Item No. : 2140
LED Worklight 900
User’s Manual
We are constantly improving our products so specifications are subject to change without notice.
LED Worklight 900 by Wagan Tech
®
1
www.wagan.com
Thank you for purchasing the LED Worklight 900 by Wagan Tech
®
. With normal
care and proper treatment, it will provide years of reliable service. Please read
all operating instructions carefully before use.
100% 50% SOS FLASH OFF
DC
LED
90°
Adjustable
Magnet at
the Bottom
USB
Output
Switch
Charging
Port
©2020 Wagan Corporation. All Rights Reserved.
Wagan Tech and wagan.com are trademarks of Wagan Corporation.
User’s Manual—Read before using this equipment
2
FEATURES
• Durable die-cast aluminum head for perfect heat dissipation.
• ABS housing with rubber coated surface.
• USB power for emergency phone charging.
• Strong N40 magnets on base.
SPECIFICATIONS
Product Name LED Worklight 900
LED Power 15W
Max Output 900 Lumen
LED Color Temperature 6000-6500K
LED Life 50000 Hours
Beam Angle 90°
Runtime
100%: about 4–5 Hours
50%: about 7–8 Hours
Battery 7.4V 4400mAh Li-ion
USB Output 5V, 1A
Material ABS, PC, aluminum alloy
LED Worklight 900 by Wagan Tech
®
3
www.wagan.com
CHARGING INSTRUCTIONS
Please charge before initial use. In order to prolong the life of the battery, be sure
to fully recharge the unit every 3 to 6 months, even if the unit has not been used.
1. AC charger: Input 110–240V, 50/60Hz 0.5A, Output 9V/1.2A
2. Car charger: Input DC 12–24V, Output 9V/1–1.5A
3. Charge time: 4–5 hours (full charge)
4. To charge, lift the protective cover at the rear of the lamp base and insert
the charging plug into the charging socket.
5. Charging is complete when all the battery status indicator lights illuminate
solid (about 5 hours).
Do not throw away or dispose of your battery with household waste. Please
recycle all batteries, in line with local environmental requirements. No user
serviceable parts.
OPERATION
Press the switch to change modes
1. Press One – Battery Indicator on
2. Press Two – Lamp ON (100% brightness)
3. Press Three - Lamp ON (50% brightness)
4. Press Four – SOS
5. Press Five – Flashing
6. Press Six – OFF
©2020 Wagan Corporation. All Rights Reserved.
Wagan Tech and wagan.com are trademarks of Wagan Corporation.
User’s Manual—Read before using this equipment
4
BATTERY CHARGE INDICATOR DURING USE
The battery indicator shows:
• All 4 LEDs ON: Battery Charge > 75%
• Red, Amber & Green LEDs ON: Battery Charge 50–74%
• Red & Amber LEDs ON: Battery Charge 25–49%
• Red LED ON: Battery Charge 5–24%
• RED FLASHING: Battery Charge < 5%
MAGNETS
The worklight has four N40 magnets on the base which will attach to steel
surfaces. Ensure both the surfaces of the lamp and vehicle are clean to prevent
marking and ensure maximum adhesion.
Do not mount on moving vehicle.
CAUTION
• Never point the light beam directly into the eyes of another person
or animal.
• This product is not a toy: Do not allow children to play with this item.
• Do not store in direct sunlight or near a heat source.
• Use for intended purposes only.
• Do not submerge in water.
• This product contains strong magnets that may cause interference with
pacemakers and other implanted medical devices when placed within a
close proximity. Keep this product at least 6 inches from your chest if you
have a pacemaker.
The WAGAN Corporation warranty is limited to products sold only in
the United States.
Warranty Duration:
Product is warranted to the original purchaser for a period of one (1) year from
the original purchase date, to be free of defects in material and workmanship.
WAGAN Corporation disclaims any liability for consequential damages. In no event
will WAGAN Corporation be responsible for any amount of damages beyond the
amount paid for the product at retail.
Warranty Performance:
During the warranty period, a product with a defect will be replaced with a
comparable model when the product is returned to WAGAN Corporation with an
original store receipt. WAGAN Corporation will, at its discretion, replace or repair
the defective part. The replacement product will be warranted for the balance of the
original warranty period. This warranty does not extend to any units which have
been used in violation of written instructions furnished.
Warranty Disclaimers:
This warranty is in lieu of all warranties expressed or implied and no representative
or person is authorized to assume any other liability in connection with the sale of our
products. There shall be no claims for defects or failure of performance or product
failure under any theory of tort, contract or commercial law including,but not limited
to negligence, gross negligence, strict liability, breach of warranty, and breach of
contract.
Returns:
WAGAN Corporation is not responsible for any item(s) returned without an official
Return Authorization number (RA#). Please contact our customer service team by
phone or email to obtain an RA#. You can also visit our website and chat with our team
during our normal business hours. For more details and instructions on how to process
a warranty claim, please read the “Returns” section under the “Contact” page on our
website. WAGAN Corporation is not responsible for any shipping charges incurred in
returning the item(s) back to the company for repair or replacement.
