EN
TUMBLE DRYER
Dryer
MODEL:
MD205H80WBC/W-UK
THANK YOU LETTER
CONTENTS
01
THANK YOU LETTER
SAFETY INSTRUCTIONS
SPECIFICATIONS
PRODUCT OVERVIEW
QUICK START GUIDE
PRODUCT INSTALLATION
OPERATION INSTRUCTIONS
APP SETUP AND OPERATION
CLEANING AND MAINTENANCE
TROUBLE SHOOTING
PRODUCT INFORMATION SHEET
TRADEMARKS, COPYRIGHTS AND LEGAL STATEMENT
DISPOSAL AND RECYCLING
DATA PROTECTION NOTICE
WARRANTY CARD
01
02
10
11
12
14
19
30
32
34
36
37
38
39
40
Read all instructions and explanations before use. Follow the instructions
carefully. Keep the operation instructions handy for later use. if the
appliance is sold or passed on then ensure that the new owner always
receives these operation instructions.
02
Intended Use
SAFETY INSTRUCTIONS
• This appliance is intended to be used in domestic household and similar
household installation environments.
• This appliance is intended to dry textiles in household amounts suitable for
domestic appliances, which have been washed with water and which are
marked on the manufacturer's care label as being suitable for tumble
drying.
• This appliance is intended for indoor usage only, not intended for outdoor,
built in or commercial usage or shared use, i.e. by several families in an
apartment building.
• Persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved.
NOTE
All other types of usage are not permitted. Manufacturer is not liable for
damage caused by improper usage or incorrect operation.
Safety with children
•
continuously supervised.
• Children should be supervised that they do not play with the appliance.
• Children from the age of 8 can use the appliance safely after they
have been given appropriate supervision or instruction concerning
use of appliance.
• Cleaning and maintenance shall not be made by children without
supervision.
• Children as well as pets may climb onto or into the appliance. Always
close the door after use.
• Children may hide things in the appliance. Check the appliance
before every operation.
• Surfaces of appliance may become very hot during operation. Keep
children and pets far away from the appliance while it is operating.
Children under 3 years shall be kept away from the appliance or
Please read the user manual carefully before using the appliance. It
provides important information on safety, installation, operation and
maintenance. This will protect you and prevent damage to the
appliance. An improper usage can cause personal injuries and damage
to properties. Failing to follow these instructions shall void any
warranty.
Keep the user manual for future reference. If the appliance is sold or
passed on, make sure that the new owner always receives these safety
instructions.
03
DANGER
WARNING OF ELECTRICAL VOLTAGE
WARNING
CAUTION
NOTE
OBSERVE INSTRUCTIONS
Refrigerant Safety
openings clear of obstruction.
• Do not damage the refrigerant circuit.
• In the appliance enclosure or in the built-in structure, keep ventilation
WARNING
Explanation of Symbols
This symbol indicates that a service technician should only operate
and maintain this appliance in accordance with the operating
instructions.
The signal word indicates important information (e.g. damage to
property), but not danger.
The signal word indicates a hazard with a low degree of risk which,
if not avoided, may result in minor or moderate injury.
The signal word indicates a hazard with a medium level of risk
which, if not avoided, may result in death or serious injury.
This symbol indicates that there is a danger to life and health of
persons due to voltage.
This symbol indicates that there are dangers to the life and health of
persons due to extremely flammable gas.
The appliance contains an environmentally friendly but flammable R290
refrigerant. Keep away from open flame and other sources of ignition.
04
This warning only covers products which contain a UV-C lamp and which
have a germs reduction function with UV-C lamp. Always read the product
guide before using the device and use the product according to the
instructions!
UV Radiation Safety
• The device contains a lamp that emits UV-C rays. Do not look at the source
of light while the lamp is operating!
• UV-C Lamp is used to provide germs reduction in textile products.
• Do not take the UV-C Lamp out of the product and do not operate it
outside!
• Do not touch the lamp!
• Use of the product except for its purpose or damage to the UV-C lamp
protection glass or surrounding may cause dangerous UV-C radiation to
occur. UV-C radiation can damage the eyes and skin even in low doses. Do
not operate any product which is damaged!
• Do not remove the UV-C lamp protection glass. Do not operate the product
without the UV-C lamp protection glass!
• After the appliance stops due to various reasons (power outage, fuse
problem, machine door opening, etc.) while UV Hygiene programs are in
progress, the program will resume to germs reduction from where it left.
• In cases where UV-C lamp and related parts need to be replaced (expiration
of lamp life, break of lamp glass, etc.), call the customer service. Do not try
to replace the parts by yourself. When waiting for customer service, make
sure the machine is closed and the plug is disconnected!
• Keep children away while using any programs with activated UV-C Lamp!
• Hygiene program incorporating UV is effective for removing Escherichia
coli, Staphylococcus aureus bacteria.
• This product contains light sources that emits light stream. Do not look at
light source of light while the light source is operating. These light sources
are available as a spare part and must only be replaced by trained specialist
staff.
Risk of fire and explosion due to damage to the tumble dryer.
Refrigerant R290 (propane) is a flammable and explosive gas if it leaks in the
event of damage.
Take measures to protect the tumble dryer against damage. Do not make any
alterations to the tumble dryer.
0505
Installation Location and Surrounding
•
not accumulate. Air must be able to circulate freely around the appliance.
Do not obstruct the front air inlet or the air intake grilles at the back of the
appliance.
• Do not install the appliance on a carpet floor. Because an obstruction of the
openings by a carpet can damage the appliance.
• Keep the appliance clear from heating sources and direct sunlight to avoid
plastic and rubber parts to corrode.
• Do not operate the appliance in rooms with a temperature of below 2°C.
This can cause damages by frost to components, like hoses, which may
burst orsplit. If it is unavoidable, make sure to pour out the condensate
water completely after every use. (see “Cleaning and Maintenance”)
• Do not use the appliance in humid and drenching environments or rooms
containing explosive or caustic gas.
• Never use flammable sprays or substances in the immediate proximity of
the appliance.
• The appliance must not be installed behind a lockable door, a sliding door
or a door with a hinge on the opposite side to that of the appliance, in such
a way that a full opening of door is restricted.
• Do not stack this dryer on washing machine without stacking kits. If you
want to stack this dryer on a washing machine, please purchase the
independent parts. Installation shall be done by the manufacturer, its
service agent or similarly qualified persons to avoid any hazards.
• Must not be installed in a non-stationary location like on a ship.
• Keep the area around the tumble dryer clean. Coal dust or flour may cause
an explosion.
• Do not restrict the floor clearance through deep pile carpets, strips of wood
or similar. This might cause heat built-up which would interfere with the
operation of the appliance. Risk of Fire!
The appliance must be installed in a clean place, where dirt, dust or fluffs do
WARNING
Installation
• Pay attention to the chapter “Product Installation”.
• Remove all packaging material before operating the appliance. Otherwise,
serious damage may result.
• Before setting up the appliance, check it for any externally visible damage.
Do not install or use a damaged appliance.
• Do not disassemble or install the dryer without any instruction or
supervision.
• Lint must not to be allowed to accumulate around the tumble dryer.
• After installation, leave the appliance to stand for 2 hours.
• Before drying laundry for the first time, the appliance shall be operated
once a machine cleaning program. (see “Operation Instructions”)
•
Electrical Connection
• The appliance corresponds to protection class I and may only be
connected to mains plug with a protective conductor protected by a fuse
complying with the data in the “Technical specifications” table or by the
rating plate (fuse rating, voltage and frequency).
• If needed, the grounding installation has to be made by a qualified
electrician. Ensure that the appliance is installed in accordance with the
local regulations.
• Don´t use multiple plugs, extension cords or similar. Risk of overheating!
• The electrical socket must be easily accessible after installation so that the
appliance can be disconnected from the electricity supply if needed.
• Always pull at the plug, not at the cable.
• Do not bend, clamp or damage the power cord and the power plug.
• Make sure the power cord is not trapped by the appliance, or it can get
damaged.
• Always unplug the appliance if it is not being used.
• Do not pull the plug out of the mains outlet if there is flammable gas
around. Risk of explosion!
• If the appliance appears high temperature abnormally, please unplug the
mains plug immediately. Call the Customer Service!
06
Electric shock hazard
WARNING：
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
• The appliance must not be supplied through an external switching device,
such as a timer, or connected to a circuit that is regularly switched on and
off by a utility.
• If the appliance is damaged, it must not be operated unless repaired by the
manufacturer, its service agent or similarly qualified persons. Never try to
repair an appliance which is defective or presumed to defective.
• Never pour water over the appliance for cleaning purpose.
• Do not make any technical alterations to the appliance.
• Do not climb or sit on the appliance.
• Never pull out power plug with wet hands.
Operation
• Pay attention to the maximum load quantity of this appliance and the
reduced load quantity of the single programs. The load quantity is
expressed in kilogram dry laundry. (see “ ”)
• Do not dry unwashed and uncleaned items in the tumble dryer.
• Do not dry laundry before being spun in a washing machine or spin
extractor.
• Items that have been soiled with substances such as vegetables or cooking
oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, hair care
products, nail vanish remover, wax and wax removers should be washed
manual in hot water with an extra amount of detergent before being dried
in the appliance. Risk of Fire! Risk of Explosion!
• Fabric softener or similar products should be used as recommended in the
instructions by manufacture. Risk of Fire!
• Oil-affected items can ignite spontaneously, especially when exposed to
heat sources such as in a tumble dryer. The items become warm, causing
an oxidation reaction in the oil. Oxidation creates heat. If the heat cannot
escape, the items can become hot enough to catch fire. Piling, stacking or
storing oil-affected items can prevent heat from escaping and so create a
fire hazard.
Program Description
• Make sure that all pockets are emptied. Sharp and rigid items such as
coins, brooches, nails, screws, stones etc. may cause serious damages to
appliance components, which can therefore cause damage to the laundry.
• Take care to remove lighters and matches before drying the laundry.
07
• Items containing foam rubber (latex foam), shower caps, water proof
textiles, rubber backed articles and clothes or pillows fitted with foam
rubber pads should not be dried in the appliance. Risk of Fire!
• Do not dry any textiles that contain padding or fillings that are damaged
(e.g. pillows, jackets). The filling may fall out and cause a fire hazard. Risk
of Fire!
• Please do not close the door with excessive force. If it is found difficult to
close the door, please check if the laundry is properly inserted and
distributed.
• Do not operate the dryer without the door lint filter and without the water
container.
• Take care when opening the door after using the steam function. Take a
step back and wait until the steam has evaporated. Risk of scalding!
• Do not lean on the opened door of the appliances.
• Condensed water is not drinking water. It can cause health problems in
both people and animals if consumed.
• Never stop a tumble dryer before the end of the drying program unless all
items are quickly removed and spread out so that the heat is dissipated.
WARNING
Maintenance
• Pay attention to the chapter “Cleaning and Maintenance”.
Always unplug the appliance before cleaning and maintenance and after
each use.
• The lint filters have to be cleaned and the water container have to emptied
after each drying program.
• Clean the appliance with a damp rag moistened with clean water and do
not spray it directly with water.
• Never use any industrial chemicals as cleaning solvents, which are
flammable, explosive or toxic. Do not use gasoline and alcohol for cleaning
the appliance. Only select cleaning solvents, that are suitable for machine
cleaning. Risk of fire and explosion!
• Do not use solvents, abrasive cleaners, glass cleaners or all-purpose
cleaners. These could damage plastic surfaces and other parts.
• The tumble dryer is not to be used if industrial chemicals have been used
for cleaning. Risk of fire and explosion!
• Fill steam generators only with liquids specified by the manufacturer.
(Suitable for the dryer with steam function)
• Do not touch the heat exchanger with your hand, which may cause an
injury. Please wear gloves when cleaning. (Suitable for the dryer with
access to the heat exchanger)
08
09
• The appliance should not be overturned during normal use or maintenance.
• Repairs shall only be carried out by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard. Manufacturer will not
be responsible for damages caused by the intervention of not authorized
persons. Failing to follow these instructions shall void any warranty.
CAUTION
Before transporting the appliance prepare it to following instructions:
• Disconnect the appliance from the power supply and pull the mains plug
out of the socket.
• Remove the external drain hose from the house installations (see “Product
Installation”)
• Empty the water container of the appliance. (see “Cleaning and
Maintenance”)
• Check if the door and the water container are closed properly.
• This appliance is heavy. Never transport or carry the appliance alone,
always with the assistance of another person.
• Never hold any protruding part of the machine when lifting. The machine
door cannot be used as a handle.
• Transport with care. If the dryer can't be transported erectly, the dryer can
be tilted to right less than 30°.
• Remove all obstacles on the transport route and from the installation
location, e.g. open doors and clear away objects lying on the floor.
• Before reinstallation of appliances check it for any externally visible
damage.
• After transportation, leave the appliance to stand for 2 hours.
• Incorrect transportation can cause personal injuries and damage to
properties. Ensure that the appliance is properly secured during
transportation.
Transport
CAUTION
• When lifting the machine, there is a risk of cuts in the lower area.
Protective gloves must be worn.
CAUTION
CO e
2
SPECIFICATIONS
MD205H80WBC/W-UK
220-240V~,50Hz
Model
A
B
E
F
D
G
C
Weight
Power Supply
Rated input power
750W
Refrigerant
R290
Rated capacity
8.0kg
46kg
3
0.00t
110g
+ 2°C ~ +35°C
595mm
850mm
GWP
Ambient temperature
Dimension
A
B
C
D
G
Quantity of refrigerant
E
F
520mm
600mm
550mm
1080mm
120mm
• The rated capacity is the maximum load quantity in kg dry weight that can
be dried at one time. Make sure that the laundry loaded into the appliance
does not exceed the rated capacity.
NOTE
10
MD205H80WBC/W-UK
8.0kg dry load
Model
Rated capacity
PRODUCT OVERVIEW
4
3
2
1
1
2
3
4
5
Accessories
11
• The following parts are optional for specific models.
• install as per the
instruction below .
If your dryer has following parts, please wear gloves to them
Hose holder
Condensing drain hose
Connector
Water container
Control panel
Door
Maintenance cover
Power cord
• The illustration above is for reference only. Please take the appearance of the
actual product as reference.
NOTE
5
12
QUICK START GUIDE
CAUTION
1. Before drying
2. Drying
• Before operation, please make sure the machine is installed properly. See chapter
"Product Installation".
1. Insert the mains plug 2. Load the laundry
1. Power on
2. Select program
3. Select options or remain
default settings
• The illustration above is for reference only. Please take the appearance of
the actual product as reference.
NOTE
4.
start the program
Press Start/Pause to
3. Close the door
13
3. After Drying
3. Pour out condensation water
1.
take out laundry
Open the door and
A acoustic signal is given and “End” will be displayed.
5. Unplug the mains plug
• If the socket with a switch is used, please press the switch to turn off the power
directly.
NOTE
2.
container
Pull out the water
4. Clean the lint filter
14
PRODUCT INSTALLATIONPRODUCT INSTALLATION
Installation Area
• Do not install the tumble dryer in a room when there is a risk of frost occurring. At
temperatures around freezing point the tumble dryer may not be able to operate
properly.
Before installing the machine, the location characterized as follows shall be
selected:
1. Rigid, dry, firm and level surface.
2.Avoid direct sunlight.
3.Sufficient ventilation.
4.Room temperature is above 2 °C .
5.Keep far away from the heat sources such as coal or gas burning appliances.
6.Place the product with its back surface to the wall (for heater models).
It is recommended that, for your convenience, the machine is positioned close to your
washing machine.
To keep vibration and noise within minimum level when the dryer is in use, it must be
placed on a firm and level surface.
WARNING
NOTE
Unpacking the Tumble Dryer
1. Remove the cardboard box and styrofoam packing.
2. Lift the appliance and remove the base packaging.
3. Remove the tape securing of the power supply cord.
15
Level Adjusting
Once in its permanent operating position, check that the dryer is absolutely level with
the aid of a spirit level. If it is not, adjust the feet by hand or using a tool.
• The feet must never be removed.
NOTE
• Packaging material (e.g. foils, styrofoam) can be dangerous for children.
• There is a risk of suffocation ! Keep all packaging well away from children.
• Children can become entangled in the packaging film or swallow small parts and
suffocate. Do not allow children to play with the packaging.
Disposal of packaging material
The packaging is designed to protect the appliance from damage during
transportation. The packaging materials are environmentally friendly and
should be recycled. Recycling the packaging can reduce the use of raw
materials in the manufacturing process and the amount of waste in landfill
sites.
•
WARNING
16
x
Install external drain hose
1. Pull out the upper drain hose
2.
floor drain
Put the external drain hose into the
3.
basin or any other sink.
Put the hose holder in the washing
Drain hose
Overflow hose
X
Drain hose
Max.80cm
20
0cm
•
• Position drain hose properly.
Do not kink, crush or protract the drain hose.
WARNING
17
Left and Right Door Repair Guidelines
Door hinge
Screws
1
• Use an M 8mm socket to remove the two hexagonal
bolts on one side of the door hinge. Due to the adhesive
inside the screws, some force may be required to
unscrew them.
• After removing the bolts, because the door assembly
is relatively heavy, it requires a partner to assist in lifting
the entire door assembly slightly upwards and removing
it from the metal front door panel. Be careful to avoid the
glass being hit and broken.
• In order to protect the appearance, first use a cotton
cloth to pad the flat side of the door during installation.
Use a PH2 screwdriver to remove the three black screws
on one side of the door latch.
3
Door catch
bracket
Screws
• Use a PH2 screwdriver to remove the 6 black screws
on one side of the hinge, and pay attention to the
distribution of the screws. There are 4 black screws on
the front side, and 2 black screws on the side where the
door is opened.
4
Screws
Swap the installation positions of the door hook and
the door hinge. Use a PH2 screwdriver to install the
three screws on one side of the door latch. Use a PH2
screwdriver to install the 6 screws on one side of the
hinge. Pay attention that there are 4 screws on the front
side and 2 screws on the side where the door opens.
Torque is 1.5N.m.
•
5
Door hinge
bracket
Door catch
bracket
Door hinge
bracket
Door catch
bracket
6
After replacement, it will look like the above picture.
•
2
Door trim panel
Screws
7
• Use a PH2 screwdriver to remove the two black
screws on the front door trim panel.
8
• One partner assists in lifting the door assembly and
hangs it on the metal front door panel from the left side.
The partner needs to keep holding the door assembly.
Use an M8mm socket to install the two hexagonal bolts
on one side of the door hinge (Torque is 2.5N.m). Use a
PH2 screwdriver to install the decorative panel on the
other side (right side) and install two black screws (Torque
is 1.5N.m) . By following the above steps, the conversion
from left-opening to right-opening door is achieved.
•
normally, whether there is an abnormal opening and closing sound, if there is an
anomaly, contact the after-sales service.
After the replacement is completed, check whether the machine is running
18
NOTE
OPERATION INSTRUCTIONS
Before Each Drying
19
• Leave it to stand for 2 hours after transporting. Before first use, please use the soft
fabric to clean the inside drum.
1. Put some clean rags into the drum.
2. Insert the mains plug, press [On/Off].
3. Select the [Time Dry] Program, press [Start/Pause] button.
4. After finishing this program, please follow the “Cleaning and Maintenance ” to
clean the door lint filter.
• During drying, the compressor and the water will generate some noise which is
entirely normal.
NOTE
1.Before drying, thoroughly spin the laundry in washing machine. High spin speed
shortens the drying time and saves energy.
2.Do not dry dripping wet laundry. The dryer may be damaged.
3.For uniform drying result, sort the laundry according to fabric type and select the
appropriate drying program.
4.Before drying, please close zips, hooks and eyelets, button, tie fabric belts, etc, with
the exception of the jackets.
5.Remove all objects from pockets such as lighters and matches.
6.Remove underwires from bras that are not sewn in or protect bras in a laundry bag.
7.Close duvet covers and pillow cases to prevent small items from being rolled up
inside them.
8.Do not over dry the clothes, because over dried clothes can easily get creases and
increase energy consumption.
9.Do not dry the textiles containing rubber or similar elastic materials.
10.The door shall be opened only after the program of the tumble dryer is finished
to avoid being scalded by hot steam or overheating of the tumble dryer.
11.Clean the lint filter and empty water container after each use to avoid extension of
drying time and increase of energy consumption.
12.Do not dry clothes after dry-clean process.
20
Jacket
( cotton 800g )
Jeans
(800g)
Single bedsheet
(cotton 600g )
Work clothes
( 1120g)
Pyjamas
( 200g)
Shirt
(cotton 300g )
NOTE
Symbol for tumble dryer
Do not tumble dry: The laundry is not suitable for tumble drying.
Normal drying: Laundry items can be safely dried at a medium temperature.
Gentle drying: in case of fabrics with this symbol please use cycles dedicated
to them with usage of Fabric Guard option. .
21
Control Panel
Switch the tumble dryer on or off.
Press the button to start or interrupt the drying program.
1
1
On/Off
1
2
Start/Pause
By selecting the options, you can change the program settings
or select additional functions.
1
3
Options
1
4
Display
The display shows you the settings, the estimated remaining time and status
messages. See page 22 for details.
1
5
Programs
Various drying programs can be selected depending on your needs
and the type of laundry to be dried.
2
5
1
3
4
22
Delay End
Child Lock
The wool drying cycle of this machine has been
tested and approved by The Woolmark Company.
The cycle is suitable to dry wool garments which
are labelled “hand wash” provided that the
garments are washed in a Woolmark endorsed
hand washing cycle and dried according to the
instructions issued by the manufacturer of this
machine.
M2132:MD205H80WBC/W-UK
Remote
Wireless Network
Fabric Guard
UV
Anti-Crease
Intensity (Iron dry, cupboard , extra ) dry dry
Signal
Clean lint filter warning
Empty water container warning
Remaining Time indicator/Error message
Cycle suitable for wool textiles
23
Program Selector
1.When the LED display screen brightens up, rotate the program knob to select the
desired program.
2.Select the [Delay End], [Time], [Intensity], [Anti-Crease] , [Fabric Guard] , [UV] options
for additional function.
3.Press the [ ]button.
4.Press the [ ] button after the program has completed.
Program Start
1.The drum will stop rotating after the program ends. The display will show "End"
and related LED will illuminate. The dryer will start [Anti-Crease] function if user
doesn't remove the load. Please press [ ] button after unloading the tumble dryer
to disconnect from the power and draw the mains plug.
2.Deal with any problems according to “Trouble Shooting” chapter. If there is an
unexpected stop during the drying process or the dryer shows an Error Code
refer to list of "Error Codes".
Program End
Before Starting the Appliance
1.Inset the mains plug into the socket.
2.Put your laundry loosely inside the drum.
3.Close the door.Take care not to trap any items.
4.Switch on the appliance.
The drum will rotate after the program starts. The estimated remaining time will
be displayed.
Do not switch the dryer off before the drying program has finished. If this is done,
the laundry must be hung up or spread out to cool it down for avoiding risk of the
laundry igniting itself.
WARNING
Max
L
oad
6.0kg
For drying mixed loads made of cotton, synthetics
including mixed fabrics.
1.0kg
Suitable for auxiliary drying of machine washable wool
clothing.
1.0kg
Time Dry
—
8.0kg
8.0kg
2.5kg
This program is suitable for drying heavy-duty cotton
items.
Note:
Use Bed Linen program to dry large, bulky items made
from cotton like bed sheets.
Use Mix program to dry small size mixed loads type made
of cotton and synthetics.
The eco program is suitable to dry wet cotton laundry.
It's the most efficient program in terms of energy
consumption.
Suitable for easy-care textiles made of synthetics or
mixed fabrics that do not need to be ironed after drying,
such as leisure wear, baby clothes or socks.
Note:
Do not exceed the maximum loading quantity.
The p
rogram is dedicated to shirts and blouses. Default
setting of the drying level is cupboard dry, which makes
manual cupboard easier. To avoid creases hang laundry
on hanger for final dry-off or iron immediately after end
of program.
Note:
Do not exceed the maximum loading quantity.
To dry bed linen, bed sheets or other Iarge items.
kg
1.5
Suitable for down clothing, such as down jackets, down
vests, down pants, thin down comforters, etc.
Note:
Do not exceed the maximum loading quantity.
The Time Dry program is suitable for pre-dried or slightly
damp laundry. Also recomend
ed for individual items or
for drying thin fabrics. The program can be set between
10 and 150 minutes.
24
Program Description
Program
Description
Refresh
2.0kg
To refresh clothes kept at closet for a long time or to
remove odors. Min. 20 min to max. 180 min.(in 10 min.
steps)
5.0kg
Health
Guard
5.0kg
To sterilize drying clothing, especially long-term heat-
resistant clothing.
Light and fine clothing are not suggest to use this
program.
Shirts
Wool
Cotton ECO
Mix
Synthetics
Down
Jackets
Bed Linen
Cotton
1,2
Program
Description
Max
Load
25
Quick dry
0.6kg
For quick drying of individual items or small quantities of
laundry. Suitable for textiles made of cotton, synthetics
and mixed fabrics. Do not exceed the maximum load
quantity for this program.
Note:
For textiles like towels, bathrobes or bathroom rugs
please use the program Towels.
Night Dry
4.0kg
For low-noise drying of clothes at night.
By using APP, you can download additional programs to
your
tumble dryer and select them under the Download
program position. Choose the program that meets your
needs in the APP.
—
Sports
Special program for iron-free sportswear and functional
textiles, made from thin polyester fabrics.
3.0kg
Jeans
Special program for jeans trousers and jeans jackets as
well as casual clothing made from denim.
Note:
Dry inside out.
4.0kg
• The max load is the maximum load quantity in kg dry weight that can be dried
at one time. Make sure that the laundry loaded into the appliance does not
exceed the rated capacity.
• Time drying programs do not automatically detect the residual moisture of
the laundry to be dried. If the laundry is still damp after drying program, it's
advisable to repeat the program if necessary and adjust the program duration.
The duration of program can be adjusted by usage of Time +/- buttons.
NOTE
Silk
To dry silk and satin clothing.
1.0kg
Towel
This program is dedicate to dry towels made of cotton
and mixed fabrics.
6.0kg
Delicate
Suitable for drying delicate fabrics.
Note:
Do not exceed the maximum loading quantity.
1.0kg
Download
3
1.The cotton program in accordance with Regulation 392/2012/EU for energy
labelling, measured in accordance with EN 61121 and suitable for drying normal cotton
load at rated load capacity.
2.The cotton program used at full and partial load is the standard drying program to
which the information in the label and the fiche relates. This program is suitable for
drying normal wet cotton laundry and it is the most efficient program in terms of
energy consumption for cotton.
3.DOWNLOAD default program is Sports.
The programs (Sports, Jeans,Silk, Towel, Delicate) can only be selected by
SmartHome App on mobile phones.
Options
26
Time+/
The duration of time controlled program can be adjusted individually by the option
[Time+/Time-]. The drying time can be set in 10 minute steps. Once the preset time
has elapsed, the program ends automatically.
Time-
Delay End
This function can be used to delay the end of the drying program by up to 24
hours. When the delayed program starts, the time on the display starts to count
down and the " " symbol lights up.
1. Place the laundry in the drum and make sure that the appliance door is
closed.
2. Press the [ ] button, then turn the program selector to choose the
desired program.
3. Press the [Delay End] button to set the desired time. Press it
repeatedly to change the delay time.
4. After the [ ]button has been pressed, the tumble dryer is in
operating mode. The drying process is starting automatically when the
delay time has elapsed.
5. If you press the [Delay End] button again, the program pauses.
6. If you want to cancel the delay end function, please press the [ ]
button, or turn the program selector also cancel the delay end function.
Intensity
You can set the degree of dryness of the laundry using the [Intensity] button.
There are three different drying level: Iron dry, Cupboard dry, Extra dry.
1. The drying level function can only be selected before the program starts.
2. Press the [Intensity] button repeatedly to change the dryness level.
Note:
This option is available for special programs.
Signal
Press the [Signal] button to activate the signal. Switch the signal tone on or off.
The signal tone is switched on by default.
When the signal tone is switched on:
1. The tumble dryer confirms the pressing of the option button with a signal
tone.
2. If the program knob is turned while the tumble dryer is running, the acoustic
signal reminds you that this is an invalid operation.
3. When the drying program is finished, you will hear a signal tone.
Anti-Crease
At the end of the drying program, a 30-minute anti-crease function is
activated as standard. The duration of this function can be set to 30-60-
90-120 minutes.
This function prevents the laundry from wrinkling.
The laundry can be removed during the anti-crease function.
27
Child Lock
UV
This tumble dryer is equipped with a special child lock function that prevents
children from pressing buttons carelessly or operating the appliance
incorrectly.
1. To activate the child lock, press the [Intensity] and [Time-] buttons for 3
seconds while the tumble dryer is running, paused or in standby mode.
2. To deactivate the child lock, press the [Intensity] and [Time-] buttons again
for 3 seconds.
The UV function helps to reduce germs that may still be present in the laundry
after washing. Particularly suitable for increased hygiene requirements.
1. Select special program.
2. Press the [UV] button and the [ ] symbol appears on the display.
3. To deactivate the UV function, press the [UV] button again.
Note:
This option is only available for special programs.
Some programs have this function activated automatically. To deactivate, press
the [UV] button and the symbol disappears from the display.
Fabric Guard
For fine and delicate fabrics, you can use this function to lower the drying
temperature, but please note that it may lengthen the drying time.
Drum Light
The drum light will be on when the button is pressed or when the door is open.
Remote
After you have connected your appliance to your wireless network, you can
operate it via the SmartHome App. Press the [Remote] button to activate the
remote control status to control your appliance via the SmartHome App. To
deactivate the function, press the button again. For information how to
connect your appliance to SmartHome App see "App Setup and Operation".
Considering the safe operation of appliance, the smartphone remote
control should meet the following conditions:
1. The appliance should connect to the Wireless Network
2. The door of drum should be closed
Note:
If the door is open at any time, the remote control function will be
deactivated.
The remote control function is turned off at the end of each drying
program automatically, if you want to use remote control function
again, you need to turn it on again.
Wireless Network
For connecting your appliance to the Internet, press the
button for 3 seconds. This activates the wireless network function. To
cancel the Wireless Network function and reset the network settings on
the appliance, press again for 3 seconds.
Note:
Information on the initial installation of the wireless network
connection see "App Setup and Operation".
[ ] Remote
28
29
better to choose the appropriate time drying program to completely dry
them if some parts of the clothes are still damp after program finishes.
• Loading the household tumble dryer up to the maximum capacity for the
respective programs will contribute to energy savings.
• As uneven material, thick and multi-layered clothes are not easy to dry, it is
NOTE
Consumption Data
The listed consumption data are measured in accordance with EN 61121 and
refer to the residual moisture of the textiles spun in the washing machine at the
indicated speed. The actual consumption data may vary from the given data.
The load quantity, type of fabric, composition of the laundry, residual moisture
in the fabric, selected level of drying and options as well as ambient conditions
can influence the consumption data.
*Acoustic airborne noise emission of the Cotton program at full load is 64dB.
*The impact of an active network connection on energy consumption is: 2 W.
Cotton
8.0kg
4.0kg
0%
3:40
2:30
1.65kWh
0.90kWh
MD205H80WBC/W-UK
0%
1000rpm
1000rpm
Model
Program
Max
Load
Final
moisture
content
Drying
Time
[h:min]
Energy
Consumption
2.5kg
2%
1:30
0.65kWh
Synthetics
800rpm
Spin
Speed
*
1. Your smartphone is connected to home wireless network,and you know the
network password.
2. You are near the home appliance.
3. The 2.4GHz band wireless signal is enabled on your wireless router.
Follow the below steps to enter the remote control state
Before you start, make sure that:
Use Your Appliance With the SmartHome App
Download the SmartHome App
On an app market (Google Play Store, Apple App Store),
search for "SmartHome*" and find the SmartHome
App. Download and install it on your phone. You can also
download the app by scanning the QR code. For QR code
look at this User Manual cover.
Register and Log In
Open the SmartHome App, and create a new account to
start (you can also register through a third-party account).
If you already have an existing account, use the account
to log in.
Connect Your Appliance to SmartHome
1. Please make sure your mobile phone is connected to the
home wireless network. If it is not, go to settings and
enable wireless networks and bluetooth.
2. Please turn on you appliance
2.1. Rotate the rotary switch to select any program
2.2. Press button [Remote] for 3 seconds to turn on the
Wireless Network
3. Open SmartHome App on your phone.
4. If a message of "Smart devices discovered nearby"
appears, click to add.
5. If no message appears, select "+" on the page and
select your appliance in the list of nearby devices
available. If your device is not listed, please add your
device manually by the device category and device
model.
6. Connect your appliance to the wireless network
according to instructions on App. If the connection
fails, please follow the instructions provided by the app
to continue with the operation.
8: 88
Download the app
& activate product
APP SETUP AND OPERATION
30
Rotate the knob randomly to indicate one of the programs, and press [ ]
continuously until the remote control icon light up in display, which means it
has entered the remote control state and you can start to control remotely.
Start the Remote Control
Wireless Network Status Light
Slowly flashing
Waiting for connection
Quickly flashing
Connecting
Connected to your wireless router
Solid
1. Make sure your appliance is powered on.
2.Keep your mobile phone close enough to your appliance when you are connecting
your device to the network.
3.Connect your mobile phone to the wireless network at home, and make sure you
know the password of the wireless network.
4.Check if your wireless router supports 2.4 GHz band and turn it on. If you are not
sure whether the router supports 2.4 GHz band, please contact the router
manufacturer.
5. The appliance cannot connect to the wireless network that requires authentication,
and it usually appears in public areas such as hotels, restaurants, etc. Please connect
to a wireless network that does not require authentication.
6. Turn off the WLAN+ (Android) or WLAN Assistant (iOS) function of your mobile
phone when connecting your appliance to the network.
7. In the case that your appliance connected to a wireless network before but it needs
to reconnect, please click "+" on the App Home page, and add your appliance again
by the appliance category and model according to the instructions on app.
8. The Max RF Output Power: Bluetooth LE: 8dBm, 2.4GHz Wireless Network: 18dBm.
Frequency band of operation: 2400-2483.5MHz.
9.The product opens TCP 6444, UDP 6445 network ports, and a UDP random network
port for device discovery and network configuration.
NOTE
31
CLEANING AND MAINTENANCE
Cleaning and Care
32
Empty the water container
1. Pull out and hold the water container
with two hands.
2. Tilt the water container, pour out the
condensation water into the basin.
3. Install the water container.
• To ensure the double-layer filter can be closed
smoothly , please insert the inner filter into the outer filter
as shown in the illustration.
• Take notice of the correct orientation before to insert the
door lint filter, as shown at .
Door Filter
Clean the door lint filter
Clean the lint filters
• Empty the water container after each use. Once the water container is filled
completely, the program will be paused and the " " will light or blink on the
display. After the container is emptied, the dryer can be restarted by pressing
[ ]button.
NOTE
NOTE
1. Open the door.
2. Take out the door lint filter.
3. Open the lint filter and remove the fluff on the
filter screen. You can use a vacuum cleaner to
remove the lint or clean it by hand.
4. Throw lint in the garbage bin and do not
wash it down the drain to avoid micro
plastics in the used water system.
This dryer has a primary door lint filter for additional
protection.
Make sure you clean the lint filter after each program
to avoid increased energy consumption and program
time.
1
1
• The first notification that appears on the display after the dryer is powered on to
clean the door filter or empty the water container is only a general reminder.
NOTE
33
Clean the heat exchanger
• Do not touch the heat exchanger with your hand, which may cause an injury.
As necessary, approx. once every month,
remove the fluff from the heat exchanger
using a vacuum cleaner with a dusting brush
attached.
• Clean the heat exchanger without applying
any pressure. Otherwise the heat exchanger
could be damaged. The dryer will not dry if
the cooling fins are damaged or bent.
•
Heat Exchanger
Foreign objects removal
•
filter, open the heat exchanger area compartment and remove the foreign
object making sure not to touch the heat exchanger with bare hands to avoid
injuries.
In case of foreign objects fall inside below the filter compartment, remove the
Clean Tumble dryer
WARNING
WARNING
After each use:
• Prepare a damp rag moistened
with clean water.
• Clean the door, especially the
inner window.
• Clean the sealing around the door
opening.
• Clean the humidity sensor inside
the drum.
• Take out the door lint filter, clean
the sealing and air flow openings.
• Before starting the dryer, make
sure that all parts are dried.
Humidity
Sensor
• Disconnect the power cord before cleaning!
• Do not spray directly with water.
• Do not use solvents, abrasive cleaners, glass cleaners or all-purpose cleaners.
These could damage plastic surfaces and other parts.
• Please wear gloves when cleaning.
• The illustration above is for reference only. Please take the appearance of
the actual product as reference.
NOTE
Problem
Display is not on
Solution
TROUBLE SHOOTING
34
Check if the power supply works.
Check if the mains plug is inserted.
Check the selected program.
Press the [On/Off] button.
“ ”is lighting or
blinking
out the water and restart the dryer.
If the container is not full, please restart the dryer
directly.
If the “ ” icon is still lighting or blinking after you
have finished the first two steps, please call the
customer service.
When the dryer is powered on standby, the" "icon
will always on only as a reminder. After startup, the
" " icon will disappear. Please perform maintenance
after each cycle
Check the water container. If it's full, please pour
condensation
Dryer does not start
Turn on the tumble dryer.
Check the the door is closed.
Check the program is set.
Press the [Start/Pause] button.
Connect the tumble dryer to the mains plug.
Degree of dryness
was not reached or
drying time too long
Clean lint filter and .
Empty the water container.
Check the drain hose.
Check installation place is appropriate.
Keep the air inlet clean.
Use higher drying intensity level program or
time program.
heat exchanger
There are humming
noises
The compressor is operating. These noises are
quite normal and do not indicate a fault.
The dryer switches
off at the end of the
program
The dryer switches off automatically for energy
saving. This is not a malfunction but a normal function.
Clean the lint filter.
When the dryer is powered on standby, the" "icon
will flash to remind the user to clean the filter . After
startup, the" " icon will disappear.Please perform
maintenance after each cycle
“ ”is inglight
The dryer does not
shut off instantly when
remote control is
paused/aborted.
Cooling in progress — the dryer will shut off
automatically when cooled down. This is a normal
operation, not a malfunction.
Whenever there is a problem with the appliance, check if you can solve it
following the tables below. If the problem persists, please draw the mains plug
and call the customer service.
35
Error Codes
Please contact customer
service if the problem occurs.
Description
Possible Cause
Solution
• Self-repair or non-professional repair may create safety risk and will void the
warranty.
• If the LED displays other prompt and the dryer does not work, please call
the customer service.
Temperature sensor error
WARNING
Container is full
Water pump failure or
water level sensor
failure
Empty water container
PCB communication error
36
PRODUCT FICHE
Model
Rated Capacity
Dryer Type
Energy efficiency class
Weighted annual energy consumption (AE )
Automatic or non-automatic
EU Ecolabel
Energy consumption of the cotton programme
Weighted energy consumption of the cotton programme at full and partial load
Energy consumption of the cotton programme at full load
Energy consumption of the cotton programme at partial load
Power consumption of the off-mode (Po)
Power consumption of the left-on mode (Pl)
Duration of the left-on mode
Programme time of the cotton programme
Weighted programme time of the cotton programme at full and partial load
Programme time of the cotton programme at full load
Programme time of the cotton programme at partial load
Condensation efficiency class A (most efficient) to G (least efficient)
Average condensation efficiency of the cotton programme at full load
Average condensation efficiency of the cotton programme at partial load
Weighted condensation efficiency for the cotton programme at full and partial load
Sound power level for the cotton programme at full load
c
❶
Energy consumption per year, based on 160 drying cycles of the cotton
programme at full and partial load, and the consumption of the low-power modes.
Actual energy consumption per cycle will depend on how the appliance is used.
The programme 'Cotton ' used at full and partial load is the standard drying
programme to which the information in the label and the fiche relates. This
programme is suitable for drying normal wet cotton laundry and it is the most
efficient programme in terms of energy consumption for cotton.
Remarks:
❶
MD205H80WBC/W-UK
8.0kg
Condenser
A++
198kWh/year
Automatic
N/A
1.22kWh
1.65kWh
0.90kWh
0.3W
0.5W
10 min
180min
220min
150min
B
82%
82%
82%
64dB
TRADEMARKS, COPYRIGHTS
AND LEGAL STATEMENT
logo, word marks, trade name, trade dress and all versions thereof are valuable
assets of Midea Group and/or its affiliates (“Midea”), to which Midea owns trademarks,
copyrights and other intellectual property rights, and all good will derived from using
any part of an Midea trademark. Use of Midea trademark for commercial purposes
without the prior written consent of Midea may constitute trademark infringement or
unfair competition in violation of relevant laws.
This manual is created by Midea and Midea reserves all copyrights thereof. No entity or
individual may use, duplicate, modify, distribute in whole or in part this manual, or
bundle or sell with other products without the prior written consent of Midea.
All the described functions and instructions were up to date at the time of printing this
manual. However, the actual product may vary due to improved functions and designs.
37
DISPOSAL AND RECYCLING
Important Instructions for Environment
This symbol indicates that this product shall not be disposed with
other household wastes at the end of its service life. Used device
must be returned to offcial collection point for recycling of
electrical electronic devices. To find these collection systems
please contact to your local authorities or retailer where the
product was purchased. Each household performs important role
in recovering and recycling of old appliance. Appropriate disposal
of used appliance helps prevent potential negative consequences
for the environment and human health.
Dispose of the appliance in accordance with local requirements for
the disposal of Waste Electrical and Electronic Equipment. The
appliance contains flammable gas(R290). Contact your municipal
authority for information on how to discard the appliance correctly.
Compliance with RoHS Directive
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It
does not contain harmful and prohibited materials specified in the Directive.
Package Information
Packaging materials of the product are manufactured from recyclable
materials in accordance with our National Environment Regulations. Do not
dispose of the packaging materials together with the domestic or other
wastes. Take them to the packaging material collection points designated
by the local authorities.
Compliance with the WEEE Directive and Disposing of the Waster Product:
This product complies with EU WEEE Directive (2012/19/EU). This product bears a
classification symbol for waster electrical and electronic equipment (WEEE).
38
DATA PROTECTION NOTICE
For the provision of the services agreed with the customer,
we agree to comply without restriction with all stipulations of applicable data protection
law, in line with agreed countries within which services to the customer will be delivered,
as well as, where applicable, the EU General Data Protection Regulation (GDPR).
Generally, our data processing is to fulfil our obligation under contract with you and for
product safety reasons, to safeguard your rights in connection with warranty and
product registration questions. In some cases, but only if appropriate data protection is
ensured, personal data might be transferred to recipients located outside of the
European Economic Area.
Further information are provided on request. You can contact our Data Protection
Officer via [email protected]. To exercise your rights such as right to object your
personal date being processed for direct marketing purposes, please contact us via
[email protected]. To find further information, please follow the QR Code.
39
Your device / serial number
Purchase date:
Place of purchase:
We provide a guarantee for this appliance in accordance with the
following conditions: You have a manufacturer’s warranty of
years from the date of purchase (proof of purchase must be
provided). Our General Terms and Conditions apply.
WARRANTY CARD
NOTES
Do you have any questions ?
We are happy to support you !
http://www.midea.com
40
41
In case of questions, please contact our local customer service center.
•
put your own and future users' lives in danger.
Only authorised specialists are allowed to carry out this repair work.
• Improper repair will void the warranty and subsequent damages
can't be recognized!
Risk of electric shock
Never try to repair an appliance which is defective or presumed to defective. You may
Customer Service
WARNING
We Wuxi Little Swan Electric Co., Ltd.
Address No.18, Changjiang South Road, Wuxi, Jiangsu, P.R.China
declare under our sole responsibility that the product
EU Declaration of Conformity
Product Name:
N/A
comply with the following directives and regulations:
Safety
Article3.1(a)
EN 60335-1:2012 + A11 + A13 + A1+ A14+A2+A15+A16
EN 60335-2-11:2022+A11
EMC
Article3.1(b)
EN 301 489-1 V2.2.3 EN 301 489-17 V3.2.4 EN IEC 55014-1:2021
EN IEC 55014-2:2021 EN IEC 61000-3-2:2019 + A1:2021
EN 61000-3-3:2013 + A1:2019 + A2:2021 + A2:2021/AC:2022-01
Radio
Article3.2
EN 300 328 V2.2.2
Health
Article3.1(a)
EN 62233:2008 + AC:2008 EN IEC 62311:2020
EN 62479:2010
Article3.3(d)
EN 18031-1:2024
Model name:
Software:
Accessories:
Dryer
MD205H80WBC/W-UK
059034052504_010201
For the evaluation of the compliance with these Directives and Regulations, the
following standards/requirements were applied:
Manufacturer Authorised representative established within the EU
Print name/Title:
Libing Fan/Certification engineer
Wuxi, China
(Place)
2025.06.30
(Date)
(Signature)
2014/53/EU (The Radio Equipment Directive)
Responsible for making this declaration is the:
Person responsible for making this declaration
16138200A23743
