USER MANUAL
NEXT GEN
TRUE WIRELESS
EARBUDS
@Groovzaudio
@Groovzaudio
Thank you for your purchase! We hope you
enjoy your new Groovz Headphones.
If you have any questions or concerns,
please reach out: support@groovzaudio.com
PLUS
FCC Information
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that
may cause undesired operation. Changes or modifications to this
unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment. NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help. This device and its antenna(s) must not be co-located or
operation in conjunction with any other antenna or transmitter.
Radiation Exposure Statement The device has been evaluated to
meet general RF exposure requirement. in portable exposure
condition without restriction.
Warning:
This equipment complies with FCC RF radiation exposure limits
set forth for an uncontrolled environment. This device and its
antenna(s) must not be co-located or conjunction with any other
antenna or transmitter.
TABLE OF CONTENTS
DEVICE DIAGRAM 01
SPECIFICATIONS 02
PACKAGE CONTENTS 02
SETTING UP YOUR
HEADPHONES 03
HOW TO OPERATE 11
CLEANING YOUR
EARBUDS 12
TROUBLESHOOTING 13
PRECAUTIONS FOR USE 15
WARRANTY
INFORMATION 17
NEED HELP? 18
• Fitting 03
• Powering On/Off 04
• Bluetooth Pairing 06
• Understanding Power
Display 07
• Charging Your
Headphones 08
• Wireless Charging 09
SPECIFICATIONS
Model: GROOVZ (PLUS)
Bluetooth: v5.4
Bluetooth Range: 30 feet
Earbud Battery: 35mAh
Charging Case Battery: 600mAh
Battery Life Indicator
1
Type-C Charging Port
2
Status Button
4
Magnetic Charge Pins
7
Touch
8
Status Light
9
Microphone
6
Ear Tip
3
Charging Thimble
5
1
3
5
2
4
8
9
6
7
BOX CONTENTS
Bluetooth Headsets
Headphone Charging Case
Type-C Charging Cable
User Guide
Set of Interchangeable
Earbud Tips
1
2
TECHNICAL SPECS
01. FITTING
Groovz Earbuds come with three sizes of ear tips:
small, medium, and large. We recommend trying
each size to find the most comfortable and secure
fit. Your earbuds should feel snug in your ears
without causing discomfort and should stay in place
during everyday movement. A proper fit also helps to
deliver the best sound quality and noise isolation.
02. POWERING ON/OFF
POWERING ON
(AUTO MODE)
POWERING ON
(MANUAL)
M SL
3
4
• Open top cover of
charging case.
• Remove earbuds
from case.
• The earbuds will
automatically enter
pairing mode.
• With earbuds already
removed from charging
case, press & hold both
left and right earbud
touch control locations
for 5 seconds.
SETTING UP YOUR HEADPHONES
5
POWERING OFF
• Remove earbuds
from ears.
• Place left and
right earbuds into
charging case.
• Close charging
case and this will
automatically power
down the earbuds.
• Remove earbuds from
charging case.
• Turn ON Bluetooth
from device.
• Find bluetooth name
“Groovz” in list of pairing
options on device.
• Click to connect, and
Groovz earbuds will announce
successful connection.
6
03.BLUETOOTH PAIRING
NOTE: Previously paired devices
will connect within 2-4 seconds.
7
• Your Groovz charging case
features LED indicators that
show the battery level of the
case and your earbuds.
• When you place the
earbuds in the case, the LED
lights will flash to indicate they
are charging.
• A full battery is shown when
all LED lights are solid. If the
lights are blinking, your case
or earbuds are still charging.
• To charge the case, connect
the included USB-C cable to a
power source. The LEDs will
light up to show charging
progress.
• When the earbuds are
placed inside the charging
case, they will begin charging
automatically.
• For the best performance,
keep your earbuds and case
fully charged before use.
8
05. CHARGING YOUR HEADPHONE04. UNDERSTANDING
POWER DISPLAY
100 100
100
9
10
• Make sure your Groovz
earbuds and charging case
support Qi wireless charging.
For best results, use a
Qi-certified pad—like the
Groovz Wireless Charging
Pad,designed to pair
perfectly with your device.
• Plug the charging pad into
a power source and place it
on a flat, stable surface.
• Put the earbuds in the
case, close the lid, and
center the case on the pad.
Align it properly for charging
to begin.
06. HOW TO USE QI
WIRELESS CHARGING
• Confirm Charging: Look for the LED on the
case—it should light up or blink. Some pads may
also have an indicator light.
• Let the earbuds charge fully. Charging time
varies by pad and battery level. Refer to the pad
manufacturer’s guidelines if needed.
• Once charged, remove the case from the pad.
Your earbuds are ready to use.
SAFETY TIPS
• Don’t place metal objects between the
pad and case.
• Avoid charging in extreme heat, cold,
or humidity.
• If issues arise, check the troubleshoot-
ing section or contact support.
11
• Gently pull off the ear tips
from each earbud.
• Rinse the ear tips with water
only—do not use soap or
household cleaners.
• Wipe the ear tips with a soft,
dry, lint-free cloth.
• Allow the ear tips to dry
completely before reattaching
them to your earbuds.
CLEANING YOUR GROOVZ EARBUDS
12
Single Tap
Double Tap
Left
Double Tap
Right
Triple Tap
Left
Triple Tap
Right
Play/Pause
Previous
Track
Next
Track
Volume +
Volume -
PLAYING STATE
CALL STATE
Double
Tap
Long
Press
Answer/
End a
Phone Call
Reject a
Phone Call
Activate
Voice
Assistant
Tap &
Hold
Right
for 1.5
Seconds
IN SIRI
HOW TO OPERATE
• Ensure Bluetooth Is On: Confirm
Bluetooth is enabled on your
smartphone, tablet,or computer.
• Check Earbud Battery: Place the
earbuds in the case and check the
LED indicators to ensure they
are charged.
• Charge the Case: Connect the
charging case to power if the battery
is low.
• Restart Your Devices: Restart
your device (phone, tablet, etc.) and
the earbuds.
• Forget the Device: Remove the earbuds from your
device’s Bluetooth list (this is often called “forget” or
“unpair”).
• Restart Bluetooth: Turn Bluetooth off and back on
again on your device.
• Re-Pair the Earbuds: Place the earbuds in pairing
mode and attempt to pair again.
HAVING TROUBLE PAIRING
YOUR GROOVZ EARBUDS?
RE-PAIRING STEPS:
• Charging Case Reset: Place the
earbuds in the charging case, then
press and hold the button on the case
until the LED indicator flashes red,
then white. This signals that your
earbuds have been reset and are
ready to pair again.
RESETTING:
13
14
ON
TROUBLESHOOTING
• Store headphones in a cool dry,
ventilated environment.
• Avoid contact with oil, watervapor,
and steam.
• Avoid cleaning with irritating, organic
solvents or materials containing these
ingredients.
• Use the headphones according to the
provided specifications, and avoid
exposing to environments that could affect
performance like moisture, dust, or
extreme heat.
15
16
• To ensure smooth connection, it is recommended
that the distance between the mobile phone and the
headphones be within 10 meters.
• If the headphones fail to connect or communicate
properly, do not dismantle the headphones without
permission. The device and its accessories are not
guaranteed otherwise.
• To charge the headphones, please use the
standard Type-C charging cable or the one specified
by our company.
• Keep the headphones sufficiently charged to
ensure normal operation.
PRECAUTIONS FOR USE
Groovz headphones come with a 1-Year Limited
Warranty from the date of purchase. The
warranty covers defects in materials and
workmanship. It does not cover accidental
damage, misuse, or unauthorized repairs.
Should your product become defective during
the warranty period, we will repair or replace (at
our option) your product.
17
WARRANTY INFORMATION
18
NEED HELP?
GROOVZ is a registered trademark of
JTB Products LLC, West Chester,PA.
Designed and Engineered in the USA.
To register your warranty or
report any defects, please
contact customer support at
SCAN THIS CODE WITH
YOUR PHONE FOR
• Step-by-step tutorial videos
• Frequently asked questions
• 7-day-a-week support
www.groovzaudio.com
West Chester, PA
