Sharp PN-V600A Professional Displays User Manual

PN-V600A

LCD MONITOR

OPERATION MANUAL

IMPORTANT:

To aid reporting in case of loss or theft, please record the

product’s model and serial numbers in the space provided.

The numbers are located in the rear of the product.

Model No.:

Serial No.:

U.S.A. ONLY

FOR CUSTOMERS IN U.K.

IMPORTANT

The wires in this mains lead are coloured in accordance with the following code:

GREEN-AND-YELLOW: Earth

BLUE: Neutral

BROWN: Live

As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the

terminals in your plug proceed as follows:

•ThewirewhichiscolouredGREEN-AND-YELLOWmustbeconnectedtotheterminalintheplugwhichismarkedbythe

letter E or by the safety earth

orcolouredgreenorgreen-and-yellow.

•ThewirewhichiscolouredBLUEmustbeconnectedtotheterminalwhichismarkedwiththeletterN or coloured black.

•ThewirewhichiscolouredBROWNmustbeconnectedtotheterminalwhichismarkedwiththeletterL or coloured red.

Ensurethatyourequipmentisconnectedcorrectly.Ifyouareinanydoubtconsultaqualiedelectrician.

“WARNING: THIS APPARATUS MUST BE EARTHED.”

IMPORTANT INFORMATION

WARNING: TOREDUCETHERISKOFFIREORELECTRICSHOCK,DONOTEXPOSETHISPRODUCT

TORAINORMOISTURE.

RISKOFELECTRIC

SHOCK

DONOTOPEN

CAUTION

CAUTION: TOREDUCETHERISKOFELECTRIC

SHOCK,DONOTREMOVECOVER.

NOUSER-SERVICEABLEPARTS

INSIDE.

REFERSERVICINGTOQUALIFIED

SERVICEPERSONNEL.

Thelightningashwitharrowheadsymbol,within

a triangle, is intended to alert the user to the

presence of uninsulated “dangerous voltage”

within the product’s enclosure that may be of

sufcientmagnitudetoconstituteariskofelectric

shock to persons.

The exclamation point within a triangle is

intended to alert the user to the presence of

important operating and maintenance (servicing)

instructions in the literature accompanying the

product.

WARNING:

FCCRegulationsstatethatanyunauthorizedchangesormodicationstothisequipmentnotexpresslyapprovedbythe

manufacturercouldvoidtheuser’sauthoritytooperatethisequipment.

NOTE:

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforClassAdigitaldevice,pursuanttoPart15ofthe

FCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferencewhentheequipment

isoperatedinacommercialenvironment.Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergyand,if

not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

Operationofthisequipmentinaresidentialareaislikelytocauseharmfulinterferenceinwhichcasetheuserwillberequired

to correct the interference at his own expense.

ThisproductutilizesaCRcoinLithiumbatterywhichcontainsaPerchloratematerial.

Special handling for this material may apply,

Californiaresidents,Seewww.dtsc.ca.gov/hazardouswaste/perchlorate/

Others,consultlocalenvironmentalofcers.

U.S.A. ONLY

IMPORTANT INFORMATION (Continued)

Information on the Disposal of this Equipment and its Batteries

IFYOUWISHTODISPOSEOFTHISEQUIPMENTORITSBATTERIES,DONOTUSETHEORDINARYWASTEBIN,

ANDDONOTPUTTHEMINTOAFIREPLACE!

UsedelectricalandelectronicequipmentandbatteriesshouldalwaysbecollectedandtreatedSEPARATELYinaccordance

with local law.

Separatecollectionpromotesanenvironment-friendlytreatment,recyclingofmaterials,andminimizingnaldisposalof

waste.IMPROPERDISPOSALcanbeharmfultohumanhealthandtheenvironmentduetocertainsubstances!TakeUSED

EQUIPMENTtoalocal,usuallymunicipal,collectionfacility,whereavailable.

RemoveUSEDBATTERIESfromequipment,andtakethemtoabatterycollectionfacility;usuallyaplacewherenew

batteries are sold.

If in doubt about disposal, contact your local authorities or dealer and ask for the correct method of disposal.

ONLYFORUSERSINTHEEUROPEANUNION,ANDSOMEOTHERCOUNTRIES;FORINSTANCENORWAYAND

SWITZERLAND:Yourparticipationinseparatecollectionisrequestedbylaw.

Thesymbolshownaboveappearsonelectricalandelectronicequipmentandbatteries(orthepackaging)toremindusers

ofthis.If‘Hg’or‘Pb’appearsbelowthesymbol,thismeansthatthebatterycontainstracesofmercury(Hg)orlead(Pb),

respectively.

UsersfromPRIVATEHOUSEHOLDSarerequestedtouseexistingreturnfacilitiesforusedequipmentandbatteries.

Batteriesarecollectedatpointsofsale.Returnisfreeofcharge.

IftheequipmenthasbeenusedforBUSINESSPURPOSES,pleasecontactyourSHARPdealerwhowillinformyouabout

take-back.Youmightbechargedforthecostsarisingfromtake-back.Smallequipment(andsmallquantities)mightbetaken

backbyyourlocalcollectionfacility.ForSpain:Pleasecontacttheestablishedcollectionsystemoryourlocalauthorityfor

take-backofyourusedproducts.

ThankyouforyourpurchaseofaSHARPLCDproduct.Toensuresafetyandmanyyearsoftrouble-freeoperationofyour

product, please read the Safety Precautions carefully before using this product.

SAFETY PRECAUTIONS

Electricityisusedtoperformmanyusefulfunctions,butitcanalsocausepersonalinjuriesandpropertydamageifimproperly

handled.Thisproducthasbeenengineeredandmanufacturedwiththehighestpriorityonsafety.However,improperusecan

resultinelectricshockand/orre.Inordertopreventpotentialdanger,pleaseobservethefollowinginstructionswheninstalling,

operatingandcleaningtheproduct.ToensureyoursafetyandprolongtheservicelifeofyourLCDproduct,pleasereadthe

following precautions carefully before using the product.

1. Readinstructions—Alloperatinginstructionsmustbereadandunderstoodbeforetheproductisoperated.

 2. Keepthismanualinasafeplace—Thesesafetyandoperatinginstructionsmustbekeptinasafeplaceforfuture

reference.

 3. Observewarnings—Allwarningsontheproductandintheinstructionsmustbeobservedclosely.

 4. Followinstructions—Alloperatinginstructionsmustbefollowed.

 5. Cleaning—UnplugthepowercordfromtheACoutletbeforecleaningtheproduct.Useadryclothtocleantheproduct.Do

notuseliquidcleanersoraerosolcleaners.

 6. Attachments—Donotuseattachmentsnotrecommendedbythemanufacturer.Useofinadequateattachmentscanresult

in accidents.

 7. Waterandmoisture—Donotusetheproductnearwater.Donotinstalltheproductinaplacewherewatermaysplashonto

it.Becarefulofequipmentwhichdrainswatersuchasanair-conditioner.

 8. Ventilation—Theventsandotheropeningsinthecabinetaredesignedforventilation.

  Donotcoverorblocktheseventsandopeningssinceinsufcientventilationcancauseoverheatingand/orshortenthelife

oftheproduct.Donotplacetheproductonasofa,rugorothersimilarsurface,sincetheycanblockventilationopenings.

Donotplacetheproductinanenclosedplacesuchasabookcaseorrack,unlessproperventilationisprovidedorthe

manufacturer’s instructions are followed.

 9. Powercordprotection—Thepowercordsmustberoutedproperlytopreventpeoplefromsteppingonthemorobjectsfrom

resting on them.

10. TheLCDpanelusedinthisproductismadeofglass.Therefore,itcanbreakwhentheproductisdroppedorappliedwith

impact.BecarefulnottobeinjuredbybrokenglasspiecesincasetheLCDpanelbreaks.

11. Overloading—DonotoverloadACoutletsorextensioncords.Overloadingcancausereorelectricshock.

12. Enteringofobjectsandliquids—Neverinsertanobjectintotheproductthroughventsoropenings.Highvoltageowsin

theproduct,andinsertinganobjectcancauseelectricshockand/orshortinternalparts.

  Forthesamereason,donotspillwaterorliquidontheproduct.

13. Servicing—Donotattempttoservicetheproductyourself.Removingcoverscanexposeyoutohighvoltageandother

dangerousconditions.Requestaqualiedservicepersontoperformservicing.

14. Repair—Ifanyofthefollowingconditionsoccurs,unplugthepowercordfromtheACoutlet,andrequestaqualiedservice

person to perform repairs.

a. Whenthepowercordorplugisdamaged.

b. Whenaliquidwasspilledontheproductorwhenobjectshavefallenintotheproduct.

c. Whentheproducthasbeenexposedtorainorwater.

d. Whentheproductdoesnotoperateproperlyasdescribedintheoperatinginstructions.

 Donottouchthecontrolsotherthanthosedescribedintheoperatinginstructions.Improperadjustmentofcontrols

notdescribedintheinstructionscancausedamage,whichoftenrequiresextensiveadjustmentworkbyaqualied

technician.

  e. Whentheproducthasbeendroppedordamaged.

  f. Whentheproductdisplaysanabnormalcondition.Anynoticeableabnormalityintheproductindicatesthattheproduct

needs servicing.

15. Replacementparts—Incasetheproductneedsreplacementparts,makesurethattheservicepersonusesreplacement

partsspeciedbythemanufacturer,orthosewiththesamecharacteristicsandperformanceastheoriginalparts.Useof

unauthorizedpartscanresultinre,electricshockand/orotherdanger.

16. Safetychecks—Uponcompletionofserviceorrepairwork,requesttheservicetechnicianto

perform safety checks to ensure that the product is in proper operating condition.

17. Wallmounting—Whenmountingtheproductonawall,besuretoinstalltheproductaccordingtothemethod

recommended by the manufacturer.

18. Heatsources—Keeptheproductawayfromheatsourcessuchasradiators,heaters,stovesandotherheat-generating

products(includingampliers).

DEAR SHARP CUSTOMER

SAFETY PRECAUTIONS (Continued)

19. Batteries—Incorrectuseofbatteriesmaycausethebatteriestoburstorignite.Aleakybatterymaycorrodetheequipment,

dirty your hands or spoil your clothing. In order to avoid these problems, make sure to observe the precautions below:

  •Usethespeciedbatteriesonly.

  •Installthebatterieswithdueattentiontotheplus(+)andminus(-)sidesofthebatteriesaccordingtotheinstructionsinthe

compartment.

  •Donotmixoldandnewbatteries.

  •Donotmixbatteriesofdifferenttypes.Voltagespecicationsofbatteriesofthesameshapemayvary.

  •Replaceanexhaustedbatterywithanewonepromptly.

  •Ifyouwillnotusetheremotecontrolforalongtime,removethebatteries.

  •Ifleakedbatteryuidgetsonyourskinorclothing,rinseimmediatelyandthoroughly.Ifitgetsintoyoureye,batheyour

eyewellratherthanrubbingandseekmedicaltreatmentimmediately.Leakedbatteryuidthatgetsintoyoureyeoryour

clothing may cause a skin irritation or damage your eye.

20. Usageofthemonitormustnotbeaccompaniedbyfatalrisksordangersthat,couldleaddirectlytodeath,personalinjury,

severe physical damage or other loss, including nuclear reaction control in nuclear facility, medical life support system, and

missile launch control in a weapon system.

21. Donotstayincontactwiththepartsoftheproductthatbecomehotforlongperiodsoftime.Doingsomayresultin

low-temperatureburns.

WARNING:

ThisisaClassAproduct.Inadomesticenvironmentthisproductmaycauseradiointerferenceinwhichcasetheusermay

berequiredtotakeadequatemeasures.

TomaintaincompliancewithEMCregulations,useshieldedcablestoconnecttothefollowingterminals:PC/AVDVI-Doutput

terminal,PC/AVDVI-Dinputterminal,PC/AVHDMIinputterminal,PCD-SUBinputterminal,PCRGBinputterminals,and

RS-232Cinput/outputterminals.

Ifamonitorisnotpositionedinasufcientlystablelocation,itcanbepotentiallyhazardousduetofalling.Manyinjuries,

particularly to children, can be avoided by taking simple precautions such as:

•Usingxingdeviceslikewallmountbracketsrecommendedbythemanufacturer.

•Onlyusingfurniturethatcansafelysupportthemonitor.

•Ensuringthemonitorisnotoverhangingtheedgeofthesupportingfurniture.

•Notplacingthemonitorontallfurniture(forexample,cupboardsorbookcases)withoutanchoringboththefurnitureandthe

monitor to a suitable support.

•Notstandingthemonitorsonclothorothermaterialsplacedbetweenthemonitorandsupportingfurniture.

•Educatingchildrenaboutthedangersofclimbingonfurnituretoreachthemonitororitscontrols.

Especially for child safety

-Don’tallowchildrentoclimbonorplaywiththemonitor.

-Don’tplacethemonitoronfurniturethatcaneasilybeusedassteps,suchasachestofdrawers.

-Rememberthatchildrencanbecomeexcitedwhilewatchingaprogram,especiallyona“largerthanlife”monitor.Care

should be taken to place or install the monitor where it cannot be pushed, pulled over, or knocked down.

-Careshouldbetakentorouteallcordsandcablesconnectedtothemonitorsothattheycannotbepulledorgrabbedby

curious children.

-TheTFTcolorLCDpanelusedinthismonitorismadewith

theapplicationofhighprecisiontechnology.However,there

may be minute points on the screen where pixels never light

or are permanently lit. Also, if the screen is viewed from

an acute angle there may be uneven colors or brightness.

Please note that these are not malfunctions but common

phenomenaofLCDsandwillnotaffecttheperformanceof

the monitor.

-Donotdisplayastillpictureforalongperiod,asthiscould

cause a residual image.

-Neverrubortapthemonitorwithhardobjects.

-PleaseunderstandthatSHARPCORPORATIONbearsno

responsibility for errors made during use by the customer or

a third party, nor for any other malfunctions or damage to this

product arising during use, except where indemnity liability is

recognizedunderlaw.

-Thismonitoranditsaccessoriesmaybeupgradedwithout

advance notice.

-Donotusethemonitorwherethereisalotofdust,where

humidity is high, or where the monitor may come into contact

withoilorsteam.Donotuseinanenvironmentwhere

therearecorrosivegases(sulfurdioxide,hydrogensulde,

nitrogendioxide,chlorine,ammonia,ozone,etc.).Asthis

couldleadtore.

-Ensurethatthemonitordoesnotcomeintocontactwith

waterorotheruids.Ensurethatnoobjectssuchaspaper

clipsorpinsenterthemonitorasthiscouldleadtoreor

electric shock.

-Donotplacethemonitorontopofunstableobjectsorin

unsafeplaces.Donotallowthemonitortoreceivestrong

shocksortostronglyvibrate.Causingthemonitortofallor

topple over may damage it.

-Donotusethemonitornearheatingequipmentorinplaces

where there is likelihood of high temperature, as this may

leadtogenerationofexcessiveheatandoutbreakofre.

-Donotusethemonitorinplaceswhereitmaybeexposedto

direct sunlight.

-Ifthemonitorisinstalledinalocationexposedtosunlight

such as next to a window, measures to reduce ultraviolet and

infraredradiationandtemperaturemeasuresarerequired.

Fordetails,consultyourdealer.

-Pleasebesuretoconstantlyremovedustandgarbagethat

has attached to the ventilation opening. If dust collects in the

ventilation opening, it may lead to excessive heat, outbreak

ofre,ormalfunction.

As a standard, clean the inside of the monitor once every

year. If dust collects inside the monitor, it may lead to

excessiveheat,outbreakofre,ormalfunction.Please

requestacleaningoftheinsideofthemonitorfroman

authorizedSHARPservicingdealerorservicecenter.

-Imagescannotberotatedonthismonitor.

Whenusinginportraitorientation,youwillneedtoprepare

appropriately orientated content in advance.

-TheACoutletshallbeinstalledneartheequipmentandshall

be easily accessible.

The Power Cord

-Useonlythepowercordsuppliedwiththemonitor.

-Donotdamagethepowercordnorplaceheavyobjectson

it, stretch it or over bend it. Also, do not add extension cords.

Damagetothecordmayresultinreorelectricshock.

-Donotusethepowercordwithapowertap.

Addinganextensioncordmayleadtoreasaresultof

overheating.

-Donotremoveorinsertthepowerplugwithwethands.

Doingsocouldresultinelectricshock.

-Unplugthepowercordifitisnotusedforalongtime.

-Donotattempttorepairthepowercordifitisbroken

or malfunctioning. Refer the servicing to the service

representative.

Manual Scope

-Microsoft,WindowsandInternetExplorerareregistered

trademarksofMicrosoftCorporation.

-HDMI,theHDMILogoandHigh-DenitionMultimedia

InterfacearetrademarksorregisteredtrademarksofHDMI

LicensingLLC.

-Adobe,Acrobat,andReaderareeitherregisteredtrademarks

or trademarks of Adobe Systems Incorporated in the United

States and/or other countries.

-ThisproductcomeswithRICOHBitmapFontsproducedand

soldbyRICOHCOMPANY,LTD.

-Allotherbrandandproductnamesaretrademarksor

registered trademarks of their respective holders.

-LanguageofOSDmenuusedinthismanualisEnglishby

way of example.

-Illustrationsinthismanualmaynotexactlyrepresentthe

actual product or display.

-Thismanualassumesuseinlandscapeorientation,except

wherespecicallynoted.

-Thismanualassumesthatthisproductwillbeusedwith

theremotecontrolunitbuttons,exceptwherespecically

noted. Operation by using the buttons on the rear side of the

product will perform the same functions.

Rear side buttons

Remote control

unit buttons

 *Foroperationwiththeremotecontrolunit,thePN-ZR01

controlkit(optional)isrequired.

LED Backlight

● TheLEDbacklightinthisproducthasalimitedlifetime.

* If the screen gets dark or does not turn on, it may be

necessarytoreplacetheLEDbacklight.ThisLED

backlight is exclusive to this product and must be replaced

byanauthorizedSharpservicingdealerorservicecenter.

* Please contact your local Sharp servicing dealer or

service center for assistance.

Fan

● Thefaninthisproducthasalimitedlifetime.

TIPS AND SAFETY INSTRUCTIONS

MOUNTING PRECAUTIONS

• Thisproductisforuseindoors.

• AmountingbracketcompliantwithVESAspecicationsis

required.

• Sincethemonitorisheavy,consultyourdealerbefore

installing, removing or moving the monitor.

• Mountingthemonitoronthewallrequiresspecialexpertise

andtheworkmustbeperformedbyanauthorizedSHARP

dealer. You should never attempt to perform any of this

work yourself. Our company will bear no responsibility

foraccidentsorinjuriescausedbyimpropermountingor

mishandling.

• Usethemonitorperpendiculartoalevelsurface.If

necessary,themonitormaybetiltedupto20degrees

upward or downward.

• Whenmountingthemonitorhorizontally,theoptionalfan

cover(PN-ZR31)isrequired.Fordetailsalongwiththe

horizontalmountingconditions,consultyourdealer.

• Thismonitorshouldbeusedatanambienttemperature

between32°F(0°C)and104°F(40°C).

• Becarefulofhightemperaturesinthesurroundingarea.

Wheninstallingthemonitorinsideahousing,orifthe

ambienttemperaturemaybeoutsideoftherangeof32ºF

(0ºC)to104ºF(40ºC),installafanortakeothermeasures

tokeeptheambienttemperaturewithintherequiredrange.

• Temperatureconditionmaychangewhenusingthemonitor

togetherwiththeoptionalequipmentsrecommendedby

SHARP.Insuchcases,pleasecheckthetemperature

conditionspecifiedbytheoptionalequipments.

• Donotblockanyventilationopenings.Ifthetemperature

inside the monitor rises, this could lead to a malfunction.

• Donotplacethemonitoronadevicewhichgeneratesheat.

• Adheretothefollowingwheninstallingthemonitorinits

portraitorientation.Failingtoadheretothefollowingmay

cause malfunctions.

-Toinstallinlandscapeorientation,rotatethemonitor90

degrees to the right.

-SettheMONITORontheSETUPmenutoPORTRAIT.

(See page 24.)

-Besuretosecurethepowercord(supplied)tothecable

clamp attachment with the supplied cable clamp.

Make sure that the power cord (supplied) does not supply

power to the terminal when being secured and do not

over bend the power cord (supplied).

Cableclamp

Power cord (Supplied)

Cableclamp

attachment

Contents

Supplied Components

If any component should be missing, please contact your dealer.



LiquidCrystalDisplayMonitor:1



Cableclamp:2



Powercord:1



CD-ROM(UtilityDiskforWindows):1



Setupmanual:1



Protection cover: 4



Handlescrew(short):4



Bezelsheet(long/short):2each



Bezelsheetattachmentinstructions:1

* SharpCorporationholdsauthorshiprightstotheUtilityDiskprogram.Donotreproduceitwithoutpermission.

* Forenvironmentalprotection!

 Donotdisposeofbatteriesinhouseholdwaste.Followthedisposalinstructionsforyourarea.

IMPORTANT INFORMATION ............................................3

DEAR SHARP CUSTOMER ..............................................5

SAFETY PRECAUTIONS ..................................................5

TIPS AND SAFETY INSTRUCTIONS ...............................7

MOUNTING PRECAUTIONS ............................................8

Supplied Components .....................................................9

Part Names .....................................................................10

Connecting Peripheral Equipment ...............................12

Multiple monitor connection .......................................13

Preparing the Remote Control Unit ..............................15

Installing the batteries ................................................15

Remote control operation range .................................15

Connecting the Power Cord .........................................15

Binding Cables ...............................................................16

Removing the Handles ..................................................16

Afxing the Protection Covers .....................................16

Turning Power On/Off ....................................................17

Turning on the main power.........................................17

Turning power on/off ..................................................17

Disablingpoweron/offoperations ..............................17

Basic Operation .............................................................18

Remote Control Mode ..................................................21

Menu Items .....................................................................22

Displayingthemenuscreen .......................................22

Menu item details .......................................................23

AdjustmentsforPCscreendisplay ............................30

Initialization (Reset)/Functional Restriction Setting

(FUNCTION) ....................................................................31

Controlling the Monitor with a PC (RS-232C) ..............32

PCconnection ............................................................32

Communicationconditions .........................................32

Communicationprocedure .........................................32

SettingoftheGAMMAuserdata ................................36

RS-232Ccommandtable ...........................................37

Controlling the Monitor with a PC (LAN) .....................45

Settings to connect to a LAN ......................................45

ControllingwithaPC ..................................................47

Troubleshooting .............................................................53

Specications ................................................................55

Mounting Precautions (For SHARP dealers and

service engineers) .........................................................60

Front view

2345

6 7 8 9

The rear buttons if seen

from the front

1. LCD panel

2. INPUT button

3. MENU button

4. VOL -/Cursor control (

) button

5. VOL +/Cursor control (

) button

6. BRIGHT -/Cursor control (

) button

7. BRIGHT +/Cursor control (

) button

8. Power button

9. Power LED

Part Names

Rear view

28272625 29

21 23

2018

3130 3433

9876 54 32

When the PN-ZB02

(optional) is attached

10. Fan/Fan cover

11. Vents

12. Handles

13. Expansion terminal cover

Additional input/output terminals are available by attaching

thePN-ZB02expansionboard(optional).

14. Optional attachment section

This section is used to connect optional hardware for

function expansion. Offering this attachment location

is not a guarantee that future compatible hardware

attachments will be released.

15. AC input terminal

16. Main power switch

17. PC/AV HDMI input terminal

18. PC D-sub input terminal

19. Audio input terminal

20. Audio output terminals

21. RS-232C output terminal

22. RS-232C input terminal

23. Optional terminal

This terminal is provided for possible future (optional)

function expansion. Offering of this terminal is not a

guarantee that future expanded functionality will be

provided.

24. Control kit terminal

When the PN-ZB02 (optional) is attached

25. PC/AV DVI-D input terminal

26. PC/AV DVI-D output terminal

27. LAN terminal

28. External speaker terminals

29. Audio 1 input terminals

30. Audio 2 input terminals

31. PC RGB input terminals

32. AV component input terminals

33. AV video input terminal

34. AV S-video input terminal

Caution

• ConsultyourSHARPdealerforattachment/detachmentof

optional parts.

• Donotblockthefancover.

• Donotopentheexpansionterminalcoverbyyourself.

There are high voltage parts inside the cover which may

cause an electric shock.

Part Names

n

Remote control unit

(Supplied with the PN-ZR01 (optional))

1. Signal transmitter

2. POWER button

3. MUTE button

4. VOL +/Cursor control (

) button

5. BRIGHT -/Cursor control (

) button

6. DISPLAY button

7. MODE button

8. INPUT button

9. MENU button

10. BRIGHT +/Cursor control (

) button

11. VOL -/Cursor control (

) button

12. SIZE button

n

Remote control sensor box

(Supplied with the PN-ZR01 (optional))

1. Brightness sensor

2. Remote control sensor

3. Connection cable

4. Mounting bracket

11109812345 712

1413 1716

When the PN-ZB02 (optional)

is attached

Caution

• Besuretoturnoffthemainpowerswitchanddisconnect

the plug from the power outlet before connecting/

disconnecting cables. Also, read the manual of the

equipmenttobeconnected.

• Becarefulnottoconfusetheinputterminalwiththeoutput

terminal when connecting cables. Accidentally reversing

cables connected to the input and output terminals may

cause malfunctions and the other problems.

• Donotuseanycablethathasadamagedordeformed

terminal. Using such cables may cause malfunctions.

TIPS

• Imagesmaynotbedisplayedproperlydependingonthe

computer (video card) to be connected.

•

Ascreenwith1920x1080resolutionmaynotbedisplayed

correctlyonPCRGB.Inthiscase,checkthesettingsofyour

computer (video card) to verify that input signals conform to

specicationsofthismonitor.(Seepage57.)

• IfthereisacheckboxtodisableEDIDindisplaycontrol

panel,checkitwhenusingPCRGB.

• UsetheautomaticscreenadjustmentwhenaPCscreen

isdisplayedforthersttimeusingPCD-SUBorPCRGB,

orwhenthesettingofthePCischanged.Thescreenis

adjustedautomaticallywhenSELFADJUSTintheOPTION

menu is set to ON.

•

If the audio output from the playback device is connected

directly to speakers or other devices, the video on the monitor

may appear delayed from the audio portion.

Audio should be played through this monitor by connecting the

playback device to the monitor’s audio input, and connecting

the monitor’s audio output to the speakers or other devices.

• Theaudioinputterminalsusedineachinputmodeare

factory-setasfollows.

Input mode

Audio input terminal

(Factory setting)

PCD-SUB,PCDVI-D,PCRGB

Audio input terminal

AVDVI-D Audio1inputterminal

AVCOMPONENT,

AVS-VIDEO,AVVIDEO

Audio2 input terminal

PCHDMI,AVHDMI PC/AVHDMIinputterminal

1. PC/AV HDMI input terminal

• UseacommerciallyavailableHDMIcable(conformingto

theHDMIstandard).

• SetHDMIofINPUTSELECTontheOPTIONmenu

according to the device to be connected.

• SelecttheaudioinputterminaltobeusedinPCHDMI

orAVHDMIofAUDIOSELECTontheOPTIONmenu.

WhenHDMIisselected,connectiontotheaudioinput

terminal is unnecessary.

2. PC D-sub input terminal

• WhenthePN-ZB02(optional)isattached,selecttheaudio

inputterminaltobeusedinPCD-SUBofAUDIOSELECT

on the OPTION menu.

3. Audio input terminal

• Useanaudiocablewithoutresistance.

• WhenthePN-ZB02(optional)isattached,settheaudio

inputterminalusedforeachinputmodeinAUDIO

SELECTontheOPTIONmenu.

4. Audio output terminals

• Theoutputsoundvariesdependingontheinputmode.

• Thevolumeoftheoutputsoundcanbexedbysetting

AUDIOOUTPUT(RCA)ontheOPTIONmenu.

• Itisnotpossibletocontrolthesoundoutputfromthe

audiooutputterminalswiththeAUDIOmenu.

5. RS-232C output terminal

6. RS-232C input terminal

• YoucancontrolthemonitorfromaPCbyconnectinga

commerciallyavailableRS-232straightcablebetween

theseterminalsandthePC.

•

WhenusingthePN-ZR01controlkit(optional)toperform

operation of multiple monitors with the remote control

unit, connect multiple monitors in a daisy chain using the

commerciallyavailableRS-232straightcable.(Seepage14.)

7. Control kit terminal

• ConnectstheremotecontrolsensorboxofthePN-ZR01

controlkit(optional).(Seepage14.)

■ Connection when the PN-ZB02 (optional)

is attached

ThePN-ZB02expansionboard(optional)allowstheuseof

additional connection terminals.

8. PC/AV DVI-D input terminal

• SetDVIofINPUTSELECTontheOPTIONmenu

according to the device to be connected.

• SelecttheaudioinputterminaltobeusedinPCDVI-Dor

AVDVI-DofAUDIOSELECTontheOPTIONmenu.

9. PC/AV DVI-D output terminal

• ThevideoofthePC/AVDVI-Dinputcanbeoutputtoan

external device.

• OutputtingHDCP-encryptedvideorequiresanexternal

devicewhichsupportsHDCP.

• Thisterminalallowsthedaisychainconnectionofupto5

monitors.

Connecting Peripheral Equipment

TIPS

• Thelengthofthesignalcablesorsurroundingenvironment

mayaffecttheimagequality.

• Thescreenmaynotdisplayproperlywhenusingterminals

otherthanPCDVI-D/AVDVI-Dfortheinputmode.Inthis

case, turn off the power to all the monitors connected in a

daisy chain and then turn the power on again.

• WhenconnectingmonitorsinadaisychainsetAUTO

INPUTCHANGEtoOFF.

• Videooutputisdisabledinthefollowingcases:

Whenthepoweristurnedoff

Whenthemonitorisininputsignalwaitingmode

10. LAN terminal

• YoucancontrolthemonitorfromaPConanetworkby

connecting a commercially available LAN cable between

this terminal and a network.

11. External speaker terminals

• Besuretouseexternalspeakerswithanimpedanceof6Ω

orgreaterandaratedinputofatleast10W.

Approx.

3-15/16 inch

(10 cm)

1.Attachaspeakercablecore(includedwiththePN-ZB02)to

the end of the speaker cable connected to the monitor.

2.Whilepushingthetab,insertthetipofthecable.

3. Release the tab.

TIPS

• Besuretoconnectthe+and-terminalsandtheleftand

right speakers properly.

• Avoidshortcircuitingthe+and-terminals.

12. Audio1 input terminals

13. Audio2 input terminals

• Settheaudioinputterminaltobeusedineachinput

modeinAUDIOSELECTontheOPTIONmenu.

14. PC RGB input terminals

• SetBNCofINPUTSELECTontheOPTIONmenutoPC

RGBwhenusingthePCRGBinputterminals.

• SelecttheaudioinputterminaltobeusedinPCRGBof

AUDIOSELECTontheOPTIONmenu.

15. AV component input terminals

•

SetBNCofINPUTSELECTontheOPTIONmenutoAV

COMPONENTwhenusingtheAVcomponentinputterminals.

• SelecttheaudioinputterminaltobeusedinAV

COMPONENTofAUDIOSELECTontheOPTIONmenu.

16. AV video input terminal

• SelecttheaudioinputterminaltobeusedinAVVIDEOof

AUDIOSELECTontheOPTIONmenu.

17. AV S-video input terminal

• SelecttheaudioinputterminaltobeusedinAVS-VIDEO

ofAUDIOSELECTontheOPTIONmenu.

Multiple monitor connection

The monitors can be aligned and used as a large screen.

[Example]

Second monitor

Secondary

(Expansion unit)

ID No.: 2

Third monitor

Secondary

(Expansion unit)

ID No.: 3

First monitor

Primary

(Main unit)

ID No.: 1

Fourth monitor

Secondary

(Expansion unit)

ID No.: 4

Remote control sensor box

(Supplied with the PN-ZR01 (optional))

TIPS

• ConnecttheRS-232Ccablesinorder,startingwiththerst

monitor (primary monitor). If monitors are connected in a

different order they may not be operable.

• Alwaysinstalltheremotecontrolsensorboxontheprimary

monitor.

■ Connection with video cable

May vary depending on the system being used.

IfusingthePC/AVDVI-Dterminal,upto5monitorscanbe

connectedinadaisychain.(WhenthePN-ZB02isattached)

shows the

signal flow

PC/AV DVI-D

input terminal

First monitor

Second monitor

PC/AV DVI-D

output terminal

PC/AV DVI-D

input terminal

Digital signal (DVI) cables

(commercially available)

To PC digital RGB output terminal

■ Connection with RS-232 cable

IfyouconnectthemonitorinadaisychainusingRS-232

cable, using the monitor buttons on the primary (main unit),

settings are copied to the secondary (expansion unit) and

operation from the primary can perform operation for all

monitors.SettingeachIDNo.inthemonitorisrequired.

1. Connect the monitors in order.

Therstmonitorwillbesetasprimary(mainunit)andthe

second monitor and beyond will be secondaries (expansion

units).

ConnecttheRS-232Coutputterminaloftherstmonitor

(primary)andtheRS-232Cinputterminalofthesecond

monitor(secondary)togetherusingRS-232cable(straight).

Connectinthesamewaytothethirdandsubsequentmonitors.

Upto25monitorscanbeconnected.(Dependingonthelength

of the cable used and the surrounding environment.)

RS-232 straight cable

(commercially available)

First monitor: primary

Second monitor: secondary

Third monitor: connects to secondary

RS-232C input terminal

RS-232C

input terminal

RS-232C

output terminal

RS-232C

output terminal

2. Set the ID No.

Perform operation with the rear side buttons on the primary

monitor.IfyousetAUTOASSIGNIDNo.,locatedinthemenu

ofthemonitortoON,theIDNo.willbeautomaticallyassigned

inorderfromtheprimary.(Seepage25.)

(IfyouattachPN-ZR01thecontrolkit(optional),youcan

perform operation of the monitors with the remote control unit.)

■ Connection with the control kit (optional)

If performing operation of the monitor with the remote control

unit,thePN-ZR01controlkit(optional)isrequired.

• Canperformoperationofanarbitrarymonitororall

monitorswiththeremotecontrolunitoftherstmonitor.

• Canperformoperationofupto25monitors.

• ConnectthemonitorstogetherinadaisychainwithRS-232

cable.

Attach the remote control sensor box as shown in the following

illustration.

* Whenattachedtotheleftside,becausethetopand

bottom for the remote control sensor box will be reversed

(the connection cable will be on top), the right side is

recommended.

Caution

• Whenattachingtheremotecontrolsensorbox,turnthe

mainpowerswitchOFF.

• Exceptfortheremotecontrolsensorboxconnectioncable,

do not insert any other cable into the control kit terminal.

Also, do not connect any connection cables that have been

extended with commercially available cables.

For the monitor in

landscape orientation

For the monitor in

portrait orientation

1. Insert the anti-rotation protrusion of the mounting

bracket into the anti-rotation hole of the monitor.

2. Secure the stand angling hole of the monitor with the

mounting screw.

3. Adjust the angle of the remote control sensor box, and

secure it with the xing screw, so that it may accurately

receive signals from the remote control unit.

Anti-rotation protrusion

Angle

adjustment

Anti-rotation hole

Mounting bracket

Mounting screw (short)

Fixing screw

Remote control

sensor box

Stand angling hole

4. Insert the remote control sensor box connection cable

into the control kit terminal.

Connection cableControl kit terminal

Remote control

sensor box

TIPS

• Whenyouconnecttheremotecontrolsensorbox,the

brightness sensor can be used.

The screen brightness will automatically change according

to lighting conditions and the surrounding brightness. (See

page25.)

• Dependingonwhereithasbeenplacedorthesurrounding

conditions, the remote control sensor box may be

affected by the brightness of the main unit screen and the

brightness sensor may respond.

• Donotinstalltheremotecontrolsensorboxinextremely

bright or dark areas. The brightness sensor may not

function properly.

Brightness

sensor

Connecting Peripheral Equipment

Connecting the Power Cord

Caution

• Useonlythepowercordsuppliedwiththemonitor.

1.Turnoffthemainpowerswitch.

2.Plugthepowercord(supplied)intotheACinputterminal.

3.Plugthepowercord(supplied)intotheACpoweroutlet.

AC input terminal

Main power switch

Power cord (Supplied)

For power

outlet

Preparing the Remote Control Unit

Installing the batteries

1. Pressthecovergentlyandslideitinthedirectionofthe

arrow.

2. See the instructions in the compartment and put in the

batteries(R-6(“AA”size)x2)(suppliedwiththePN-ZR01

(optional))withtheirplus(+)andminus(-)sidesoriented

correctly.

3. Closethecover.

TIPS

• Whenthebatteriesbecomeexhaustedreplacethemwith

new (commercially available) batteries.

• Thesuppliedbatteries(R-6(“AA”size)x2)maybecome

exhaustedquicklydependingonhowtheyarestored.

• Ifyouwillnotbeusingtheremotecontrolforalongtime,

remove the batteries.

• Usemanganeseoralkalinebatteriesonly.

Remote control operation range

TheoperationrangeofthePN-ZR01(optional)remotecontrol

unit is approx. 23 feet (7 m) when aimed directly at the remote

controlsensorbox.Whenusedatanangleofapprox10°from

the center to the top/bottom/right/left of the remote control

sensor,useitwithinadistanceofapprox16.4feet(5m).

Remote control

sensor

10º10º

16.4 feet

(5 m)

16.4 feet

(5 m)

23.0 feet

(7 m)

23.0 feet

(7 m)

TIPS

• Donotexposetheremotecontrolunittoshockbydropping

or stepping on it. This could lead to a malfunction.

• Donotexposetheremotecontrolunittoliquids,anddonot

place it in an area with high humidity.

• Theremotecontrolunitmaynotworkproperlyiftheremote

control sensor is under direct sunlight or strong lighting.

• Objectsbetweentheremotecontrolunitandtheremote

control sensor may prevent proper operation.

• Replacethebatterieswhentheyrunlowasthismay

shorten the remote control’s operation range.

• Ifauorescentlightisilluminatedneartheremotecontrol

unit, it may interfere with proper operation.

• Donotuseitwiththeremotecontrolofotherequipment

such as air conditioner, stereo components, etc.

• AdjusttheangleofthePN-ZR01(optional)remotecontrol

sensor and have it face the area where operation with the

remote control unit will take place.

Binding Cables

The cables connected to the terminals on the rear of the monitor can be fastened with the cable clamps.

Insert the cable clamp into the cable clamp attachment on the rear of the monitor and fasten the cables.

: Cable clamp attachment

Cable clamp

Cable

Cable clamp

attachment

Removing the Handles

The handles can be removed.

The removed handles can be attached on the side.

1. Removethehandlescrewsandremovethehandlesand

handle spacers.

2. Pass the handle screws through the handles and handle

spacers in order and secure.

Caution

• Thehandles,handlescrewsandhandlespacersarefor

thismonitor.Donotusethemforanyotherdevices.

• Whenattachingthehandles,alwaysusethismonitor’s

handles, handle spacers, and handle screws.

• Besurethehandlesareattachedsecurely.

TIPS

• Tolowertheheightofthehandles,attachthehandleswith

the handle spacers removed. To attach the handles with

the handle spacers removed, secure the handles with the

included handle screws (short).

Handle

Handle screws

Handle spacers

Afxing the Protection Covers

Afterinstallingthemonitor,afxtheprotectioncovers

(4 pieces) as necessary.

Protection cover

Turning Power On/Off

Caution

• TurnonthemonitorrstbeforeturningonthePCor

playback device.

Turning on the main power

Main power switch

Caution

• Themainpowermustbeturnedon/offwiththemainpower

switch.Donotconnect/disconnectthepowercordorturn

the breaker on/off while the main power switch is on.

• WhenswitchingthemainpowerswitchorthePOWER

buttonoffandbackon,alwayswaitforatleast5seconds.

• Foracompleteelectricaldisconnection,pulloutthemain

plug.

Turning power on/off

PressthePOWERbuttonontheremotecontrolunitorthe

monitoritselftoturnthepowerON/OFF.

Whenthemainpowerswitchisoff,themonitorcannotbe

turnedonusingthePOWERbuttonontheremotecontrolunit.

Power LEDPower button

Status of a power LED Status of the monitor

Lit green Power on

Lit orange Power off (Standby mode)

Flashinggreen Input signal waiting mode

Caution

• WhenswitchingthemainpowerswitchorthePOWER

buttonoffandbackon,alwayswaitforatleast5seconds.

A short interval may result in a malfunction.

TIPS

• Ifthemonitorisintheinputsignalstandbymodeandyou

pressthePOWERbuttonontheremotecontrolunit,the

monitor enters standby mode.

• SettingtheSCHEDULEashesthepowerLEDalternately

in red and orange in standby mode.

• Todisablethelogoscreenfromdisplayingwhenturning

thepowerON,setLOGOSCREENtoOFFontheSETUP

menu.(Seepage25.)

• IfyouchangetheremotecontrolmodetoALLMONITORS,

powercanbeturnedON/OFFforallsecondarymonitors

connectedwithRS-232cable.(Foroperationwiththe

monitor buttons, use the buttons on the primary monitor.)

Date/time setting

•

Ifthetimehasyettobesetwhenthemonitorisrstturnedon,

the date/time setting screen appears. Set the date and time.

DATE/TIME SETTING

SET

CANCEL

OK···[MENU]

: :

01 01 11

12 AM00

:/ 20

1. Press , , or to select the date and

time, and press

or to change the numerical

values.

2. Press

or toselectSETandthenpress

• Besuretosetthedateandtime.

•

The date/time setting screen will close automatically if no

operationisperformedforabout15seconds.Thedate

andtimecanbesetusingDATE/TIMESETTINGfromthe

OPTION menu when the date/time setting screen disappears.

TIPS

•

Setthedatein“Month/Day/Year”order.

•

Setthetimeona12-hourbasis.

•

The clock is maintained by the internal battery.

•

If you already set the time but the date/time setting

screen appears when the power is turned on, the

internal battery may be exhausted. Please contact

your local Sharp servicing dealer or service center for

assistance with battery replacement.

•

Estimatedservicelifeoftheinternalbattery:About5

years (depending on monitor operation)

•

The initial battery was inserted at the factory when the

monitor was shipped, so it may run out of power before

its expected operation life.

Disabling power on/off operations

Power on/power off operations can be disabled in order to protect

themonitorfromanaccidentalpoweroff.SettheADJUSTMENT

LOCKinFUNCTIONmenuto“ON2”.(Seepage31.)

Basic Operation

Whenperformingoperationofmultiplemonitorswiththe

remotecontrolunit,rstsettheremotecontrolunittothe

appropriateremotecontrolmode(seepage21).

TIPS

• Youcanperformoperationofthemonitorwiththerear

buttons.Utilizethebuttonsbelongingtothemonitorthat

you would like to operate.

• Operationbyusingthebuttonsontherearsideofthe

product will perform the same functions.

Rear side buttons

Remote control

unit buttons

This manual assumes that this product will be used with

theremotecontrolunitbuttons,exceptwherespecically

noted.

1. INPUT (Input mode selection)

The menu is displayed. Press

or to select the input

mode, and press

to enter.

Input mode Video Audio

PCD-SUB PCD-subinputterminal

Audio input terminal

PCHDMI

PC/AVHDMIinputterminal

AVHDMI

PC/AVHDMIinputterminal

When the PN-ZB02 (optional) is attached

Input mode Video Audio

PCDVI-D

PC/AVDVI-Dinputterminal

PCHDMI

PC/AVHDMIinputterminal

PCD-SUB

PCD-subinputterminal

PCRGB

PCRGBinputterminals

AVDVI-D

PC/AVDVI-Dinputterminal

AVHDMI

PC/AVHDMIinputterminal

AVCOMPONENT

AVcomponentinputterminals

AVS-VIDEO AVS-videoinputterminal

AVVIDEO AVvideoinputterminal

*1 SelecttheterminaltobeusedinHDMIofINPUTSELECT.

(See page 26.)

*2 SelecttheterminalforAUDIOSELECTwhichisusedfor

audio input. (See page 26.)

*3 SelecttheterminaltobeusedinDVIofINPUTSELECT.

(See page 26.)

*4 SelecttheterminaltobeusedinBNCofINPUTSELECT.

(See page 26.)

2. MUTE

Turns off the volume temporarily.

PresstheMUTEbuttonagaintoturnthesoundbacktothe

previous level.

If using the monitor buttons, either hold both

and at the

sametimeorselectMUTEAUDIOfromtheOPTIONmenu.

3. MENU

Displaysandturnsoffthemenuscreen(seepage22).

4. VOL +/- (Volume adjustment)

Pressing

or displaystheVOLUMEmenuwhenthe

menu screen is not displayed.

V OLUME 15

Press or toadjustthevolumeofthesound.

* If you do not press any buttons for about 4 seconds, the

VOLUMEmenuautomaticallydisappears.

5. BRIGHT +/- (Backlight adjustment)

Pressing

or displaystheBRIGHTmenuwhenthe

menu screen is not displayed.

BRIGHT 15

Press or toadjustthebrightness.

* If you do not press any buttons for about 4 seconds, the

BRIGHTmenuautomaticallydisappears.

* WhenBRIGHTNESSSENSORisONorON:DISPLAY,

whenthebrightnessisadjustedBRIGHTNESSSENSOR

willbecomeOFF.

6. SIZE (Screen size selection)

The menu is displayed.

Press

or toselectthescreensize.(Seepage20.)

Ifusingthemonitorbuttons,selectSIZEfromtheOPTION

menu.

7. DISPLAY

Displaysmonitorinformation.Whenyoupressthisbutton

again, the display disappears.

WhenthePN-ZB02(optional)isattached,thedisplaychanges

fromINFORMATION1→INFORMATION2→cleardisplay,

and so on every time you press this button.

• Thedisplaydisappearsautomaticallyafterabout15

seconds.

•

LAN

is displayed during LAN communication.

• If

LAN

is displayed in red, there is a duplicate IP address.

If using the monitor buttons, press

underINFORMATIONin

the OPTION menu.

8. MODE (Color mode selection)

Eachtimeyoupressthisbutton,thecolormodechangesin

the following order:

STD(Standard)→VIVID→sRGB→

HIGHILLUMINANCE→STD...

• HIGHILLUMINANCEisadisplaywithcolorssuitedto

bright locations.

• sRGBappliestoPCinputonly.

 sRGBisinternationalstandardofcolorrepresentation

speciedbyIEC(InternationalElectrotechnical

Commission).Colorconversionismadeintakingaccount

ofliquidcrystal’scharacteristicsandrepresentscolortone

close to its original image.

Ifusingthemonitorbuttons,selectCOLORMODEfromthe

PICTUREmenu.

Basic Operation

Switching the screen size

Evenwhenthescreensizeischanged,thedisplaymayremainthesamedependingontheinputsignal.

WIDE PCinput Displaysimagesoitllstheentirescreen.

AVinput Animagewitha4:3aspectratioisstretchedtolltheentire

screen.

ZOOM 1

PCinput Animagewitha4:3aspectratioisenlargedtolltheentirescreen

without changing the aspect ratio. The edges of the image may be

cut off.

AVinput

ZOOM 2

PCinput UsethissizeifZOOM1cutsoffthesubtitles.

AVinput

NORMAL

PCinput Displaysimagesoitllsthescreenwithoutchangingtheaspect

ratio of the input signals.

AVinput Displaystheentireimageoftheaspectratioof4:3without

changing the aspect ratio.

Dot by Dot

PCinput DisplaysthedotsofthesignalsinputfromtheconnectedPCas

the corresponding dots on the screen.

AVinput Displaysthedotsoftheinputsignalsasthecorrespondingdotson

the screen.

TIPS

• Usingthismonitor’sscreen-sizeswitchingordual-screendisplayfunctionstocompressorexpandthescreenforcommercial

orpublicviewinginestablishmentslikecafesorhotelsmayinfringeontherightsofthecreators,asprotectedbyCopyright

Law, so please be careful.

• When“Enlarge”isset,thescreensizeisxedto“WIDE”mode.

• Whendual-screendisplayisselected,thescreensizecannotbechanged.

• Theappearanceoftheoriginalvideomaychangeifyouselectascreensizewithadifferentaspectratiothantheoriginal

image(e.g.TVbroadcastorvideoinputfromexternalequipment).

• Whenanordinarynon-wideimage(4:3)isviewedwiththewholescreenusingthescreen-sizeswitchingfunctionofthis

monitor, the edge of the image may be lost or appear distorted. If you wish to respect the creator’s intentions, set the screen

sizeto“NORMAL”.

• Whenplayingcommercialsoftware,partsoftheimage(likesubtitles)maybecropped.Inthiscaseselecttheoptimalscreen

sizeusingthescreen-sizeswitchingfunctionofthismonitor.Withsomesoftware,theremaybenoiseordistortionatthe

edges of the screen. This is due to the characteristics of the software, and is not a malfunction.

• Dependingontheoriginalimagesize,blackbandsmayremainattheedgesofthescreen.

Remote Control Mode

Withtheremotecontrolunitit’spossibletoperformoperation

of...

• Theprimarymonitor

• MonitorswithaspeciedIDNo.

• Allprimary/secondarymonitors

It’s necessary to specify which type of operation will be

performed in advance.

1. If using the remote control unit, press

MODE

for approx 5

seconds.

If using the monitor buttons, hold both

and at

the same time on the primary.

▲

THIS MONITOR ONLY

REMOTE CONTROL MODE

MODE

OK CANCEL

Operate this monitor.

2. Press

, select the mode, then perform

settings.

THIS MONITOR ONLY

Performs operation of only the primary using the remote

control unit.

[Example]Ifthevolumeislowered,thevolumeoftheprimary

will lower.

Secondary

ID No.: 2

Secondary

ID No.: 3

Primary

ID No.: 1

Secondary

ID No.: 4

VOLUME 10

Press to lower the volume

SPECIFIED MONITOR

PerformsoperationofamonitorwithaspeciedIDNo.using

the remote control unit.

Press

or toselectIDNo.,thenpress or to

selecttheIDNo.ofthemonitorthatyouwilloperate.

*Whenitreceivessignalsfromtheremotecontrolunit,

“Operatingspeciedmonitor.”willbedisplayedonthe

primary screen.

[Example.]IfIDNo.issetto3andthevolumeislowered,

thevolumeofthemonitorforIDNo.:3willlower.

Secondary

ID No.: 2

Secondary

ID No.: 3

Primary

ID No.: 1

Secondary

ID No.: 4

VOLUME 10

Press to lower the volume

WhenyouwouldliketoconrmtheIDNo.thatissettothe

monitor, press

or toselectIDNo.DISPLAY,then

press

.TheIDNo.willbedisplayedonthescreen.

ALL MONITORS

Performs operation of all primary/secondary monitors.

ALL

will be displayed on the menu of the primary.

*Whenitreceivessignalsfromtheremotecontrolunit,

“Operating all monitors.” will be displayed on the secondary

screen.(Excludingpowerandinputmodeselectionoperation)

*Settingsmaynotbereecteddependingonthestateofthe

connected monitors.

[Example]IfthepowerfortheprimaryisturnedON,thepower

for all the monitors will be turned ON.

Secondary

ID No.: 2

Secondary

ID No.: 3

Primary

ID No.: 1

Secondary

ID No.: 4

Power ON Power ON

Power ON

Press to turn the power ON

POWER

Press or toselectEXPANDITEM,andpress or

to select to perform this action or not.

OFF ...........Forallmonitors,onlypower,inputmode

selection, and product information display

operationswillberecognized.

ON .............Forallmonitors,alloperationswillbe

recognized.

After returning to the normal screen with

procedure3,when5minuteshavepassedfrom

the end of operation, it will automatically return

toOFF.

ALL [EXPAND ITEM]

will be displayed on the menu of

the primary.

EvenwhenREMOTECONTROLMODEisset

to ALL MONITORS, certain settings such as

LANsettingsandIDNo.settingswillnotbe

reectedontheothermonitors.

3. Press

or to select OK, then press

and

return to the normal screen.

4. Perform operation.

Caution

• WhentheremotecontrolmodeissettoALLMONITORS

andEXPANDITEMissettoON,performingremotecontrol

operationsthatchangeadjustmentvalueswillresultin

thesecondaryadjustmentvaluesbeingthesameasthe

primaryadjustmentvalues.

Secondary

ID No.: 2

Secondary

ID No.: 3

Primary

ID No.: 1

Secondary

ID No.: 4

Secondary

ID No.: 2

Secondary

ID No.: 3

Primary

ID No.: 1

Secondary

ID No.: 4

VOLUME 12 VOLUME 11

VOLUME 10

VOLUME 9

VOLUME 10 VOLUME 10

VOLUME 10

Press to lower the volume

Becarefulofthiswhenadjustingindividualdisplays.

TIPS

• Youcancopythesettingvaluesoftheprimarytoother

monitorswithCOPYSETTINGVALUE.(Seepage25.)

• Thebuttonsonthemonitoritself(primary)arealsoeffective

in remote control mode.

• Whenmonitorsconnectedinadaisychainareinstandby

modeforLOWPOWER,operationcannotbeperformedfor

subsequentmonitors.

Menu Items

Displaying the menu screen

Videoandaudioadjustmentandsettingsofvariousfunctions

are enabled. This section describes how to use the menu

items. See pages 23 to 27 for details of each menu items.

Caution

• Donotturnthemainpowerswitchoffwhilethemenuitems

arebeingdisplayed.Doingsomayinitializethesettings.

Example of operation

(AdjustingCONTRASTinthePICTUREmenu)

1. Press

to display the menu screen.

1366x768

V: 60 Hz H: 47.7 kHz

AUTO

CLOCK

PHASE

H-POS

V-POS

H-SIZE

V-SIZE

H-RESOLUTION

V-RESOLUTION

RESET

SCREEN


AUDIO

SETUP

OPTION

MULTI

PIP/PbyP

600

610

1366

768

SCREEN 1/1

END···[MENU]

PC D-SUB

2. Press

to select PICTURE, and press

3. Press

to select CONTRAST.

AUTO

ANALOG GAIN

ANALOG OFFSET

BRIGHT

CONTRAST

BLACK LEVEL

TINT

COLORS

SHARPNESS

RGB INPUT RANGE

1/2

FULL

PC D-SUB


SCREEN


AUDIO

SETUP

OPTION

MULTI

PIP/PbyP

OK···[MENU]MOVE OSD···[DISPLAY]

1366x768

V: 60 Hz H: 47.7 kHz

4. Press or

to adjust the setting.

AUTO

ANALOG GAIN

ANALOG OFFSET

BRIGHT

CONTRAST

BLACK LEVEL

TINT

COLORS

SHARPNESS

RGB INPUT RANGE

1/2

FULL

PC D-SUB


SCREEN


AUDIO

SETUP

OPTION

MULTI

PIP/PbyP

OK···[MENU]MOVE OSD···[DISPLAY]

1366x768

V: 60 Hz H: 47.7 kHz

Foritemsthathave , press , make settings and then

press

5. Press

twice to close the menu screen.

TIPS

• Themenuwilldifferdependingontheinputmode.

• Themenuscreenwillcloseautomaticallyifnooperationis

performedforabout15seconds.(DATE/TIMESETTING,

SCHEDULEandLANSETUPscreenswillcloseinabout4

minutes.)

Menu screen display

AUTO

ANALOG GAIN

ANALOG OFFSET

BRIGHT

CONTRAST

BLACK LEVEL

TINT

COLORS

SHARPNESS

RGB INPUT RANGE

1/2

FULL

PC D-SUB

SCREEN


AUDIO

SETUP

OPTION

MULTI

PIP/PbyP


OK···[MENU]MOVE OSD···[DISPLAY]

1366x768

V: 60 Hz H: 47.7 kHz

1 Nameofthemenu

2 Input mode

3 An item being selected (highlighted)

4 Screen resolution of input signal, and other data.

TIPS

• Itemsthatcannotbeselectedappearingray.

(e.g.Functionnotsupportedbythecurrentinputsignal)

Menu Items

The displayed menu items vary depending on whether or not

thePN-ZB02(optional)isattached.

ThefollowingmenuswillbedisplayedonlywhenthePN-ZB02

(optional) is attached.

Menu Item

PICTURE ADVANCED 3D-Y/C

SETUP HOTPLUGCONTROL DVI

RS-232C/LANSELECT

LANSETUP

AUTOASSIGNFIXEDIPADDR.

OPTION INPUTSELECT DVI

BNC

AUDIOSELECT PCDVI-D

PCD-SUB

PCRGB

AVDVI-D

AVCOMPONENT

AVS-VIDEO

AVVIDEO

COLORSYSTEM

PIP/PbyP PIPSOURCE

Menu item details

The menu will differ depending on the input mode.

SCREEN

You can move the menu screen display position each time

DISPLA

is pressed.

AUTO (PC D-SUB/PC RGB)

TheCLOCK,PHASE,H-POS,andV-POSareautomatically

adjusted.

Pressing

performsadjustment.

UsethisautomaticadjustmentwhenyouusethePCD-sub

inputterminalorPCRGBinputterminalstodisplayaPC

screenforthersttimeorwhenyouchangethesettingof

thePC.(Seepage30.)

CLOCK (PC D-SUB/PC RGB)

Adjustsfrequencyforsamplingclockforapplicablevideo.

Adjustwhenthereisickeringintheformofverticalstripes.

Whenusingtheadjustmentpattern(seepage30),make

adjustmentssothatnoverticalstripenoiseappearsinit.

PHASE (PC D-SUB/PC RGB)

Adjustssamplingclockphaseforapplicablevideo.

Useful when small characters appear with low contrast and/

orthereareickersatcorners.

Whenusingtheadjustmentpattern(seepage30),make

adjustmentssothatnohorizontalstripenoiseappearsinit.

* AdjustmentstoPHASEshouldbemadeonlyafterCLOCK

has been correctly set.

H-POS

Adjustthehorizontalpositionoftheimage.

V-POS

Adjusttheverticalpositionoftheimage.

H-SIZE

Adjustthehorizontalsizeoftheimage.

V-SIZE

Adjusttheverticalsizeoftheimage.

H-RESOLUTION (PC D-SUB/PC RGB)

Setsproperhorizontalresolutionwhentheresolutionof

inputsignalsisnotrecognizedproperly.(Adjustmentmaybe

impossible with some signals.)

V-RESOLUTION (PC D-SUB/PC RGB)

Sets proper vertical resolution when the resolution of input

signalsisnotrecognizedproperly.(Adjustmentmaybe

impossible with some signals.)

RESET

ResetsthevaluesoftheSCREENmenuitemstothefactory

preset values.

Select “ON” and then press


You can move the menu screen display position each time

DISPLA

is pressed.

AUTO (PC D-SUB/PC RGB)

TheANALOGGAINandANALOGOFFSETare

automaticallyadjusted.

Pressing

performsadjustment.

ANALOG GAIN (PC D-SUB/PC RGB)

Adjuststhebrightportionsofthevideoinputsignal.

ANALOG OFFSET (PC D-SUB/PC RGB)

Adjuststhedarkportionsofthevideoinputsignal.

BRIGHT

Adjuststhebacklightbrightness.(InPIPmode,themainside

settingisreectedintheimage.)

CONTRAST

Adjuststhedifferencebetweenthebrightanddarkportions

of the image.

BLACK LEVEL

Adjuststheentirebrightnessofthevideosignals.

TINT

Adjuststhehue.Selecting+changesthecolortowards

green,andselecting-changesittowardsmagenta.

COLORS

Adjuststhecolorintensity.

SHARPNESS

Adjuststhesharpnessoftheimage.

RGB INPUT RANGE (PC DVI-D/PC HDMI/PC D-SUB/PC

RGB/AV DVI-D/AV HDMI)

SetstheRGBinputsignalrange.WhenusingHDMIsetto

AUTO,theRGBinputsignalisdetectedautomatically.Use

AUTO normally.

IftheRGBinputsignalrangecannotbesetappropriately

evenwhenusingAUTO,setaccordingtotheimage.When

the setting is different, images will be displayed with washed

out blacks and compressed gradients.

ADVANCED (AV input)

Youcanadjustmorespecically.(Seepage30.)

COLOR MODE

Changesthecolormodeonthescreen.Thecolormodeon

the screen can also be changed using a remote control unit.

(Seepage19.)

* sRGBisforPCinputonly.Seepage19fordetails.

WHITE BALANCE

THRU .............. Displaystheinputsignallevelasis.(forPC

DVI-D/PCHDMIonly)

PRESET ......... SelectsthecolortemperatureusingPRESET.

USER .............. UsedforadjustingR-/G-/B-CONTRASTand

R-/G-/B-OFFSETrespectively.

PRESET

SelectsthecolortemperaturewhentheWHITEBALANCEis

settoPRESET.

The setting values are shown for reference. The color

temperature of the screen varies over time.

This function is not intended to keep the color temperature

constant.

Menu Items

USER

AdjustseachitemwhentheWHITEBALANCEissetto

USER.

R-CONTRAST ....Adjustsbright-tonedredcomponent.

G-CONTRAST ....Adjustsbright-tonedgreencomponent.

B-CONTRAST .... Adjustsbright-tonedbluecomponent.

R-OFFSET ..........Adjustsdark-tonedredcomponent.

G-OFFSET .........Adjustsdark-tonedgreencomponent.

B-OFFSET ..........Adjustsdark-tonedbluecomponent.

COPY TO USER

CopiesthevaluesetforPRESETtotheUSERsetting.

Select “ON” and then press

GAMMA

Selectsthegamma.USERsetsthegammatothesent

value (see page 36). (In PIP mode, the main side setting is

reectedintheimage.)

DISPLAY COLOR PATTERN

Displaysacolorpattern.Canbedisplayedwhilethemenu

screen is displayed, so you can refer to the pattern while

adjustingtheimage.

OFF ....................No pattern display.

WHITE ................Whitesinglecolorpatterndisplay.

RED ....................Red single color pattern display.

GREEN ...............Greensinglecolorpatterndisplay.

BLUE ..................Bluesinglecolorpatterndisplay.

USER.................. R e d/green/blue mixed color pattern display.

WhenUSERisselected,seteachcolor’s

level.

RESET

ResetsthevaluesofthePICTUREmenuitemstothefactory

preset values.

Select “ON” and then press

AUDIO

TREBLE

Adjuststhevolumeoftreble-levelsound.

BASS

Adjuststhevolumeofbass-levelsound.

BALANCE

Adjuststhebalanceoftheaudiosoundbetweenrightand

left.

RESET

ResetsthevaluesoftheAUDIOmenuitemstothefactory

preset values.

Select “ON” and then press

SETUP

OSD H-POSITION

Adjuststhehorizontaldisplaypositionofmenuscreen.

OSD V-POSITION

Adjuststheverticaldisplaypositionofmenuscreen.

SCREEN MOTION

Residual images are reduced by moving the screen.

PATTERN1 ..... The whole screen moves vertically and

horizontally.

PATTERN2 ..... A black screen spreads from the bottom of

the screen and then shrinks to the bottom of

the screen.

If the monitor is installed in the portrait

orientation, a black screen spreads from the

left end of the screen and then shrinks to the

left end of the screen.

PATTERN3 ..... A black bar moves from the left end to the

right end of the screen.

If the monitor is installed in the portrait

orientation, a black bar moves from the top

to the bottom of the screen.

PATTERN4 ..... Blackscreensappearfromboththetopand

bottom of the screen, and the displayed

imageiscompressedintothecentraleld.

If the monitor is installed in the portrait

orientation, the screen is compressed from

the left and right ends.

PATTERN1 PATTERN2

PATTERN4PATTERN3

MOTION TIME 1

Specifyatimeperiod(operatinginterval)untilSCREEN

MOTION starts.

MOTION TIME 2

SpecifyatimeperiodduringwhichSCREENMOTION

operates (time period during which the screen will move).

MONITOR

Select the installation direction of the monitor.

LANDSCAPE ............Landscape orientation

PORTRAIT ...............Portrait orientation

LANGUAGE

Sets the display language for the menu screen.

POWER ON DELAY

You can delay the screen display after the monitor is turned

on.Theperiodcanbesetupto60secondsinunitsofone

second.Whenthisfunctionisactivated,thepowerLED

ashes(atapprox.1secondinterval)inorange.Thisfunction

isdisabledwhen0isspecied.

STANDBY MODE

WhenSTANDARDisselected,startuptimefromstandby

mode is reduced. Note, however that, more power will be

consumed in standby mode.

WhenLOWPOWERisselected,currentconsumption

is reduced while the monitor is in standby mode. Note,

however, that the startup time from standby mode becomes

longer.

IfsettoLOWPOWER,certainRS-232Ccommandscannot

be used in standby mode, and control via LAN will be

disabled.

Menu Items

BRIGHTNESS SENSOR SETTING

(When connected to the PN-ZR01 (optional) only)

Performsadjustmentstothebrightnesssensor.Performs

operation with the primary monitor.

Set the surrounding brightness and the current screen

luminancetoAMBIENTBRIGHTNESSandSCREEN

BRIGHTNESS.

IndividuallysetWHENLIGHT:andWHENDARK:.

EvenifbrighterordarkerthanthesetAMBIENT

BRIGHTNESS,thescreenbrightnesswillnotchange.

CURRENTAMBIENTBRIGHTNESSisshownforreference.

COPY SETTING VALUE

Whenthemonitorhasbeenconnectedtomultiplemonitors

withRS-232C,youcancopytheprimarysettingdetailsto

the secondary. Perform operations with the primary monitor.

SelectsthesettingstocopywithCOPYSETTINGVALUE

TARGET.

“PICTURE”ONLY

... CopiesthePICTUREmenusettings.*

ALL ........................ Copiesallthe settings.*

SelecttheIDNo.ofthemonitorthatyouwouldlikecopyto

withCOPYTOIDNo.,thenselectCOPYandpress

If you select ALL, settings will be copied to all monitors.

WhenyouwouldliketoconrmtheIDNo.thatissettothe

monitor,selectIDNo.DISPLAYandpress

.TheIDNo.

will be displayed on the screen.

*CertainsettingdetailssuchasANALOGGAIN,ANALOG

OFFSET,andDISPLAYCOLORPATTERNcannotbe

copied.

LOGO SCREEN

Sets whether or not to display the logo screen.

OFF IF NO OPERATION

Determineswhetherornottosetthemonitortogointo

standby mode when there is no operation from the remote

controlunit,RS-232Ccommands,orLANforover4hours.

HOT PLUG CONTROL

SetswhethertousehotplugcontrolforthePC/AVHDMI

andPC/AVDVI-Dinputterminals.

RS-232C/LAN SELECT

Selects the method with which to control the monitor from

the computer.

ID No. SET

AssignsIDnumberstomonitorsconnectedinadaisychain

(seepage34),usingtheRS-232cables.

Thenumbers1to255areavailableforIDnumbers.

If“0”isset,thesystemregardsthisasthestatewherenoID

number is set.

AUTO ASSIGN ID No.

IDNo.tobeusedwillbeautomaticallyassignedwhen

multiplemonitorsareconnectedwithRS-232C.

Select ON, then press

. Perform operations with the

primary monitor.

BAUD RATE

SelectsthecommunicationspeedusedforRS-232C

communication.

LAN SETUP

Conguresthesettingstocontrolthemonitorfromthe

computerviaLAN.(Seepage45.)

AUTO ASSIGN FIXED IP ADDR.

CanbeenabledwhenRS-232C/LANSELECTisLANand

theDHCPCLIENTisOFF.

SettheDHCPCLIENTforsecondarymonitorsconnected

byRS-232CtoOFFandaxedIPaddressisautomatically

allocated.

If the IP address is a duplicate with a network device other

than a monitor, individually change the IP address.

HDMI AUTO VIEW

WhenONisselected,thescreensizeisadjusted

automaticallyaccordingtothescreensizecontrolsignal

includedinthevideosignalinputfromtheAVHDMIinput

terminal.

BRIGHTNESS SENSOR

(When connected to the PN-ZR01 (optional) only)

WhensettoONorON:DISPLAY,thebrightnesswill

automatically change according to the lighting and

surrounding brightness. Performs operation with the primary

monitor.IfsettoON:DISPLAY,theeffectwillbedisplayed

with a

If connecting to multiple monitors, the brightness of all the

monitors will change.

The

will be displayed on the primary only.

WhensettingBRIGHTinSCHEDULEontheOPTIONmenu,

setBRIGHTNESSSENSORtoOFF.

Menu Items

OPTION

DATE/TIME SETTING

Set the date and time. Press

to select the date

and time, and press

to change the numerical

values.

Setthedatein“Month/Day/Year”order.

Setthetimeona12-hourbasis.(Factorydefault)

DATE/TIME FORMAT

Sets the date/time display format.

DATE ..................MM/DD/YYYY

DD/MM/YYYY

YYYY/MM/DD

(YYYY:Year,MM:Month,DD:Day)

TIME ...................Select12-or24-hourtime.

SCHEDULE (See page 29.)

You can turn the power on/off and change the screen

brightnessataspeciedtime.

INPUT SELECT

SelecttheinputmodetobeusedinPC/AVDVI-Dinput

terminal,PC/AVHDMIinputterminalandPCRGB/AV

component input terminals.

AUDIO SELECT

Selects the terminal used to input audio signals in each input

mode.

INPUT SIGNAL (PC D-SUB/PC RGB)

IfacomputerconnectedtothePCD-sub/PCRGBinput

terminal outputs any of the following resolutions, make a

selection from the following options.

480LINES .......... AUTO, 640x480or848x480

768LINES ..........AUTO,1024x768,1280x768,1360x768or

1366x768

1050LINES ........1400x1050or1680x1050

ZOOM2SPECIALSETTING(Seepage29.)

SCAN MODE (AV input)

SetsthescanmodeusedforAVmodeinput.

MODE1 ...............Over-scan display

MODE2 ...............Under-scandisplay

MODE3 ...............Under-scandisplaywhentheinputsignal

is1080i/p.Otherwise,over-scandisplay

*EvenwhenMODE1isselected,under-scandisplayisused

whentheinputsignalis1080i/pandthescreensizeisDot

byDot.

POWER MANAGEMENT

POWERMANAGEMENTdetermineswhetherornotto

switch modes from no signal to the input signal standby

mode.

COLOR SYSTEM (AV S-VIDEO/AV VIDEO)

SelectthecolorsystemoftheAVequipmentwhichis

connectedtoAVS-videoandAVvideoinputterminal.(AUTO/

PAL/PAL-60/SECAM/NTSC3.58/NTSC4.43)

WhenAUTOisselected,thecolorsystemisautomaticallyset

according to the input signal.

AUDIO OUTPUT(RCA)

Sets the volume of sound output from the audio output

terminals.WhensettoVARIABLE2,audioisnotoutputfrom

the external speaker terminals.

VARIABLE .......... You canadjustthevolumeusingVOLUME.

FIXED ................. Disablesvolumeadjustmentandxesthe

sounds.

WhenthePN-ZB02(optional)isattached:

VARIABLE1 ........ YoucanadjustthevolumeusingVOLUME.

VARIABLE2 ........ YoucanadjustthevolumeusingVOLUME,

but audio is not output from the external

speaker terminals.

FIXED ................. Disablesvolumeadjustmentandxesthe

sounds.

AUDIO LEVEL(STEREO MINI)

Selects the maximum audio input level of the audio input

terminal.

SELF ADJUST

OnaPCD-SUB/PCRGBscreen,specifywhetherto

performscreenadjustmentautomaticallyornot.WhenON

isselected,thescreenisautomaticallyadjustedwhenits

resolutionis800x600orhigherandthetimingofinput

signalschanges.“ADJUSTING”appearsonthescreen

duringtheadjustment.Forimageswithblackedges,etc.,

dependingonthesignal,adjustmentmaynotbepossible.

InthiscaseselectOFF.(Performmanualadjustmentofthe

screen.)

AUTO INPUT CHANGE

Specifywhethertochangeinputsautomatically.WhenONis

selected and no signal is present in the selected input mode,

AUTOINPUTCHANGEautomaticallychangestheselected

mode to another mode where a video signal is present.

Whenvideosignalsexistinmultipleinputmodes,the

switching priority is as follows:

PCD-SUB,PCHDMIandAVHDMI

WhenthePN-ZB02(optional)isattached:

PCDVI-D,PCHDMI,PCD-SUB,PCRGB,AVDVI-D,AV

HDMI,AVCOMPONENT,AVS-VIDEOandAVVIDEO

(Inputmodeswitchingmaytake15secondsormore,

dependingontheconnectedequipment.Inputsignals

may not be detected properly and a priority may change,

dependingontheconnectedequipmentorvideosignals.)

FAN SPEED

Sets the rotation speed of the fan.

As this number increases, the rotation speed becomes

faster.WhensettoAUTO,therotationspeedofthefanwill

change depending on the internal temperature.

SIZE

Selectsscreensize.(Seepage20.)

MUTE AUDIO

Cantemporarilyturnoffthevolume.

INFORMATION

If you press

, monitor information can be checked.

Menu Items

MULTI

ENLARGE (See page 28.)

Sets whether or not to use the enlarge function.

ADVANCED (ENLARGE)

ENLARGEH/ENLARGEV

......... Sets the number of screen splits (number of

monitors)inthehorizontal/verticaldirectionusedfor

the enlargement.

ENLARGE-POS

......... Specify the split screen to be displayed when the

enlargement function is used.

H-POS/V-POS

......... Adjustthehorizontal/verticalpositionoftheenlarged

screen.

BEZEL ADJUST

Sets whether or not to use the frame correction function.

ADVANCED (BEZELADJUST)

BEZELADJUST(TOP)/BEZELADJUST(BOTTOM)/

BEZELADJUST(RIGHT)/BEZELADJUST(LEFT)

......... Adjustssothatthetop/bottom/left/rightconnecting

jointsofgroupedunitswillbedisplayedsmoothly

when a group of monitors are aligned in multiples to

display a single image.

BEZEL(TOP)/BEZEL(BOTTOM)/BEZEL(RIGHT)/

BEZEL(LEFT)

......... Sets the frame width of the display.

PIP/PbyP

PIP MODES

Sets the display method.

OFF .........Displaysonescreen.

PIP ...........Displaysasubscreeninsideamainscreen.

PbyP ........Displaysamainscreenandasubscreeninaline.

PbyP2 ......

Displaysamainscreenwhichmeasures1024pixels

in the longest direction and a sub screen in a line.

PIP SIZE

SetsthesizeofthesubscreeninPIPmode.

PIP H-POS

AdjuststhehorizontalpositionofthesubscreeninPIP

mode.

PIP V-POS

AdjuststheverticalpositionofthesubscreeninPIPmode.

PIP BLEND

In PIP mode, use this menu item to display the sub screen

transparently.

PIP SOURCE

Selects the input signal of the sub screen in PIP, PbyP, or

PbyP2 mode.

SOUND CHANGE

Sets the sound which is output in PIP, PbyP, or PbyP2 mode.

If the main screen is displayed as a full screen by the AUTO

OFFfunction,thesoundforthemainscreenisoutputeven

whenthesoundforthesubscreenisspecied.

MAIN POS

Sets the position of the main screen in PbyP or PbyP2 mode.

PbyP2 POS

Sets the position of the sub screen in PbyP2 mode.

AUTO OFF

Sets the display method when no signals for the sub screen

are input in PIP, PbyP, or PbyP2 mode.

MANUAL .......

Displaysamainscreenandablacksubscreen.

AUTO ............ Displaysthemainscreenasafullscreen.

TIPS

• WhenWHITEBALANCEissettoTHRU,BLACKLEVEL,

CONTRAST,TINT,COLORS,RGBINPUTRANGE,

GAMMAandCOPYTOUSERcannotbeset.

• IfCOLORMODEissettosRGB,thefollowingitemscannot

be set.

WHITEBALANCE,PRESET,USER,COPYTOUSER,and

GAMMA

• WhentheCOLORMODEissettoVIVIDorHIGH

ILLUMINANCE,GAMMAcannotbeadjusted.

• STANDBYMODEcannotbesettoLOWPOWERwhen

SCHEDULEiseffectiveorwhenOFFisselectedforLEDin

FUNCTION.

• Whendisplayingthecolorpattern,itispossibletoadjust

certainitemsofthePICTUREmenu.

Non-adjustableitemscannotbeselected.

 AudioinputfromtheHDMIinputterminalisalsonotoutput.

Dual screen display

YoucandisplaythescreensofthePCinputsignalandAV

input signal simultaneously.

Setthisfunctionwith“PIPMODES”inthePIP/PbyPmenu.

PIP

Main screen

Sub

screen

A sub screen is displayed

inside a main screen.

PbyP

Main

screen

Sub

screen

A main screen and a sub

screen are displayed in a

line.

PbyP2

Main screen

Sub

screen

Displaysamainscreen

whichmeasures1024

pixels in the longest

direction and a sub

screen in a line.

* The currently selected input signal is displayed on the main

screen.

* You cannot simultaneously display the screens of signals

ofthesametype,suchastwotypesofPCinputsignalsor

twotypesofAVinputsignals.

* The dual screen display cannot be used with the

combinationofPCDVI-DandAVHDMIorofAVDVI-Dand

PCHDMI.

TIPS

• Youmightinfringeonacopyrightoftheauthorwhichis

protected by copyright law when you display the images of

thecomputerscreenandtelevision/VCRsimultaneouslyfor

prot-makingortoshowtheimagetothepublic.

• Thescreensizefordual-screendisplayisthesameas

thescreensizeforsingle-screendisplay.TheDotbyDot

screenisdisplayedinNORMALsizeexceptwhenitisset

as the PIP main screen.

• Whendual-screendisplayisselected,theSCREEN

MOTION function is disabled.

• Whendual-screendisplayisselected,theAUTOINPUT

CHANGEfunctionisdisabled.

• Whendual-screendisplayisselected,thescreencannot

be enlarged.

• Whendual-screendisplayisselected,theINPUTSELECT

options cannot be set.

• Whenaninterlacedsignal(1080i,480i,video,S-Video)is

inputtothesubscreen,horizontallinesmayicker.Ifthis

happens, display the image on the main screen.

Menu Items

Enlarge

• Youcanalignseveralmonitorsandintegratethemintoa

single large screen to display.

• Uptovemonitorscanbealignedinboththehorizontal

and vertical directions.

• Eachmonitordisplaysenlargedviewsofseparatedimages.

(Example)

Horizontal direction: 2 monitors

Vertical direction: 2 monitors

Horizontal direction: 3 monitors

Vertical direction: 2 monitors

Setting procedure

Set using the MULTI menu.

1. Set ENLARGE to ON.

2. Select ADVANCED (ENLARGE).

3. Set the number of monitors aligned in the horizontal

direction in ENLARGE H.

4. Set the number of monitors aligned in the vertical

direction in ENLARGE V.

5. Set the section of the separated image to be displayed

on each monitor in ENLARGE-POS.

1) Press

2) Press

, , or to select position, then

press

TIPS

• WhenEnlargeisused,theSCREENMOTIONfunctionis

disabled.

• WhenEnlargeisused,theAUTOINPUTCHANGEfunction

is disabled.

• WhenEnlargeisused,theHDMIAUTOVIEWfunctionis

disabled.

ZOOM2 SPECIAL SETTING

If you connect a laptop computer with any of the following

screen resolutions and black bands appear around the

screen,setZOOM2SPECIALSETTINGofINPUTSIGNALon

theOPTIONmenutoONandthenselectZOOM2intheSIZE

setting.

This displays the area inside the black band.

Laptop computer

resolution

Correspondingsignal*

1280x800 1280x1024,1280x960,1400x1050*

1280x600 1280x720

1024x600 1024x768

*1:Thissettingiseffectiveonlywhenthescreenresolution,

including the black band, is one of the resolutions listed

above.

*2:Usetheautomaticscreenadjustment.

SCHEDULE

You can set the time to switch the monitor on and off.

Setthisfunctionwith“SCHEDULE”intheOPTIONmenu.(See

page 26.)

WhenBRIGHTisset,setBRIGHTNESSSENSORtoOFFon

theSETUPmenu.

– – – – – – – – – – – –– – – – –

SCHEDULE

No.

POWERDAY OF THE WEEK

TIMEINPUT BRIGHT

– –

– – – – – – –

– –

– – – –

PC D-SUB

(1)

–

– – – – – – – – – – – –– – – – ––

(5)(2)(3) (4)(6)

OK···[MENU]

1366x768

V: 60 Hz H: 47.7 kHz

1. Press or to select the SCHEDULE number, and

press

2. Set the SCHEDULE. (See the description below.)

Press

or to select items, and press or to

change the setting.

3. Press

SCHEDULEbecomeseffective.

(1)

●:SCHEDULEeffective

:SCHEDULEnoteffective

(2) POWER

ON : Switchesthemonitoronatthespeciedtime.

OFF: Switchesthemonitoroffatthespeciedtimeandputs

the monitor in standby mode.

(3) DAY OF THE WEEK

SpeciesthedayoftheweektoexecutetheSCHEDULE.

0:ONLYONCE

ExecutestheSCHEDULEonceonthespeciedday.

SpecifythedayoftheweektoexecutetheSCHEDULE.

1:EVERYWEEK

ExecutestheSCHEDULEonthespecieddayoftheweek

every week. Specify the day of the week to execute the

SCHEDULE.

Periodicsettingsuchas“MondaythroughFriday”isalso

possible.

2:EVERYDAY

ExecutestheSCHEDULEeverydayregardlessoftheday

of the week.

(4) TIME

SpeciesthetimetoexecutetheSCHEDULE.

Setthetimeona12-hourbasis.(Factorydefault)

Canbeenteredas24-hourtimeusingtheTIMEsettingin

DATE/TIMEFORMAT.

(5) INPUT

Speciestheinputmodeatpower-on.Whennotspecifying,

thescreenatthepreviouspower-offappears.

InputmodesdisplayedonDVI,HDMIandBNCdependon

INPUTSELECTsettings.

(6) BRIGHT

Sets the brightness when changing the screen brightness at

aspeciedtime.

Caution

• Donotswitchoffthemainpoweraftersettingthe

SCHEDULE.

• Specifythecorrectdateandtime.(Seepage26.)

SCHEDULEdoesnotfunctionunlessthedateandtimeare

specied.

• Checkregularlythatthesetdateandtimearecorrect.

• WhenSTANDBYMODEisLOWPOWER,SCHEDULE

cannot be set.

• Whenatemperatureabnormalityoccursandthebacklight

brightness is reduced, the brightness is not changed even

ifaschedulesettoBRIGHTisexecuted.

TIPS

• Upto8SCHEDULEitemscanberegistered.

• SettingtheSCHEDULEashesthepowerLEDalternately

in red and orange in standby mode.

• ASCHEDULEthathasalargenumberhasprecedence

over that of a small number when schedules overlap.

Menu Items

ADVANCED items (AV input) (See page 23

for additional Menu item details.)

FLESH TONE

Adjustthehuecontrol.

3D-NR

Reduce the noise of playback images on video.

Settingahigherlevelreducesmorenoise.However,itmay

cause blurring on an image.

MPEG-NR

Reduce block noise caused by digital compression.

3D-Y/C (AV VIDEO)

Specifywhethertoperform3-dimensionY/Cseparation.

Ifdotinterferenceorcross-colorisoccurringinfast-motion

scenes,selecting“OFF”mayimprovetheimagequality.

C.M.S.-HUE

Adjustscolortonewith6colorsofR(red),Y(yellow),G

(green),C(cyan),B(blue),andM(magenta).

C.M.S.-SATURATION

Adjustscolorvividnesswith6colorsofR(red),Y(yellow),G

(green),C(cyan),B(blue),andM(magenta).

C.M.S.-VALUE

Adjustscolorbrightnesswith6colorsofR(red),Y(yellow),

G(green),C(cyan),B(blue),andM(magenta).

TIPS

• WhenFLESHTONEissettoLOWorHIGH,C.M.S.-HUE/

-SATURATION/-VALUEcannotbeset.

Adjustments for PC screen display

Automatic adjustment

WhenyouusethePCD-subinputterminalorPCRGBinput

terminalstodisplayaPCscreenforthersttime,orwhen

youchangethesettingofthePC,usetheautomaticscreen

adjustment.

1. Switch the input to PC D-SUB or to PC RGB and display

the adjustment pattern. (See the description below.)

2. Press

and use or to display the SCREEN

menu.

3. Press and select “AUTO”.

4. Press

 Theautomaticadjustmentiscompleteinseveralseconds.

5. Press

twice to close the menu screen.

TIPS

• Ifthescreencannotbeadjustedproperlywithone

automaticadjustment,repeattheautomaticadjustmenttwo

orthreetimes.Trymanualadjustmentifnecessary.

Screen display for adjustment

BeforemakingadjustmentsintheSCREENmenuor

PICTUREmenu,displayanimagetobrightentheentire

screen.IfyouareusingaWindowsPC,usetheadjustment

patternonthesuppliedCD-ROM.

Opening the adjustment pattern

ThefollowingexampleisperformedinWindows7.

1. Load the supplied CD-ROM into the computer’s CD-

ROM drive.

2. Open [CD Drive] in [Computer].

 InWindowsXP,open[CDDrive]in[MyComputer].

3. Double-click [Adj_uty.exe].

 Theadjustmentpatternwillappear.

 Adjustthescreenautomaticallyormanually.

4. When adjustment is nished, press the [Esc] on the

computer’s keyboard to quit the adjustment program.

5. Eject the CD-ROM from the CD-ROM drive.

TIPS

• Ifthedisplaymodeonthecomputeryouareusingis

65,000colors,thecolorlevelsinthecolorpatternmay

appear differently or grayscale may appear to be colored.

(Thisisduetothespecicationsoftheinputsignalandis

not a malfunction.)

Menu Items

Youcanreturnthesettingstotheirfactory-presetvaluesand

restrict operations.

1. If using the remote control unit, press

SIZE

until “F”

is displayed in the upper left area of the screen, then

while “F” is being displayed, press

, , , and

in that order.

If using the monitor buttons, press

and at the

same time until “F” is displayed in the upper left area

of the screen, then while “F” is being displayed, press

and at the same time.

OFF

UNLOCKED

ON1

LED

OFF

MONITOR

FUNCTION

1/1

ALL RESET

ADJUSTMENT LOCK

ADJUSTMENT LOCK TARGET

RS-232C

OSD DISPLAY

LED

TEMPERATURE ALERT

STATUS ALERT

POWER BUTTON

CONTROLLER INPUT

END

…

[MENU]

2. Select and set the items.

ALL RESET

Resets the settings to the factory default settings.

Press

,selectALLRESET,andthenpress

Afterinitialization,turnthemainpowerswitchoffand

then back on.

WhenthePN-ZB02(optional)isattached,press ,

select the resetting method, and then press

ALLRESET1 ....Resets all the settings to the factory

default settings.

ALLRESET2 ....Returns all settings to the factory default

settings except for the following items:

LANSETUP,RS-232C/LANSELECT,

IDNo.SET,BAUDRATE,NETWORK,

MAIL,SERVICE&SUPPORT,and

SNMP(Seepages24,25,andpages49

to52.)

ADJUSTMENT LOCK

You can disable operations on the monitor and the

remote control unit that use buttons.

OFF ...Enablesoperation.

ON1 ..Disablesalloperationsotherthanturningpower

on/off,FUNCTIONandREMOTECONTROL

MODE.

ON 2 ..OnlytheFUNCTIONandREMOTECONTROL

MODEoperationsareenabled.

DisablesalloperationsotherthanFUNCTION

andREMOTECONTROLMODE(notevenpower

on/off).

ADJUSTMENT LOCK TARGET

Sets the target to prohibit operation of with

ADJUSTMENTLOCK.

REMOTECONTROL

...Prohibits remote control operation

MONITORBUTTONS

....Prohibits monitor button operation

BOTH ........................ Prohibits remote control and

monitor button operation

Initialization (Reset)/Functional Restriction Setting (FUNCTION)

RS-232C

(RS-232C/LAN when the PN-ZB02 (optional) is

attached)

SpecieswhethertoallowcontrolviaRS-232CorLAN

(seepages32and45).

OSD DISPLAY

Shows/hides the menu, modes and messages.

TheFUNCTIONandREMOTECONTROLMODE

screens cannot be hidden.

ON1 ............. Shows all menus, modes and messages.

ON 2 ............. Hidesmessagesautomaticallydisplayed

by the display. Shows messages during

operation.

OFF .............. Hidesallmenus,modesandmessages.

LED

SpecieswhethertolightthepowerLED.

OFFcannotbeselectedwhenSTANDBYMODEisLOW

POWER.

TEMPERATURE ALERT

Selectsthenoticationmethodforanabnormal

temperature.

OFF .............. Donotnotifyaboutanabnormal

temperature.

OSD&LED .. Whenanabnormaltemperatureis

detected,thepowerLEDashesinred

and green alternately and the screen

displaysamessage:TEMPERATURE.

LED............... Whenanabnormaltemperatureis

detected,thepowerLEDashesinred

and green alternately.

STATUS ALERT

Selectsthenoticationmethodforahardwareerror.

OFF .............. Donotnotifyabouttheerror.

OSD&LED .. Whenahardwareerrorisdetected,the

powerLEDashesinredandthescreen

displaysamessage:STATUS[xxxx].

LED............... Whenahardwareerrorisdetected,the

powerLEDashesinred.

POWER BUTTON

Normally, leave this setting as MONITOR.

Whenusinganoptionalpart,ifinstructionappears,

change the setting accordingly.

CONTROLLER INPUT

Normally, you do not need to change this setting.

Whenusinganoptionalpart,ifinstructionappears,

change the setting accordingly.

3. Press

to return to the normal screen.

TIPS

• Whenbothabnormaltemperatureandhardwareerrorare

detected,thehardwareerrornoticationoverrides.

• IfTEMPERATUREALERTorSTATUSALERTissetto

OSD&LED,alertmessageswillappeareveniftheOSD

DISPLAYissettoON2orOFF.

• IfTEMPERATUREALERTorSTATUSALERTissettoLED

orOSD&LED,theLEDlightseveniftheLEDfunctionis

settoOFF.

Controlling the Monitor with a PC (RS-232C)

YoucancontrolthismonitorfromaPCviaRS-232C(COM

port)onthePC.

You can also connect multiple monitors via a daisy chain by

usingaPC.ByassigningIDnumberstoeachmonitor(see

page34),youcanmakeinputmodeselection/adjustmentor

cancheckthestatusofaspecicmonitor.

Precautions when the PN-ZB02 (optional) is attached

• TocontrolthemonitorviaRS-232C,setRS-232C/LAN

SELECTtoRS-232C.

• YoucannotuseRS-232CandLANcontrolsimultaneously.

PC connection

One-to-one connection with a PC

ConnectwithRS-232straightcablebetweenthePC’sCOM

port(RS-232Cconnector)andtheRS-232Cinputterminalon

the monitor.

RS-232 straight cable

(commercially available)

To COM port

RS-232C input terminal

Daisy chain connection…

Advanced operation

ConnectwithRS-232straightcablebetweenthePC’sCOM

port(RS-232Cconnector)andtheRS-232Cinputterminalon

therstmonitor.

Next,connectRS-232straightcabletotherstmonitor’s

RS-232Coutputterminalandtothesecondmonitor’s

RS-232Cinputterminal.Connectinthesamewaytothethird

andsubsequentmonitors.

Upto25monitorscanbeconnected.(Dependingonthe

length of the cable used and the surrounding environment.)

RS-232 straight cables

(commercially available)

First monitor Second monitor

To COM port

RS-232C

input terminal

RS-232C

output terminal

Communication conditions

SettheRS-232CcommunicationsettingsonthePCtomatch

the monitor’s communication settings as follows:

Baudrate *

Stop bit

1bit

Datalength 8 bits Flowcontrol None

Parity bit None

*SettothesamebaudrateastheBAUDRATEsettingof

SETUPmenu.(Initialsetting:38400bps)

*Whenconnectingmultiplemonitorsinadaisychain,setall

monitorstothesameBAUDRATE.

Communication procedure

Command format

WhenacommandissentfromthePCtothemonitor,the

monitor operates according to the received command and

sendsaresponsemessagetothePC.

C1 C2 C3 C4 P1 P2 P3 P4

Return code

Command field

(4 prescribed

alphanumerical characters

)

Parameter field

(4 character string comprised of:

0-9, +, -, space, ?)

Example:VOLM0030

 VOLM

30

* Besuretoinput4charactersfortheparameter.Padwith

spaces (“

”) if necessary.

(“

”isareturncode(0D

,0A

or0D

))

Wrong :VOLM30

Right :VOLM 30

Wheninputtinganegativevalue,specifyanumericalvaluein

three digits.

Example:AUTR-005

DonotusespacesforMPOS,DATE,andSC01through

SC08.Specifyparametersusingaspeciednumberof

characters.

Example:MPOS010097

Ifacommandhas“R”listedfor“DIRECTION”inthe

“RS-232Ccommandtable”onpage37,thecurrentvaluecan

be returned by using “?” as the parameter.

Example:

VOLM???? ←

FromPCtomonitor(Howmuch

is current volume setting?).

30 ←

FrommonitortoPC(Current

volumesetting:30).

* IfanIDnumber(seepage33)hasbeenassigned

(Forexample,IDnumber=1).

VOLM

? ←

FromPCtomonitor.

30 001 ←

FrommonitortoPC.

Controlling the Monitor with a PC (RS-232C)

Response code format

When a command has been executed correctly

O K

Return code

(0DH, 0AH)

A response is returned after a command is executed.

* IfanIDnumberhasbeenassigned

O K SPC 0 0 1

ID number of respondin

monitor

Space (20

Return code

(0DH, 0AH)

When a command has not been executed

R R E

Return code

(0DH, 0AH)

* IfanIDnumberhasbeenassigned

R R E SPC 0 0 1

ID n

Space (20H)

Return code

(0DH, 0AH)

TIPS

• “ERR”isreturnedwhenthereisnorelevantcommandor

when the command cannot be used in the current state of

the monitor.

• Ifcommunicationhasnotbeenestablishedforreasons

suchasabadconnectionbetweenthePCandmonitor,

nothingisreturned(notevenERR).

• “ERR”maybereturnedwhenacommandcan’tbe

received correctly due to interference from the surrounding

environment.

Please ensure that the system or software retries the

command if this occurs.

• IfnomonitorhasbeenassignedthedesignatedIDnumber

(e.g.ifthecommandIDSL0002

is used, but no monitor

withIDnumber:2isfound),noresponseisreturned.

If execution of the command is taking some time

I W T A

Return code

(0DH, 0AH)

Whenthefollowingcommandsareused,“WAIT”isreturned.

Inthiscase,avaluewillbereturnedifyouwaitawhile.Donot

send any command during this period.

NoIDnumberisattachedtoWAITresponse.

• CommandswhichreturnWAIT:

1. Whenrepeatercontrolisused

2. WhenanIDSLorIDLKcommandisused

3. Whenoneofthefollowingcommandsisused:RSET,

INPS,ASNC,WIDE,EMAG,EPOS,PXSL,POWR,

AGIN,MWIN,MWIP,MWPP,ESTG,EMHV,EPHV,

ESHV,ENLG

When control via RS-232C is locked (to prevent use)

using the operation lock function (see page 31)

E C D K O L

Return code

(0D

H, 0AH)

When RS-232C/LAN SELECT is set to LAN

U N S E L E C T E D

Return code

(0D

H, 0AH)

Communication interval

• AfterOKorERRisreturned,youmustsendthefollowing

commands.

 Tosetatimeoutforthecommandresponse,specify10

seconds or longer.

Whenconnectingmultiplemonitorsinadaisychain,setthe

timeout to at least the product of the monitor’s position from

thecomputermultipliedby10seconds.

Example)3rdmonitorfromcomputer:30secondsorlonger.

• Provideanintervalof100msormorebetweenthe

command response and the transmission of the next

command.

VOLM0020

INPS0001

WAIT

Interval of 100 ms or more

TIPS

• WhenexecutingALLRESET,setthetimeoutperiodto30

seconds or longer.

• WhenturningthepoweronwhilethePOWERONDELAY

functionisinuse,setthetimeoutperiodtothePOWERON

DELAYperiod+10secondsorlonger.

Controlling the Monitor with a PC (RS-232C)

Advanced operation

This section explains commands for daisy chain connection.

The basic communication procedure is the same as in the

“One-to-oneconnectionwithaPC”section.

ID numbers

YoucanassignauniqueIDnumbertoeachmonitor(see

page25).Thisallowsyoutocontrolaparticularmonitorina

daisy chain of monitors.

YoucanassignIDnumberseitherfromthemenuscreenor

fromthePCusingRS-232cable.

xamp

]

ID number: 1 ID number: 2 ID number: 3 ID number: 4

If monitors are connected as shown above, you can

execute commands like “Set the volume of the monitor with

ID4to20”.

WhendesignatingIDnumbersforasetofmonitorslinkedina

daisychain,youshouldbasicallyavoidanyduplicationofID

numbers.

IDnumbersdonothavetobeassignedinascendingorder

startingfromthePC.Theycanalsobeconnectedasshown

below.

xamp

]

ID number: 3 ID number: 2 ID number: 4 ID number: 1

Commands for ID control

The command examples shown on this page assume the

followingconnectionandIDnumbersetup.

ID number: 1 ID number: 2 ID number: 3 ID number: 4

IDST .........AmonitorreceivingthiscommandsetsitsownID

numberintheparametereld.

Example:

IDST0001

OK

001 ←

TheIDnumberofthismonitorissetto1.

TIPS

YoucanautomaticallyassignIDnumbersbyusingtheIDST

command with the Repeater control (see “Repeater control”

onpage35).

Forexample,usingthecommand“IDST001+”automatically

setstheIDnumbers,asshownbelow.

xamp

]

ID number: 1 ID number: 2 ID number: 3 ID number: 4

IDST001+ ←

IDsettingcommandwithrepeatercontrol

WAIT

OK

001 ←

“OK”responsefromIDnumber:1

OK 002 ←

“OK”responsefromIDnumber:2

OK 003 ←

“OK”responsefromIDnumber:3

OK 004 ←

“OK”responsefromIDnumber:4(End)

IDSL ........TheparameterofthiscommandsetstheIDnumber

ofthemonitor.Themonitorissubjecttothenext

command.

Example:

IDSL0002 ←

The next command is for the monitor

withIDnumber:2.

WAIT ←

SearchingformonitorwithIDnumber:

OK 002 ←

FoundmonitorwithIDnumber:2

VOLM0030 ←

SetsvolumeofmonitorwithID

number:2to30.

WAIT ←

Processing

OK 002 ←

OKresponsefrommonitorwithID

number: 2

VOLM0020 ←

Setsvolumeto20.

OK 001 ←

ThevolumeofthemonitorwithID

number:1(theonedirectlyconnected

tothePC)issetto20.*

* TheIDSLcommandiseffectiveonlyonce,forthe

immediately succeeding command.

Controlling the Monitor with a PC (RS-232C)

IDLK ........

TheparameterofthiscommandsetstheID

numberofthemonitor.Themonitorissubjecttoall

subsequentcommands.

Example:

IDLK0002 ←

Followingcommandsareforthemonitor

withIDnumber:2.

WAIT ←

SearchingformonitorwithIDnumber:

OK 002 ←

FoundmonitorwithIDnumber:2

VOLM0030 ←

SetsvolumeofmonitorwithID

number:2to30.*

WAIT ←

Processing

OK 002

VOLM0020 ←

SetsvolumeofmonitorwithID

number:2to20.*

WAIT

OK

002

IDLK0000 ←

CancelingxedIDnumbersetting

WAIT ←

CancelingIDLK

OK 002 ←

Cancelationcomplete

VOLM0010

OK

001 ←

ThevolumeofthemonitorwithIDnumber:

1(theonedirectlyconnectedtothePC)is

setto10.(IDLKiscanceled.)

* TheIDLKcommandremainseffectiveuntilitis

canceled, or power is shut off.

IDCK ........ProvidesscreendisplayoftheIDnumbercurrently

assignedtoamonitor,andtheIDnumbercurrently

setforIDLK(ifany).

Example:

(AfterexecutingIDLK0002)

IDCK0000

←

(Parameter has no meaning.)

ID:001IDLK:002

←

Returnedresponse.TheID

number is also displayed on the

monitor screen.

IDCK000+

←

Repeater control. (If a command

isusedwithrepeatercontrol,ID

designationusingIDSLorIDLK

is canceled.)

WAIT

ID:001IDLK:002

ID:002IDLK:002

ID:003IDLK:002

ID:004IDLK:002

Repeater control

This system has a function to allow setting of multiple

monitors connected in a daisy chain using a single command.

This function is called repeater control. You can use Repeater

controlfunctionwithoutassigningIDnumbers.

xamp

]

Set 1

Set 2 Set 3Set 4

* If monitors are connected as shown above, you can

execute a command like “Set all monitors’ input settings to

PCD-SUB”.

Repeater control command

RepeatercontrolisachievedbysettingtheFOURTH

CHARACTERoftheparameterto“+”.

Example:

VOLM030+ ←

Setsvolumeofallmonitorsto30.

In repeater control, responses are returned by all the

connected monitors.

If you want to determine that a value has been returned by a

specicset,assignIDnumberstoeachmonitorinadvance.

Whensomemonitorsdonotreturntheirresponses,the

probable cause is that the monitors could not receive the

commandorcommandprocessingisnotcomplete.Donot

send a new command.

Example: (When4monitorsareconnected,and

assignedIDnumbers:1through4)

VOLM030+

WAIT

OK

001

OK

002

OK

003

OK

004 ← If 4 monitors are connected in

a chain, reliable operation can

be ensured by sending a new

command only after a reply

has been returned by 4th (last)

monitor.

Repeater control can also be used for reading settings.

Example:

VOLM???+

WAIT

10

001

Volumesettingsforall

monitors are returned.

20

002

30

003

30

004

TIPS

• IfrepeatercontrolisusedduringIDdesignation(IDSL,

IDLK),theIDdesignationiscanceled.

Controlling the Monitor with a PC (RS-232C)

Setting of the GAMMA user data

To transfer the GAMMA user data

Usetheuserdatatransfercommands(UGRW,UGGWand

UGBW).ForeachoftheR,GandBcolors,dividethetotal

512piecesofuserdatainto16blocks,andtransfer32pieces

of data with each command.

C1 C2 C3 C4 P1 P2 P3 P4

…

S1 S2

Command field

Block number (01 to 16)

Data fieldChecksum field

Example:Totransferthedataofblock1(0to31levels)

of red (R) data

UGRW01000000010002 … 0031C0

Command

Block number

32 pieces of data Checksum

One piece of data consists

of 4 digits.

* Ifdataislessthan4digits,adda“0”(zero)tomakeit4

digits.

* Thechecksumeldisthecharacterstring(ASCII)dataof

lower-orderonebytewhichindicatesthesumoftheblock

numberand32piecesofdatainhexadecimal(0toF).

Saving the GAMMA user data

Usetheuserdatasavecommand(UGSV)tosavethe

transferred user data in the monitor.

If the data is not saved, it will be cleared when:

• Themainpowerswitchisoff

• STANDBYMODEisLOWPOWERandthemonitorenters

standby mode

Activating the GAMMA user data

Toactivatethetransferreduserdata,selectUSERforGAMMA

ofthePICTUREmenu,orsendthecorrespondingRS-232C

command.

Checking the GAMMA user data

Usetheuserdatareadcommands(UGRR,UGGRand

UGBR)toreturn512piecesofuserdataforeachoftheR,

GandBcolors.Dividethedatainto16blocksandreturn32

pieces of data with each command. The value to be returned

is not the value stored in the monitor, but the value in the

temporary memory for display. (These values are the same

whentheuserdatasavecommand(UGSV)abovehasbeen

sent.)

TIPS

• TheuserdataisnotinitializedbyRESETofthePICTURE

menu.Toinitializetheuserdata,useALLRESETofthe

FUNCTIONmenu.

TheGAMMAuserdatainitializecommand(UGRS)allows

theinitializationoftheuserdataonly.

RS-232C command table

How to read the command table

Command: Commandeld(Seepage32.)

Direction: W Whenthe“Parameter”issetintheparametereld(seepage32),thecommandfunctionsasdescribed

under“Control/ResponseContents”.

R The returned value indicated under “Reply” can be obtained by setting “????”, “

?”or“???+”

(repeatercontrol)intheparametereld(seepage32).

Parameter: Parametereld(Seepage32.)

Reply: Response (Returned value)

*1:

“●”

indicatesacommandwhichcanbeusedinpowerstandbymoderegardlessoftheSTANDBYMODE

setting.

 “○”indicatesacommandwhichcanalsobeusedinpowerstandbymodewhenSTANDBYMODEissetto

STANDARD.

“–”indicatesacommandwhichcannotbeusedinpowerstandbymoderegardlessoftheSTANDBYMODEsetting.

*2: PN-ZB02(optional)limitations

 (A)WhenPN-ZB02(optional)isnotattached,(B)WhenPN-ZB02(optional)isattached.

 ○:Thecommandcanbeused.

 - :Error(ERR)

Power control/Input mode selection

Function

Command Direction

Parameter Reply Control/Response contents *1

(A) (B)

POWERCONTROL POWR W 0

Switches to standby mode.

● ○ ○

1 Returns from standby mode.

R 0 Standby mode

1 Normal mode

2 Input signal waiting mode

INPUTMODESELECTION INPS W 0 Togglechangeforinputmode.TerminalsnotselectedinINPUTSELECT

cannot be selected.

●

○ ○

1 PCDVI-D

“ERR”whenAVDVI-DisselectedforDVIofINPUTSELECT.

○

2 PCD-SUB

○ ○

3 AVCOMPONENT

“ERR”whenPCRGBisselectedforBNCofINPUTSELECT.

○

4 AVVIDEO -

○

6 PCRGB

“ERR”whenAVCOMPONENTisselectedforBNCofINPUTSELECT.

○

7 AVDVI-D

“ERR”whenPCDVI-DisselectedforDVIofINPUTSELECT.

○

8 AVS-VIDEO -

○

9 AVHDMI

“ERR”whenPCHDMIisselectedforHDMIofINPUTSELECT.

○ ○

10 PCHDMI

“ERR”whenAVHDMIisselectedforHDMIofINPUTSELECT.

○ ○

R 1 PCDVI-D

● ○ ○

2 PCD-SUB

3 AVCOMPONENT

4 AVVIDEO

6 PCRGB

7 AVDVI-D

8 AVS-VIDEO

9 AVHDMI

10 PCHDMI

Controlling the Monitor with a PC (RS-232C)

SCREEN menu

Function

Command Direction

Parameter Reply Control/Response contents *1

(A) (B)

AUTO ASNC W 1 WhentheinputmodeisPCD-SUB,PCRGB.

○ ○

CLOCK CLCK WR 0-1200 0-1200 WhentheinputmodeisPCD-SUB,PCRGB.

Variesdependingonthesignal.

PHASE PHSE WR 0-63 0-63 WhentheinputmodeisPCD-SUB,PCRGB.

POSITIONING POSITIONOF

THELONGEST

DIRECTION

HPOS WR 0-100 0-100 0-800onPCD-SUB,PCRGB.

Variesdependingonthesignal.

POSITIONOF

THESHORTEST

DIRECTION

VPOS WR 0-100 0-100 0-200onPCD-SUB,PCRGB.

Variesdependingonthesignal.

SIZE SIZEOFTHE

LONGEST

DIRECTION

HSIZ WR 0-100 0-100

SIZEOFTHE

SHORTEST

DIRECTION

VSIZ WR 0-100 0-100

RESOLUTION

LONGEST

DIRECTION

RESOLUTION

HRES WR 300-1920 300-1920 WhentheinputmodeisPCD-SUB,PCRGB.

Only even numbers are valid for parameters.

Variesdependingonthesignal.

SHORTEST

DIRECTION

RESOLUTION

VRES WR 200-1200 200-1200

RESET ARST W 1

Controlling the Monitor with a PC (RS-232C)

PICTURE menu

Function

Command Direction

Parameter Reply Control/Response contents *1

(A) (B)

AUTO AGIN W 1 WhentheinputmodeisPCD-SUB,PCRGB.

○

ANALOGGAIN ANGA WR 0-127 0-127 WhentheinputmodeisPCD-SUB,PCRGB.

○

ANALOGOFFSET ANOF WR 0-127 0-127 WhentheinputmodeisPCD-SUB,PCRGB.

CONTRAST CONT WR 0-60 0-60

BLACKLEVEL BLVL WR 0-60 0-60

TINT TINT WR 0-60 0-60

COLORS COLR WR 0-60 0-60

SHARPNESS SHRP WR 0-24 0-24

RGBINPUTRANGE(AVHDMI) AHDR WR 0-2 0-2 0:AUTO,1:FULL,2:LIMITED

RGBINPUTRANGE(PCHDMI) PHDR WR 0-2 0-2 0:AUTO,1:FULL,2:LIMITED

RGBINPUTRANGE(AVDVI) ADVR WR 1-2 1-2 1:FULL,2:LIMITED

RGBINPUTRANGE(PCDVI) PDVR WR 1-2 1-2 1:FULL,2:LIMITED

RGBINPUTRANGE(D-SUB) PDSR WR 1-2 1-2 1:FULL,2:LIMITED

RGBINPUTRANGE(PCBNC) PBRR WR 1-2 1-2 1:FULL,2:LIMITED

ADVANCED

(Whentheinput

modeisAV.)

FLESHTONE FLES WR 0-2 0-2 0:OFF,1:LOW,2:HIGH

○

3D-NR TDNR WR 0-2 0-2 0:OFF,1:LOW,2:HIGH

MPEG-NR MPNR WR 0-1 0-1 0:OFF,1:ON

3D-Y/C YCSP WR 0-1 0-1 0:OFF,1:ON(WhentheinputmodeisAVVIDEO)

C.M.S.-HUE CMHR WR -10-10 -10-10 R

○

CMHY Y

CMHG G

CMHC C

CMHB B

CMHM M

CRST W 1 Resets the hue.

C.M.S.-

SATURATION

CMSR WR -10-10 -10-10 R

CMSY Y

CMSG G

CMSC C

CMSB B

CMSM M

CRST W 2 Resets the saturation.

C.M.S.-VALUE CMVR WR -10-10 -10-10 R

CMVY Y

CMVG G

CMVC C

CMVB B

CMVM M

CRST W 3 Resets the brightness.

COLORMODE BMOD WR 0 0 STD

○

2 2 VIVID

3 3 sRGB(WhentheinputmodeisPC)

4 4 HIGHILLUMINANCE

WHITEBALANCE THRU CTMP WR 0 0 WhentheinputmodeisPCDVI-D/PCHDMI.

○

PRESET 1-18 1-18 From1:approximately3,000Kto15:approximately10,000K

(500Ksteps)

16:approximately5,600K,17:approximately9,300K,

18:approximately3,200K

USER 99 99

R-CONTRAST CRTR WR 0-256 0-256 “ERR”whenCTMPisnotsetto99.

G-CONTRAST CRTG WR 0-256 0-256

B-CONTRAST CRTB WR 0-256 0-256

R-OFFSET OFSR WR -127-127 -127-127

G-OFFSET OFSG WR -127-127 -127-127

B-OFFSET OFSB WR -127-127 -127-127

COPYTOUSER CPTU W 0 Copiesapresetvaluetotheusersetting.

GAMMA GAMM WR 0-2 0-2 0:1.8,1:2.2,2:2.4(duringPCinput)

0:LIGHT2,2:DARK(duringAVinput)

○

4-6 4-6 4:USER,5:2.0,6:STD(duringPCinput)

4:USER,5:LIGHT1,6:STD(duringAVinput)

DISPLAYCOLORPATTERN PTDF WR 0 0 No pattern display.

1 1 Whitesinglecolorpatterndisplay.

2 2 Red single color pattern display.

3 3 Greensinglecolorpatterndisplay.

4 4 Bluesinglecolorpatterndisplay.

99 99 Red/green/blue mixed color pattern display.

Seteachcolor'slevelwithRED,GREEN,BLUE.

RED PTDR WR 0-15 0-15 “ERR”whenPTDFisnotsetto99.

GREEN PTDG WR 0-15 0-15

BLUE PTDB WR 0-15 0-15

RESET ARST W 2

Controlling the Monitor with a PC (RS-232C)

AUDIO menu

Function

Command Direction

Parameter Reply Control/Response contents *1

(A) (B)

TREBLE AUTR WR -5-5 -5-5

○

○ ○

BASS AUBS WR -5-5 -5-5

BALANCE AUBL WR -10-10 -10-10

RESET ARST W 3

SETUP menu

Function

Command Direction

Parameter Reply Control/Response contents *1

(A) (B)

OSDH-POSITION OSDH WR 0-100 0-100

○

○ ○

OSDV-POSITION OSDV WR 0-100 0-100

SCREENMOTION SCSV WR 0-4 0-4 0:OFF,1-4:PATTERN1-4

○

MOTIONTIME1 MTIM WR 0-20 0-20

○

MOTIONTIME2 PATTERN1 MINT WR 10-990 10-990 Per10seconds

○

PATTERN2-4 MINT WR 5-20 5-20 Per second

MONITOR STDR WR 0-1 0-1 0:LANDSCAPE,1:PORTRAIT

○

LANGUAGE LANG WR 14 14 ENGLISH

○

1 1 DEUTSCH

2 2 FRANÇAIS

3 3 ITALIANO

4 4 ESPAÑOL

5 5 РУССКИЙ

6 6

POWERONDELAY PWOD WR 0 0 OFF

○

1-60 1-60 ON

STANDBYMODE STBM WR 0-1 0-1 0:STANDARD,1:LOWPOWER

(“ERR"whenSCHEDULEiseffectiveorOFFisselectedforLED.)

○

OFFIFNOOPERATION ATOF WR 0-1 0-1 0:OFF,1:ON

○

HOTPLUGCONTROL(DVI) HPCT WR 0-1 0-1 0:OFF,1:ON

○

HOTPLUGCONTROL(HDMI) HPCH WR 0-1 0-1 0:OFF,1:ON

○ ○ ○

RS-232C/LANSELECT CTLS WR 0-1 0-1 0:RS-232C1:LAN

○

IDNUMBER IDNO.SETTING IDST W 0-255 Setsthemonitor’sIDnumber.(“0”means“noIDnumber”.)

○ ○ ○

R 0-255 Returnsthemonitor’sIDnumber.

IDNO.SETTING

(ONCE)

IDSL W 1-255 SetsamonitorIDnumber.

ThisIDnumberisonlyeffectiveforthecommandimmediatelyafterthis

command.

0 ClearstheIDnumberifonehasbeendesignated.

IDNO.SETTING

(SUBSEQUENT)

IDLK W 1-255 SetsamonitorIDnumber.

ThisIDnumberiseffectiveforthenextandallsubsequentcommands

after this command.

0 ClearstheIDnumberifonehasbeendesignated.

IDCHECK IDCK W 0 ID :xxx

IDLK :yyy

Displaysmonitor’sownIDnumberandtheselectedIDnumberonthe

screen.

IDDISPLAY IDDP W 0-2 0:OFF,1:ON,2:ON(turnsOFFafter4sec.)

(WhenthePN-ZB02isattached,theIPaddressandMACaddressare

both displayed.)

BAUDRATE BAUD WR 0-2 0-2 0:9600bps,1:19200bps,2:38400bps

○ ○ ○

HDMIAUTOVIEW HDAW WR 0-1 0-1 0:OFF,1:ON

○ ○ ○

BRIGHTNESSSENSOR(When

connectedtothePN-ZR01(optional)

only)

OPTS WR 0-2 0-2 0:OFF,1:ON,2:ON:DISPLAY

○ ○ ○

BRIGHTNESS

SENSOR

SETTING(When

connected to

thePN-ZR01

(optional) only)

WHENDARK:

AMBIENT

BRIGHTNESS

OPSD WR 0-99 0-99

○ ○ ○

WHENDARK:

SCREEN

BRIGHTNESS

OPDD WR 0-30 0-30

WHENLIGHT:

AMBIENT

BRIGHTNESS

OPSL WR 1-100 1-100

WHENLIGHT:

SCREEN

BRIGHTNESS

OPDL WR 1-31 1-31

SETTINGCOPYMODE CPMD WR 0 0 Copytoallmonitors.

○ ○ ○

1-225 1-225 CopytothemonitorwiththesetIDNumber.

SETTINGCOPYTARGET CPTG WR 0 0 CopiesthePICTUREmenusettings.

1 1 Copiesallthesettings.

LOGOSCREEN BTSC WR 0-1 0-1 0:OFF,1:ON

Controlling the Monitor with a PC (RS-232C)

OPTION menu

Function

Command Direction

Parameter Reply Control/Response contents *1

(A) (B)

DATE/TIMESETTING DATE WR

AABBCCDDEE AABBCCDDEE

AA:Year,BB:Month,CC:Day,DD:Hour,EE:Minute

○ ○ ○

DATEDISPLAYFORMAT DTFT WR

0-2 0-2

0:YYYY/MM/DD,1:MM/DD/YYYY,2:DD/MM/YYYY

YYYY:Year,MM:Month,DD:Day

TIMEDISPLAYFORMAT TMFT WR

0-1 0-1

0:24-HOURTIME,1:12-HOURTIME

SCHEDULE SC01-

SC08

WR ABCDEFFGGH ABCDEFFGGH Scheduleofaspeciednumber

A:Schedule 0=Noteffective,1=Effective

B:Power 0=OFF,1=ON

C:Dayoftheweek1 0=Onlyonce,1=Everyweek,2=Everyday

D:Dayoftheweek2 0=Sunday,1=Mondaythrough6=Saturday,

 9=Notexist

E:Dayoftheweek3 0=Sunday,1=Mondaythrough6=Saturday,

 9=Notexist

F:Hour 00-23

G:Minute 00-59

H:Input 0=Notspecied,1=PCDVI-D/AVDVI-D,

2=PCD-SUB,3=PCRGB/AVCOMPONENT,

4=AVVIDEO,5=AVS-VIDEO,

6=PCHDMI/AVHDMI

“ERR”whenLOWPOWERisselectedforSTANDBYMODE.

SCHEDULEBRIGHTNESS SB01-

SB08

WR 0-31 0-31 Screen brightness to change

99 99 Disablebrightnesssetting

INPUTSELECT DVI DVSL WR 0-1 0-1 0:PCDVI-D,1:AVDVI-D

○

BNC BNSL WR 0-1 0-1 0:PCRGB,1:AVCOMPONENT

○

HDMI HDSL WR 0-1 0-1 0:PCHDMI,1:AVHDMI

○ ○

AUDIOSELECT PCDVI-D ASDP WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA)

○

PCD-SUB ASAP WR 1-3 1-3 1:AUDIO(STEREOMINI)

○

2:AUDIO1(RCA),3:AUDIO2(RCA) -

PCHDMI ASHP WR 0-1 0-1 0:HDMI,1:AUDIO(STEREOMINI)

○

2-3 2-3 2:AUDIO1(RCA),3:AUDIO2(RCA) -

PCRGB ASCP WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA) -

AVDVI-D ASDA WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA) -

AVHDMI ASHA WR 0-1 0-1 0:HDMI,1:AUDIO(STEREOMINI)

○

2-3 2-3 2:AUDIO1(RCA),3:AUDIO2(RCA) -

AVCOMPONENT ASCA WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA) -

AVS-VIDEO ASSA WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA) -

AVVIDEO ASVA WR 1-3 1-3 1:AUDIO(STEREOMINI),2:AUDIO1(RCA),3:AUDIO2(RCA) -

INPUT

RESOLUTION

(PC)

RESOLUTIONCHECK

PXCK R - Returns current resolution in the form of hhh, vvv.

○ ○

PIXELSETTING

(PCD-SUB,PC

RGB)

PXSL WR 0 0 768)1366x768

1 1 768)1360x768

2 2 768)1280x768

3 3 768)1024x768

5 5 480)848x480

6 6 480)640x480

7 7 1050)1680x1050

8 8 1050)1400x1050

9 9 768) AUTO

10 10 480)AUTO

INPUTRESOLUTION(AV)

RESOLUTIONCHECK

RESO R - 480i,480p,1080i,720p,1080p,VGA,etc. -

ZOOM2SPECIALSETTING

(PCD-SUB,PCRGB)

Z2SP WR 0-1 0-1 0:OFF,1:ON

○

SCANMODE SCAN WR 0-2 0-2 0:MODE1,1:MODE2,2:MODE3(WhentheinputmodeisAV)

○

POWERMANAGEMENT(PC) PMNG WR 0-1 0-1 0:OFF,1:ON

○

POWERMANAGEMENT(AV) PMAV WR 0-1 0-1 0:OFF,1:ON

○

COLORSYSTEM CSYS WR 0-5 0-5 0:AUTO,1:PAL,2:PAL-60,3:SECAM,4:NTSC3.58,5:NTSC4.43

○

AUDIOOUTPUT(RCA) AOUT WR 0-1 0-1 0:VARIABLE,1:FIXED

○ ○

AUDIOOUTPUT(RCA)

WhenthePN-ZB02(optional)isattached

AOUT WR 0-2 0-2 0:VARIABLE1,1:FIXED,2:VARIABLE2

○

AUDIOLEVEL(STEREOMINI) AIVP WR 0-1 0-1 0:1.0Vrms,1:0.5Vrms

○

○ ○

SELFADJUST AADJ WR 0-1 0-1 0:OFF,1:ON

○

AUTOINPUTCHANGE AINC WR 0-1 0-1 0:OFF,1:ON

○

FANSPEED FCTL WR 0-4 0-4 0:AUTO,1-4:SPEED1-4

○

MULTI menu

Function

Command Direction

Parameter Reply Control/Response contents *1

(A) (B)

ENLARGE ENLG WR 0-1 0-1 0:OFF,1:ON

○ ○

ENLARGEMODE EMAG WR 0-4 0-4 0:OFF,1:2x2,2:3x3,3:4x4,4:5x5

EMHV WR 11-55 11-55 1x1(OFF)to5x5(“mxn”isexpressedas“mn”,wheremandnare

thenumbersofmonitorsspeciedforthelongestdirectionandthe

shortest direction respectively.)

IMAGEPOSITION(MxN) EPHV WR 11-55 11-55 SpeciesvaluesintheorderofIMAGEPOSITIONINLONGEST/

SHORTESTDIRECTION.

IMAGEPOSITION(2x2) EPOS WR 0-3 0-3 See the description below.

IMAGEPOSITION(3x3) EPOS WR 0-8 0-8

IMAGEPOSITION(4x4) EPOS WR 0-15 0-15

IMAGEPOSITION(5x5) EPOS WR 0-24 0-24

ENLARGED

SCREEN

POSITIONING

THELONGEST

DIRECTION

EPSH WR -999-999 -999-999 ThesettingrangedependsontheENLARGEMODEsettingandthe

IMAGEPOSITION.

THESHORTEST

DIRECTION

EPSV WR -999-999 -999-999

BEZELADJUST BZCO WR 0-1 0-1 0:OFF,1:ON

BEZELADJUST TOP BZCT WR 0-1 0-1 0:OFF,1:ON

BOTTOM BZCB WR 0-1 0-1 0:OFF,1:ON

RIGHT BZCR WR 0-1 0-1 0:OFF,1:ON

LEFT BZCL WR 0-1 0-1 0:OFF,1:ON

BEZELWIDTH TOP BZWT WR 0-100 0-100

BOTTOM BZWB WR 0-100 0-100

RIGHT BZWR WR 0-100 0-100

LEFT BZWL WR 0-100 0-100

ENLARGE/IMAGEPOSITIONSETTING ESTG WR XXYY XXYY XX:ENLARGEMODE(SameasEMAG),YY:IMAGEPOSITION(Same

asEPOS)

ESHV WR XXYY XXYY XX:ENLARGEMODE(SameasEMHV),YY:IMAGEPOSITION(Same

asEPHV)

• IMAGEPOSITION(EPOS)setting

In landscape orientation

2 x 2 4 x 4 5 x 53 x 3

012

345

678

13 14

In portrait orientation

2 x 2 4 x 4 5 x 53 x 3

3813

9141924

Controlling the Monitor with a PC (RS-232C)

PIP/PbyP menu

Function

Command Direction

Parameter Reply Control/Response contents *1

(A) (B)

PIPMODES MWIN WR 0-3 0-3 0:OFF,1:PIP,2:PbyP,3:PbyP2

○

○ ○

PIPSIZE MPSZ WR 1-64 1-64

○

PIP POS THELONGEST

DIRECTION

MHPS W 0-100

○

R 0-100

○

THESHORTEST

DIRECTION

MVPS W 0-100

○

R 0-100

○

PIPPOSLD+SDBATCH MPOS W 0-100,0-100 Specify the position in MPOSxxxyyy format.

(xxx: Longer side, yyy: Shorter side position)

○

R 0-100,0-100 Returns a response in (xxx,yyy) format.

(xxx: Longer side, yyy: Shorter side position)

○

PIPBLEND MWBL WR 0-15 0-15

○

PIPSOURCE MWIP WR 1 1 PCDVI-D

○

2 2 PCD-SUB

○ ○

3 3 AVCOMPONENT -

○

4 4 AVVIDEO -

○

6 6 PCRGB -

○

7 7 AVDVI-D -

○

8 8 AVS-VIDEO -

○

9 9 AVHDMI

○ ○

10 10 PCHDMI -

○

SOUNDCHANGE MWAD WR 1-2 1-2 1:MAIN,2:SUB

○

○ ○

MAIN POS (Main screen) MWPP WR 0-1 0-1 0:POS1,1:POS2

○

PbyP2 POS (Sub screen) MW2P WR 0-2 0-2 0:POS1,1:POS2,2:POS3

○

AUTOOFF MOFF WR 0-1 0-1 0:MANUAL,1:AUTO

○

Initialization/Functional Restriction Setting (FUNCTION) menu

Function

Command Direction

Parameter Reply Control/Response contents *1

(A) (B)

ALLRESET RSET W 0 0:ALLRESET -

○

0-1 0:ALLRESET1,1:ALLRESET2 - -

○

ADJUSTMENTLOCK ALCK WR 0-2 0-2 0:OFF,1:ON1,2:ON2

○

○ ○

ADJUSTMENTLOCKTARGET ALTG WR 0-2 0-2 0:REMOTECONTROL,1:MONITORBUTTONS,2:BOTH

○

OSDDISPLAY LOSD WR 0-2 0-2 0:ON1,1:OFF,2:ON2

○

LED OFLD WR 0-1 0-1 0:ON,1:OFF

“ERR”whenLOWPOWERisselectedforSTANDBYMODE.

○

TEMPERATUREALERT TALT WR 0-2 0-2 0:OFF,1:OSD&LED,2:LED

○

STATUSALERT SALT WR 0-2 0-2 0:OFF,1:OSD&LED,2:LED

○

POWERBUTTON PBTN WR 0-1 0-1 0:MONITOR,1:CONTROLLER

○

CONTROLLERINPUT PCIP WR 0-2 0-2 0:D-SUB,1:HDMI(“ERR”whenMONITORisselectedforPOWER

BUTTON.)

○ ○ ○

2:DVI-D(“ERR”whenMONITORisselectedforPOWERBUTTON.)

○

Controlling the Monitor with a PC (RS-232C)

Others

Function

Command Direction

Parameter Reply Control/Response contents *1

(A) (B)

SCREENSIZE(PC) WIDE WR 1-5 1-5 1:WIDE,2:NORMAL,3:DotbyDot,4:ZOOM1,5:ZOOM2

○

○ ○

SCREENSIZE(AV) WIDE WR 1-5 1-5 1:WIDE,2:ZOOM1,3:ZOOM2,4:NORMAL,5:DotbyDot

○

VOLUME VOLM WR 0-31 0-31

○

MUTE MUTE WR 0-1 0-1 0:OFF,1:ON -

INFORMATION MODEL INF1 R Value

●

SERIALNO SRNO R Value

BRIGHT VLMP WR 0-31 0-31

○

TEMPERATURESENSOR DSTA R 0 Internal temperature normal

●

1 Internal temperature abnormal has occurred and the monitor is in

standby mode

2 Internal temperature abnormal occurred (To delete the information of

temperature abnormal, turn off the main power.)

3 Internal temperature abnormal has occurred and backlight brightness is

dimmed

4 Temperature sensor abnormal

TEMPERATUREACQUISITION ERRT R Value Temperatureattemperaturesensors1through4arereturnedinthe

following forms:

[Sensor1],[Sensor2],[Sensor3],[Sensor4]

Indicatesatemperaturesensorabnormalitywhen“126”isreturned.

○

CAUSEOFLASTSTANDBYMODE STCA W 0 Initialization

●

R 0 No detectable error has occurred

1 StandbymodebyPOWERbutton

2 Main power off by the main power switch

3 StandbymodebyRS-232CorLAN

4 Input signal waiting mode by No Signal

6 Standby mode by abnormal temperature

8 StandbymodebySCHEDULEsetting

20 StandbymodebyOFFIFNOOPERATIONsetting

Commands for setting of the GAMMA user data

Function

Command Direction

Parameter Reply Control/Response contents *1

(A) (B)

REDGAMMADATATRANSFER UGRW W aaxxxx

···

xxxxcc

(xxxx: 32 pieces)

aa:01-16

xxxx:0000-1023

cc:00-FF

aa:Blocknumber

xxxx: 32 pieces of user data

cc:Checksum(ASCIIdata)oftheblocknumberanduserdata

○ ○ ○

GREENGAMMADATATRANSFER UGGW W

BLUEGAMMADATATRANSFER UGBW W

REDGAMMADATAREAD UGRR W 1-16 xxxx

···

xxxx

(xxxx: 32 pieces)

xxxx:0000-1023

xxxx: User data of 32 pieces

GREENGAMMADATAREAD UGGR W 1-16

BLUEGAMMADATAREAD UGBR W 1-16

USERDATAINITIALIZE UGRS W 0 Initializetheuserdata.

USERDATASAVE UGSV W 0 Save the user data in the monitor.

Controlling the Monitor with a PC (RS-232C)

WhenthePN-ZB02(optional)isattached,yourmonitorcan

beconnectedtoaLANallowingyoutocontrolitfromaPCon

the LAN.

Youcanalsocongurethemonitortosende-mailnotication

when it has a problem.

TheconnectionrequiresacommerciallyavailableLANcable

(UTPcable,Category5,straightthrough).

Hub

LAN terminal

LAN cable (commercially available, straight)

Network (LAN)

TIPS

• YoumustassignanIPaddresstothemonitorbyfollowing

the procedures in “Settings to connect to a LAN”. (See the

description on the right.)

• YourPCmustbeinstalledwithInternetExplorer(version7.0

or later).

• TocontrolthemonitorviaLAN,setRS-232C/LANSELECT

toLAN.(Seepage25.)

• YoucannotuseRS-232CandLANcontrolsimultaneously.

Initializing personal information

• WhenthePN-ZB02(optional)isattached,personal

informationsuchase-mailaddressescanberegisteredin

themonitor.Beforetransferringordisposingofthemonitor,

initializeallsettingsbyselectingALLRESET1.(See

page31.)NotethatALLRESET2willnotinitializee-mail

addresses and other settings.

Controlling the Monitor with a PC (LAN)

Settings to connect to a LAN

Set the monitor’s IP address and subnet mask to match the

settings of your LAN.

ThesesettingscanbemadeoneitherthemonitororaPC

connected to the monitor.

ThesettingsdependonthecongurationofyourLAN.Ask

your LAN administrator for details.

■ To set on the monitor

SetRS-232C/LANSELECTontheSETUPmenutoLAN,and

thensettheLANSETUPoptions.(Seepage25.)

Aftersettingeachitem,selectSETandpress

DHCP CLIENT

IfyourLANhasaDHCPserverandyouwishtoobtainan

address automatically, change this setting to ON.

Tosettheaddressmanually,setthistoOFF.

IP ADDRESS

IftheDHCPCLIENTissettoOFF,specifyanIPaddress.

Press

or to select items, and press or to

change the values.

SUBNET MASK

IftheDHCPCLIENTissettoOFF,specifythesubnetmask.

Press

or to select items, and press or to

change the values.

DEFAULT GATEWAY

IftheDHCPCLIENTissettoOFF,specifythedefault

gateway.

Ifyouarenotusingagateway,specify“0.0.0.0”.

Press

or to select items, and press or to

change the values.

RESET

Resets the values of the LAN settings to the factory preset

values.

Select ON and then press

TIPS

• WhenmanuallysettingtheIPaddress,theIPaddress

forsecondarymonitorsconnectedbyRS-232Ccanbe

automaticallyallocated.(Seepage25.)

■ To set from a PC

WhenthemonitorisconnectedtoaPC,LANsettingscanbe

conguredviaPC.

Set up process

(1)ConnectyourmonitortoaPC

(2)SpecifythePC’sIPaddress

(3)Congurethemonitor’sLANsettings

(1) Connecting your monitor to a PC

ConnectacommerciallyavailablecrossoverLANcable

(UPTcable,Category5)totheLANportonthePCandthis

monitor.

LAN cable

(

commerciall

available, crossover

)

To LAN terminal

LAN terminal

(2) Specifying the PC’s IP address

Tocongurethemonitor’sLANsettings,youmusttemporarily

changethesettingsonthePC.

ThisexplanationisbasedonWindows7.

1. LogontothePCwithanadministratoraccount.

2. Click[Start],andthenclick“ControlPanel”.

3. Click“Viewnetworkstatusandtasks”in“Networkand

Internet”.

In“ClassicView”,click“NetworkandSharingCenter”.

4. Click“LocalAreaConnection”andthen“Properties”.

5. Click“InternetProtocolVersion4(TCP/IPv4)”andthen

“Properties”.

6. Make a note of the current IP address, subnet mask, and

default gateway settings.

Make sure you write this information now as you will

be changing the IP address, subnet mask, and default

gateway settings back to these settings afterwards.

7. Temporarily change the IP address and subnet mask.

To access the monitor as it is shipped from the factory, set

as follows.

• IPAddress:192.168.150.1

• SubnetMask:255.255.255.0

• DefaultGateway:(leaveblank)

8. Click[OK]andthenrebootthePC.

TIPS

• Thismonitorisfactorypresetasshownbelow.

 (WhenDHCPCLIENTissettoOFF)

 IPAddress :192.168.150.2

 SubnetMask :255.255.255.0

 DefaultGateway :0.0.0.0

(3) Conguring the monitor’s LAN settings

AccessthemonitorusingInternetExplorer.

Controllingthemonitor

1. TurnthepowerONtothemonitor.

2. SetRS-232C/LANSELECTontheSETUPmenutoLAN.

3. SetDHCPCLIENTtoOFFinLANSETUPontheSETUP

menu.

PCoperation

4. LaunchInternetExplorer,inthe“Address”boxtype

“http://192.168.150.2/”andpresstheEnterkey.

You will be prompted to enter a user name and password.

5. Leavetheusernameandpasswordboxesblankandclick

[OK].

6. Clickon“LANSETUP”underNETWORK.

Controlling the Monitor with a PC (LAN)

7. Specifythe“DHCPCLIENT”,“IPADDRESS”,etc.

DHCP CLIENT

IfyourLANhasaDHCPserverandyouwishtoobtainan

address automatically, change this setting to “ON”.

Tosettheaddressmanually,setthisto“OFF”.

IP ADDRESS

IftheDHCPCLIENTissetto“OFF”,specifyanIP

address.

SUBNET MASK

IftheDHCPCLIENTissetto“OFF”,specifythesubnet

mask.

DEFAULT GATEWAY

IftheDHCPCLIENTissetto“OFF”,specifythedefault

gateway.

Ifyouarenotusingadefaultgateway,specify“0.0.0.0”.

8. Whenthesettingischanged,click[Apply].

9. Checkthemessageandclick[OK].

.ExitInternetExplorer.

11.

RestorethePC’sIPaddressjottedinStep6,“(2)

SpecifyingthePC’sIPaddress”.

12.

ConnectthemonitorandthePCtotheLAN.

Caution

• Wait10secondsafterclicking[OK]beforeproceeding.

• Whenoperatingusingtheremotecontrolunitorsimilar,

click[Refresh].

TIPS

• WhenmanuallysettingtheIPaddress,theIPaddress

forsecondarymonitorsconnectedbyRS-232Ccanbe

automaticallyallocated.(Seepage25.)

Controlling with a PC

■ Basic operation

YouuseInternetExploreronaPContheLANtocontrolthe

monitor.

1. LaunchInternetExploreronthePC.

In the “Address” box, type “http://” followed by your monitor’s

IPaddressfollowedby“/”,thenpresstheEnterkey.

 YoucanconrmtheIPaddresswiththeDISPLAYfunction.

Whenpromptedtoenterausernameandpassword,type

theusernameandpasswordthatyouspeciedinthe

securitysettings(seepage49),andclick[OK].

If you did not make any security settings, leave the spaces

blankandclickon[OK].

3. You can check, control, and change the monitor’s status

and settings by clicking the menu items on the left side of

the screen.

• Ifyouseean[Apply]buttonnexttoasetting,clickitafter

you change that setting.

TIPS

• Seepages48to52fordetailsoneachsetting.

• Ifyouclick[Refresh]beforethescreennishesupdating

thecurrentdisplay,the“ServerBusyError”willappear.

Waitforamomentbeforeoperatingyourmonitoragain.

• Youcannotoperatethemonitorwhileitiswarmingup.

• If“DHCPCLIENT”issetto“ON”,press

DISPLA

on the

remote control unit two times and then check the monitor’s

IP address.

Controlling the Monitor with a PC (LAN)

■ INFORMATION

Information about this monitor appears.

■ CONTROL

You can control the operations corresponding to the buttons

(

POWER

INPUT

SIZE

)ontheremotecontrolunit.(Seepages18

and19.)

TIPS

• Instandbymode,PowerONistheonlyoperationavailable.

■ ADJUSTMENT

Youcanadjustthesesettingswhicharealsoavailableonthe

monitor’s menu.

• SCREEN(Seepage23.)

• PICTURE(Seepage23.)

• PICTURE(ADVANCED)(Seepage30.)

• AUDIO(Seepage24.)

• SETUP(Seepage24.)

• OPTION(Seepage26.)

• SCHEDULE(Seepage29.)

• MULTI(Seepage27.)

• PIP/PbyP(Seepage27.)

• FUNCTION(Seepage31.)

TIPS

• AfterchangingDISPLAYCOLORPATTERNtoOFF,click

[Refresh]tocorrectlyretrievethestatusofthemonitor.

Controlling the Monitor with a PC (LAN)

■ NETWORK (LAN SETUP)

This screen allows you to set the settings necessary when the

monitor is connected to a LAN.

DHCP CLIENT

IfyourLANhasaDHCPserverandyouwishtoobtainan

address automatically, change this setting to “ON”.

Tosettheaddressmanually,setthisto“OFF”.

IP ADDRESS

IftheDHCPCLIENTissetto“OFF”,specifyanIPaddress.

SUBNET MASK

IftheDHCPCLIENTissetto“OFF”,specifythesubnet

mask.

DEFAULT GATEWAY

IftheDHCPCLIENTissetto“OFF”,specifythedefault

gateway.

Ifyouarenotusingadefaultgateway,specify“0.0.0.0”.

DNS SERVER

SpecifytheDNSserveraddress.

IfyouarenotusingaDNSserver,specify“0.0.0.0”.

RESET

Clicking[Execute]returnsalloftheLANSETUPsettings

tothefactory-presetvaluesexceptfortheDNSSERVER

setting.

TIPS

• WhenmanuallysettingtheIPaddress,theIPaddress

forsecondarymonitorsconnectedbyRS-232Ccanbe

automaticallyallocated.(Seepage25.)

■ NETWORK (SECURITY)

Thisscreenallowsyoutospecifythesecurity-relatedsettings.

USER NAME / PASSWORD

Sets up a user name and password to restrict access to this

monitor.

Afterenteringausernameandpassword,click[Apply].

ACCEPT IP ADDRESS

You can limit access to this monitor by registering IP

addressesofPCsthatshouldhaveaccess.

Tolimitaccess,specifytheoption“FromonlyspecicIP

addresses”.Otherwise,toallowaccessfromanyPC,specify

“All IP Addresses”.

IP ADDRESS 1 to 3

If“ACCEPTIPADDRESS”issetto“FromonlyspecicIP

addresses”, enter the IP addresses that you want to allow.

TIPS

• TheUSERNAMEandPASSWORDcanbeupto8

alphanumeric characters or symbols.

• Tocanceltheusernameand/orpasswordafterithasbeen

set,maketheboxemptyandclick[Apply].

Controlling the Monitor with a PC (LAN)

■ NETWORK (GENERAL)

This screen allows you to specify the general LAN settings.

MONITOR NAME

Specify a name for this monitor as it should appear on the

InternetExplorerscreen.

AUTO LOGOUT TIME

Specify the time (in minutes) to elapse before automatically

disconnecting this monitor from the network.

Specifyinminutesfrom1to65535.Avalueof‘0’willdisable

this function.

DATA PORT

SpecifytheTCPportnumbertouseforexchangingdatawith

the monitor.

Specifyavaluefrom1025to65535.

SEARCH PORT

Specify the port number to use when searching for this

monitor.

Specifyavaluefrom1025to65535.

INSTALLATION INFORMATION (NAME/LOCATION)

Specify the information to display for this monitor in the

InternetExplorerwindow.

TIPS

• TheMONITORNAMEcanbeupto16alphanumeric

characters or symbols.

• Enterupto50charactersintheNAMEeldinthe

INSTALLATIONINFORMATION.

• Enterupto100charactersintheLOCATIONeldinthe

INSTALLATIONINFORMATION.

■ MAIL (ORIGINATOR)

Thisscreenallowsyoutocongurethee-mailsentperiodically

or when the monitor has an error.

ThesettingsdependonthecongurationofyourLAN.Ask

your LAN administrator for details.

SMTP SERVER

SpecifytheSMTPserveraddressforsendinge-mail.

* Whenusingadomainname,makesuretospecifythe

DNSSERVERaswell.(Seepage49.)

ORIGINATOR E-MAIL ADDRESS

Specifythee-mailaddressforthismonitor.

Thisaddressbecomesthee-mailaddressoftheoriginator.

ORIGINATOR NAME

Specify the name for the originator.

Thisnameappearsinthe“OriginatorName”eldofthe

e-mail.

AUTHENTICATION

Specify the authentication method to use when sending

e-mail.

POP SERVER

Ifthe“AUTHENTICATION”methodis“POPbeforeSMTP”,

specify the POP server address.

ACCOUNT NAME / PASSWORD

Ifthe“AUTHENTICATION”methodis“POPbeforeSMTP”,

specify the account name and password to connect to the

POP server.

TIPS

• Youcanenterupto64alphanumericcharactersorsymbols

fortheORIGINATORE-MAILADDRESS,ORIGINATOR

NAME,ACCOUNTNAME,andPASSWORD.

• TheSMTPSERVERandPOPSERVERcanbeupto64

characters.

Thefollowingcharacterscanbeused:a-z,A-Z,0-9,-,.

Controlling the Monitor with a PC (LAN)

■ MAIL (RECIPIENT)

Thisscreenallowsyoutospecifytherecipientsofthee-mail

sent periodically or when the monitor has an error.

RECIPIENT E-MAIL ADDRESSES

Specifythee-mailaddressestosenderrornoticatione-mail

to.

CONDITION

Specify the conditions to send mails.

WhenyoucheckPERIODICAL,specifythedateandtimeto

sendthemailsinthePERIODICALsetting.

CONFIRMATION

Sendsteste-mail.

Thisallowsyoutoconrmthatthee-mailsettingsare

conguredproperly.

Attach the log le to a TEMPERATURE/HARDWARE error

e-mail.

Whenthisoptionischecked,alogisaddedtothemailwhich

notiesatemperatureorstatuserror.

TIPS

• TheRECIPIENTE-MAILADDRESSEScanbeupto64

alphanumeric characters or symbols.

Controlling the Monitor with a PC (LAN)

■ MAIL (PERIODICAL)

WhenPERIODICALforCONDITIONofMAIL(RECIPIENT)is

checked, set the date and time to send the mail.

DAY OF THE WEEK

Specify the day of the week to send the periodical mails.

TIME

Specify the time of the day to send the periodical mails.

Caution

• Donotturnoffthemainpowerwhenyousettosendthe

periodical mails.

• Specifythecorrectdateandtime.(Seepage26.)

If the date and time settings are incorrect, the periodical

mail is not sent properly.

• Regularlyconrmthatthespecieddateandtimeis

correct.

• WhenLOWPOWERisselectedforSTANDBYMODE,

periodical mails will not be sent in standby mode.

Controlling the Monitor with a PC (LAN)

■ SNMP

YoucanconguresettingsrelatedtoSNMP.

SNMP SETTING

Set whether to enable or disable SNMP.

VERSION

Set the version of the SNMP to be supported.

COMMUNITY NAME 1 to 3

Setthenameofthecommunityrequiredfortheaccess.

USER 1 to 3

Set the user name, password, authentication method and

otheroptionsrequiredforaccess.

TRAP SETTING

Set whether to enable or disable the trap function.

Whenthisfunctionisenabled,atrapwillbesentwhenthe

monitor is turned on.

TRAP SETTING OF AUTHENTICATION ERROR

Setwhetherthetrapfunctionsendsanoticationwhen

authentication fails.

TRAP ADDRESS & PORT

Set the destination address and port number of the

noticationsentbythetrapfunction.

Caution

• AfteryousetSNMP,click[Switchthemainpowerof

monitoroffandonnow.]orturnoffthemonitorandthen

turnitonagainwiththemainpowerswitch.Whenthe

monitorrestarts,waitabout30secondsandthenstartthe

next operation.

• IftheIPaddressischangedwhiletheSNMPfunctionis

operational, turn off the monitor and then turn it on again

with the main power switch.

TIPS

• DependingontheSNMPsettings,ashortdelaymayoccur

before the SNMP is usable. (About 2 minutes)

• Upto16alphanumericlettersandsymbolscanbeusedfor

the community name, user name and password.

■ SERVICE & SUPPORT

(URL INFORMATION)

YoucandisplayaspecicURLintheURLINFORMATION

eldontheINFORMATIONscreenwhenanerroroccursin

the monitor. (See page 48.)

URL INFORMATION

EntertheURLtodisplayontheINFORMATIONscreenwhen

an error occurs on the monitor.

Up to 64 alphanumeric characters or symbols can be used.

CONDITION

Specify the condition to display the URL.

CONFIRMATION

ThehomepageofthespeciedURLisdisplayed.

You can check whether the URL you entered is correct.

TIPS

• Itisalsopossibletospecifythemessagetext,suchasthe

name of a contact or a telephone number, to be displayed

instead of the linked URL.

Troubleshooting

If you are experiencing any problem with your display, before

calling for service, please review the following troubleshooting

tips.

There is no picture or sound.

• Isthepowercorddisconnected?(Seepage15.)

• Isthemainpowerswitchoff?(Seepage17.)

• Isthemonitorinstandbymode(thepowerLEDilluminating

in orange)?

• Makesurecorrectinputmodeisselected.(Seepage18.)

• Ifanyexternalequipmentisconnected,makesurethe

equipmentisoperating(playingback).

Remote control does not work.

• Arethebatteriesinsertedwithpolarity(+,-)aligned?(See

page15.)

• Arethebatteriesexhausted?

• Pointtheremotecontrolunittowardtheremotecontrol

sensor.

• Isthemenudisplayhiddenorisoperationdisabled?(See

page31.)

• IsthePN-ZR01(optional)remotecontrolsensorbox

disconnected?

• Ifthemainunitisconnectedtomultiplemonitors,isthe

RS-232cabledisconnected?HastheIDNo.beenset?

Sound from left and right speakers is reversed.

Sound is heard from only one side.

• Areaudiocablesconnectedproperly?(Seepages12to

13.)

• Makesureaudiocablesforexternalspeakersare

connected properly: left and right cables may be reversed

or one of the two cables may not be connected. (See page

13.)

• CheckthesettingofBALANCEforAUDIOmenu.(See

page 24.)

There is a picture but no sound.

• Isthesoundmuted?

• Makesurethevolumeisnotsettominimum.

• Areaudiocablesconnectedproperly?

• IsthesettingofAUDIOSELECTontheOPTIONmenu

correct? (See page 26.)

Unstable video.

• Thesignalmaybeincompatible.

• TrytheautomaticscreenadjustmentwhenthePCD-sub

inputterminalorPCRGBinputterminalsareused.

The video from the PC/AV HDMI input terminal does not

appear properly.

• IsthesettingforHDMIofINPUTSELECTontheOPTION

menu correct? (See page 26.)

• IstheHDMIcableHDMIstandardcompliant?Themonitor

will not work with cables that are not standard compliant.

• Istheinputsignalcompatiblewiththismonitor?(Seepages

57to58.)

The video from the PC/AV DVI-D input terminal does not

appear properly.

• IsthesettingforDVIofINPUTSELECTontheOPTION

menu correct? (See page 26.)

• Istheinputsignalcompatiblewiththismonitor?(Seepages

57to58.)

• Turnoffthepowertotheconnectedequipmentandthen

turn the power on again.

• Ifthemonitorsareconnectedinadaisychain,turnoffthe

power to all the monitors connected in a daisy chain and

then turn the power on again.

The video from PC RGB, AV COMPONENT, or AV VIDEO

does not appear correctly.

• IsthesettingforBNCofINPUTSELECTontheOPTION

menu correct? (See page 26.)

• Istheinputsignalcompatiblewiththismonitor?(Seepages

57to58.)

Control buttons do not work.

There is no picture.

• Loadnoisesfromoutsidemaybeinterferingwithnormal

operation. Turn off the power and turn it on after waiting at

least5seconds,andthenchecktheoperation.

The input mode changes automatically.

• WhentheAUTOINPUTCHANGEisONandnosignal

is present in a selected input mode, the AUTO INPUT

CHANGEautomaticallychangestheselectedmodetoa

mode where a video signal is present.

The input mode may change in the following cases:

-Whenacomputerisinstandbymode.

-Whenvideoplayisstoppedwithaplaybackdevice.

Power LED ashes red.

“STATUS [xxxx]” appears in the corner of the screen.

• Hardwarehasaproblem.Turnoffthemonitorandrequest

repairfromyourSHARPdealer.

(WhenSTATUSALERTissettoOSD&LED.Thisvaries

depending on the setting.)

When “AUTO DIMMING” is displayed.

• Whentheinternaltemperatureofthemonitorrises

excessively, the brightness of the backlight automatically

decreases in order to prevent a further temperature rise. If

you attempt to use

toadjustthebrightnesswhile

themonitorisinthisstate,“AUTODIMMING”isdisplayed

and you cannot change the brightness.

• Removethecauseoftheexcessivetemperaturerise.

The monitor makes a cracking sound.

• Youmayoccasionallyhearacrackingsoundfromthe

monitor. This happens when the cabinet slightly expands

and contracts according to change in temperature. This

does not affect the monitor’s performance.

The Power LED is ashing in red and green alternately.

When “TEMPERATURE” is displayed in the corner of the

screen.

• Whentheinternaltemperatureofthemonitorrises

excessively, the brightness of the backlight decreases

automaticallyinordertopreventhigh-temperature-

relatedproblems.Whenthisoccurs,“TEMPERATURE”is

displayedonthescreenandthePowerLEDashesred

andgreenalternately.(WhenTEMPERATUREALERTis

settoOSD&LED.Thisvariesdependingonthesetting.)

• Iftheinternaltemperaturerisesfurther,themonitor

automaticallyentersstandbymode.(ThePowerLED

continuesashingredandgreenalternately.)

• Removethecauseoftheexcessivetemperaturerise.

-Ifthemonitorentersstandbymodeduetoarisein

temperature, to return to normal display, turn the power

switch off and then back on again. The monitor, however,

will enter standby mode again if the cause of the

temperature rise is not eliminated.

-Checkwhetherthemonitorisplacedatalocationwhere

aquickriseintemperatureislikely.Internaltemperature

risesquicklyiftheventsonthemonitorareblocked.

-Internaltemperaturerisesquicklyifdustaccumulates

inside the monitor or around the vents. Remove dust if

possible.AskSHARPdealeraboutremovinginternaldust.

Troubleshooting

Specications

PN-V600A Product Specications

Model PN-V600A

LCDcomponent

60"Class[60inch(152.4cm)diagonal]TFTLCD

Max. resolution (pixels)

1366x768

Max. colors

Approx.16.77Mcolors

Pixel pitch

0.973mm(H)×0.973mm(V)

Viewingangle

176°right/left/up/down(contrastratio≥10)

Screen active area inch (mm)

52-5/8x29-7/16 (1328.8x747.1)

Computerinputsignal

Digital(DVI1.0standard-compliant),AnalogRGB(0.7Vp-p)[75

]

Sync signal

Horizontal/verticalseparate(TTL:positive/negative),Sync-on-green,

Compositesync(TTL:positive/negative)

Videocolorsystem

NTSC(3.58MHz)/NTSC(4.43MHz)/PAL/PAL-60/SECAM

Plug and play

VESADDC2B

Power management

VESADPMS,DVIDMPM

Input terminals

PC/AV

Digital

HDMIx1

Analog

MiniD-sub15pin,3rowsx1

Audio

3.5mmministereojackx1

Serial(RS-232C)

D-sub9pinx1

WhenPN-ZB02

(optional) is

attached

PC/AV

Digital

DVI-D24pin(HDCPcompatible)x1

Analog

BNC

x1

Compositevideo

BNCx1

S-video

x1

Component BNC(Y,Cb/Pb,Cr/Pr)*

x1

Audio

RCApin(L/R)x2

Output terminals

Audio

RCApin(L/R)x1

Serial(RS-232C)

D-sub9pinx1

WhenPN-ZB02

(optional) is

attached

PC/AV

Digital

DVI-D24pinx1

Externalspeaker 10W+10W

]

LAN terminal

[

WhenPN-ZB02(optional)isattached

]

10BASE-T/100BASE-TX

Powerrequirement AC100V-240V,50/60Hz

Operating temperature

32°Fto104°F(0°Cto40°C)

Operating humidity 20%to80%(nocondensation)

Power consumption

(maximum / input signal waiting mode

/ standby

mode

)

305W/1.0W/1.0W

Powerconsumption[PN-ZB02(optional)] 310W

Dimensions(excludingprotrusions) inch (mm)

Approx. 52-5/8(W)x5-7/8(D)x29-11/16(H)(1335.9x149.3x754.2)

Weight lbs. (kg)

Weight

[PN-ZB02(optional)]

lbs. (kg)

Approx. 90.4(41)

Approx. 1.102 (0.5)

*1 Cannotbeusedsimultaneously.

*2 Doesnotsupportplugandplay.

*3 TemperatureconditionmaychangewhenusingthedisplaytogetherwiththeoptionalequipmentsrecommendedbySHARP.

Insuchcases,pleasecheckthetemperatureconditionspeciedbytheoptionalequipments.

*4 WhenAUTOINPUTCHANGEissettoOFF.

*5 WhenSTANDBYMODEissettoSTANDARD.WhenSTANDBYMODEissettoLOWPOWER:0.5W.

Asapartofourpolicyofcontinuousimprovement,SHARPreservestherighttomakedesignandspecicationchangesforproductimprovement

withoutpriornotice.Theperformancespecicationguresindicatedarenominalvaluesofproductionunits.Theremaybesomedeviationsfrom

these values in individual units.

PN-ZR01 (optional) Product Specications

Model PN-ZR01

Remote control sensor box dimensions inch (mm)

Approx. 1-3/8(W)x7/8(D)x5-1/8(H)(34.2 x 23 x 130)

Remote control sensor box weight lbs. (kg)

Approx. 0.220 (0.1)

Specications

Dimensional Drawings

Note that the values shown are approximate values.

Unit: inch [mm]

52-5/8 [1335.9]

Opening width (52-5/16 [1329.4])

Opening height (29-7/16 [747.7])

29-11/16 [754.2]

7-7/8 [200]

5-7/8

[149.3]

52-5/8 [1335.9]

3-5/8

[92.3]

7-7/8

[200]

7-7/8

[200]

VESA holes *

3-15/16

[100]

3-15/16

[100]

 Whenmountingthemonitor,besuretouseawall-mountbracketthatcomplieswiththeVESA-compatiblemountingmethod.

SHARPrecommendsusingM6screwsandtightenthescrews.

Notethatscrewholedepthofthemonitoris3/8inch(10mm).Loosemountingmaycausetheproducttofall,resultingin

seriouspersonalinjuriesaswellasdamagetotheproduct.Thescrewandholeshouldcometogetherwithover5/16inch

(8mm)lengthofthread.UseabracketwhichhasbeenapprovedforUL1678standard,andwhichcanendureatleast4times

or more the weight of the monitor.

Power management

ThismonitorconformstoVESADPMSandDVIDMPM.Bothyourvideocardandcomputermustsupportthesamestandardin

order for the monitor’s power management function to work.

DPMS:DisplayPowerManagementSignaling

DPMS Screen

Power

consumption*

Hsync Vsync

ONSTATE Display 305W Yes Yes

STANDBY

display

1.0W*

No Yes

SUSPEND Yes No

OFFSTATE No No

*1 WhenPN-ZB02(optional)isnotconnected.

*2 WhenAUTOINPUTCHANGEissettoOFF.

DMPM:DigitalMonitorPowerManagement

DMPM Screen

Power

consumption*

Monitor ON Display 305W

ActiveOFF No display 1.0W*

DDC (plug and play)

ThemonitorsupportstheVESADDC(DisplayDataChannel)standard.

DDCisasignalstandardforplugandplaybetweenmonitorsandcomputers.Informationaboutresolutionandotherparameters

isexchangedbetweenthetwo.ThisfunctioncanbeusedifthecomputersupportsDDCandithasbeenconguredtodetect

plug-and-playmonitors.

ThereareseveraltypesofDDC,dependingonthecommunicationmethodused.ThismonitorsupportsDDC2B.

Compatible signal timing (PC)

VESA

Wide

US TEXT

Sun

Screen resolution HsyncVsyncDot frequency

Digital

640 × 480

800 × 600

848 × 480

1024 × 768

1152 × 864

1280 × 768

1280 × 800

1280 × 960

1280 × 1024

1360 × 768

1400 × 1050

1440 × 900

1600 × 1200

1680 × 1050

1280 × 720

1366 × 768

1920 × 1080

720 × 400

1024 × 768

1152 × 900

1280 × 1024

1600 × 1000

31.5kHz

37.9kHz

37.5kHz

35.1kHz

37.9kHz

48.1kHz

46.9kHz

31.0kHz

48.4kHz

56.5kHz

60.0kHz

67.5kHz

47.8kHz

60.3kHz

49.7kHz

60.0kHz

64.0kHz

80.0kHz

47.7kHz

65.3kHz

55.9kHz

75.0kHz

65.3kHz

44.7kHz

47.7kHz

66.3kHz

67.5kHz

31.5kHz

48.3kHz

53.6kHz

56.6kHz

61.8kHz

71.8kHz

71.7kHz

81.1kHz

68.6kHz

60Hz

72Hz

75Hz

56Hz

60Hz

72Hz

75Hz

60Hz

70Hz

75Hz

60Hz

75Hz

60Hz

75Hz

60Hz

70Hz

60Hz

66Hz

70Hz

66Hz

76.2Hz

67.2Hz

76Hz

66Hz

25.175MHz

31.5MHz

36.0MHz

40.0MHz

50.0MHz

49.5MHz

33.75MHz

65.0MHz

75.0MHz

78.75MHz

108.0MHz

79.5MHz

102.25MHz

83.5MHz

108.0MHz

135.0MHz

85.5MHz

121.75MHz

106.5MHz

162.0MHz

146.25MHz

74.4MHz

85.383MHz

148.5MHz

28.3MHz

64.13MHz

70.4MHz

74.25MHz

94.88MHz

108.23MHz

117.01MHz

134.99MHz

135.76MHz

Yes

Analog

(D-SUB/RGB*

)

Yes

DVI*

HDMI

Yes

*1 Displays a reduced image, except in Dot by Dot. In Dot by Dot, the image will be cut down to panel size then displayed.

*2 Available when the PN-ZB02 (optional) is attached.

* Allarecompliantonlywithnon-interlaced.

* DependingontheconnectedPC,imagesmaynotbedisplayedproperlyevenifthecompatiblesignaldescribedaboveisinput.

* ThefrequencyvaluesfortheSunarereferencevalues.

Specications

Compatible signal timing (AV)

Screen resolution Frequency DVI-D*

HDMI Component

1920×1080p

24Hz - Ye s -

50Hz Yes Yes Yes

59.94Hz Yes Yes Yes

60Hz Yes Yes Yes

1920×1080i

50Hz Yes Yes Yes

59.94Hz Yes Yes Yes

60Hz Yes Yes Yes

1280×720p 50Hz Yes Yes Yes

59.94Hz Yes Yes Yes

60Hz Yes Yes Yes

720×576p 50Hz Yes Yes Yes

720×480p 59.94Hz Yes Yes Yes

60Hz Yes Yes Yes

640×480p(VGA) 59.94Hz Yes Yes -

60Hz Yes Yes -

720(1440)×576i 50Hz - Yes Yes

720(1440)×480i 59.94Hz - Ye s Yes

60Hz - Ye s Yes

*1Displaysareducedimage,exceptinDotbyDot.InDotbyDot,theimagewillbecutdowntopanelsizethendisplayed.

*2AvailablewhenthePN-ZB02(optional)isattached.

Specications

PC/AV DVI-D input terminal pins

(DVI-D 24 pin)

No. Function No. Function

1 TMDSdata2- 13 N.C.

2 TMDSdata2+ 14 +5V

3 TMDSdata2/4shield 15 GND

4 N.C. 16 Hot-plugdetection

5 N.C. 17 TMDSdata0-

6 DDCclock 18 TMDSdata0+

7 DDCdata 19 TMDSdata0/5shield

8 N.C. 20 N.C.

9 TMDSdata1- 21 N.C.

10 TMDSdata1+ 22 TMDSclockshield

11 TMDSdata1/3shield 23 TMDSclock+

12 N.C. 24 TMDSclock-

PC D-sub input terminal pins

(Mini D-sub 15 pin)

No. Function No. Function

1 Red video signal input 9 +5V

2 Greenvideosignalinput 10 GND

3 Bluevideosignalinput 11 N.C.

4 N.C. 12 DDCdata

5 GND 13 Hsyncsignalinput

6 GNDforredvideosignal 14 Vsyncsignalinput

7 GNDforgreenvideosignal 15 DDCclock

8 GNDforbluevideosignal

PC/AV DVI-D output terminal pins

(DVI-D 24 pin)

No. Function No. Function

1 TMDSdata2- 13 N.C.

2 TMDSdata2+ 14 +5V

3 TMDSdata2/4shield 15 GND

4 N.C. 16 Hot-plugdetection

5 N.C. 17 TMDSdata0-

6 DDCclock 18 TMDSdata0+

7 DDCdata 19 TMDSdata0/5shield

8 N.C. 20 N.C.

9 TMDSdata1- 21 N.C.

10 TMDSdata1+ 22 TMDSclockshield

11 TMDSdata1/3shield 23 TMDSclock+

12 N.C. 24 TMDSclock-

PC/AV HDMI input terminal pins

(HDMI

Connector)

No. Function No. Function

1 TMDSdata2+ 11 TMDSclockshield

2 TMDSdata2shield 12 TMDSclock-

3 TMDSdata2- 13 CEC

4 TMDSdata1+ 14 N.C.

5 TMDSdata1shield 15 SCL

6 TMDSdata1- 16 SDA

7 TMDSdata0+ 17 DDC/CECGND

8 TMDSdata0shield 18 +5V

9 TMDSdata0- 19 Hot-plugdetection

10 TMDSclock+

RS-232C input terminal pins

(D-sub 9 pin)

No. Function No. Function

1 N.C. 6 N.C.

2 Transmitted data 7 N.C.

3 Received data 8 N.C.

4 N.C. 9 N.C.

5 GND

RS-232C output terminal pins

(D-sub 9 pin)

No. Function No. Function

1 N.C. 6 N.C.

2 Received data 7 N.C.

3 Transmitted data 8 N.C.

4 N.C. 9 N.C.

5 GND

Mounting Precautions (For SHARP dealers and service engineers)

• Wheninstalling,removingormovingthemonitor,ensurethatthisiscarriedoutbyatleast2people.

• Besuretouseawall-mountbracketdesignedordesignatedformountingthemonitor.

• Thismonitorisdesignedtobeinstalledonaconcretewallorpillar.Reinforcedworkmightbenecessaryforsomematerials

such as plaster / thin plastic board / wood before starting installation.

This monitor and bracket must be installed on a wall which can endure at least 4 times or more the weight of the monitor.

Install by the most suitable method for the material and the structure.

• ToattachaVESA-compliantmountingbracket,useM6screwsthatare5/16inch(8mm)to3/8inch(10mm)longerthanthe

thickness of the mounting bracket.

• Whenmovingthemonitor,besuretoholditwitheitherhandlesorthecornersonthebottomoftheunit.DonotholdtheLCD

panel.Thismaycauseproductdamage,failure,orinjury.

• Whenperforminganinstallationwherethemonitorisstacked,pleaseinstallitsuchthatloadisnotplacedonthemonitor

frame.

• Aftermounting,pleasecarefullyensurethemonitorissecure,andnotabletocomeloosefromthewallormount.

• DonotuseanyscrewholesotherthanVESAholesforinstallation.

PN-V600A Mu EN13J(1)

Sharp PN-V600A Professional Displays

Product's Documents

PN-V600A Operation Manual

Specifications

Sharp PN-V600A Questions and Answers
