘Residentia Group’ means Residentia Group
Pty Ltd of 165 Barkly Ave, Burnley VIC 3121,
ACN 600 546 656 in respect of Appliances
purchased in Australia;
(f ) ‘major failure’ as referred to in clause 10
of this warranty has the same meaning
referred to in the ACL and includes a
situation when an Appliance cannot be
repaired or it is uneconomic for Residentia
Group, at its discretion, to repair an
Appliance during the Warranty Period;
(g) ‘Warranty Period’ means:
(i) where the Appliance is used for
personal, domestic or household
use (i.e. normal single family use)
as set out in the instruction manual,
the Appliance is warranted against
manufacturing defects for 24
months, following the date of original
purchase of the Appliance;
(h) ‘you’ means the purchaser of the Appliance
not having purchased the Appliance for
re-sale, and ‘your’ has a corresponding
meaning.
2. This warranty only applies to Appliances
purchased and used in Australia and is in
addition to (and does not exclude, restrict,
or modify in any way) any
non-excludable statutory warranties in
Australia.
3. During the Warranty Period Residentia
Group or its ASR will, at no extra charge
if your Appliance is readily accessible for
service, without special equipment and
subject to these terms and conditions, repair
or replace any parts which it considers to be
defective. Residentia Group or its ASR may
use remanufactured parts to repair your
Appliance. You agree that any replaced
Appliances or parts become the property
of Residentia Group. This warranty does
not apply to light globes, batteries, filters or
similar perishable parts.
4. Parts and Appliances not supplied by
Residentia Group are not covered by
this warranty.
15
5. You will bear the cost of transportation,
travel and delivery of the Appliance to and
from Residentia Group or its ASR. If you
reside outside of the service area, you will
bear the cost of:
(a) travel of an authorised representative;
(b) transportation and delivery of the Appliance
to and from Residentia Group or its ASR,
in all instances, unless the Appliance is
transported by Residentia Group or its ASR,
the Appliance is transported at the owner’s
cost and risk while in transit to and from
Residentia Group or its ASR.
6. Proof of purchase is required before you can
make a claim under this warranty.
7. You may not make a claim under this
warranty unless the defect claimed
is due to faulty or defective parts or
workmanship. Residentia Group is not liable
in the following situations (which are not
exhaustive):
(a) the Appliance is damaged by:
(i) accident
(ii) misuse or abuse, including failure to
properly maintain or service
(iii) normal wear and tear
(iv) power surges, electrical storm
damage or incorrect power supply
(v) incomplete or improper installation
(vi) incorrect, improper or inappropriate
operation
(vii) insect or vermin infestation
(viii) failure to comply with any additional
instructions supplied with the
Appliance;
(b) the Appliance is modified without authority
from Residentia Group in writing;
(c) the Appliance’s serial number or warranty
seal has been removed or defaced;
(d) the Appliance was serviced or repaired by
anyone other than Residentia Group, an
authorised repairer
or ASR.
8. This warranty, the contract to which it
relates and the relationship between you
and Residentia Group are governed by the
law applicable where the Appliance was
purchased.
9. To the extent permitted by law, Residentia
Group excludes all warranties and liabilities
(other than as contained in this document)
including liability for any loss or damage
whether direct or indirect arising from your
purchase, use or non use of the Appliance.
10. For Appliances and services provided
by Residentia Group in Australia, the
Appliances come with a guarantee by
Residentia Group that cannot be excluded
under the Australian Consumer Law. You
are entitled to a replacement or refund
for a major failure and for compensation
for any other reasonably foreseeable loss
or damage. You are also entitled to have
the Appliance repaired or replaced if the
Appliance fails to be of acceptable quality
and the failure does not amount to a major
failure. The benefits to you given by this
warranty are in addition to your other rights
and remedies under a law in relation to the
Appliances or services to which the warranty
relates.
11. At all times during the Warranty Period,
Residentia Group shall, at its discretion,
determine whether repair, replacement or
refund will apply if an Appliance has a valid
warranty claim applicable to it.
12. Missing parts are not covered by warranty.
Residentia Group reserves the right to assess
each request for missing parts in a case by
case basis. Any parts that are not reported
missing in the first week after purchase will
not provide free of charge.
13. To enquire about claiming under this
warranty, please follow these steps:
(a) carefully check the operating instructions,
user manual and the terms of this warranty;
(b) have the model and serial number
of the Appliance available;
(c) have the proof of purchase (e.g. an invoice)
available;
(d) telephone the numbers shown below.
14. You accept that if you make a warranty
claim, Residentia Group and its ASR may
exchange information in relation to you
to enable Residentia Group to meet its
obligations under this warranty.
IMPORTANT
Before calling for service, please ensure that the
steps in point 13 have been followed.
Telephone contacts
► Service: Please call 1300 11 HELP (4357)
► Spare Parts: Please call 1300 11 SPARE (7727)
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
The Australian Consumer
Law requires the inclusion
of the following statement
with this warranty:
16
T. 1300 11 4357
E. support@residentiagroup.com.au
E S S E N T I A L S FOR LIFE
An initiative by
Residentia Group
www.solt.house
