Product Specification
Product Type: Commercial LCD Display
Product Model: M43MAQ
Version: V1.0
Technical Specifications
1. Product Features
• Equal-width bezels on all four sides
• 2 downward-facing USB ports
• Display mode: Landscape and Portrait (clockwise), forward tilt ≤15° mounting supported
• Built-in speakers
• IPS panel
• PWM dimming
• 2K FHD display
• IR remote control
• Standard cloud playback and local playback
• Wi-Fi and RJ45 networking
2. Display Parameters
Size
42.5 inches
Screen Type
IPS
Response Time
8ms
Aspect Ratio
16:9
Max. Display Size
940.896(H)×529.254(V)mm
Resolution
1920(H)×1080(V)
Pixel Pitch
0.490mm×0.490mm
Refresh Rate
60Hz
Color Depth
16.7M(8bit)
Color Gamut (Typ)
72% NTSC
Contrast (Typ)
1200:1
Viewing Angle
178°/178°(H/V)
Backlight Type
DLED
Brightness (Typ)
1000/900 cd/
㎡
(panel brightness / after white balance
adjustment)
Lifespan
≥30,000 hours
3.Operating System
OS Version
Android 9.0
RAM
1G
ROM
16G
CPU
Quad-Core A53
GPU
Mali-450MP2
4.Speakers
Channels
2.0
Power
2×2W
5.Electrical Parameters
Power Input
100-240V~50/60Hz 1.5A
Max. Power Consumption
125W
Standby Power Consumption
≤0.5W
6.I/O Interfaces
HDMI IN
1
Supports 1920×1080@60Hz
USB 2.0
2
System upgrade / data transfer
AUDIO OUT
1
3.5mm headphone jack
RJ45 IN
1
10/100Mbps
7.Size / Weight
Overall Dimensions
(L×W×T)
960.7×550×57.8mm
Package Dimensions
(L×W×H)
1059×137×652.5mm
VESA Hole Pattern (L×W)
400×200mm
Wall-Mount Screw Spec
M6
Net Weight
9.4kg
Gross Weight
11.9kg
8.Accessories
Power Cord
×1
Remote Control
×1
AAA Battery
×2
9. Environmental Factors
Working Temperature
0℃~40℃
Working Humidity
10%~80%RH
Storage Temperature
-10℃~55℃
Storage Humidity
10%~80%RH
10.Dimensions
11.Disclaimer
The actual dimensions and weight of the device may vary due to product configuration and
manufacturing process; please refer to the actual product.
The product images in this Specification are for illustration purposes only. The appearance of
the actual product (including but not limited to look, color, and size) may differ slightly;
please refer to the actual product.
In order to provide as accurate specification parameters as possible, the text descriptions and
image effects in this Specification may be adjusted and revised in real time to match the
actual product performance and specifications.
Shanghai Goodview Electronic Technology Co., Ltd. | Sales Hotline: 400-138-8858
Address: No. 458 Jinwan Road, Pudong New District, Shanghai | www.goodview.com
If it becomes necessary to make the above modifications and adjustments, no special notice
will be given.
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
*RF warning for Mobile device:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
