70mm
95mm
• Water Resistance: Do not immerse the earphones in water, as it
may cause short-circuit and damage.
• Battery Maintenance: Fully charge the earphones at least once a
month if left unused for long periods.
• Disassembly & After-sales: Do not disassemble the product
without authorization. Stop use immediately and contact after-sales
support if defects are found.
• Cleaning: Wipe the earphones clean after exercise, especially the
charging port, to prevent corrosion from sweat or saltwater.
• Safety Precautions: Keep away from fire, heat, freezing sources,
and chemicals. Avoid violent impact, squeezing, or disassembly.
• Charging: Use only a USB charger with an output of 5V/≤1A.
Charging
Finished charging
Search for a match
Normally on blue light
Normally on red light
Blue and red lights flash alternately
Status Indicator Light Behavior
While connected via Wireless, double-click the " " button and
you’ll hear a prompt tone, after which you can control your phone with
voice commands.
Example Voice Commands:
What time is it now......Today's weather......
Navigate to Taipei 101......Call someone ……..
Care & cleaning
Product parameterTroubleshooting & SolutionsSchematic diagram Basic Usage Guide Button Operation Guide LED Indicator Status
Version: 6.0
Battery: 220mAh
Charging time: ≈2h
Model: L10 Air
weight: ≈26g
Input: 5V/180mA
Call parameters: -38dB
Distance: ≈10 meter
Operating time : ≈10h@60% Volume
Profile: HFP A2DP AVRCP
Unable to boot
Determine whether the headset is fully charged, whether the button
is misoperated, and then charge and activate.
Unable to connect to Wireless
Check if the earphone indicator light is in a stage of alternating blue
and red flashes. If the blue light is off, it indicates that the earphones
are already connected to another device, and you need to disconnect
the current connected device.
Can't back to even
Make sure the front end (e.g., Wireless) is open properly.
Headphone volume is low
Whether the phone increases the volume, the phone needs to
increase or decrease the volume. Wearing a way Whether it is right.
Product warranty card
This card is a product warranty certificate, please keep it properly
Product maintenance records
Product name: Product model:
Purchase date:
Contact:
Clients name:
Date SolutionBad phenomenon
Certificate of conformity
Q.C.Passed
( Phone needs to support
voice wake-up function )
Voice control Wireless connected
StatusFunction
Al intelligent voice control
Operation
Music playing
Volume 十
Volume 一
Next song
Previous song
Status
Phone calls in
On the phone
Pause
Music pauseResume
Answer the call
Hang up
Decline the call
Function Operation
Wireless connected
Wireless connected
Power on
Power off
Double-click ‘ ’
The red light
stays on for 1s.
Switch between
Game/Music mode
Switch Earpiece
Phone/Headphone
单击“ ”
单击“ ”
Click ‘ ’
Click ‘ ’
Press ‘ ’ for 2s
Press ‘ ’ for 2s
长按“ ”2秒
长按“ ”2秒
基础使用指南
产品保修卡
该卡为产品保修凭证，请妥善保管
产品维修记录
产品名称： 产品型号：
购买日期：
联系方式：
客戶名称：
日期 方案不良现象
合 格 證
Q.C.Passed
产品参数
版本 : 6.0
充电 : ≈2h
播放 : ≈10h&60%音量
输入 : 5V/180mA
型号 : L10 Air
重量 : ≈26g
通话 : -38dB
距离 : ≈10米
容量 : 220mAh
协议 : HFP A2DP AVRCP
注意事项
• 防水警示：耳机严禁浸入水中，避免短路损坏。
• 电池养护：长期不使用时，至少每月充满电一次。
• 拆装与售后：禁止私自拆装部件；产品出现缺陷时，请立即停用并
联系销售方售后。
• 清洁保养：运动后及时擦拭耳机，重点清洁充电口，防止汗水、盐
水腐蚀，延长使用寿命。
• 安全须知：远离火源、热源、冷冻源及化学品，严禁暴力撞击、挤
压或拆装。
• 充电要求：请使用输出为 5V/1A 及以内 的充电头。
首次配对：开机自进入配对模式。在手机设置里的无线列表中找到
" L10 Air " 并连接，连接成功后指示灯熄灭。
切换 / 重连设备：先断开当前连接，耳机将进入红蓝交替闪烁的配
对模式。其他设备可搜索并点击 " L10 Air " 完成配对。
自动重连：正常开机后，耳机将自动连接最近配对的设备。确保前
端设备（如手机）的无线已开启。
连接充电线后，手机将显示耳机电量。当电量过低时，请插入充电
线充电。
充满电约需 2 小时，充电时指示灯为红色，充满后变为蓝色。
注意：请使用输出为 5V/≤1A 的 USB 充电器。
本产品内置可充电电池，需回收处理，
请勿投入火中，以防爆炸。
指示灯状态说明
正在充电
充满电量
搜索配对
红灯常亮
蓝灯常亮
红蓝灯交替闪烁
故障排查与解决
无法开机
确定耳机是否充满电量，按键是否误操作，同时充电激活。
无法无线连接
耳机指示灯是否处于红蓝灯交替闪烁阶段，如耳机处于蓝灯熄灭，
表示耳机与其他设备已经连接，需要断开当前连接设备。
无法回连
确定前端（如手机无线）是否正常开启。
耳机音量较小
手机是否需加大音量，需要手机增加或减小音量。确认佩戴方式是
否正确。
按键操作指南
音量 十
音量 一
下一曲
上一曲
暂停播放
恢复播放
状态 状态 指示灯表现
播放音乐
无线已连接
音乐暂停播放
来电时
无线已连接
通话中
接听电话
拒接电话
手机/耳机音源切换
开机
关机
功能 操作
挂断电话
游戏/音乐模式切换
红蓝灯闪烁1秒
红灯亮1秒
长按 “ ” 3-5秒
(手机需支持语音唤醒功能)
AI智能语音控制
无线已连接语音控制
功能 状态操作
双击“ ”
智能运动，轻松好玩
说明: 在无线连接状态中，双击“ ”，听到提示音后即可语音操控
手机，便捷高效。
示例指令：
查询类：现在几点钟？/ 今天天气怎么样？
导航 / 通话：导航去深圳世界之窗 / 打电话给某某
应用 / 音乐控制：打开网易云音乐 / 播放刘德华的《冰雨》 / 下一
曲 / 音量降低 / 打开美团 / 打开喜马拉雅 / 打开微信 / 播放戏曲
单击“ ”
长按“ ”2秒
4击“ ”
Press ‘ ’ for 2s
4-click ‘ ’
Click ‘ ’
Smart exercise, easy and full of fun
Press ‘ ’ for 3-5s
使用指南及保修说明
User Manual & Warranty Information
气传导耳机
使用指南及保修说明
User Manual & Warranty Information
Microphone
Power / Mode key
Volume 十 / Next
Volume 一 / Previous
Indicator light
Charging port
示意图
音量十/下一曲
音量一 /上一曲
麦克风
电源键/模式键
指示灯
充电口
Red and blue lights
flash for 1s
无线配对
充电
First Pairing: Power on to enter pairing mode automatically. Find
"
L10 Air
" in your device's Wireless list and connect. The indicator
light will turn off once connected.
Switch/Reconnect Devices: Disconnect from the current device,
then the earphones will enter pairing mode with red and blue lights
flashing alternately. Other devices can search for and tap "
L10 Air
"
to pair.
Auto-Reconnect: Power on normally to reconnect to the last paired
device automatically. Ensure the front-end device's Wireless is
enabled.
When connected, your phone will display the earphone battery level.
Plug in the charging cable when the battery is low.
Full charge takes approx. 2 hours. Indicator is red during charging and
blue when fully charged.
Use a USB charger with 5V/≤1A output only.
The rechargeable battery must be recycled
properly. Do NOT dispose of it in fire to avoid
explosion.
Wireless Connection
Charging
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
AIR CONDUCTION MOTION
HEADPHONES
undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
