PLEASE SAVE THIS
MANUAL FOR
FUTURE REFERENCE.
READ THIS MANUAL CAREFULLY.
SEE INSIDE COVER FOR IMPORTANT
INFORMATION ABOUT THIS MANUAL.
KEEP INSTRUCTION WITH
APPLIANCE FOR FUTURE REFERENCE.
Version 05292025
DÉCOR PLATE
INSTALLATION MANUAL
FOR MODELS:
FITS ALL EF SERIES
Compatible with ceiling mount and wall mount applications only.
2
Eurofaseheating.com
Warnings
PLEASE READ ALL INSTRUCTIONS PRIOR
TO INSTALLING THE DÉCOR PLATE
OR USING HEATER.
This unit may cause a shock or possible ignition if service
is attempted without rst disconnecting its power source.
Keep electrical cords, drapery, furnishings and other combustible
materials at least 3.3ft (1m) from the heater’s front cover and away
from sides and rear.
For optimal heater
performance and
longevity, a 15 minute
cool down period is
recommended after
4 hours of continuous
usage.
GOOD
TO
KNOW!
WARNING
• Décor Plate are compatible with ceiling mount and wall mount applications only.
• Not applicable with ush mount applications.
• Do not install, remove, or perform maintenance to this Décor Plate while
electrical power is switched on.
• Handle Décor Plate with care.
• Handle Décor Plate only once it’s cooled
• Do not touch Décor Plate while the heater is operational
Note: Eurofase Heating reserves the right to make changes to specifications, parts, components and equipment without prior notification.
This Installation, operation and service manual may not be reproduced in any form without prior written consent from Eurofase Heating.
3
Eurofaseheating.com
Contents
Contents
WARNINGS .....................................................................................................Page 2
GETTING STARTED .........................................................................................Page 4
INSTALLATION INSTRUCTIONS ......................................................................Page 5
Step 1: Removal of standard grill ...........................................................Page 5
Step 2: Décor Plate installation ..............................................................Page 6
4
Eurofaseheating.com
Getting Started
This Décor Plate is designed to work with all EF heater series. Eurofase Heater offers custom Décor Plate designs,
please contact us for details.
Please read the entire Décor Plate installation manual to ensure safe operation.
Décor Plate is compatible with ceiling mount and wall
mount applications only. Not applicable for ush mount
applications.
HEATER
DÉCOR PLATE
Front
Inside
All pictures shown are for illustration purpose only.
5
Eurofaseheating.com
Installation Instructions
STEP 1:
Removal of standard grill
All pictures shown are for illustration purpose only.
Remove the standard grill by squeezing the middle of the grill, flip it up and slide the tabs out.
HEATER WITH STANDARD GRILL (indicated in green)
Standard grill removed
1.
3.
←
←
Squeeze the center bars together to release tabs and remove the grill
Tabs
Tabs
Tabs
Tabs
Tabs
Tabs
Tabs
Tabs
Tabs
Tabs
2.
6
Eurofaseheating.com
Installation Instructions
STEP 2:
Décor Plate installation
1.
3.
2.
START BY INSERTING THE DÉCOR PLATE
TO THE BOTTOM OF THE HEATER’S
INDENTED SLOT.
INSPECT OVERALL DÉCOR PLATE TO
MAKE SURE IT IS SNUG FIT ONTO THE
THE HEATER BODY.
APPLY SLIGHT PRESSURE DOWNWARDS
TO SNUG FIT TOP PORTION OF THE
DÉCOR PLATE TO THE TOP INDENTED SLOT.
←
←
HEATER BODY DÉCOR PLATE
All pictures shown are for illustration purpose only.
