www.SQUATZ.com
2
Features:
• Smart and Portable Design
• Cordless Convenience
• Lightweight and Easy to Use
• Soft Rubber Material and Anti-Corrosion
• Auto Timer Setting and Has USB Outlet
• 3 Vibration Intensity Levels
• Automatic Mode to Choose, One Switch Button to Operate
• Can be used for Hands, Arms, Abdomen, Waist, and Legs
• With a Strong Heating Function
• Can Warm Up the Body Like Joints and Muscle Tension, Aches or Pains
• 360 Degree Massager Roller
• 2 to 5 Hours Power Life
• High and Firm Nodules, Portable and Rechargeable
• Help Reduce Pain and Soreness and Penetrate Deep into Muscles for an Eective Tension Massage
What's in the Box:
• Massage Ball
• Adapter
• PE Bag
Technical Specs:
• Construction Material: Silica Gel + ABS
• Diameter: 3.70" inches
• Intensity Speed: 4400 RPM (Motor)
• Battery: 1200mAh
• Output: DC 9V,1A
• Weight Capacity: 0.68 lbs.
• Product Dimensions (L x W x H): 3.70’’ x 3.70’’ x 3.78" -inches
www.SQUATZ.com
3
Safety Instructions
1. Please keep it in good condition for future use.
2. When using this product, please pay special attention and observe the following safety
instructions!
3. Before using, please read all the instructions carefully.
4. Do not immerse in water. Keep away from liquids or heat sources.
Keep ventilation ports free from dust and debris.
5. Do not remove screws or attempt to disassemble.
6. Do not operate continuously for more than one hour.
7. Unplug the charge from device battery after charging or prior to use.
8. For adult use only. Do not use if injured. Consult your doctor before using this product.
9. Never leave the Wireless Vibrating Massage Ball charging unattended.
PLEASE DO NOT USE THE VIBRATING MASSAGER WITHOUT FIRST OBTAINING APPROVAL
FROM YOUR DOCTOR IF ANY OF THE FOLLOWING APPLY:
Pregnancy, diabetes with complications such as neuropathy or retinal damage, tted with pacemakers,
recent surgery, epilepsy or migraines, herniated disks, spondylolisthesis, spondylolysis, or spondylosis,
recent joint replacements or IUD’s, metal pins or plates or any concerns about your physical health.
Frail individuals and children should be accompanied by an adult when using any vibration device.
These conditions do not mean that you are not able to use a vibration or exercise device but we
advise you to consult a doctor rst.
Ongoing research is being done to the eects of vibration exercise for specic medical disorders.
This will be likely result in the shortening of the list of contraindications as shown above.
Practical experience has shown that integration of vibration exercise into a treatment plan is
advisory in a number of cases. This must be done on the advice of and in accompaniment with a
doctor, specialist or physiotherapist.
www.SQUATZ.com
4
Charging Method
1. Connect the power adapter charging plug to the product charging port.
2. Plug the power adapter into a 100-240V, 50/60Hz power socket.
3. When charging starts, the red LED ashes from red to green during charging.
4. If the Massage Ball is continuously charged for 4 hours, the charging lights are still not green
(full state), unplug the power adapter and contact the maintenance person to avoid danger.
5. The vibration function cannot be used while charging.
6. After the charging is completed, the LED light continues to illuminate to green color indicate that
the battery is fully charged.
7. It takes about 2 hours to send it from empty to full charge.
8. When charging is complete, disconnect the AC adapter and charging plug.
OPERATION
Charging light
Green: High battery left
Yellow: Middle battery left
Red: low battery left
Charging port
Speed 1
Speed 2
Automatic mode
Speed 3
Power button
www.SQUATZ.com
5
OPERATION
The vibrating massage ball offers 1 automatic mode and 3 speed mode.
You can make a selection by pressing the function button.
• Press and hold Power button for 3 seconds is turned on; the automatic vibrating massage starts.
The vibration speed is speed 1, and an intensity indicator light is displayed.
• Press the button for the second time, the vibration speed is increased to the speed 2, and two
intensity indicators are displayed.
• Pressing the button for the third time, the vibration enters to automatic mode, the vibration speed
is automatically become weak to strong, and then from strong to weak, and the cycle is repeated,
displaying three intensity indicators.
• Pressing the button for the fourth time, the vibration speed becomes speed 3, showing four
intensity indicators.
• Shut down: Press the button for the fth time, the massager is turned o, the movement stops all
massage vibration function, enters to shutdown state, and the intensity indicator does not ash.
How to Maintain
Before cleaning the product, make sure the power switch is turned o and unplug the power cord.
• Wipe the Wireless Vibrating Massage Ball with a clean, soft cotton cloth.
• Do not use corrosive cleaning agents such as benzene to clean the Product.
• Do not wipe the switch control surface with a wet cloth to avoid machine malfunction.
Wipe it with a dry cloth.
• Do not dip the product into water or other liquids. If water is spilled on the product, it may cause
electric shock.
Storage Method
To keep the product clean and clean, keep the product away from high humidity.
• Store the equipment ideally in its original packaging and keep it in a clean, dry place.
• Do not place in direct sunlight or high temperatures.
• If not used for a long time. Cover with a dust cover and remove the power plug from the power
outlet.
Correct Handing
This symbol indicates that this product cannot be disposed of with household waste in any EU country.
In order to avoid any possible damage to the environment and human health, it should be recycled
to increase the reusability of the remaining available substances. Recycle used equipment, follow
the recycling process, or contact the original retailer. They can recycle products for environmental
safety.
