D-Pad
Select Buon
Sta Buon
ABXY Buons
K Buon
= Buon
Customizable Function Buon
RC Buon
Customizable Function Buon
Power Buon NAV BuonR2 Buon
Le Speaker
LED Power Indicator
Note: The specic functions and
denitions of the K buon, controller
buons and other features are subject
to updates in the AYASeing APP,
AYAWindow APP versions. For the latest
information, please refer to the AYASet-
ting APP, AYAWindow APP updates and
announcements.
R1 Buon L1 Buon
L2 Buon
LC Buon
Customizable Function Buon
Active Cooling Air Outlet
Right SpeakerType-C Po
Micro SD Card Slot
Vol Wheel
Microphone 3.5mm headphone jack
Active Cooling Air Intake
In the power-on state, press the power buon " " to put the KONKR Pocket ADVANCE into sleep mode.
In sleep mode, press the power buon " " to wake up the KONKR Pocket ADVANCE. If a security screen lock has
been set, you will need to draw the paern, enter the password, or PIN to unlock and access the system inteace. If
both security screen lock and ngerprint recognition are congured, you can simply touch the power buon to com-
plete ngerprint recognition, which will quickly wake up and enter the system inteace.
Note: Aer a power-o and resta, or aer a resta while the device is powered on, you will need to re-verify the
security screen lock before you can use ngerprint unlock to access the screen.
In the power-o state, press and hold the power buon " " for about 3 seconds and then release to power on
the KONKR Pocket ADVANCE.In the power-on state, press and hold the power buon " " for about 2 seconds to
bring up the menu. Select " " to shut down the KONKR Pocket ADVANCE, or select " " to resta the KONKR
Pocket ADVANCE.
Names and Contents of Hazardous Substances in the Product
This table is compiled according to SJ/T11364 regulations.
〇: Indicates that the content of the hazardous substance in all homogeneous materials of the
pa is below the limit requirement specied in GB/T26572.
X: Indicates that the content of the hazardous substance in at least one homogeneous material
of the pa exceeds the limit requirement specied in GB/T26572.
Note: This product applies an environmentally friendly design concept and eectively controls hazardous
substances. The "X" indicates that the hazardous substance is primarily due to the limitations of techno-
logical development, making substitution of the hazardous substance impossible.
Environmental Protection Use Period
The symbol indicates the period (ten years) during which the hazardous substances contained in electronic and
electrical products will not leak or undergo abrupt changes under normal use conditions. During this period, the
use of these electronic and electrical products will not cause severe pollution to the environment or cause
serious harm to the user’s health and propey.
Power Cables
Metal Pas
Plastic Pas
PCB Components
Pa Name
(Pb)
(Hg)
(Cd)
Hazardous Substance
(Cr(VI)) (PBB) (PBDE)
Power On / Power O / Resta
Volume Control
You can use the Vol Wheel control volume function. Alternatively, you can go to " " > " " to adjust the
media volume, notication volume, alarm volume, etc. accordingly.
Pull-down Menu
Storage Expansion
To access the pull-down menu, swipe down from the top of the screen for the rst time to quickly toggle seings
such as WLAN and Bluetooth. Swipe down again to display the full pull-down quick menu. You can adjust the screen
brightness by sliding the brightness slider, and peorm other quick seings congurations.
The KONKR Pocket ADVANCE is equipped with a Micro SD card expansion slot. Open the dust cover, it‘s allowing you
to install or replace the Micro SD card.
Cleaning
Please use a lint free cloth to clean KONKR Pocket ADVANCE. Do not let the opening of the body get damp. Do not
use aerosol sprays, solvents, or abrasives for cleaning.
Service and Suppo
When you submit a valid claim under the warranty service policy, AYANEO will, at its discretion, repair, replace, or
refund your KONKR Pocket ADVANCE. The warranty rights you have are in addition to the rights provided by local
consumer law. When you make a claim under this warranty policy, you may be required to provide detailed information
about your purchase receipt.
For more suppo and troubleshooting information, please visit www.ayaneo.com
Electromagnetic Inteerence (EMI)
The KONKR Pocket ADVANCE contains components with magnets and emits electromagnetic elds from radio
waves, which may inteere with medical devices, pacemakers, debrillators, or other medical equipment. Maintain a
safe distance between medical devices and the KONKR Pocket ADVANCE. Consult your physician and the medical
device manufacturer for information on your medical devices. If you suspect that the KONKR Pocket ADVANCE is
inteering with your pacemaker, debrillator, or other medical devices, stop using the KONKR Pocket ADVANCE.
Warranty
KONKR warrants the hardware products and accessories included with your purchase against defects in materials
and workmanship under normal use for one year from the date of original retail purchase. This warranty does not
cover normal wear and tear or damage caused by accidents or misuse. For service, visit the AYANEO store or an
authorized AYANEO service provider. Available service options may depend on the country or region where the ser-
vice is requested and may be limited to the country or region of original sale. There may be a charge for call and inter-
national shipping fees, depending on your location.
Baery and Charging
Please use the ceied adapter correctly for charging to ensure safety compliance. Do not use adapters without
safety ceication as they may damage internal components and pose unpredictable risks.
When plugging in a USB Type-C cable to a power source, avoid prolonged skin contact with the plug to prevent
discomfo or injury.Do not aempt to replace the KONKR Pocket ADVANCE baery on your own, as this may damage
the baery, leading to overheating which could cause res and personal injury.
The lithium-ion baery of the KONKR Pocket ADVANCE should be serviced or recycled by AYANEO or authorized
service providers. Self replacement of baeries may pose a risk of explosion.
Please follow local environmental regulations for baery disposal. The baery should only be replaced by AYANEO or
an authorized AYANEO service provider. Using incorrect baery models for replacement poses a risk of explosion.
Internet / Bluetooth
The AYANEO Pocket AIR Mini suppos WLAN networks. To connect to a WLAN network, go to " " > "Network and
Internet" > "Internet". Select the network you want to connect to, enter the connection password in the "Security" box,
then click "Connect".
Text Input
When you need to enter text, tap the input box to bring up the touch keyboard. Use touch input to enter text.
Sleep Mode
Bluetooth: To connect to a Bluetooth device, go to " " > " " > " ".
Search for the Bluetooth device you want to connect to in the list and click on it.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party.
Responsible for compliance could void the user’s authority to operate this
equipment. (Example- use only shielded interface cables when connecting to computer
or peripheral devices).
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
Specific Absorption Rate (SAR) information: This device meets the government's
requirements for exposure to radio waves. The guidelines are based on standards that
were developed by in dependent scientific organizations through periodic and
thorough evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons regardless of age or health.
FCC RF Exposure Information and Statement the SAR limit of USA (FCC) is 1.6 W/kg
averaged over one gram of tissue. Device types: device has also been tested against this
SAR limit. This device was tested for typical body-worn operations with the back of the
Portable Gaming Computer kept 0mm from the body. To maintain compliance with
FCC RF exposure requirements, use accessories that maintain an 0mm separation
distance between the user's body and the back of the Portable Gaming Computer.
The use of belt clips, holsters and similar accessories should not contain metallic
components in its assembly. The use of accessories that do not satisfy these
requirements may not comply with FCC RF Exposure requirements, and should be
avoided.
