1. Connect the power supply and power up the product.
2. Place the phone/earphone/watch in the corresponding
charging position and charge it normally.
Package
Functional component
Use steps Warranty
Input: 9V-3A / 12V-3A / 15V-3A / 20V-3A
Phone Output: 5W / 7.5W / 10W / 15W / 25W
Earphone Output: 5W
Watch Output: 2.5W (Apple / Samsung) Fan
Power: Approx. 1W (5000 RPM) Cooling
Power: 7W / 15W
Phone Charging Distance: ≤ 4mm
Frequency: 2.5W (326.5 kHz); 5W, 7.5W, 10W (110–205 kHz);
MPP 15W / 25W (360 kHz)
Input Port: USB-C
Magnetic Force: 0.8 kg
Size : 111mm × 145mm × 160mm Phone Adjust Angle: 90°
Product specification
For your rights and interests, please fill in carefully and keep it properly
as a pre maintenance voucher!
Do not modify the content without authorization, otherwise it will be
deemed invalid.
The company reserves the final right to interpret the after-sales service
regulations of the product.
Product Warranty Card
尺寸：60x90mm
材质：105G铜板纸
折叠：风琴折
正反面四色印刷
1. Smartphones: Compatible with iPhone 12 to 17 series and
subsequent models, and all phones supporting Qi wireless
charging protocol
2. Earphones: Compatible with Apple AirPods, Samsung
earphones and other Qi-certified charging devices
3. Smart Watches: Compatible with Apple Watch and
Samsung smart watches
Applicable Devices
5V power supply is not applicable.
- It is recommended to use adapters of 9V/3A and above.
Max 25W charging power for single phone with input over
12V/3A.
Simultaneous charging power: 25W for phone, 5W for
earphone, 2.5W for watch with input over 20V/3A.
- To activate full power mode with semiconductor cooling and
25W fast charging, please use a 20V/3A adapter rated 60W
or higher.
The maximum output of QC adapter is 18W.
45W PD adapter only supports 7W cooling power.
- The cooling function cannot be activated when input power
is lower than 45W.
60W PD adapter supports full-power 3-in-1 charging, with 7W
and 15W adjustable cooling levels.
Power Supply & Power Parameters
Caution
1. Please use the original iphone 12~17 phone case or take off
the phone case to use
2. For non-MagSafe phones, please use anextra magnetic ring
or MagSafe case to use this product
3. Do not excessively squeeze or bump the device.
4. Please do not place it too close to magnetic cards with
magnetic stripes/chips (ID cards, bank cards, etc.) to avoid
causing the magnetic cards to fail.
5.Please do not use thick phone cases/magnetic rings, which
will affect the magnetic force and normal charging
6.Do not use a 5V power adapter, as it will prevent the device
from charging properly. Please use a power adapter with an
output voltage of 9V or higher
The three guarantee period of this product: from purchasing date
(Prevail to the customer receipt date or invoice date),
provide 12 months guarantee. product surface man-made
damage,accessories missed are not include in this guarantee,
repair service for the product is out of the guarantee period
or not covered by warranty ,customer need to pay the repair charge.
LED intelligent indicator
Touching button functions
Mode
Single click
Long press
Night light (cool light → warm light → off, cycle
repeatedly)
Adjust night light brightness (bright → dim, cycle
repeatedly)
Functions
Mode Functions
Double click
Adjust cooling power
7W cooling: LED indicator shows green
15W cooling: LED indicator shows red
Cooling off: LED indicator shows ice blue
Cycle mode: 7W → 15W → off.
No memory function after power restart.
Mode
Power-on
Standby
Charging
Metal foreign
object detection
Ice blue light light stays on for 30s
Ice blue light turns off
Corresponding colored light breathes for 30
seconds then turns off, cooling fan works
Red light flashes rapidly continuously, fan stops
operation; function recovers after removing
foreign object
*No indicator prompt for earphone and watch
charging
Indicator Light
Full Charged LED light off, cooling fan stops
Touch switch
(TEC Cooling +
Desk Lamp)
Mobile phone
Wireless Charging
Area
Earphone charging
area
Earphone charging
area
Watch Wireless
Charging Area
Anti-slip mat
Type-C interface
Desk Lamp
TEC Cooling
4-in-1 Magnetic Wireless Charger
*1
Type-C charging cable
*1
User Manual
*1
4-in-1 Magnetic Wireless
Charger
USER MANUAL
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.—Consult the dealer or an experienced radio/TV technician for help.
Note: The Grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. such modifications could void the user's authority to operate the equipment.
The device has been evaluated to meet general RF exposure requirement.
To maintain compliance with FCC's RF exposure guidelines, the distance must be at least 20 cm between the radiator and your body, and fully supported by the operating and installation configurations of the
transmitter and its antenna(s).
